DATA SHEET
ARUBA CLEARPASS
POLICY MANAGER
The most advanced Secure NAC
platform available
Aruba’s ClearPass Policy Manager, part of the Aruba 360
Secure Fabric, provides role- and device-based secure network
access control for IoT, BYOD, corporate devices, as well as
employees, contractors and guests across any multivendor
wired, wireless and VPN infrastructure.
With a built-in context-based policy engine, RADIUS,
TACACS+, non-R ADIUS enforcement using OnConnect, device
proling, posture assessment, onboarding, and guest access
options, ClearPass is unrivaled as a foundation for network
security for organizations of any size.
For comprehensive integrated security coverage and
response using rewalls, EMM/MDM and other existing
solutions, ClearPass supports the Aruba 360 Security
Exchange Program. This allows for automated threat
detection and response workows that integrate with third-
party security vendors and IT systems previously requiring
manual IT intervention.
In addition, ClearPass supports secure self-service
capabilities, making it easier for end users trying to access
the network. Users can securely congure their own devices
for enterprise use or Internet access based on admin policy
controls. Aruba wireless customers in particular can take
advantage of unique integration capabilities such as AirGroup,
as well as ClearPass Auto Sign-On (ASO). ASO enables a
user’s network authentication to pass automatically to their
enterprise mobile apps so they can get right to work.
The result is detailed visibility of all wired and wireless
devices connecting to the enterprise, increased control
through simplied and automated authentication or
authorization of devices, and faster, better incident analysis
and response through the integration of Aruba IntroSpect
UEBA and third-party partner ecosystems. This is achieved
with a comprehensive and scalable policy management
platform that goes beyond traditional A A A solutions to
deliver extensive enforcement capabilities for IT-owned and
BYOD security requirements.
KEY FEATURES
• Role-based, unied network access enforcement across
multi-vendor wireless, wired and VPN networks.
• Intuitive policy conguration templates and visibility
troubleshooting tools.
• Supports multiple authentication/authorization sources
(AD, LDAP, SQL dB).
• Self-service device onboarding with built-in certicate
authority (CA) for BYOD.
• Guest access with extensive customization, branding and
sponsor-based approvals.
• Integration with key EMM/MDM solutions for in-depth
device assessments.
• Comprehensive integration with the Aruba 360 Security
Exchange Program.
• Single sign-on (SSO) support works with Ping, Okta
and other identity management tools to improve user
experience to SAML 2.0-based applications.
THE CLEARPASS DIFFERENCE
ClearPass is the only policy platform that centrally enforces
all aspects of enterprise-grade access security for any
industry. Granular policy enforcement is based on a
user’s role, device type and role, authentication method,
EMM/MDM attributes, device health, trac patterns, location,
and time-of-day.
Deployment scalability supports tens of thousands of devices
and authentications which surpasses the capabilities oered
by legacy AAA solutions. Options exist for small to large
organizations, from centralized to distributed environments.
DATA SHEET
ARUBA CLEARPASS POLICY MANAGER
ADVANCED POLICY MANAGEMENT
Enforcement and visibility for wired and wireless
With ClearPass, organizations can deploy wired or wireless
using standards-based 802.1X enforcement for secure
authentication. ClearPass also supports MAC address
authentication for IoT and headless devices that may lack
support for 802.1X. For wired environments where RADIUS
based authentication cannot be deployed, OnConnect, oers
an alternative using SNMP based enforcement.
Authentication methods can be used to concurrently support
a variety of use-cases. It also includes support for multi-
factor authentication based on log-in times, posture checks,
and other context such as new user, new device, and more.
Attributes from multiple identity stores such as Microsoft Active
Directory, LDAP-compliant directory, ODBC-compliant SQL
database, token servers and internal databases across domains
can be used within a single policy for ne- grained control.
Contextual data from these proled devices allows for IT
to dene what devices can access either the wired, VPN, or
wireless network. Device prole changes are dynamically
used to modify authorization privileges. For example, if a
Windows laptop appears as a printer, ClearPass policies can
automatically deny access.
Secure device conguration of personal devices
ClearPass Onboard provides automated provisioning of any
Windows, macOS, iOS, Android, Chromebook, and Ubuntu
devices via a user driven self-guided portal. Network details,
security settings and unique device identity certicates
are automatically congured on authorized devices. Cloud
identity services like Microsoft Azure Active Directory, Google
G Suite and Ok ta can also be leveraged as identity providers
with Onboard for secure certicate enrollment.
