QuickSpecs
Aruba 2930M Switch Series
Overview
1
Aruba 2930M Switch Series
Product overview
The Aruba 2930M Switch Series is designed for customers creating digital workplaces that are optimized for mobile users with an
integrated wired and wireless approach. These
advanced security and
network management tools like Aruba
Central, you
A powerful Aruba ProVision ASIC delivers performance, robust feature support, and value with flexible programmability for fut
applications
approach. The 2930M supports 10GbE and
Rate (IEEE 802.3bz), robust QoS,
with no software licensing
required.
The Aruba 2930M Switch Series provides a convenient and
Zero Touch Deployment. The switches include a limited lifetime warranty.
Key Features
•
dynamic segmentation,
• Models with 24 ports of HPE Smart Rate with IEEE 802.3bz
Layer 3 access switches are easy to deploy and manage with
ClearPass Policy Manager and Aruba AirWave. With support from cloud-based Aruba
can quickly set up remote offices with little or no IT support.
. High performance modular stacking for up to 10 switches provides simplicity, scalability with a pay as you grow
40GbE uplinks, dual modular power supplies, up to 1440 Watts of PoE+, HPE Smart
RIP, Access OSPF routing, dynamic segmentation, PIM, VRRP and IPv6
cost-effective access switch solution that can be quickly set up with
Aruba Layer 3 Switch with 10 chassis backplane stacking, static, RIP and access OSPF routing,
ACLs, SDN and robust QoS
• Advanced security and network management tools like Aruba ClearPass Policy Manager, Aruba AirWave and Aruba
Central
• Modular 10GbE or 40GbE uplinks and HPE Smart Rate (IEEE 802.3bz), up to 1440W PoE+
ure
Page
QuickSpecs
Aruba 2930M Switch Series
Overview
2
•
Features and Benefits
Software-defined networks
Unified Wired and Wireless
Quality of Service (QoS)
Connectivity
compliant end device;
• IPv6
Ready for the software defined network with REST APIs and OpenFlow support
• Simple deployment with Zero Touch Provisioning
Supports REST APIs, Openflow 1.0 and 1.3, and more, to enable automation of network operations, monitoring, and
troubleshooting.
• ClearPass Policy Manager supports unified wired and wireless policies using Aruba ClearPass Policy Manager
• Multiple programmatic interfaces supported
• Switch auto-configuration automatically configures switch for different settings such as VLAN, CoS, PoE max power, and
PoE priority when an Aruba access point is detected.
• User Role defines a set of switch-based policies in areas such as security, authentication, and QoS. A user role can be
assigned to a group of users or devices, using switch-based local user role or download from ClearPass.
• Dynamic segmentation provides a secured tunnel to transport network traffic on a per-port or per-user-role basis to an
Aruba Controller. In per-user-role Tunneled Node, users are authenticated with ClearPass Policy Manager which can
direct the traffic to be tunneled to Aruba controller or switch locally.
• Large buffers provide graceful congestion management
• Traffic prioritization (IEEE 802.1p) allows real-time traffic classification into eight priority levels mapped to eight queues
• Layer 4 prioritization enables prioritization based on TCP/ UDP port numbers
• Class of Service (CoS) sets the IEEE 802.1p priority tag based on IP address, IP Type of Service (ToS), Layer 3 protocol,
TCP/UDP port number, source port, and DiffServ
• Rate limiting sets per-port ingress enforced maximums and per-port, per-queue minimums
• Unknown Unicast Rate Limiting throttles unicast packets with unknown destination addresses and limits flooding on the
VLAN
• HPE Smart Rate (IEEE 802.3bz) connectivity 4 port HPE Smart Rate Port module available to connect to 802.11ac
wireless access points
• Flexible configurations include:
- Switch with 24 Smart Rate ports
- Switch with 40 gigabit ports and 8 Smart Rate ports
- All 2930M switches support optional 4 port Smart Rate module
• Flexible 10 Gb/s Ethernet connectivity Modular 4 port 10 Gigabit (SFP+) available
• 40Gbps Uplink port connectivity Modular 40Gbps QSFP+ port available
• Auto-MDIX provides automatic adjustments for straight-through or crossover cables on all 10/100 and 10/100/1000
ports
• IEEE 802.3at Power over Ethernet (PoE+) provides up to 30 W per port that allows support of the latest PoE+-capable
devices such as IP phones, wireless access points, and security cameras, as well as any IEEE 802.3afeliminates the cost of additional electrical cabling and circuits that would otherwise be necessary in IP phone and WLAN
deployments
• Pre-standard PoE support detects and provides power to pre-standard PoE devices
Page
QuickSpecs
Aruba 2930M Switch Series
Overview
3
- IPv6 host enables switches to be managed in an IPv6 network
Performance
ASIC, providing very low latency, increased packet buffering, and adaptive power
Convergence
Resiliency and high availability
• Energy-efficient design
• Designed with the latest Aruba Provision
• Selectable queue configurations allows for increased performance by selecting the number of queues and associated
• Stacking Topology
- Dual stack (IPv4 and IPv6) transitions from IPv4 to IPv6, supporting connectivity for both protocols
- MLD snooping forwards IPv6 multicast traffic to the appropriate interface
- IPv6 ACL/QoS supports ACL and QoS for IPv6 network traffic
- IPv6 routing supports static and RIPng protocols
- Security provides RA guard, DHCPv6 protection, dynamic IPv6 lockdown, and ND snooping
- 80 PLUS Gold and Platinum Certified power supplies increase power efficiency and savings
- Energy-efficient Ethernet (EEE) support reduces power consumption in accordance with IEEE 802.3az
consumption
memory buffering that best meet the requirements of the network applications
- Ring Stacking Topology High Performance stacking—up to 100 Gbps of stacking throughput per switch. Each 2-
port stacking module can support up to 25Gbps in each direction per port.
