Aruba 7000 Series Cloud Services Controllers

Overview

1
Aruba 7000 Series Cloud Services Controllers
Extend the digital workplace to branch offices
Product overview
Aruba 7000 series Cloud Services Controllers optimize cloud services and secure enterprise applications for SD-WAN at branch offices, while reducing the cost and complexity of deploying and managing the network.
The 7005, 7008, 7010, 7024 and 7030 series Cloud Services Controllers combine wireless, wired and hybrid support up to 64 APs and 24 Ethernet ports, and feature integrated WAN compression, health checks, zero and policy more secure to create an all
Supporting over 4,000 users, the 7000 series performs stateful firewall policy enforcement at up to 8 Gbps. Secure IP tunnels protect WAN traffic across the public and private transport netwo integrated firewall, secure VPN, 3G/4G LTE cellular failover, threat management with content filtering, and local bridging, b end
Th usage and performance for over 1,500 apps, including cloud and web
SharePoint, Box, Salesforce. changes in real
bandwidth, priority, and network paths in branch and remote offices to safeguard the best possible user experience
A adjust RF management and roaming parameters for latency type.
WAN services,
- touch configuration,
-based routing. The 7000 series also unifies policy management with third-party security services, making it simpler and
-wireless workplace.
-user application or IT traffic forwarding requirements.
e 7000 series supports Aruba’s Next-Generation Mobility Firewall with AppRF technology, which continuously evaluates app
com and apps that are hidden as encrypted or web traffic. It then automatically makes configuration
-time to ensure optimal
real-time dashboard makes it easy to identify and correct Quality-of-Service tags, load-balance specific applications across APs,
rk to the cloud and data center. Additional features include
-based services like Skype for Business,
-sensitive apps, and apply bandwidth contracts per app or application
ased on
Page
QuickSpecs
Aruba 7000 Series Cloud Services Controllers
Overview
2
Integration with cloud services such as Palo Alto Networks GlobalProtect and Microsoft Skype for Business make extending security and QoS for mobile unified communications easier and more reliable across the distributed enterprise.
The 7000 series h Radio Management, ClientMatch, and RFProtect spectrum analysis and wireless intrusion protection.
The 7000 series can be deployed in minutes wit branch locations simpler and more efficiently.
Product Summary
sized branch deployments that require unprecedented scale and
andles other enterprise-critical capabilities like authentication, encryption, IPv4 and IPv6 services, Adaptive
h zero-touch provisioning via cloud-based Aruba Activate, enabling IT to deploy
7005 Cloud Services Controller is a compact, fanless entry-level branch platform that can be powered by a Power-over­Ethernet (PoE) switch.
7008 Cloud Services Controller is a compact, fanless entry-level branch platform with 8 integrated PoE and PoE+ switch
ports for small branch locations with some PoE requirements
7010 Cloud Services Controller is designed for mid-sized branch deployments that require several PoE and PoE+ switch
ports.
7024 Cloud Services Controller is designed for mid-sized branch offices that require up to 24 switch ports for unified
wired and wireless access.
7030 Cloud Services Controller is ideal for mid- to large-
performance.
Page
QuickSpecs
Aruba 7000 Series Cloud Services Controllers

Configuration

3
7000 Ordering Guide
Step 1: Select the appropriate 7005 Chassis
Description
Part Number
Aruba 7005 (RW) 4-port 10/100/1000BASE-T 16 AP and 1K Client Controller
JW633A
Aruba 7005 (US) 4-port 10/100/1000BASE-T 16 AP and 1K Client Controller
JW634A
Aruba 7005 (IL) 4-port 10/100/1000BASE-T 16 AP and 1K Client Controller
JW637A
Aruba 7005 (JP) 4-port 10/100/1000BASE-T 16 AP and 1K Client Controller
JW639A
Aruba 7005 (EG) 4x 10/100/1000BASE-T Ports 16 AP Branch Controller
JY849A
Aruba 7005 (RW) FIPS/TAA-compliant 4-port 10/100/1000BASE-T 16 AP and 1K Client Controller
JW635A
Aruba 7005 (US) FIPS/TAA-compliant 4-port 10/100/1000BASE-T 16 AP and 1K Client Controller
JW636A
Aruba 7005 (IL) FIPS/TAA-compliant 4-port 10/100/1000BASE-T 16 AP and 1K Client Controller
JW638A