Device health checks
ClearPass OnGuard delivers endpoint posture assessments
over wireless, wired and VPN connections. OnGuard’s
health-check capabilities ensure endpoints meet security
and compliance policies before they connect to the
network. OnGuard oers a variety of exible deployment
options including agentless, disolvable agents and agent-
based conguration.
Customizable visitor management
ClearPass Guest simplies visitor workow processes to
enable employees, receptionists, and other non-IT sta to
create temporary guest accounts for secure wireless and
wired access. Highly customizable, mobile friendly portals
provide easy-to-use login processes that include self-
registration, sponsor approval, and bulk credential creation
support any visitor needs – enterprise, retail, education,
large public venue. Credentials can be delivered by SMS,
email, printed badges, or input directly through cloud identity
providers such as Facebook or Twitter.
Built in support for commercial oriented guest Wi-Fi hotspots
with credit card billing and 3rd party advertising driven workows
make it simple to integrate into a wide variety of environments.
ARUBA 360 SECURITY EXCHANGE PROGR AM
Integrate with security and workow systems
Support for the Aruba 360 Security Exchange Program is an
integrated component of ClearPass. Using features like REST-
based APIs, RADIUS Accounting Proxy, and Syslog ingestion
help facilitate workows with EMM/MDM, SIEM, rewalls,
help-desk systems and more. Context is shared between each
component for end-to-end policy enforcement and visibility.
The ClearPass Ingress Event Engine provides 3rd party
systems the means to share information in real-time using
Syslog. This enables ClearPass to respond to changing
threats for users and devices after they have authenticated
to the network. By utilizing an open dictionar y approach,
anyone can write a parsing ruleset without the need for
costly add-ons or locked in 3rd party ecosystems.
ADVANCED REPORTING AND ALERTING
ClearPass Insight provides advanced reporting capabilities
via customizable reports. Information about authentication
trends, proled devices, guest data, on-boarded devices,
and endpoint health can also be viewed in an easy to use
dashboard. Insight also has support for granular alerts and a
watchlist to monitor specic authentication failures.
DATA SHEET
ARUBA CLEARPASS POLICY MANAGER
SPECIFICATIONS
Appliances
ClearPass is available as hardware or as a virtual appliance. Virtual
appliances are supported on VMware vSphere Hypervisor (ESXi),
Microsoft Hyper-V, CentOS KVM & Amazon EC2.
• VMware ESXi 6 up to 6.7
• Microsoft Hyper-V 2012/2016 R2 and Windows 2012/2016
R2 Enterprise
• KVM on CentOS 7.5
• Amazon AWS (EC2)
Platform
• Deployment templates for any network type, identity store
and endpoint
• 802.1X, MAC authentication and captive portal support
• ClearPass OnConnect for SNMP-based enforcement on
wired switches
• Advanced reporting, analytics and troubleshooting tools
• Interactive policy simulation and monitor mode utilities
• Multiple device registration portals – Guest, Aruba
AirGroup, BYOD, and un-managed devices
• Admin/operator access security via CAC and TLS certicates
Framework and protocol support
• RADIUS, RADIUS Dynamic Authorization, TACACS+, web
authentication, SAML v2.0
• RadSec
• EAP-FAST (EAP-MSCHAPv2, EAP-GTC, EAP-TLS)
• PEAP (EAP-MSCHAPv2, EAP-GTC, EAP-TLS, EAP-PEAP-
Public, EAP-PWD)
• TTLS (EAP-MSCHAPv2, EAP-GTC, EAP- TLS, EAP-MD5,
PAP, CHAP)
• EAP-TLS
• PAP, CHAP, MSCHAPv1, MSCHAPv2, EAP-MD5
• OAuth2
• WPA3
• Windows machine authentication
• SMB v2/v3
• Online Certicate Status Protocol (OCSP)
• SNMP generic MIB, SNMP private MIB