- Ring topology—Supports up to 10 member stack
- Virtualized Switching Provides simplified management as the switches act as a single chassis when stacked
• IP multicast snooping and data-driven IGMP automatically prevent flooding of IP multicast traffic
• LLDP-MED (Media Endpoint Discovery) defines a standard extension of LLDP that stores values for parameters such as
QoS and VLAN to configure automatically network devices such as IP phones
• IEEE 802.1AB Link Layer Discovery Protocol (LLDP) facilitates easy mapping using network management applications
with LLDP automated device discovery protocol
• PoE and PoE+ allocations support multiple methods (automatic, IEEE 802.3at dynamic, LLDP-MED fine grain, IEEE
802.3af device class, or user-specified) to allocate and manage PoE/PoE+ power for more efficient energy savings
• Local MAC Authentication assigns attributes such as VLAN and QoS using locally configured profile that can be a list of
MAC prefixes
• IP multicast routing includes PIM sparse and dense modes to route IP multicast traffic
• Protocol Independent Multicast for IPv6 supports one-to-many and many-to-many media casting use cases such as IPTV
over IPv6 networks
• Virtual Router Redundancy Protocol (VRRP) allows groups of two routers to back each other up dynamically to create
highly available routed environments in IPV4 and IPV6 networks
• IEEE 802.1s Multiple Spanning Tree provides high link availability in multiple VLAN environments by allowing multiple
spanning trees; provides legacy support for IEEE 802.1d and IEEE 802.1w
• IEEE 802.3ad link-aggregation-control protocol (LACP) and port trunking Support up to 26 static, dynamic, or distributed
trunks with each trunk having up to eight links (ports) per static trunk
• SmartLink provides easy-to-configure link redundancy of active and standby links
• Dual hot-swappable power supplies
- Increased Resiliency provides secondary power supply to enable complete switch power redundancy in case or
power line or supply failure
- Increased PoE+ Power provides secondary power supply to increase the total available PoE+ power
Page
QuickSpecs
Aruba 2930M Switch Series
Overview
4
Management
Manageability
(UDLD) monitors the link between two switches and blocks the ports on both ends of the link
Layer 2 switching
VLAN Spanning Tree (RPVST+) allows each VLAN to build a separate spanning tree to improve link bandwidth
Layer 3 services
Layer 3 routing
OSPF area and up to eight interfaces are supported.
• Zero-Touch-Provisioning (ZTP) simplifies installation of the switch infrastructure using Aruba Activate-based or DHCP-
• Flexible management with same hardware - Supports both cloud-based Central and on-premise AirWave with the same
• Built-in programmable and easy to use REST API interface provides configuration automation for mobile-first campus
• Out-of-band Ethernet management port enables management a separate physical management network, and keeps
• SNMPv1, v2, and v3 provide complete support of SNMP; provide full support of industry-standard Management
• Dual flash images provides independent primary and secondary operating system files for backup while upgrading
• Aruba Central cloud- based management platform offers simple, secure and cost effective way to manage switches
• Friendly port names allow assignment of descriptive names to ports
• Find-Fix-Inform finds and fixes common network problems automatically, then informs administrator
• Multiple configuration files allow multiple configuration files to be stored to a flash image
• Software updates free downloads from the Web
• RMON, XRMON, and sFlow provide advanced monitoring and reporting capabilities for statistics, history, alarms, and
• Troubleshooting ingress and egress port monitoring enable network problem solving
• Unidirectional link detection
• Power down mode allows power savings while the switch is not in use by powering down most of the switch, except for a
based process with AirWave Network Management
hardware ensuring change management platform without ripping and replacing switching infrastructure
networks
management traffic segmented from network data traffic
Information Base (MIB) plus private extensions; SNMPv3 supports increased security using encryption
events
if the link goes down at any point between the two devices
clock which will boot up the switch on a schedule
LANs on a high-speed campus or metro network
• VLAN Support and Tagging supports IEEE 802.1Q (4094 VLAN IDs) and 2K VLANs simultaneously
• Jumbo packet support improves the performance of large data transfers; supports frame size of up to 9220 bytes
• IEEE 802.1v protocol VLANs isolate select non-IPv4 protocols automatically into their own VLANs
• Rapid Per-
usage; is compatible with PVST+
• GVRP and MVRP allows automatic learning and dynamic assignment of VLANs
• VxLAN encapsulation (tunneling) protocol for overlay network that enables a more scalable virtual network deployment
• IEEE 1588v2 Transparent Clock Mode1-step and end to end delay mode support critical timing Applications
• DHCP server centralizes and reduces the cost of IPv4 address management
• Static IP routing provides manually configured routing; includes ECMP capability
• IEEE802.1ad QinQ Increases the scalability of an Ethernet network by providing a hierarchical structure; conets multiple
• Routing Information Protocol (RIP) provides RIPv1, RIPv2, and RIPng routing
• Access OSPF provides OSPFv2 and OSPFv3 protocols for routing between access and the next layer on the LAN. One
Page
QuickSpecs
Aruba 2930M Switch Series
Overview
5
•
Security
IEEE 802.1X uses an IEEE 802.1X supplicant on the client in conjunction with a RADIUS server to authenticate in
based environment, similar to IEEE 802.1X, to authenticate clients
Role ensures that important infrastructure devices such as IP phones are allowed network
chatty legacy devices to stay authenticated by pinning client MAC addresses to the port
rt until the
specific to each authenticated network user
Policy-based routing uses a classifier to select traffic that can be forwarded based on policy set by the network
administrator (limited to 16 next-hop routes)
• Multiple user authentication methods
-
accordance with industry standards
- Web-based authentication provides a browser-