Aruba 7005 (JP) FIPS/TAA-compliant 4-port 10/100/1000BASE-T 16 AP and 1K Client Controller
JW640A
Step 2: Select Power Supply (Optional)
Description
Part Number
AP-AC-12V30A 12V/30W AC/DC Desktop Style 1.7/4.0/9.5mm Circular 90 Deg Plug DoE Level VI Adapter
JX989A
NOTE: 7005 Controller is normally powered by 802.3at complaint PoE
Step 3: Power Cord for Optional Supply (JX989A)
Description
Part Number
PC-AC-ARG Argentina 220V AC 10A 2-meter AC Power Cord
JW113A
PC-AC-AUS Australian AC Power Cord
JW114A
PC-AC-BR Brazil AC Power Cord
JW115A
PC-AC-CHN China AC Power Cord
JW116A
PC-AC-DEN Denmark 220V AC 10A 2-meter AC Power Cord
JW117A
PC-AC-EC Continental European/Schuko AC Power Cord
JW118A
PC-AC-IN India AC Power Cord
JW119A
PC-AC-IL Israel 250V AC 10A 2-meter AC Power Cord
JW120A
PC-AC-IT Italian AC Power Cord
JW121A
PC-AC-JP Japanese AC Power Cord
JW122A
PC-AC-KOR Korea AC Power Cord
JW123A
PC-AC-NA North America AC Power Cord
JW124A
PC-AC-SWI Switzerland 220V AC 10A 2-meter AC Power Cord
JW125A
PC-AC-UK UK AC Power Cord
JW127A
PC-AC-ZA South Africa 250V AC 10A 2-meter AC Power Cord
JW128A
Step 4: Shelf Mount Kit (Optional)
Description
Part Number
Aruba 7005-MNT-19 7005 Series 19-inch Rack Mount Kit
JW084A
Step 5: Available Individual AP licenses
Description
Part Number
Aruba LIC-AP Controller per AP Capacity License E-LTU
JW472AAE
Aruba LIC-PEF Controller Policy Enforcement Firewall Per AP License E-LTU
JW473AAE
Page
QuickSpecs
Aruba 7000 Series Cloud Services Controllers
Configuration
4
Aruba LIC-RFP Controller RFProtect Per AP License E-LTU
JW474AAE
Aruba LIC-ACR Controller Advanced Cryptography 1 Session License E-LTU
Q9B90AAE
Aruba LIC-ACR-8 Controller Advanced Cryptography 8 Session License E-LTU
JW538AAE
Aruba LIC-ACR-32 Controller Advanced Cryptography 32 Session E-LTU
JW539AAE
Aruba LIC-ACR-64 Controller Advanced Cryptography 64 Session License E-LTU
JW540AAE
Aruba LIC-ACR-128 Controller Advanced Cryptography 128 Session License E-LTU
JW541AAE
Aruba LIC-ACR-256 Controller Advanced Cryptography 256 Session License E-LTU
JW542AAE
Aruba LIC-ACR-512 Controller Advanced Cryptography 512 Session License E-LTU
JW543AAE
Aruba LIC-ACR-1024 Controller Advanced Cryptography 1024 Session License E-LTU
JW544AAE
Aruba Controller Web Content Classification 1 Year Subscription E-STU
JY028AAE
Aruba Controller Web Content Classification 3 Year Subscription E-STU
JY029AAE
Aruba Controller Web Content Classification 5 Year Subscription E-STU
JY030AAE
Aruba Controller Web Content Classification 7 Year Subscription E-STU
JY031AAE
Aruba Controller Web Content Classification 10 Year Subscription E-STU
JY032AAE
NOTE: For each AP attached to the controller the minimal configuration is 1xLIC-AP per AP.
Step 6: Bundled AP license
Description
Part Number
Aruba LIC-ENT Enterprise (LIC-AP LIC-PEF LIC-RFP and LIC-AW) License Bundle E-LTU
JW471AAE
NOTE: Configure these as at least one per AP connected to the controller
LIC-AW is a device license for AirWave Management system
Step 7: PEFV License
Description
Part Number
Aruba LIC-7005-PEFV Controller Policy Enforcement Firewall for Aruba 7005 Cntrlr License E-LTU
JW495AAE
NOTE: This license enables firewall services on a per controller basis for VPN termination such as Aruba VIA and IAP-VPN
7008 Ordering Guide
Step 1: Select the appropriate 7008 Chassis
Description
Part Number
Aruba 7008 (IL) 8p 100W PoE+ 10/100/1000BASE-T 16 AP and 1K Client Controller
JX925A
Aruba 7008 (JP) 8p 100W PoE+ 10/100/1000BASE-T 16 AP and 1K Client Controller
JX926A
Aruba 7008 (RW) 8p 100W PoE+ 10/100/1000BASE-T 16 AP and 1K Client Controller
JX927A
Aruba 7008 (US) 8p 100W PoE+ 10/100/1000BASE-T 16 AP and 1K Client Controller
JX928A
Aruba 7008 (IL) FIPS/TAA 8p 100W PoE+ 10/100/1000BASE-T 16 AP and 1K Client Controller
JX929A
Aruba 7008 (JP) FIPS/TAA 8p 100W PoE+ 10/100/1000BASE-T 16 AP and 1K Client Controller
JX930A
Aruba 7008 (RW) FIPS/TAA 8p 100W PoE+ 10/100/1000BASE-T 16 AP and 1K Client Controller
JX931A
Aruba 7008 (US) FIPS/TAA 8p 100W PoE+ 10/100/1000BASE-T 16 AP and 1K Client Controller
JX932A
Step 2: Select AC power cord for main power supply
Description
Part Number
PC-AC-ARG Argentina 220V AC 10A 2-meter AC Power Cord
JW113A
PC-AC-AUS Australian AC Power Cord
JW114A
PC-AC-BR Brazil AC Power Cord
JW115A
LIC-ENT (JW471AAE) is equivalent to 1 each of LIC-AP, LIC-REF, LIC-RFP, and LIC-AW.
