QuickSpecs
Aruba 205H Hospitality Series Access Points
Overview
1
Aruba 205H Hospitality Series Access Points
High-performance dual-radio 802.11ac access points for hospitality and branch deployments
Product overview
The multifunctional and affordable AP-205H access point (AP) combines high-performance wireless mobility with wired
Gigabit Ethernet access in a surprisingly compact device
This compact and cost
system to provide secure wired and wireless network access in dormitories, classrooms, hotels, medical clinics and multitenan
environments.
In addition, using a unique mount kit accessory, the AP
benefits for branch offices and teleworkers.
Capable of delivering high
WLAN deployment costs. The AP
warranty.
The 205H delivers wireless data rates of up to 867 Mbps to 5
MIMO streams while simultaneously supporting 2.4
The integrated antennas of the 205H are optimized for the deployments with the AP mounted vertically on either a wall or desk.
-effective dual-radio AP easily mounts to a standard data wall-box and uses the existing structured cabling
-performance Wi-Fi services to multiple rooms, the 205H simplifies RF coverage planning and reduces
-205H is built to provide years of trouble-free operation and is backed by Aruba’s limited lifetime
-205H can easily be converted to a desk mounted AP to provide the same
-GHz devices with 802.11ac technology leveraging two spatial
-GHz 802.11n clients with data rates of up to 400 Mbps.
t
Page
QuickSpecs
Aruba 205H Hospitality Series Access Points
Overview
2
The antenna patterns are slightly directional, focusing RF energy to and from the area facing the front of the AP.
Three local Gigabit Ethernet ports are available to securely attach wired devices to your network. One of these ports is also capable
of supplying PoE power to the attached device.
The 205H itself receives power from eithe
uplink Gigabit Ethernet port.
Features and Benefits
Unique Benefits
Two devices in one
The 205H ships with everything you need to deploy it as a wall
single gang data wall
mounted remote AP
Advanced Cellular Coexistence (ACC)
Aruba’s Advanced Cellular Coexistence
from 3G/4G LTE networks, distributed antenna systems and commercial small cell/femtocell equipment.
Wi
To eliminate sticky client behavior while us
gathers session performance metrics from mobile devices.
If a mobile device moves away from an AP or if RF interference impedes performance, ClientMatch automatically steers th
to a better AP.
Quality of service for unified communication apps
Aruba APs support priority handling and policy enforcement for unified communication apps, including Microsoft Lync with
encrypted videoconferencing, voice, chat and desktop sharing
Choose your operating mode
Aruba offers a choice of AP operating modes to meet your unique management and deployment requirements:
Simplify deployment with Aruba Activate
For large installations across multiple sites, the Aruba Activate service significantly reduces deployment time by automating device
provisioning, firmware upgrades, and inventory management.
With Aruba Activate, Instant APs are factory-shipped to any site and configure themselves when powered up.
Aruba 205H Specifications
205H (Aruba Instant): Dual radio 2x2:2 802.11ac APs for hospitality and branch
Advanced Features
- Adaptive Radio Management (ARM) technology automatically assigns channel and power settings, provides
r an AC-to-DC adapter accessory or from the switch it attaches to, using PoE via the
-mounted hospitality AP, attaching directly to a standard
-box. In addition, using an optional accessory stand, the 205H can easily be converted to a desk
.
(ACC) feature enables WLANs to perform at peak efficiency by minimizing interference
-Fi client optimization
ers roam, Aruba APs feature patented ClientMatch technology, which continuously
.
• Controller-managed mode. When managed by Aruba Mobility Controllers, Aruba APs offer centralized configuration,
data encryption, policy enforcement and network services, as well as distributed and centralized traffic forwarding. Please
refer to the Aruba Mobility Controller data sheets for more details.
• Aruba Instant mode. In Aruba Instant mode, a single AP automatically distributes the network configuration to other
Instant APs in the WLAN. Simply power-up on Instant AP, configure it over the air, and plug in the other
e device
• AP-205H (controller-managed) and IAP-
offices with integrated antennas, three local Gigabit Ethernet ports, PoE out, USB host interface.
Supports wall-box and desk mount deployments
• RF Management
Page
QuickSpecs
Aruba 205H Hospitality Series Access Points
Overview
3
airtime fairness and ensures that APs stay clear of all sources of RF interference to deliver reliable, high-
time or dedicated air monitoring for spectrum analysis and wireless
Operating Modes
Wireless R
MHz channel) wireless data
•
• Spectrum analysis
• Security
• Mobility Controller-managed AP
• Aruba Instant AP
• Remote AP (RAP) for branch deployments
• Air monitor (AM) for wireless IDS, rogue detection and containment
• Spectrum analyzer, dedicated or hybrid
• Secure enterprise mesh
performance WLANs.