that do not support the IEEE 802.1X supplicant
- MAC-based authentication authenticates the client with the RADIUS server based on the client’s MAC address
• TPM-based Security
- Includes a Trusted Platform Module (TPM) for secure hardware-based generation and storage of cryptographic
keys that can be used for a variety of authentication purposes
• Authentication flexibility
- Multiple IEEE 802.1X users per port provides authentication of multiple IEEE 802.1X users per port; prevents a
user from “piggybacking” on another user’s IEEE 802.1X authentication
- Concurrent IEEE 802.1X, Web, and MAC authentication schemes per port switch port will accept up to 32
sessions of IEEE 802.1X, Web, and MAC authentications
- Open Authentication Role simplifies first-time deployment of AAA in brownfield deployments by allowing full
network access for failed clients and provides instant connectivity as soon as a client is plugged-in
- Critical Authentication
access even in the absence of a RADIUS server
- MAC Pinning allows non-
until the clients logoff or get disconnected
• Open authentication role simplifies first-time deployment of AAA in brownfield deployments by allowing full network
access for failed clients and provides instant connectivity as soon as a client is plugged-in
• Critical authentication role ensures that important infrastructure devices such as IP phones are allowed network access
even in the absence of a RADIUS server
• MAC pinning allows non-chatty legacy devices to stay authenticated by pinning client MAC addresses to the po
clients logoff or get disconnected
• Access control lists (ACLs) provide IP Layer 3 filtering based on source/destination IP address/subnet and
source/destination TCP/UDP port number
• Control plane policing: Set rate limit on control protocols to protect CPU overload
• Source-port filtering allows only specified ports to communicate with each other
• RADIUS/TACACS+ eases switch management security administration by using a password authentication server
• Secure shell encrypts all transmitted data for secure remote CLI access over IP networks
• Secure Sockets Layer (SSL) encrypts all HTTP traffic, allowing secure access to the browser-based management GUI in
the switch
• Port security allows access only to specified MAC addresses, which can be learned or specified by the administrator
• MAC address lockout prevents particular configured MAC addresses from connecting to the network
• Secure FTP allows secure file transfer to and from the switch; protects against unwanted file downloads or unauthorized
copying of a switch configuration file
• Switch management logon security helps secure switch CLI logon by optionally requiring either RADIUS or TACACS+
authentication
• Custom banner displays security policy when users log in to the switch
• STP BPDU port protection blocks Bridge Protocol Data Units (BPDUs) on ports that do not require BPDUs, preventing
forged BPDU attacks
• DHCP protection blocks DHCP packets from unauthorized DHCP servers, preventing denial-of-service attacks
• Dynamic ARP protection blocks ARP broadcasts from unauthorized hosts, preventing eavesdropping or theft of network
data
• STP root guard protects the root bridge from malicious attacks or configuration mistakes
• Identity-driven ACL enables implementation of a highly granular and flexible access security policy and VLAN assignment
Page
QuickSpecs
Aruba 2930M Switch Series
Overview
6
•
switch ports (1Gbps or 10Gbps or HPE Smart Rate) using
Monitor and diagnostics
Warranty
; for details on the
Per-port broadcast throttling configures broadcast control selectively on heavy traffic port uplinks
• Private VLAN provides network security by restricting peer-to-peer communication to prevent a variety of malicious
attacks; typically a switch port can only communicate with other ports in the same community and/or an uplink port,
regardless of VLAN ID or destination MAC address
• IEEE 802.1AE MACsec provides security on a link between two
standard encryption and authentication Control plane policing
• Digital optical monitoring of SFP+ and 1000BASE-T transceivers allows detailed monitoring of the transceiver settings
and parameters
• Limited Lifetime Warranty
See http://www.hpe.com/networking/warrantysummary
product purchase.
• Software releases to find software for your product, refer to http://www.hpe.com/networking/support
software releases available with your product purchase, refer to http://www.hpe.com/networking/warrantysummary
for warranty and support information included with your
Page
QuickSpecs
Aruba 2930M Switch Series
Configuration
7
Build To Order:
BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-Shippable solution.
Aruba 2930M 40G 8 HPE Smart Rate PoE+ 1-slot Switch
JL323A
•
• 1U - Height
See Configuration
Aruba 2930M 24 HPE Smart Rate PoE+ 1-slot Switch
JL324A
•
NOTE:
• 1U - Height
Aruba 2930M 24G 1-slot Switch
JL319A
•
• 1U - Height
See Configuration
Aruba 2930M 24G PoE+ 1-slot Switch
JL320A
•
• 1U - Height
See Configuration
Aruba 2930M 48G 1-slot Switch
JL321A
•
• 1U - Height
See Configuration
Aruba 2930M 48G PoE+ 1-slot Switch
JL322A
8 Smart Rate Ports 1/2.5/5/10GbaseT PoE+
• 36 10/100/1000BaseT Ports PoE+
• 4 Combo Ports 10/100/1000BaseT PoE+ or 100M/1G SFP Ports
• min=0 \\ max=4 SFP Transceivers
• 1 Uplink Module Slot
• 1 Stacking Module Slot
• Must select minimum 1 Power Supply (Default Qty1 JL087A)
NOTE: 1
24 Smart Rate Ports 1/2.5/5Gbps PoE+ (
No 10Gbps)
• 1 Uplink Module Slot
• 1 Stacking Module Slot
• Must select minimum 1 Power Supply (Default Qty1 JL087A)
4 Combo Ports 10/100/1000BaseT or 100M/1G SFP Ports
• 20 10/100/1000BaseT
• min=0 \\ max=4 SFP Transceivers
• 1 Uplink Module Slot
• 1 Stacking Module Slot
• Must select minimum 1 Power Supply (Default Qty1 JL085A)
4 Combo Ports 10/100/1000BaseT PoE+ or 100M/1G SFP Ports
• 20 10/100/1000BaseT PoE+
• min=0 \\ max=4 SFP Transceivers
• 1 Uplink Module Slot
• 1 Stacking Module Slot
• Must select minimum 1 Power Supply (Default Qty1 JL086A)
NOTE: 1
NOTE: 1
4 Combo Ports 10/100/1000BaseT or 100M/1G SFP Ports
• 44 10/100/1000BaseT
NOTE: 1
• min=0 \\ max=4 SFP Transceivers
• 1 Uplink Module Slot
• 1 Stacking Module Slot
• Must select minimum 1 Power Supply (Default Qty1 JL085A)
Page