Page
QuickSpecs
Aruba 7000 Series Cloud Services Controllers
Configuration
5
PC-AC-CHN China AC Power Cord
JW116A
PC-AC-DEN Denmark 220V AC 10A 2-meter AC Power Cord
JW117A
PC-AC-EC Continental European/Schuko AC Power Cord
JW118A
PC-AC-IN India AC Power Cord
JW119A
PC-AC-IL Israel 250V AC 10A 2-meter AC Power Cord
JW120A
PC-AC-IT Italian AC Power Cord
JW121A
PC-AC-JP Japanese AC Power Cord
JW122A
PC-AC-KOR Korea AC Power Cord
JW123A
PC-AC-NA North America AC Power Cord
JW124A
PC-AC-SWI Switzerland 220V AC 10A 2-meter AC Power Cord
JW125A
PC-AC-UK UK AC Power Cord
JW127A
PC-AC-ZA South Africa 250V AC 10A 2-meter AC Power Cord
JW128A
Step 3: Spare Power Supply (Optional)
Description
Part Number
Aruba PSU-310-AC 7008 Series 150W AC Spare Power Supply
JX933A
Step 4: Select AC power cord for spare power supply
Description
Part Number
PC-AC-ARG Argentina 220V AC 10A 2-meter AC Power Cord
JW113A
PC-AC-AUS Australian AC Power Cord
JW114A
PC-AC-BR Brazil AC Power Cord
JW115A
PC-AC-CHN China AC Power Cord
JW116A
PC-AC-DEN Denmark 220V AC 10A 2-meter AC Power Cord
JW117A
PC-AC-EC Continental European/Schuko AC Power Cord
JW118A
PC-AC-IN India AC Power Cord
JW119A
PC-AC-IL Israel 250V AC 10A 2-meter AC Power Cord
JW120A
PC-AC-IT Italian AC Power Cord
JW121A
PC-AC-JP Japanese AC Power Cord
JW122A
PC-AC-KOR Korea AC Power Cord
JW123A
PC-AC-NA North America AC Power Cord
JW124A
PC-AC-SWI Switzerland 220V AC 10A 2-meter AC Power Cord
JW125A
PC-AC-UK UK AC Power Cord
JW127A
PC-AC-ARG Argentina 220V AC 10A 2-meter AC Power Cord
JW113A
Step 5: Shelf Mount Kit (Optional)
Description
Part Number
Aruba 7008-MNT-19 7008 Series 19-inch Rack Mount Kit
JX934A
Step 6: Available Individual AP licenses
Description
Part Number
Aruba LIC-AP Controller per AP Capacity License E-LTU
JW472AAE
Aruba LIC-PEF Controller Policy Enforcement Firewall Per AP License E-LTU
JW473AAE
Aruba LIC-RFP Controller RFProtect Per AP License E-LTU
JW474AAE
Aruba LIC-ACR Controller Advanced Cryptography 1 Session License E-LTU
Q9B90AAE
Aruba LIC-ACR-8 Controller Advanced Cryptography 8 Session License E-LTU
JW538AAE
Aruba LIC-ACR-32 Controller Advanced Cryptography 32 Session E-LTU
JW539AAE
Aruba LIC-ACR-64 Controller Advanced Cryptography 64 Session License E-LTU
JW540AAE
Aruba LIC-ACR-128 Controller Advanced Cryptography 128 Session License E-LTU
JW541AAE
Page
QuickSpecs
Aruba 7000 Series Cloud Services Controllers
Configuration
6
Aruba LIC-ACR-256 Controller Advanced Cryptography 256 Session License E-LTU
JW542AAE
Aruba LIC-ACR-512 Controller Advanced Cryptography 512 Session License E-LTU
JW543AAE
Aruba LIC-ACR-1024 Controller Advanced Cryptography 1024 Session License E-LTU
JW544AAE
Aruba Controller Web Content Classification 1 Year Subscription E-STU
JY028AAE
Aruba Controller Web Content Classification 3 Year Subscription E-STU
JY029AAE
Aruba Controller Web Content Classification 5 Year Subscription E-STU
JY030AAE
Aruba Controller Web Content Classification 7 Year Subscription E-STU
JY031AAE
Aruba Controller Web Content Classification 10 Year Subscription E-STU
JY032AAE
NOTE: For each AP attached to the controller the minimal configuration is 1xLIC-AP per A
Step 7: Bundled AP license
Description
Part Number
Aruba LIC-ENT Enterprise (LIC-AP LIC-PEF LIC-RFP and LIC-AW) License Bundle E-LTU
JW471AAE
NOTE: Configure these as at least one per AP connected to the controller
Step 8: PEFV License
Description
Part Number
Aruba LIC-7008-PEFV Controller Policy Enforcement Firewall for Aruba 7008 Cntrlr License E-LTU
JY342AAE
NOTE: This license enables firewall services on a per controller basis for VPN termination such as Aruba VIA and IAP-VPN.