- The 205H can be configured to provide part-
intrusion protection, VPN tunnels to extend remote locations to corporate resources, and wireless mesh
connections where Ethernet drops are not available.
- Capable of part-time or dedicated air monitoring, the spectrum analyzer remotely scans the 2.4-GHz and 5-GHz
radio bands to identify sources of RF interference
- With an OpenDNS service subscription, Aruba Instant RAPs deliver integrated web filtering, malware and botnet
protection to every device connected to the WLAN
- Integrated Trusted Platform Module (TPM) for secure storage of credentials and keys
- SecureJack-capable for secure tunneling of wired Ethernet traffic
• AP type: Indoor, dual radio, 5-GHz 802.11ac and 2.4-GHz 802.11n 2x2:2
• Software-configurable dual radio supports 5 GHz (Radio 0) and 2.4 GHz (Radio 1)
• 2x2 MIMO with two spatial streams and up to 867 Mbps (80-MHz channel) or 400 Mbps (40-
• Support for up to 255 associated client devices per radio, and up to 16 BSSIDs per radio
• Supported frequency bands (country-specific restrictions apply):
• Available channels: Dependent on configured regulatory domain
• Dynamic frequency selection (DFS) optimizes the use of available RF spectrum
• Supported radio technologies:
• Supported modulation types:
• Transmit power: Configurable in increments of 0.5 dBm
• Maximum transmit power (antenna gain not included):
• Advanced Cellular Coexistence (ACC) minimizes interference from cellular networks
• Maximum ratio combining (MRC) for improved receiver performance
• Cyclic delay/shift diversity (CDD/CSD) for improved downlink RF performance
• Short guard interval for 20-MHz, 40-MHz and 80-MHz channels
• Space-time block coding (STBC) for increased range and improved reception
adio Specifications
rate
- 2.4000GHz to 2.4835 GHz
- 5.150 to 5.250 GHz
- 5.250 to 5.350 GHz
- 5.470 to 5.725 GHz
- 5.725 to 5.850 GHz
- 802.11b: Direct-sequence spread-spectrum (DSSS)
- 802.11a/g/n/ac: Orthogonal frequency-division multiplexing (OFDM)
- 802.11b: BPSK, QPSK, CCK
- 802.11a/g/n/ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM
- 5-GHz band: +21 dBm (18 dBm per chain)
- 2.4-GHz band: +21 dBm (18 dBm per chain)
- Power may be restricted to comply with local regulatory rules
Low-density parity check (LDPC) for high-efficiency error correction and increased throughput.
Page
QuickSpecs
Aruba 205H Hospitality Series Access Points
Overview
4
•
Encrypted Thr
Antennas
•
Other
Power
- 802.3af PoE: restricted (USB and PoE-PSE disabled)
• Supported data rates (Mbps):
• 802.11n high-throughput (HT) support: HT 20/40
• 802.11ac very high throughput (VHT) support: VHT 20/40/80
• 802.11n/ac packet aggregation: A-MPDU, A-MSDU
• Max IPsec encrypted wired throughput = 40Mbps
Four integrated semi-directional antennas for 2x2 MIMO with maximum antenna gain of 4.5 dBi in 2.4 GHz and
• 5.0 dBi in 5 GHz. Built-in antennas are optimized for vertical orientation of the AP.
Interfaces
• Uplink: 10/100/1000BASE-T Ethernet (RJ-45, back)
• Local: Three 10/100/1000BASE-T Ethernet (RJ-45, bottom)
• Passive pass-through interface (two RJ-45, back and bottom)
• USB 2.0 host interface (Type A connector)
• DC power interface, accepts 1.35/3.5-mm center-positive circular plug with 9.5-mm length
• Visual indicators (LEDs):
• Reset/LED control button (“paperclip access”)
• Serial console interface (custom, four-pin header)
• Kensington security slot
Transmit beam-forming (TxBF) for increased reliability in signal delivery
- 802.11b: 1, 2, 5.5, 11
- 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54
- 802.11n: 6.5 to 300 (MCS0 to MCS15)
- 802.11ac: 6.5 to 867 (MCS0 to MCS9, NSS = 1 to 2)
oughput
- Auto-sensing link speed and MDI/MDX
- 802.3az Energy Efficient Ethernet (EEE)
- PoE-PD (input): 48 Vdc (nominal) 802.3af/at PoE
- Auto-sensing link speed and MDI/MDX