QuickSpecs
Aruba 2930M Switch Series
Configuration
8
•
• 1U - Height
See Configuration
Configuration Rules:
NOTE 1
The following Transceivers install into this Module: (Use #0D1 or #B01 if switch is CTO) - if applicable
HPE X121 1G SFP LC LH Transceiver
J4860C
HPE X121 1G SFP LC LX Transceiver
J4859C
HPE X121 1G SFP LC SX Transceiver
J4858C
HPE X111 100M SFP LC FX Transceiver
J9054C
Aruba 1G SFP LC SX 500m OM2 MMF Transceiver
J4858D
Aruba 1G SFP LC LX 10km SMF Transceiver
J4859D
Aruba 1G SFP LC LH 70km SMF Transceiver
J4860D
Aruba 1G SFP RJ45 T 100m Cat5e Transceiver
J8177D
Aruba 100M SFP LC FX 2km MMF Transceiver
J9054D
Rack Level Integration CTO Models
Aruba 2930M 40G 8 HPE Smart Rate PoE+ 1-slot Switch
JL323A
•
• 1U - Height
See Configuration
Aruba 2930M 24 HPE Smart Rate PoE+ 1-slot Switch
JL324A
•
• 1U - Height
See Configuration
Aruba 2930M 24G 1-slot Switch
JL319A
•
• 1U - Height
See Configuration
Aruba 2930M 24G PoE+ 1-slot Switch
JL320A
4 Combo Ports 10/100/1000BaseT PoE+ or 100M/1G SFP Ports
• 44 10/100/1000BaseT PoE+
• min=0 \\ max=4 SFP Transceivers
• 1 Uplink Module Slot
• 1 Stacking Module Slot
• Must select minimum 1 Power Supply (Default Qty1 JL086A)
NOTE: 1
• 36 10/100/1000BaseT Ports PoE+
• 4 Combo Ports 10/100/1000BaseT PoE+ or 100M/1G SFP Ports
• min=0 \\ max=4 SFP Transceivers
• 1 Uplink Module Slot
• 1 Stacking Module Slot
• Must select minimum 1 Power Supply
• 1 Uplink Module Slot
• 1 Stacking Module Slot
• Must select minimum 1 Power Supply
• 20 10/100/1000BaseT
• min=0 \\ max=4 SFP Transceivers
• 1 Uplink Module Slot
• 1 Stacking Module Slot
• Must select minimum 1 Power Supply
8 Smart Rate Ports 1/2.5/5/10GbaseT PoE+
NOTE: 1, 2, 3
24 Smart Rate Ports 1/2.5/5Gbps PoE+ (NOTE: No 10Gbps)
NOTE: 2, 3
4 Combo Ports 10/100/1000BaseT or 100M/1G SFP Ports
NOTE: 1, 2, 3
Page
QuickSpecs
Aruba 2930M Switch Series
Configuration
9
•
• 1U - Height
See Configuration
Aruba 2930M 48G 1-slot Switch
JL321A
•
•
See Configuration
Aruba 2930M 48G PoE+ 1-slot Switch
JL322A
•
• 1U - Height
See Configuration
Configuration Rules:
NOTE 1
The following Transceivers install into this Module: (Use #0D1 or #B01 if switch is CTO) - if applicable
HPE X121 1G SFP LC LH Transceiver
J4860C
HPE X121 1G SFP LC LX Transceiver
J4859C
HPE X121 1G SFP LC SX Transceiver
J4858C
HPE X111 100M SFP LC FX Transceiver
J9054C
Aruba 1G SFP LC SX 500m OM2 MMF Transceiver
J4858D
Aruba 1G SFP LC LX 10km SMF Transceiver
J4859D
Aruba 1G SFP LC LH 70km SMF Transceiver
J4860D
Aruba 1G SFP RJ45 T 100m Cat5e Transceiver
J8177D
Aruba 100M SFP LC FX 2km MMF Transceiver
J9054D
NOTE 2
If this switch is factory installed in HPE Racks, Then the J9583A#0D1 is required.
NOTE 3
If HPE CTO Switch Chassis is selected to for Rack Level Integration, Then the CTO Switch Chassis needs to
integrate (with #0D1) to the HPE Rack.
Enter the following menu selections as integrated to the CTO Model X server above if order is factory built.
Networking
Uplink Modules
System (std 0 // max 1) User Selection (min 0 // max 1) per enclosure
4 Combo Ports 10/100/1000BaseT PoE+ or 100M/1G SFP Ports
• 20 10/100/1000BaseT PoE+
• min=0 \\ max=4 SFP Transceivers
• 1 Uplink Module Slot
• 1 Stacking Module Slot
• Must select minimum 1 Power Supply
4 Combo Ports 10/100/1000BaseT or 100M/1G SFP Ports
• 44 10/100/1000BaseT
• min=0 \\ max=4 SFP Transceivers
• 1 Uplink Module Slot
• 1 Stacking Module Slot
• Must select minimum 1 Power Supply
1U - Height
4 Combo Ports 10/100/1000BaseT PoE+ or 100M/1G SFP Ports
• 44 10/100/1000BaseT PoE+
• min=0 \\ max=4 SFP Transceivers
• 1 Uplink Module Slot
• 1 Stacking Module Slot
• Must select minimum 1 Power Supply
NOTE: 1, 2, 3
NOTE: 1, 2, 3
NOTE: 1, 2, 3
Page
QuickSpecs
Aruba 2930M Switch Series
Configuration
10
Aruba 3810M/2930M 1-port QSFP+ 40GbE Module
JL078A
•
See Configuration
NOTE: 3
Aruba 3810M 4 HPE Smart Rate PoE+ Module
JL081A
•
Aruba 3810M/2930M 4-port 100M/1G/10G SFP+ MACsec Module
JL083A
•
See Configuration
NOTE: 1, 2
Configuration Rules:
NOTE 1
The following 1G Transceivers install into this Module (Use #0D1 or #B01 quoted to switch if switch is CTO) if applicable
HPE X121 1G SFP LC LH Transceiver
J4860C
HPE X121 1G SFP LC LX Transceiver
J4859C
HPE X121 1G SFP LC SX Transceiver
J4858C
HPE X111 100M SFP LC FX Transceiver
J9054C
Aruba 1G SFP LC SX 500m OM2 MMF Transceiver
J4858D
Aruba 1G SFP LC LX 10km SMF Transceiver
J4859D
Aruba 1G SFP LC LH 70km SMF Transceiver
J4860D
Aruba 1G SFP RJ45 T 100m Cat5e Transceiver
J8177D
NOTE 2
The following 10G Transceivers install into this Module (Use #0D1 or #B01 quoted to switch if switch is CTO)
- if applicable
HPE X132 10G SFP+ LC ER Transceiver
J9153A
HPE X132 10G SFP+ LC SR Transceiver
J9150A
HPE X132 10G SFP+ LC LR Transceiver
J9151A
HPE X132 10G SFP+ LC LRM Transceiver
J9152A
Aruba 10G SFP+ LC SR 300m OM3 MMF Transceiver
J9150D
Aruba 10G SFP+ LC LR 10km SMF Transceiver
J9151D
Aruba 10G SFP+ LC LRM 220m OM2 MMF Transceiver
J9152D
Aruba 10G SFP+ LC ER 40km SMF Transceiver
J9153D
Aruba 10G SFP+ to SFP+ 1m Direct Attach Copper Cable
J9281D
Aruba 10G SFP+ to SFP+ 3m Direct Attach Copper Cable
J9283D
Aruba 10G SFP+ to SFP+ 7m Direct Attach Copper Cable
J9285D
HPE X242 10G SFP+ to SFP+ 1m Direct Attach Copper Cable
J9281B
HPE X242 10G SFP+ to SFP+ 3m Direct Attach Copper Cable
J9283B
HPE X242 10G SFP+ to SFP+ 7m Direct Attach Copper Cable
J9285B
NOTE 3
The following 40G Transceivers install into this Module (Use #0D1 or #B01 quoted to switch if switch is CTO)
- if applicable
Aruba 40G QSFP+ LC Bidirectional 150m MMF 2-strand Transceiver
JL308A
HPE X142 40G QSFP+ MPO SR4 Transceiver
JH231A
HPE X142 40G QSFP+ LC LR4 SM Transceiver
JH232A
HPE X142 40G QSFP+ MPO eSR4 300M Transceiver
JH233A
Aruba 40G QSFP+ LC Bidirectional 150m MMF 2-strand Transceiver
JL308A
HPE X242 40G QSFP+ to QSFP+ 1m Direct Attach Copper Cable
JH234A
1 x QSFP+ Ports
4 x HPE Smart Rate Ports
4 x 10GbE SFP+ Ports
Page
QuickSpecs
Aruba 2930M Switch Series
Configuration
11
HPE X242 40G QSFP+ to QSFP+ 3m Direct Attach Copper Cable
JH235A
HPE X242 40G QSFP+ to QSFP+ 5m Direct Attach Copper Cable
JH236A
Remarks:
Watson Only Blue Note - Although all 3810M/2930M Switches are compatible with the 4 Port HPE Smart
Rate module, non PoE switches do not provide PoE power to the HPE Smart Rate Module.