7010 Ordering Guide
Step 1: Select the appropriate 7010 Chassis
Description
Part Number
Aruba 7010 (RW) 16p 150W PoE+ 10/100/1000BASE-T 1G BASE-X SFP 32 AP and 2K Clients Controller
JW678A
Aruba 7010 (US) 16p 150W PoE+ 10/100/1000BASE-T 1G BASE-X SFP 32 AP and 2K Clients Controller
JW679A
Aruba 7010(IL) 16p 150W PoE+ 10/100/1000BASE-T 1G BASE-X SFP 32 for AP and 2K Clients Cntrlr
JW680A
Aruba 7010 (JP) 16p 150W PoE+ 10/100/1000BASE-T 1G BASE-X SFP for 32 AP and 2K Clients Cntrlr
JW681A
Aruba 7010 (EG) 16x 1000BASE-T + 2x SFP Ports 32 AP Branch Controller
JY850A
Aruba 7010 (RW) FIPS/TAA 16p 150W PoE+ 10/100/1000BASE-T 1GBASE-X SFP 32 AP and 2K Clnts Cntrlr
JW702A
Aruba 7010 (US) FIPS/TAA 16p 150W PoE+ 10/100/1000BASE-T 1GBASE-X SFP 32 AP and 2K Clnts Cntrlr
JW703A
Aruba 7010 (IL) FIPS/TAA 16p 150W PoE+ 10/100/1000BASE-T 1G BASE-X SFP 32 AP and 2K Clnts Cntrlr
JW704A
Aruba 7010 (JP) FIPS/TAA 16p 150W PoE+ 10/100/1000BASE-T 1GBASE-X SFP 32 AP and 2K Clnts Cntrlr
JW705A
Step 2: Select AC power cord
Description
Part Number
PC-AC-ARG Argentina 220V AC 10A 2-meter AC Power Cord
JW113A
PC-AC-AUS Australian AC Power Cord
JW114A
PC-AC-BR Brazil AC Power Cord
JW115A
LIC-ENT (JW471AAE) is equivalent to 1 each of LIC-AP, LIC-REF, LIC-RFP, and LIC-AW.
LIC-AW is a device license for AirWave Management system
Page
QuickSpecs
Aruba 7000 Series Cloud Services Controllers
Configuration
7
PC-AC-CHN China AC Power Cord
JW116A
PC-AC-DEN Denmark 220V AC 10A 2-meter AC Power Cord
JW117A
PC-AC-EC Continental European/Schuko AC Power Cord
JW118A
PC-AC-IN India AC Power Cord
JW119A
PC-AC-IL Israel 250V AC 10A 2-meter AC Power Cord
JW120A
PC-AC-IT Italian AC Power Cord
JW121A
PC-AC-JP Japanese AC Power Cord
JW122A
PC-AC-KOR Korea AC Power Cord
JW123A
PC-AC-NA North America AC Power Cord
JW124A
PC-AC-SWI Switzerland 220V AC 10A 2-meter AC Power Cord
JW125A
PC-AC-UK UK AC Power Cord
JW127A
PC-AC-ZA South Africa 250V AC 10A 2-meter AC Power Cord
JW128A
Step 3: Select Transceivers for SFP Ports
Description
Part Number
SFP-LX 1000BASE-LX SFP 1310nm LC Connector Pluggable GbE XCVR
JW087A
SFP-SX 1000BASE-SX SFP 850nm LC Connector Pluggable GbE XCVR
JW088A
NOTE: There are 2 SFP 10/100/1000 ports on 7010
Step 4: Spare Mount Kit
Description
Part Number
Aruba 7010-MNT-19 7010 Series Replacement 19-inch Rack Mounting Kit
JW085A
Step 5: Available Individual AP licenses
Description
Part Number
Aruba LIC-AP Controller per AP Capacity License E-LTU
JW472AAE
Aruba LIC-PEF Controller Policy Enforcement Firewall Per AP License E-LTU
JW473AAE
Aruba LIC-RFP Controller RFProtect Per AP License E-LTU
JW474AAE
Aruba LIC-ACR Controller Advanced Cryptography 1 Session License E-LTU
Q9B90AAE
Aruba LIC-ACR-8 Controller Advanced Cryptography 8 Session License E-LTU
JW538AAE
Aruba LIC-ACR-32 Controller Advanced Cryptography 32 Session E-LTU
JW539AAE
Aruba LIC-ACR-64 Controller Advanced Cryptography 64 Session License E-LTU
JW540AAE
Aruba LIC-ACR-128 Controller Advanced Cryptography 128 Session License E-LTU
JW541AAE
Aruba LIC-ACR-256 Controller Advanced Cryptography 256 Session License E-LTU
JW542AAE
Aruba LIC-ACR-512 Controller Advanced Cryptography 512 Session License E-LTU
JW543AAE
Aruba LIC-ACR-1024 Controller Advanced Cryptography 1024 Session License E-LTU
JW544AAE
Aruba Controller Web Content Classification 1 Year Subscription E-STU
JY028AAE
Aruba Controller Web Content Classification 3 Year Subscription E-STU
JY029AAE
Aruba Controller Web Content Classification 5 Year Subscription E-STU
JY030AAE
Aruba Controller Web Content Classification 7 Year Subscription E-STU
JY031AAE
Aruba Controller Web Content Classification 10 Year Subscription E-STU
JY032AAE
NOTE: For each AP attached to the controller the minimal configuration is 1xLIC-AP per AP
Step 6: Bundled AP Licenses
Description
Part Number
Aruba LIC-ENT Enterprise (LIC-AP LIC-PEF LIC-RFP and LIC-AW) License Bundle E-LTU
JW471AAE
NOTE: Configure these as at least one per AP connected to the controller
LIC-AW is a device license for AirWave Management system
LIC-ENT (JW471AAE) is equivalent to 1 each of LIC-AP, LIC-REF, LIC-RFP, and LIC-AW.