- 802.3az Energy Efficient Ethernet (EEE)
- One port: PoE-PSE (output): 48 Vdc (nominal) 802.3af PoE
- Aruba Beacon USB radio module
- 3G/4G cellular modems
- Device battery charging port
- Capable of supplying up to 1A/5 watts of power to an attached device
- Power/system status
- PoE-PSE status
- Factory reset (when activated during device power up)
- LED control: toggle off/normal
• Direct DC source: 48 Vdc nominal, +/- 5%
• Power over Ethernet (PoE): 48 Vdc (nominal) 802.3af/at compliant source
• Power sources sold separately. Recommended Aruba part numbers:
• When both power sources are connected and active, DC power takes priority
• Power modes:
- DC: AP-AC-48V36C (48V/36 watts)
- PoE: PD-9001GR-AC (802.3at)
- DC: unrestricted mode (USB: 5 watts max, PoE-PSE: 15.4 watts max)
- 802.3at PoE: reduced mode (USB disabled when PoE-PSE enabled, PoE-PSE reduced power budget: 10 watts
max)
Page
QuickSpecs
Aruba 205H Hospitality Series Access Points
Overview
5
•
Mounting
Mechanical
Environmental
Regulatory
For more country
Reliability
Regulatory Mod
Certifications
Warranty
Minimum Software Versions
• ArubaOS 6.4.3.0
• Maximum (worst-case) power consumption in idle mode (excluding PoE-PSE, USB): 7.5 watts
• Included with AP: Mount plate to attach AP to single gang wall-box (most international variations covered), security screw
• Optional mounting kits:
• Dimensions/weight (with supplied single-gang wall box mount plate, as mounted):
• Dimensions/weight (shipping):
• Operating:
• Storage and transportation:
Maximum (worst-case) power consumption:
- DC: 12 watts max, plus 16.5 watts max for PoE-PSE and 5.5 watts max for USB
- 802.3at PoE: 13 watts max, plus 11.5 watts max for PoE-PSE or 6 watts max for USB
- 802.3af PoE: 13 watts max
- AP-205H-MNT2: Mount plate and insert for use with dual gang box (most North America variations covered)
- AP-205H-MNTR: Aruba 205H Access Point desk mount conversion kit – includes desk mount and RJ45 jumper
- 86 mm (W) x 40 mm (D) x 150 mm (H), 3.38” (W) x 1.57” (D) x 5.90” (H)
- 375 g/13.22 oz
- 115 mm (W) x 63 mm (D) x 167 (H), 4.52” (W) x 2.4” (D) x 6.57” (H)
- 500 g/17.63 oz
- Temperature: 0° C to +40° C (+32° F to +104° F)
- Humidity: 5% to 95% non-condensing
- Temperature: -40° C to +70° C (-40° F to +158° F)
• CE Marked
• R&TTE Directive 1999/5/EC
• Low-Voltage Directive 2006/95/EC
• EN 300 328
• EN 301 489
• EN 301 893
• UL/IEC/EN 60950
• EN 60601-1-1 and EN 60601-1-2
• FCC/Industry of Canada
• MTBF: 709,492 hours (81 years) at +25° C operating temperature
• AP-205H and IAP-205H: APINH205
• CB Scheme Safety, cTUVus
• Wi-Fi Alliance (WFA) certified 802.11a/b/g/n/ac
• Aruba limited lifetime warranty
-specific regulatory information and approvals, please see your Aruba representative.
el Number
Page
QuickSpecs
Aruba 205H Hospitality Series Access Points
Overview
6
•
Aruba InstantOS 4.2.0.0
Page
QuickSpecs
Aruba 205H Hospitality Series Access Points
Configuration
7
Ordering Guide
Step 1: Select AP Model
Description
Part Number
Configuration Impact
Aruba AP-205H Hospitality 802.11ac Dual 2x2:2 Radio
Integrated Antenna AP
JW166A
mount accessory
Aruba AP-205H FIPS/TAA-compliant Hospitality 802.11ac
Dual 2x2:2 Radio Integrated Antenna AP
JW167A
mount accessory
Aruba Instant IAP
2x2:2 Radio Integrated Antenna AP
Aruba Instant IAP
2x2:2 Radio Integrated Antenna AP
Aruba Instant IAP
2x2:2 Radio Integrated Antenna AP
Aruba Instant
2x2:2 Radio Integrated Antenna AP
Aruba Instant IAP
Radio Integrated Antenna AP
Step 2: Add Powering Accessories (Optional)
Description
Part Number
Configuration Impact
PD-3510G-AC 15.4W 802.3af PoE 10/100/1000Base-T
Ethernet Midspan Injector
JW627A
Add AC power cable
PD-9001GR-AC 30W 802.3at PoE+ 10/100/1000 Ethernet
Indoor Rated Midspan Injector
Add AC power cable
AP-AC-48V36C 48V/36W AC/DC Desktop Style