Stacking Modules
System (std 0 // max 1) User Selection (min 0 // max 1) per Stacking Module
Aruba 2930 2-port Stacking Module
JL325A
•
See Configuration
NOTE:
Configuration Rules:
NOTE 1
One of the following Stacking Cables must be selected:
Aruba 2920/2930M 0.5m Stacking Cable
J9734A
Aruba 2920/2930M 1m Stacking Cable
J9735A
Aruba 2920/2930M 3m Stacking Cable
J9736A
Transceivers
SFP Transceivers
HPE X121 1G SFP LC LH Transceiver
J4860C
HPE X121 1G SFP LC LX Transceiver
J4859C
HPE X121 1G SFP LC SX Transceiver
J4858C
HPE X111 100M SFP LC FX Transceiver
J9054C
Aruba 100M SFP LC FX 2km MMF Transceiver
J9054D
Aruba 1G SFP LC SX 500m OM2 MMF Transceiver
J4858D
Aruba 1G SFP LC LX 10km SMF Transceiver
J4859D
Aruba 1G SFP LC LH 70km SMF Transceiver
J4860D
Aruba 1G SFP RJ45 T 100m Cat5e Transceiver
J8177D
SFP+ Transceivers
HPE X132 10G SFP+ LC ER Transceiver
J9153A
HPE X132 10G SFP+ LC SR Transceiver
J9150A
HPE X132 10G SFP+ LC LR Transceiver
J9151A
HPE X132 10G SFP+ LC LRM Transceiver
J9152A
Aruba 10G SFP+ LC SR 300m OM3 MMF Transceiver
J9150D
Aruba 10G SFP+ LC LR 10km SMF Transceiver
J9151D
Aruba 10G SFP+ LC LRM 220m OM2 MMF Transceiver
J9152D
Aruba 10G SFP+ LC ER 40km SMF Transceiver
J9153D
Aruba 10G SFP+ to SFP+ 1m Direct Attach Copper Cable
J9281D
Aruba 10G SFP+ to SFP+ 3m Direct Attach Copper Cable
J9283D
Aruba 10G SFP+ to SFP+ 7m Direct Attach Copper Cable
J9285D
HPE X242 10G SFP+ to SFP+ 1m Direct Attach Copper Cable
J9281B
HPE X242 10G SFP+ to SFP+ 3m Direct Attach Copper Cable
J9283B
HPE X242 10G SFP+ to SFP+ 7m Direct Attach Copper Cable
J9285B
QSFP+ Transceivers
min=1 \ max=2 Stacking Cables
1
Page
QuickSpecs
Aruba 2930M Switch Series
Configuration
12
Aruba 40G QSFP+ LC Bidirectional 150m MMF 2-strand Transceiver
JL308A
HPE X142 40G QSFP+ MPO SR4 Transceiver
JH231A
HPE X142 40G QSFP+ LC LR4 SM Transceiver
JH232A
HPE X142 40G QSFP+ MPO eSR4 300M Transceiver
JH233A
Aruba 40G QSFP+ LC Bidirectional 150m MMF 2-strand Transceiver
JL308A
HPE X242 40G QSFP+ to QSFP+ 1m Direct Attach Copper Cable
JH234A
HPE X242 40G QSFP+ to QSFP+ 3m Direct Attach Copper Cable
JH235A
HPE X242 40G QSFP+ to QSFP+ 5m Direct Attach Copper Cable
JH236A
Internal Power Supplies
System (std 0 // max 2) User Selection (min 1 // max 2) per enclosure
Aruba X371 12VDC 250W 100-240VAC Power Supply
JL085A
See Configuration
NOTE: 1, 3
PDU Cable NA/MEX/TW/JP
JL085A#B2B
• C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU Cable ROW
JL085A#B2C
• C15 PDU Jumper Cord (ROW)
High Volt Power Supply to Wall Power Cord
JL085A#B2E
• NEMA L6-20P Cord (NA/MEX/JP/TW)
No Power Cord
JL085A#AC3
• No Localized Power Cord Selected
Aruba X372 54VDC 680W 100-240VAC Power Supply
JL086A
See Configuration
NOTE: 2, 3
PDU Cable NA/MEX/TW/JP
JL086A#B2B
• C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU Cable ROW
JL086A#B2C
• C15 PDU Jumper Cord (ROW)
High Volt Power Supply to Wall Power Cord
JL086A#B2E
• NEMA L6-20P Cord (NA/MEX/JP/TW)
No Power Cord
JL086A#AC3
• No Localized Power Cord Selected
Aruba X372 54VDC 1050W 110-240VAC Power Supply
JL087A
See Configuration
NOTE: 2, 3
PDU Cable NA/MEX/TW/JP
JL087A#B2B
Page
QuickSpecs
Aruba 2930M Switch Series
Configuration
13
• C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU Cable ROW
JL087A#B2C
• C15 PDU Jumper Cord (ROW)
High Volt Power Supply to Wall Power Cord
JL087A#B2E
• NEMA L6-20P Cord (NA/MEX/JP/TW)
No Power Cord
JL087A#AC3
• No Localized Power Cord Selected
Configuration Rules:
NOTE 1
This PSU is compatible with the following Switches: JL319A; JL321A
NOTE 2
This PSU is compatible with the following Switches: JL320A; JL322A; JL323A; JL324A
NOTE 3
Localization required on orders without #B2B, #B2C, #B2E and #AC3 options
Remarks:
Drop down under power supply should offer the following options and results:
Switch/Router/Power Supply to PDU Power Cord
#B2C ROW. (Watson Default B2B or B2C for Rack Level CTO)
Switch/Router/Power Supply to Wall Power
CTO)
High Volt Switch/Router/Power Supply to Wall Power Cord
Mexico, Taiwan, and Japan)
No Power Cord - #AC3 Option
Watson Blue NOTE: It is recommended that both power supplies match for full redundancy in the case of a
fully populated switch, but not required.