Page
QuickSpecs
Aruba 7000 Series Cloud Services Controllers
Configuration
8
Step 7: PEFV License
Description
Part Number
Aruba LIC-7010-PEFV Controller Policy Enforcement Firewall for Aruba 7010 Cntrlr License E-LTU
JW496AAE
NOTE: This license enables firewall services on a per controller basis for VPN termination such as Aruba VIA and IAP-VPN.
7024 Ordering Guide
Step 1: Select the appropriate 7024 Chassis
Description
Part Number
Aruba 7024 (RW) 24-port 400W PoE+ 10G BASE-X SFP+ 32 AP and 2K Clients Controller
JW682A
Aruba 7024 (US) 24-port 400W PoE+ 10G BASE-X SFP+ 32 AP and 2K Clients Controller
JW683A
Aruba 7024 (IL) 24-port 400W PoE+ 10G BASE-X SFP+ 32 AP and 2K Clients Controller
JW684A
Aruba 7024 (JP) 24-port 400W PoE+ 10G BASE-X SFP+ 32 AP and 2K Clients Controller
JW685A
Aruba 7024 (RW) FIPS/TAA-compliant 24p 400W PoE+ 10G BASE-X SFP+ 32 AP and 2K Clients Controller
JW706A
Aruba 7024 (US) FIPS/TAA-compliant 24p 400W PoE+ 10G BASE-X SFP+ 32 AP and 2K Clients Controller
JW707A
Aruba 7024 (IL) FIPS/TAA-compliant 24p 400W PoE+ 10G BASE-X SFP+ 32 AP and 2K Clients Controller
JW708A
Aruba 7024 (JP) FIPS/TAA-compliant 24p 400W PoE+ 10G BASE-X SFP+ 32 AP and 2K Clients Controller
JW709A
Step 2: Select AC power cord
Description
Part Number
PC-AC-ARG Argentina 220V AC 10A 2-meter AC Power Cord
JW113A
PC-AC-AUS Australian AC Power Cord
JW114A
PC-AC-BR Brazil AC Power Cord
JW115A
PC-AC-CHN China AC Power Cord
JW116A
PC-AC-DEN Denmark 220V AC 10A 2-meter AC Power Cord
JW117A
PC-AC-EC Continental European/Schuko AC Power Cord
JW118A
PC-AC-IN India AC Power Cord
JW119A
PC-AC-IL Israel 250V AC 10A 2-meter AC Power Cord
JW120A
PC-AC-IT Italian AC Power Cord
JW121A
PC-AC-JP Japanese AC Power Cord
JW122A
PC-AC-KOR Korea AC Power Cord
JW123A
PC-AC-NA North America AC Power Cord
JW124A
PC-AC-SWI Switzerland 220V AC 10A 2-meter AC Power Cord
JW125A
PC-AC-UK UK AC Power Cord
JW127A
PC-AC-ZA South Africa 250V AC 10A 2-meter AC Power Cord
JW128A
Step 3: Select Transceivers for SFP/SFP+ Ports (Optional)
Description
Part Number
SFP-LX 1000BASE-LX SFP 1310nm LC Connector Pluggable GbE XCVR
JW087A
SFP-SX 1000BASE-SX SFP 850nm LC Connector Pluggable GbE XCVR
JW088A
SFP-TX 1000BASE-T SFP Copper GbE RJ45 Connector Pluggable XCVR
JW089A
SFP-10GE-LRM 10GBASE-LRM SFP+ 1310nm LC Connector Pluggable 10GbE XCVR
JW090A
SFP-10GE-SR 10GBASE-SR SFP+ 850nm Pluggable LC Connector 10GbE XCVR
JW091A
Page
QuickSpecs
Aruba 7000 Series Cloud Services Controllers
Configuration
9
SFP-10GE-LR 10GBASE-LR SFP+ 1310nm Pluggable LC Connector 10GbE XCVR
JW092A
DAC-SFP-10GE-1M 1m 10GbE SFP+ Twinax Connectors Direct Attach Cable
JW101A
DAC-SFP-10GE-3M 3m 10GbE SFP+ Twinax Connectors Direct Attach Cable
JW102A
DAC-SFP-10GE-50CM 50cm10GbE SFP+ Twinax Connectors Direct Attach Cable
JW100A
DAC-SFP-10GE-5M 5m 10GbE SFP+ Twinax Connectors Direct Attach Cable
JW103A
DAC-SFP-10GE-7M 7m 10GbE SFP+ Twinax Connectors Direct Attach Cable
JW104A
Step 4: Mount (Optional)
Description
Part Number
Aruba 7030-MNT-19 7030 Series Replacement 19-inch Rack Mounting Kit
JW086A
Aruba SPR-WL2-MNT S1500-24/-48/S2500/S1500-24/-48/S2500 Wall and Rack Mount Kit
JW083A
Step 5: Available Individual AP licenses