• Common Event Format (CEF), Log Event Extended Format
(LEEF)
Supported identity stores
• Microsoft Active Directory
• RADIUS
• Any LDAP compliant directory
• MySQL, Microsoft SQL, PostGRES and Oracle 11g
ODBC-compliant SQL server
• Token servers
• Built-in SQL store, static hosts list
• Kerberos
• Microsoft Azure Active Directory
• Google G Suite
RFC standards
2246, 2248, 2407, 2408, 2409, 2548, 2759, 2865, 2866, 2869,
2882, 3079, 3579, 3580, 3748, 3779, 4017, 4137, 4301, 4302,
4303, 4308, 4346, 4514, 4518, 4809, 4849, 4851, 4945, 5176,
5216, 5246, 5280, 5281, 5282, 5755, 5759, 6614, 6818, 6960,
7030, 7296, 7321, 7468, 7815, 8032, 8247
Internet drafts
Protected EAP Versions 0 and 1, Microsoft CHAP extensions,
dynamic provisioning using EAP-FAST, TACACS+, draft-ietf-
curdle-pkix-00 EdDSA, Ed25519, Ed448, Curve25519 and
Curve448 for X.509, draft-nourse-scep-23 (Simple Certicate
Enrollment Protocol)
Proling methods
• Active: Nmap, WMI, SSH, SNMP
• Passive: MAC OUI, DHCP, TCP, Netow v5/v10, IPFIX,
sFLOW, ‘SPAN’ Port, HTTP User-Agent, IF-MAP
• Integrated & 3rd Party: Onboard, OnGuard, ArubaOS,
EMM/MDM, Cisco device sensor
IPv6 Support
• Web and CLI based management
• IPv6 addressed authentication & authorization servers
• IPv6 accounting proxy
• IPv6 addressed endpoint context servers
• Syslog, DNS, NTP, IPsec IPv6 targets
• IPv6 Virtual IP for high availability
• HTTP Proxy
• Ingress Event Engine Syslog sources
Information assurance validations
• FIPS 140-2 – Certicate #2577
• Common Criteria NDcPP + Authentication Server
(ClearPass)
DATA SHEET
ARUBA CLEARPASS POLICY MANAGER
C1000 Appliance ( JZ508A) C2000 Appliance ( JZ509A) C3000 Appliance ( JZ510A)
APPLIANCE SPECIFICATIONS
Hardware Model Unicom S-1200 R4 HPE DL20 Gen 9 HPE DL360 Gen 9
CPU (1) Eight Core 2.4GHz Atom C2758
Memory 8 GB 16 GB 64 GB
Hard drive storage
Out of Band Management N/A
Serial Port Yes (RJ-45) Yes (Virtual Serial via iLO) Yes (DB-9)
Performance & Scale
FORM FACTOR
Rackmount Included
Dimensions (WxHxD) 17.2” x 1.7” x 11.3” 17.11” x 1.70” x 15.05” 17.1” x 1.7” x 27.5”
Weight (Max Cong) 8.5 Lbs Up to 19.18 Lbs Up to 33.3 Lbs
POWER
Power supply 200 watts max
Power redundancy N/A Optional Optional
AC input voltage 100/240 VAC auto-selecting 100/240 VAC auto-selecting 100/240 VAC auto-selecting
AC input frequency 50/60 Hz auto-selecting 50/60 Hz auto-selecting 50/60 Hz auto-selecting
ENVIRONMENTAL
Operating temperature 5º C to 35º C (41º F to 95º F) 10° to 35°C (50° to 95°F) 10º C to 35º C (50º F to 95º F)
Operating vibration
Operating shock
Operating altitude
(1) SATA (7.3K RPM)
1TB hard drive
Please refer to the ClearPass
Scaling & Ordering Guide
0.25 G at 5 Hz to 200 Hz
for 15 minutes
1 shock pulse of 20 G
for up to 2.5 ms
-16 m to 3,048 m
(-50 ft to 10,000 ft)
(1) Xeon 3.5Ghz E3-1240v5 with
Four Cores (8 Threads)
(2) SATA (7.2K RPM)
1TB hard drives,
RAID-1 controller
HPE Integrated Lights-Out (iLO)
Standard
Please refer to the ClearPass
Scaling & Ordering Guide
1U SFF Easy Install Rail
1U Cable Management Arm
HPE 900W AC 240VDC
Power Input FIO Module*
Random vibration at
0.000075 G²/Hz,
10Hz to 300Hz, (0.15 G’s nominal)
2 G’s 2 G’s
3,050 m (10,000 ft). 3,050 m (10,000 ft)
(2) Xeon 2.4GHz E5-2620_V3 with
Six Cores (12 Threads)
(6) SAS (10K RPM)
600GB Hot-Plug hard drives,
RAID-10 controller
HPE Integrated Lights-Out (iLO)
Advanced
Please refer to the ClearPass
Scaling & Ordering Guide
1U SFF Easy Install Rail
1U Cable Management Arm
HPE 500W Flex Slot Platinum
Hot Plug Power Supply
Random vibration at
0.000075 G²/Hz,
10Hz to 300Hz, (0.15 G’s nominal)
* The HPE 900W Redundant Power Supply supports100VAC to 240VAC and also supports 240VDC.