Cables
Stacking Cables
(std 0 // max 99) User Selection (min 0 // max 99) per switch
Aruba 2920/2930M 0.5m Stacking Cable
J9734A
Aruba 2920/2930M 1m Stacking Cable
J9735A
Aruba 2920/2930M 3m Stacking Cable
J9736A
Console Cables
(std 0 // max 99) User Selection (min 0 // max 99) per switch
Aruba X2C2 RJ45 to DB9 Console Cable
JL448A
Multi-Mode Cables
(std 0 // max 99) User Selection (min 0 // max 99) per switch
HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 1m Cable
QK732A
HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 2m Cable
QK733A
HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 5m Cable
QK734A
HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 15m Cable
QK735A
- #B2B in North America, Mexico, Taiwan, and Japan or
Cord - Localized Option (Watson Default for BTO and Box Level
- #B2E Option. (Offered only in North America,
Page
QuickSpecs
Aruba 2930M Switch Series
Configuration
14
HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 30m Cable
QK736A
HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 50m Cable
QK737A
Switch Enclosure Options
Mounting Kit
HPE X410 1U Universal 4-post Rackmount Kit
J9583A
See Configuration
NOTE: 1
Configuration Rules:
NOTE 1
If this Mounting Kit is ordered with #0D1, then it integrates to the HP Universal Rack. (not the switch)
Page
QuickSpecs
Aruba 2930M Switch Series
Technical Specifications
15
Aruba 2930M 24G 1-slot Switch (JL319A)
I/O ports and slots
20 Autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASETX,
IEEE 802.3ab Type 1000Base-T); Duplex: 10BASE-T/100BASE-TX:half or full;1000BASE-T:full only
4 Combo 10/100/1000BASE-T or 100/1000Mbps SFP Ports
Additional ports and
1 Dual Personality (RJ-45 or USB Micro-B) serial console port
1 USB B port for uploading/ downloading files
1 100BASE-T Out of Band Management Port
1 Uplink Slot
1 Stacking Module Slot
2 Power Supply Slots (power supplies not included)
Physical characteristics
Dimensions
1.73" (Height) x 17.42" (Width) x 12.77" (Depth) (4.39cm x 44.25cm x
32.43cm)
Weight
9.81 lbs 4.45kg
Memory and processor
Dual Core ARM Cortex A9 @ 1016 MHz
1 GB DDR3 SDRAM
Packet Buffer Size: 12.38 MB 4.5MB Ingress/7.875MB Egress
4GB eMMC
Performance
IPv6 Ready certified
10 Mbps Latency
< 98.5us (FIFO 64 byte packets)
100 Mbps Latency
<11.8us (FIFO 64-byte Packets)
1000 Mbps Latency
< 3.1us (FIFO 64-byte packets)
10Gbps Latency
<3.4us (FIFO 64-byte packets)
Throughput
95.2Mpps
Stacking Performance
100 Gbps
Switching Capacity
128 Gbps
Switching Capacity
228 Gbps
Routing table Size
10000 entries (IPv4), 5000 entries (IPv6)
Mac Address Table Size
32768 entries
Environment
Operating temperature
32˚ F to 131˚F (0° C to 55° C) up to 5000ft, 32˚ F to 122˚F (0° C to
50° C). Derate -1 degree C for every 1000 ft from 5000 ft to 10000 ft
Operating relative
humidity
15%to 95% (Non-condens- ing) 10,000 ft
Nonoperating/Storage
temperature
-40°C to 70°C up to 15000 ft
Nonoperating/Storage
relative humidity
90% at 65°C (non-condens- ing); 15,000 ft
Acoustic
Sound Power LWaD=4.0 Bel, Sound Pressure LpAm, Bystander = 22.8 dB
Primary Airflow
direction
Front to Back
Electrical Characteristics
Frequency
50/60Hz
Maximum Heat
150 kJ/hr
Voltage
slots
(including Stacking)
Dissipation
145 BTU/hr
JL085A PSU: 100-127/200-240
Page
QuickSpecs
Aruba 2930M Switch Series
Technical Specifications
16
Current
JL085A PSU: 1A/0.5A
Maximum power rating
93W
Idle Power
28W
PoE Power
(Max Possible)
N/A
Hibernate Power
7W
Notes
Idle power is the actual power consumption of the device with no ports
plugged in, and all modules populated.