Description
Part Number
Aruba LIC-AP Controller per AP Capacity License E-LTU
JW472AAE
Aruba LIC-PEF Controller Policy Enforcement Firewall Per AP License E-LTU
JW473AAE
Aruba LIC-RFP Controller RFProtect Per AP License E-LTU
JW474AAE
Aruba LIC-ACR Controller Advanced Cryptography 1 Session License E-LTU
Q9B90AAE
Aruba LIC-ACR-8 Controller Advanced Cryptography 8 Session License E-LTU
JW538AAE
Aruba LIC-ACR-32 Controller Advanced Cryptography 32 Session E-LTU
JW539AAE
Aruba LIC-ACR-64 Controller Advanced Cryptography 64 Session License E-LTU
JW540AAE
Aruba LIC-ACR-128 Controller Advanced Cryptography 128 Session License E-LTU
JW541AAE
Aruba LIC-ACR-256 Controller Advanced Cryptography 256 Session License E-LTU
JW542AAE
Aruba LIC-ACR-512 Controller Advanced Cryptography 512 Session License E-LTU
JW543AAE
Aruba LIC-ACR-1024 Controller Advanced Cryptography 1024 Session License E-LTU
JW544AAE
Aruba Controller Web Content Classification 1 Year Subscription E-STU
JY028AAE
Aruba Controller Web Content Classification 3 Year Subscription E-STU
JY029AAE
Aruba Controller Web Content Classification 5 Year Subscription E-STU
JY030AAE
Aruba Controller Web Content Classification 7 Year Subscription E-STU
JY031AAE
Aruba Controller Web Content Classification 10 Year Subscription E-STU
JY032AAE
NOTE: For each AP attached to the controller the minimal configuration is 1xLIC-AP per AP.
Step 6: Bundled AP license
Description
Part Number
Aruba LIC-ENT Enterprise (LIC-AP LIC-PEF LIC-RFP and LIC-AW) License Bundle E-LTU
JW471AAE
NOTE: Configure these as at least one per AP connected to the controller
Step 7: PEFV License
Description
Part Number
Aruba LIC-7024-PEFV Controller Policy Enforcement Firewall for Aruba 7024 Cntrlr License E-LTU
JW497AAE
NOTE: This license enables firewall services on a per controller basis for VPN termination such as Aruba VIA and IAP-VPN.
7030 Ordering Guide
LIC-ENT (JW471AAE) is equivalent to 1 each of LIC-AP, LIC-REF, LIC-RFP, and LIC-AW.
LIC-AW is a device license for AirWave Management system
Page
QuickSpecs
Aruba 7000 Series Cloud Services Controllers
Configuration
10
Step 1: Select the appropriate 7030 Chassis
Description
Part Number
Aruba 7030 (RW) 8p Dual Pers 10/100/1000BASE-T/1GBASE-X SFP 64 AP and 4K Clients Controller
JW686A
Aruba 7030 (US) 8p Dual Pers 10/100/1000BASE-T/1GBASE-X SFP 64 AP and 4K Clients Controller
JW687A
Aruba 7030 (IL) 8p Dual Pers 10/100/1000BASE-T/1GBASE-X SFP 64 AP and 4K Clients Controller
JW688A
Aruba 7030 (JP) 8p Dual Pers 10/100/1000BASE-T/1GBASE-X SFP 64 AP and 4K Clients Controller
JW689A
Aruba 7030 (EG) 8x 1000BASE-T or 8xSFP64 AP Branch Controller
JY851A
Aruba 7030 (RW) FIPS/TAA 8p Dual Pers 10/100/1000BASE-T/1GBASE-X SFP 64 AP and 4K Clnts Cntrlr
JW710A
Aruba 7030 (US) FIPS/TAA 8p Dual Pers 10/100/1000BASE-T/1GBASE-X SFP 64 AP and 4K Clnts Cntrlr
JW711A
Aruba 7030 (IL) FIPS/TAA 8p Dual Pers 10/100/1000BASE-T 1GBASE-X SFP 64 AP and 4K Clnts Cntrlr
JW712A
Aruba 7030 (JP) FIPS/TAA 8p Dual Pers 10/100/1000BASE-T/1GBASE-X SFP 64 AP and 4K Clnts Cntrlr
JW713A
Step 2: Select AC power cord for main power supply for AC Powered Units
Description
Part Number
PC-AC-ARG Argentina 220V AC 10A 2-meter AC Power Cord