1.35/3.5/9.5mm Circular 90 Deg Plug DoE Level VI Adapter
JX991A
Add AC power cable
Add three-prong AC power cord for injector or AC adapter:
PC-AC-ARG Argentina 220V AC 10A 2-meter AC Power Cord
JW113A
PC-AC-AUS Australian AC Power Cord
JW114A
PC-AC-BR Brazil AC Power Cord
JW115A
PC-AC-CHN China AC Power Cord
JW116A
PC-AC-DEN Denmark 220V AC 10A 2-meter AC Power Cord
JW117A
PC-AC-EC Continental European/Schuko AC Power Cord
JW118A
PC-AC-IN India AC Power Cord
JW119A
PC-AC-IL Israel 250V AC 10A 2-meter AC Power Cord
JW120A
PC-AC-IT Italian AC Power Cord
JW121A
PC-AC-JP Japanese AC Power Cord
JW122A
PC-AC-KOR Korea AC Power Cord
JW123A
PC-AC-NA North America AC Power Cord
JW124A
PC-AC-SWI Switzerland 220V AC 10A 2-meter AC Power Cord
JW125A
PC-AC-TW Taiwan AC Power Cord
JW126A
PC-AC-UK UK AC Power Cord
JW127A
PC
JW128A
-205H (RW) Hospitality 802.11ac Dual
-205H (US) Hospitality 802.11ac Dual
-205H (JP) Hospitality 802.11ac Dual
IAP-205H (IL) Hospitality 802.11ac Dual
-205H (EG) 802.11n/ac 2x2:2 Dual
Add optional PoE injector, AC adapter or
Add optional PoE injector, AC adapter or
JW216A
JW217A
JW218A
JW219A
JY858A
JW629A
-AC-ZA South Africa 250V AC 10A 2-meter AC Power Cord
Page
QuickSpecs
Aruba 205H Hospitality Series Access Points
Configuration
8
Step 3: Add Mount Accessories (Optional)
Description
Part Number
AP-205H-MNT2 AP Mount Kit for AP-205H Dual Gang Wall Box Mount Adapter
JW041A
AP-205H-MNTR with Desk Mount and RJ45 Jumper RAP Conversion Kit
JW042A
Step 4: Add Other (Optional)
Description
Part Number
AP-CBL-SER AP Proprietary DB9 Female Serial Adapter Cable
JW071A
Page
QuickSpecs
Aruba 205H Hospitality Series Access Points
Technical Specifications
9
18.0
-93.0
15.5
-75.0
RF Performance Table
Maximum transmit power (dBm)
per transmit chain
Receiver sensitivity (dBm) per
receive chain
2.4 GHz
802.11b
1 Mbps 18.0 -97.0
11 Mbps 18.0 -89.0
802.11g
6 Mbps
54 Mbps
802.11n HT20
MCS0/8
MCS7/15
18.0 -92.0
14.0 -71.0
802.11n HT40
MCS0/8
MCS7/15
802.11ac VHT20
MCS0
MCS8
802.11ac VHT40
MCS0
MCS9
18.0 -89.0
14.0 -68.0
18.0 -92.0
12.5 -68.0
18.0 -89.0
12.0 -63.0
Page
QuickSpecs
Aruba 205H Hospitality Series Access Points
Technical Specifications
10
Numbers above exclude antenna gain. Table shows maximum capability of the radios. Transmit power may be restricted in
software to comply with local regulatory rules.
Horizontal or Azimuth plane (top view, AP front facing left)
802.11a
5 GHz
6 Mbps
54 Mbps
802.11n HT20
MCS0/8
MCS7/15
802.11n HT40
MCS0/8
MCS7/15
802.11ac VHT20
MCS0
MCS8
802.11ac VHT40
16.0 -95.0
15.0 -77.0
16.0 -94.0
14.5 -71.0
16.0 -90.0
14.5 -68.0
16.0 -94.0
14.0 -69.0
MCS0
MCS9
16.0 -86.0
14.0 -60.0
802.11ac VHT80
MCS0 16.0 -86.0
MCS9
14.0 -59.0
Page
QuickSpecs
Aruba 205H Hospitality Series Access Points
Technical Specifications
11
2.4 GHz
5 GHz
Elevation plane (side view, AP front facing left)
2.4 GHz
5 GHz
Elevation plane (front view)
2.4 GHz
5 GHz
Page
QuickSpecs
Aruba 205H Hospitality Series Access Points
Summary of Changes
12
Date
Version History
Action
Description of Change
06-Mar-2017
From Version 2 to 3
Changed
Updates made on Features and Benefits and Configuration
07-Nov-2016
From Version 1 to 2
Added
Model added: JY858A
01-Nov-2016
Version 1
Created
Document creation.
Sign up for updates
© Copyright 2017 Hewlett Packard Enterprise Development LP. The information contained herein is
subject to change without notice. The only warranties for Hewlett Packard Enterprise products and
services are set forth in the express warranty statements accompanying such products and services.
Nothi
shall not be liable for technical or editorial errors or omissions contained herein.
To learn more, visit
c05272692
sections
ng herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise
: http://www.hpe.com/networking
- 15703 - Worldwide - V3 - 06-March-2017
Page
Loading...