Aruba 2930M 24G PoE+ 1-slot Switch (JL320A)
I/O ports and slots
20 Autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASETX,
full;1000BASE-T:full only
4 Combo 10/100/1000BASE-T PoE+ or 100/1000Mbps SFP Ports
Additional ports and
1 Dual Personality (RJ-45 or USB Micro-B) serial console port
1 USB B port for uploading/ downloading files
1 100BASE-T Out of Band Management Port
1 Uplink Slot
1 Stacking Module Slot
2 Power Supply Slots (power supplies not included)
Physical characteristics
Dimensions
1.73" (Height) x 17.42" (Width) x 12.77" (Depth) (4.39cm x 44.25cm x
32.43cm)
Weight
9.92 lbs 4.50 kg
Memory and processor
Dual Core ARM Cortex A9 @ 1016 MHz
1 GB DDR3 SDRAM
Packet Buffer Size: 12.38 MB 4.5MB Ingress/7.875MB Egress
4GB eMMC
Performance
IPv6 Ready certified
10 Mbps Latency
< 98.5us (FIFO 64 byte packets)
100 Mbps Latency
<11.8us (FIFO 64-byte Packets)
1000 Mbps Latency
< 3.1us (FIFO 64-byte packets)
10Gbps Latency
<3.4us (FIFO 64-byte packets)
Throughput
95.2Mpps
Stacking Performance
100 Gbps
Switching Capacity
128 Gbps
Switching Capacity
(including Stacking)
228 Gbps
Routing table Size
10000 entries (IPv4), 5000 entries (IPv6)
Mac Address Table Size
32768 entries
Environment
Operating temperature
32˚ F to 131˚F (0° C to 55° C) up to 5000ft, 32˚ F to 122˚F (0° C to
Operating relative
humidity
15%to 95% (Non-condens- ing) 10,000 ft
slots
connected. Maximum power rating and maximum heat dissipation are the
worst case theoretical maximum numbers provide for planning the
infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports
IEEE 802.3ab Type 1000Base-T IEEE 802.3at PoE+); Duplex: 10BASE‑T/100BASE-TX:half or
50° C). Derate -1 degree C for every 1000 ft from 5000 ft to 10000 ft
Page
QuickSpecs
Aruba 2930M Switch Series
Technical Specifications
17
Nonoperating/Storage
temperature
-40°C to 70°C up to 15000 ft
Nonoperating/Storage
relative humidity
90% at 65°C (non-condens- ing); 15,000 ft
Acoustic
Sound Power LWaD=4.1 Bel, Sound Pressure LpAm, Bystander = 23.7 dB
Primary Airflow
direction
Front to Back
Electrical Characteristics
Frequency
50/60Hz
Maximum Heat
162 kJ/hr
Voltage
JL087A PSU: 110-127/200- 240 VAC
Current
JL086A PSU (each): 5A/2.5A
JL087A PSU (each): 8.5A/5A
Maximum power rating
JL086A PSU (each): 470W
JL087A PSU (each): 860W
Idle Power
30W
PoE Power
(Max Possible)
720 Watts
Hibernate Power
7W
Notes
Idle power is the actual power consumption of the device with no ports
plugged in, and all modules populated.
Aruba 2930M 48G 1-slot Switch (JL321A)
I/O ports and slots
44 Autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASETX,
IEEE 802.3ab Type 1000Base-T); Duplex: 10BASE-T/100BASE-TX:half or full;1000BASE-T:full only
4 Combo 10/100/1000BASE-T or 100/1000Mbps SFP Ports
Additional ports and
1 Dual Personality (RJ-45 or USB Micro-B) serial console port
1 USB B port for uploading/ downloading files
1 100BASE-T Out of Band Management Port
1 Uplink Slot
1 Stacking Module Slot
2 Power Supply Slots (power supplies not included)
Physical characteristics
Dimensions
1.73" (Height) x 17.42" (Width) x 12.77" (Depth) (4.39cm x 44.25cm x
32.43cm)
Weight
10.14 lbs 4.60 kg
Memory and processor
Dual Core ARM Cortex A9 @ 1016 MHz
1 GB DDR3 SDRAM
Packet Buffer Size: 12.38 MB 4.5MB Ingress/7.875MB Egress
4GB eMMC
Performance
IPv6 Ready certified
10 Mbps Latency
< 98.5us (FIFO 64 byte packets)
100 Mbps Latency
<11.8us (FIFO 64-byte Packets)
1000 Mbps Latency
< 3.1us (FIFO 64-byte packets)
Dissipation
150 BTU/hr
JL086A PSU: 100-127/200- 240 VAC
connected. Maximum power rating and maximum heat dissipation are the
worst case theoretical maximum numbers provide for planning the
infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports
slots
Page
QuickSpecs
Aruba 2930M Switch Series
Technical Specifications
18
10Gbps Latency
<3.4us (FIFO 64-byte packets)
Throughput
112 Mpps
Stacking Performance
100 Gbps
Switching Capacity
176 Gbps
Switching Capacity
(including Stacking)
276 Gbps
Routing table Size
10000 entries (IPv4), 5000 entries (IPv6)
Mac Address Table Size
32768 entries
Environment
Operating temperature
32˚ F to 131˚F (0° C to 55° C) up to 5000ft, 32˚ F to 122˚F (0° C to
50° C). Derate -1 degree C for every 1000 ft from 5000 ft to 10000 ft
Operating relative
humidity
15%to 95% (Non-condens- ing) 10,000 ft
Nonoperating/Storage
temperature
-40°C to 70°C up to 15000 ft
Nonoperating/Storage
relative humidity
90% at 65°C (non-condens- ing); 15,000 ft
Acoustic
Sound Power LWaD=4.6 Bel, Sound Pressure LpAm, Bystander = 28.8 dB
Primary Airflow
direction
Front to Back
Electrical Characteristics
Frequency
50/60Hz
Maximum Heat
194kJ/hr
Voltage
JL085A PSU: 100-127/200- 240
Current
JL085A PSU: 1A/0.5A
Maximum power rating
111W
Idle Power
36W
PoE Power
(Max Possible)
N/A
Hibernate Power
7W
Notes
Idle power is the actual power consumption of the device with no ports
plugged in, and all modules populated.