JW113A
PC-AC-AUS Australian AC Power Cord
JW114A
PC-AC-BR Brazil AC Power Cord
JW115A
PC-AC-CHN China AC Power Cord
JW116A
PC-AC-DEN Denmark 220V AC 10A 2-meter AC Power Cord
JW117A
PC-AC-EC Continental European/Schuko AC Power Cord
JW118A
PC-AC-IN India AC Power Cord
JW119A
PC-AC-IL Israel 250V AC 10A 2-meter AC Power Cord
JW120A
PC-AC-IT Italian AC Power Cord
JW121A
PC-AC-JP Japanese AC Power Cord
JW122A
PC-AC-KOR Korea AC Power Cord
JW123A
PC-AC-NA North America AC Power Cord
JW124A
PC-AC-SWI Switzerland 220V AC 10A 2-meter AC Power Cord
JW125A
PC-AC-UK UK AC Power Cord
JW127A
PC-AC-ZA South Africa 250V AC 10A 2-meter AC Power Cord
JW128A
Step 3: Select Transceivers for Combo Ports (Optional)
Description
Part Number
SFP-LX 1000BASE-LX SFP 1310nm LC Connector Pluggable GbE XCVR
JW087A
SFP-SX 1000BASE-SX SFP 850nm LC Connector Pluggable GbE XCVR
JW088A
NOTE: There are 8 combo ports on 7030 10/100/1000 or SFP
Step 4: Mount (Optional)
Description
Part Number
Aruba 7030-MNT-19 7030 Series Replacement 19-inch Rack Mounting Kit
JW086A
Step 5: Available Individual AP licenses
Description
Part Number
Aruba LIC-AP Controller per AP Capacity License E-LTU
JW472AAE
Aruba LIC-PEF Controller Policy Enforcement Firewall Per AP License E-LTU
JW473AAE
Aruba LIC-RFP Controller RFProtect Per AP License E-LTU
JW474AAE
Aruba LIC-ACR Controller Advanced Cryptography 1 Session License E-LTU
Q9B90AAE
Aruba LIC-ACR-8 Controller Advanced Cryptography 8 Session License E-LTU
JW538AAE
Aruba LIC-ACR-32 Controller Advanced Cryptography 32 Session E-LTU
JW539AAE
Aruba LIC-ACR-64 Controller Advanced Cryptography 64 Session License E-LTU
JW540AAE
Page
QuickSpecs
Aruba 7000 Series Cloud Services Controllers
Configuration
11
Aruba LIC-ACR-128 Controller Advanced Cryptography 128 Session License E-LTU
JW541AAE
Aruba LIC-ACR-256 Controller Advanced Cryptography 256 Session License E-LTU
JW542AAE
Aruba LIC-ACR-512 Controller Advanced Cryptography 512 Session License E-LTU
JW543AAE
Aruba LIC-ACR-1024 Controller Advanced Cryptography 1024 Session License E-LTU
JW544AAE
Aruba Controller Web Content Classification 1 Year Subscription E-STU
JY028AAE
Aruba Controller Web Content Classification 3 Year Subscription E-STU
JY029AAE
Aruba Controller Web Content Classification 5 Year Subscription E-STU
JY030AAE
Aruba Controller Web Content Classification 7 Year Subscription E-STU
JY031AAE
Aruba Controller Web Content Classification 10 Year Subscription E-STU
JY032AAE
NOTE: For each AP attached to the controller the minimal configuration is 1xLIC-AP per AP.
Step 6: Bundled AP license
Description
Part Number
Aruba LIC-ENT Enterprise (LIC-AP LIC-PEF LIC-RFP and LIC-AW) License Bundle E-LTU
JW471AAE
NOTE: Configure these as at least one per AP connected to the controller
LIC-AW is a device license for AirWave Management system
Step 7: PEFV License
Description
Part Number
Aruba LIC-7030-PEFV Controller Policy Enforcement Firewall for Aruba 7030 Cntrlr License E-LTU
JW498AAE
NOTE: This license enables firewall services on a per controller basis for VPN termination such as Aruba VIA and IAP-VPN.
LIC-ENT (JW471AAE) is equivalent to 1 each of LIC-AP, LIC-REF, LIC-RFP, and LIC-AW.