DATA SHEET
ARUBA CLEARPASS POLICY MANAGER
ORDERING GUIDANCE
Please refer to the ClearPass Scaling & Ordering Guide for detailed information on appropriate sizing and required licensing to
deploy ClearPass. This can be found on the Aruba support website in the ClearPass documentation section.
ORDERING INFORMATION
Part Number Description
Hardware Appliances
JZ508A Aruba ClearPass C1000 S-1200 R4 HW-BasedAppliance
JZ509A Aruba ClearPass C2000 DL20 Gen9 HW-BasedAppliance
JZ510A Aruba ClearPass C3000 DL360 Gen9 HW-BasedAppliance
Virtual Appliances
JZ399AAE Aruba ClearPass Cx000V VM-Based Appliance E-LTU
Power Supplies
JX923A Aruba ClearPass DL20 Spare Power Supply
JX922A Aruba ClearPass-Airwave DL360 500W Spare Power Supply
Hardware/Virtual Appliance Warranty
Hardware 1 year parts*
Software 90 days*
Perpetual Licenses
JZ400AAE Aruba ClearPass New Licensing Access 100 Concurrent Endpoints E-LTU
JZ401AAE Aruba ClearPass New Licensing Access 500 Concurrent Endpoints E-LTU
JZ402AAE Aruba ClearPass New Licensing Access 1K Concurrent Endpoints E-LTU
JZ403AAE Aruba ClearPass New Licensing Access 2500 Concurrent Endpoints E-LTU
JZ404AAE Aruba ClearPass New Licensing Access 5K Concurrent Endpoints E-LTU
JZ405AAE Aruba ClearPass New Licensing Access 10K Concurrent Endpoints E-LTU
JZ406AAE Aruba ClearPass New Licensing Access 25K Concurrent Endpoints E-LTU
JZ407AAE Aruba ClearPass New Licensing Access 50K Concurrent Endpoints E-LTU
JZ408AAE Aruba ClearPass New Licensing Access 100K Concurrent Endpoints E-LTU
R1U35AAE Aruba ClearPass New Licensing Entry 100 Concurrent Endpoints E-LTU
R1U36AAE Aruba ClearPass New Licensing Entry 500 Concurrent Endpoints E-LTU
R1U37AAE Aruba ClearPass New Licensing Entry 1K Concurrent Endpoints E-LTU
R1U38AAE Aruba ClearPass New Licensing Entry 2500 Concurrent Endpoints E-LTU
R1U39AAE Aruba ClearPass New Licensing Entry 5K Concurrent Endpoints E-LTU
R1U40AAE Aruba ClearPass New Licensing Entry 10K Concurrent Endpoints E-LTU
R1U41AAE Aruba ClearPass New Licensing Entry 25K Concurrent Endpoints E-LTU
R1U42AAE Aruba ClearPass New Licensing Entry 50K Concurrent Endpoints E-LTU
R1U43AAE Aruba ClearPass New Licensing Entry 100K Concurrent Endpoints E-LTU
R1U44AAE Aruba ClearPass New Licensing Access Upgrade 100 Concurrent Endpoints E-LTU
R1U45AAE Aruba ClearPass New Licensing Access Upgrade 500 Concurrent Endpoints E-LTU
R1U46AAE Aruba ClearPass New Licensing Access Upgrade 1K Concurrent Endpoints E-LTU
* Extended with support contract
ARUBA CLEARPASS POLICY MANAGER
ORDERING INFORMATION
Part Number Description
Perpetual Licenses
R1U47AAE Aruba ClearPass New Licensing Access Upgrade 2500 Concurrent Endpoints E-LTU
R1U48AAE Aruba ClearPass New Licensing Access Upgrade 5K Concurrent Endpoints E-LTU
R1U49AAE Aruba ClearPass New Licensing Access Upgrade 10K Concurrent Endpoints E-LTU
R1U50AAE Aruba ClearPass New Licensing Access Upgrade 25K Concurrent Endpoints E-LTU
R1U51AAE Aruba ClearPass New Licensing Access Upgrade 50K Concurrent Endpoints E-LTU
R1U52AAE Aruba ClearPass New Licensing Access Upgrade 100K Concurrent Endpoints E-LTU
Perpetual Licenses Warranty