Page
QuickSpecs
Aruba 7000 Series Cloud Services Controllers

Technical Specifications

12
Performance and Capacity
Features 7005 7008 7010 7024 7030
Maximum campus AP licenses
Maximum remote AP licenses
16
16
16
16
32
32
32
32
64
64
Maximum concurrent users/devices 1,024 1,024 2,048 2,048 4,096
Maximum VLANs 4,094 4,094 4,094 4,094 4,094
Active firewall sessions 16,384 16,384 32,768 32,768 65,536
Concurrent GRE tunnels
256
256
512
512
1,024
Concurrent IPsec sessions 512 512 1,024 1,024 2,048
Mobility Access Switch tunneled­node ports
512
512 1,024 1,024 2,048
Firewall throughput 2 Gbps 2 Gbps 4 Gbps 4 Gbps 8 Gbps
Encrypted throughput (3DES, AES­CBC)
1.2 Gbps 1.2 Gbps 2.4 Gbps 2.4 Gbps 2.4 Gbps
Encrypted throughput (AES-CCM) 1.6 Gbps 1.6 Gbps 3.4 Gbps 3.4 Gbps 4.0 Gbps
Page
QuickSpecs
Aruba 7000 Series Cloud Services Controllers
Technical Specifications
13
45)
45)
45)
45)
45)
7.9”)
13.3”)
Interfaces and Indicators
Features 7005 7008 7010 7024 7030
Form factor/footprint
Auto-negotiating 10/100/1000BASE-T
Gigabit Ethernet ports (GBIC or SFP)
USB 2.0
Management/status LEDs
LINK/ACT and status LEDs
LCD panel and navigation buttons
Console port
Out-of-band management port
Compact Compact 1 rack unit 1 rack unit 1 rack unit
4 8 16 24 8 (combo)
N/A N/A 2 SFP 2 SFP+ 8 (combo)
Yes (1) Yes (2) Yes (2) Yes (1) Yes (1)
Yes Yes Yes Yes Yes
No No No Yes Yes
No No Yes Yes Yes
Yes
(micro
USB/RJ-
Yes
(micro
USB/RJ-
Yes
(micro
USB/RJ-
Yes
(micro
USB/RJ-
Yes
(micro
USB/RJ-
No No Yes Yes Yes
Features 7005 7008 7010 7024 7030
Dimensions (H x W x D)
Weight
MTBF (hours, @ 25C)
Physical
4.1 cm x 20 cm x 20 cm
(1.6” x
7.9” x
0.92 kg
(2.03 lbs)
4.2 cm x 20.32 cm x 20 .32cm
(1.65” x 8.0” x
8.0”)
1.0 kg
(2.2 lbs)
323,896 300,000 232,843 311,901 390,679
4.42 cm x
31.75 cm x
33.7 cm (1.74” x
12.75” x
3.4 kg
(7.5 lbs)
4.37 cm x
44.2 cm x
31.3 cm
(1.72” x 17.4”
x 12.32”)
5.127 kg
(11.3 lbs)
4.4 cm x 30.5 cm x 21.1 cm
(1.7” x 12” x
8.3”)
2.06 kg
(4.54 lbs)
Page
QuickSpecs
Aruba 7000 Series Cloud Services Controllers
Technical Specifications
14
PoE)
NOM (obtained by partners and distributors)
CE mark, cTUVus, CB, C-tick, Anatel, NOM, MIC
Environmental Range
Specification 7005 7008 7010 7024 7030
Operating temperature
Storage temperature
0° C to 40° C
-40° C to 70° C
Humidity/storage humidity 10% to 95%, NC
Operating altitude 10,000 feet
Acoustic noise1
0 dBA
(fanless)
0 dBA
(fanless)
39.8 –
58.6 dBA
126W with
Maximum power consumption
16.6 W
(with USB)
PoE
(26W without
190 W
(with PoE)
Regulatory and Safety Compliance
Description Specification
34.3 –
71.2 dBA
450 W
(with PoE)
29.1 –
57.4 dBA
55 W
Safety certifications UL 60950-1 Second Edition
CAN/CSA-C22.2 No. 60950-1 Second Edition EN 60950-1 Second Edition
EN 60950:2005
IEC 60950-1 Second Edition
Electromagnetic emissions certifications
FCC Part 15 Class B CE AS/NZS CISPR22 Class B
CISPR22 Class A (7010, 7024, 7030), Class B (7005)
EN55022 Class A (7010, 7024, 7030), Class B (7005)
ICES-003 Class A (7010, 7024, 7030), Class B (7005)
VCCI Class A (7010, 7024, 7030), Class B (7005) EN61000-3-2
EN61000-3-3
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4- 6, EN 61000-
4-8, EN 61000-4-11, AS/NZS 3548
KN22 Class B KCC
CNS13438 Class B EN55024/CISPR24 KN24
Industry Canada Class B
Telco Common Language Equipment Identifier (CLEI) Code
Page
QuickSpecs
Aruba 7000 Series Cloud Services Controllers
Technical Specifications
15
Regulatory SKU information
ARCN01014(7005), ARCN0103(7010), ARCN7024(7024), ARCN7030(7030)
Minimum ArubaOS Release
7005, AOS 6.4.1.0; 7010, AOS 6.4.1.0; 7024, AOS 6.4.3.0; 7030, AOS 6.4.1.0
Page
QuickSpecs
Aruba 7000 Series Cloud Services Controllers
Summary
of Changes
16
Date
Version History
Action
Description of Change
08-Jan-2018
From Version 3 to 4
Added
SKUs added: Q9B90AAE, JW538AAE, JW539AAE, JW540AAE,
JY029AAE, JY030AAE, JY031AAE, JY032AAE
07-Aug-2017
From Version 2 to 3
Changed
Aruba footer removed. 07-Nov-2016
From Version 1 to 2
Added
Models added: JY849A, JY850A, JY851A
01-Nov-2016
Version 1
Created
Document creation.
Sign up for updates
© Copyright 2018 Hewlett Packard Enterprise Development LP. The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements accompanying such pro Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.
To learn more, visit
c05272689
JW541AAE, JW542AAE, JW543AAE, JW544AAE, JY028AAE,
Family series photo updated.
ducts and services.
: http://www.hpe.com/networking
- 15702 - Worldwide – V4 - 08-January-2018
Page
Loading...