Software 90 days*
Subscription Licenses (1 Year)
JZ409AAE Aruba ClearPass New Licensing Access 100 Concurrent Endpoints 1yr E-STU
JZ410AAE Aruba ClearPass New Licensing Access 500 Concurrent Endpoints 1yr E-STU
JZ411AAE Aruba ClearPass New Licensing Access 1K Concurrent Endpoints 1yr E-STU
JZ412AAE Aruba ClearPass New Licensing Access 2500 Concurrent Endpoints 1yr E-STU
JZ413AAE Aruba ClearPass New Licensing Access 5K Concurrent Endpoints 1yr E-STU
JZ414AAE Aruba ClearPass New Licensing Access 10K Concurrent Endpoints 1yr E-STU
JZ415AAE Aruba ClearPass New Licensing Access 25K Concurrent Endpoints 1yr E-STU
JZ416AAE Aruba ClearPass New Licensing Access 50K Concurrent Endpoints 1yr E-STU
JZ417AAE Aruba ClearPass New Licensing Access 100K Concurrent Endpoints 1yr E-STU
Subscription Licenses (3 Year)
JZ418AAE Aruba ClearPass New Licensing Access 100 Concurrent Endpoints 3yr E-STU
JZ419AAE Aruba ClearPass New Licensing Access 500 Concurrent Endpoints 3yr E-STU
JZ420AAE Aruba ClearPass New Licensing Access 1K Concurrent Endpoints 3yr E-STU
JZ421AAE Aruba ClearPass New Licensing Access 2500 Concurrent Endpoints 3yr E-STU
JZ422AAE Aruba ClearPass New Licensing Access 5K Concurrent Endpoints 3yr E-STU
JZ423AAE Aruba ClearPass New Licensing Access 10K Concurrent Endpoints 3yr E-STU
JZ423AAE Aruba ClearPass New Licensing Access 25K Concurrent Endpoints 3yr E-STU
JZ423AAE Aruba ClearPass New Licensing Access 50K Concurrent Endpoints 3yr E-STU
JZ423AAE Aruba ClearPass New Licensing Access 100K Concurrent Endpoints 3yr E-STU
Subscription Licenses (5 Year)
JZ427AAE Aruba ClearPass New Licensing Access 100 Concurrent Endpoints 5yr E-STU
JZ428AAE Aruba ClearPass New Licensing Access 500 Concurrent Endpoints 5yr E-STU
JZ429AAE Aruba ClearPass New Licensing Access 1K Concurrent Endpoints 5yr E-STU
JZ430AAE Aruba ClearPass New Licensing Access 2500 Concurrent Endpoints 5yr E-STU
JZ431AAE Aruba ClearPass New Licensing Access 5K Concurrent Endpoints 5yr E-STU
JZ432AAE Aruba ClearPass New Licensing Access 10K Concurrent Endpoints 5yr E-STU
JZ433AAE Aruba ClearPass New Licensing Access 25K Concurrent Endpoints 5yr E-STU
JZ434AAE Aruba ClearPass New Licensing Access 50K Concurrent Endpoints 5yr E-STU
JZ435AAE Aruba ClearPass New Licensing Access 100K Concurrent Endpoints 5yr E-STU
DATA SHEET
* Extended with support contract
ORDERING INFORMATION
Part Number Description
Customized Guest Portal
JW470AAE Aruba ClearPass Guest Custom Skin E-LTU
Expandable application software
ClearPass Onboard – device
conguration and certicate
management
ClearPass OnGuard – endpoint
device health
* Extended with support contract
Refer to ClearPass Onboard Datasheet
Refer to ClearPass OnGuard Datasheet
DATA SHEET
ARUBA CLEARPASS POLICY MANAGER
© Copyright 2019 Hewlett Packard Enterprise Development LP. The information contained herein is subject to change without
notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements
accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. Hewlett
Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.
DS_ClearPassPolicyManager_021319 a00064815enw
Contact Us Share
Loading...