Aruba 2930M 48G PoE+ 1-slot Switch (JL322A)
I/O ports and slots
44 Autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASETX,
full;1000BASE-T:full only
4 Combo 10/100/1000BASE-T PoE+ or 100/1000Mbps SFP Ports
Additional ports and
1 Dual Personality (RJ-45 or USB Micro-B) serial console port
1 USB B port for uploading/ downloading files
1 100BASE-T Out of Band Management Port
1 Uplink Slot
1 Stacking Module Slot
2 Power Supply Slots (power supplies not included)
Dissipation
185 BTU/hr
connected. Maximum power rating and maximum heat dissipation are the
worst case theoretical maximum numbers provide for planning the
infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports
IEEE 802.3ab Type 1000Base-T, IEEE 802.3at PoE+); Duplex: 10BASE‑T/100BASE-TX:half or
slots
Page
QuickSpecs
Aruba 2930M Switch Series
Technical Specifications
19
Physical characteristics
Dimensions
1.73" (Height) x 17.42" (Width) x 12.77" (Depth) (4.39cm x 44.25cm x
32.43cm)
Weight
10.25 lbs 4.65 kg
Memory and processor
Dual Core ARM Cortex A9 @ 1016 MHz
1 GB DDR3 SDRAM
Packet Buffer Size: 12.38 MB 4.5MB Ingress/7.875MB Egress
4GB eMMC
Performance
IPv6 Ready certified
10 Mbps Latency
< 98.5us (FIFO 64 byte packets)
100 Mbps Latency
<11.8us (FIFO 64-byte Packets)
1000 Mbps Latency
< 3.1us (FIFO 64-byte packets)
10Gbps Latency
<3.4us (FIFO 64-byte packets)
Throughput
112 Mpps
Stacking Performance
100 Gbps
Switching Capacity
176 Gbps
Switching Capacity
(including Stacking)
278 Gbps
Routing table Size
10000 entries (IPv4), 5000 entries (IPv6)
Mac Address Table Size
32768 entries
Environment
Operating temperature
32˚ F to 131˚F (0° C to 55° C) up to 5000ft, 32˚ F to 122˚F (0° C to
Operating relative
humidity
15%to 95% (Non-condens- ing) 10,000 ft
Nonoperating/Storage
temperature
-40°C to 70°C up to 15000 ft
Nonoperating/Storage
relative humidity
90% at 65°C (non-condens- ing); 15,000 ft
Acoustic
Sound Power LWaD=4.6 Bel, Sound Pressure LpAm, Bystander = 28.8 dB
Primary Airflow
Front to Back
Electrical Characteristics
Frequency
50/60Hz
Maximum Heat
216 kJ/hr
Voltage
Current
JL086A PSU (each): 5A/2.5A
JL087A PSU (each): 8.5A/5A
Maximum power rating
JL086A PSU (each): 470W
JL087A PSU (each): 860W
Idle Power
40W
PoE Power
(Max Possible)
1440 Watts
Hibernate Power
7W
Notes
Idle power is the actual power consumption of the device with no ports
worst case theoretical maximum numbers provide for planning the
50° C). Derate -1 degree C for every 1000 ft from 5000 ft to 10000 ft
direction
200 BTU/hr
Dissipation
JL086A PSU: 100-127/200- 240 VAC
JL087A PSU: 110-127/200-240 VAC
connected. Maximum power rating and maximum heat dissipation are the
Page
QuickSpecs
Aruba 2930M Switch Series
Technical Specifications
20
infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports
plugged in, and all modules populated.
Aruba 2930M 40G 8 HPE Smart Rate PoE+ 1-slot Switch (JL323A)
I/O ports and slots
36 Autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASETX,
T:full
only
4 Combo 10/100/1000BASE-T PoE+ or 100/1000Mbps SFP
8 802.3bz 1/2.5/5 and 10GbaseT copper PoE+ ports
Additional ports and
1 Dual Personality (RJ-45 or USB Micro-B) serial console port
1 USB B port for uploading/downloading files
1 100BASE-T Out of Band Management Port
1 Uplink Slot
1 Stacking Module Slot
2 Power Supply Slots (power supplies not included)
Physical characteristics
Dimensions
1.73" (Height) x 17.42" (Width) x 12.77" (Depth) (4.39cm x 44.25cm x
32.43cm)
Weight
9.81 lbs 4.45 kg
Memory and processor
Dual Core ARM Cortex A9 @ 1016 MHz
1 GB DDR3 SDRAM
4GB eMMC
Performance
IPv6 Ready certified
10 Mbps Latency
< 98.5µs (FIFO 64 byte packets)
100 Mbps Latency
< 11.8µs (FIFO 64-byte Packets)
1000 Mbps Latency
< 3.1µs (FIFO 64-byte packets)
2.5 Gbps Latency
< 6.5µs (FIFO 64-byte packets)
5 Gbps Latency
< 4.2µs (FIFO 64-byte packets)
10 Gbps Latency
< 3.4µs (FIFO 64-byte packets)
Throughput
112 Mpps
Stacking Performance
100 Gbps
Switching Capacity
320 Gbps
Switching Capacity
(including Stacking)
420 Gbps
Routing table Size
2,000 IPv4, 1,000 IPv6 in hardware, 200 OSPF, 256 Static, 10,000 RIP
Mac Address Table Size
32768 entries
Environment
Operating temperature
Derate -1 degree C for every 1000 ft from 5000 ft to 10000 ft
Operating relative
humidity
Nonoperating/Storage
Nonoperating/Storage
relative humidity
slots
IEEE 802.3ab Type 1000Base-T PoE+); Duplex: 10BASE-T/100BASE-TX:half or full;1000BASE-
Packet Buffer Size: 12.38MB and 4.5MB Ingress/7.875MB Egress
32°F to 131°F (0°C to 55°C) up to 5000ft, 32°F to 122°F (0°C to 50°C).
15% to 95% (Non-condensing) 10,000 ft
-40°C to +70°C up to 15000 ft
temperature
90% at 65C (non-condensing); 15,000 ft
Page
QuickSpecs
Aruba 2930M Switch Series
Technical Specifications
21
Acoustic
Sound Power LWaD=4.4 Bel, Sound Pressure LpAm, Bystander = 26.0
dB
Primary Airflow
direction
Port to Power
Electrical Characteristics
Frequency
50/60Hz
Maximum Heat
Voltage
110-127/200-240 VAC
Current
JL086A PSU (each): 5.7/3A
JL087A PSU (each): 10A/5.1A
Maximum power rating
JL086A PSU (each): 538W
JL087A PSU (each): 941W
Idle Power
75W
PoE Power
(Max Possible)
1440 Watts
Hibernate Power
7W
Notes
Idle power is the actual power consumption of the device with no ports
plugged in, and all modules populated.
Aruba 2930M 24 HPE Smart Rate PoE+ 1-slot Switch (JL324A)
I/O ports and slots
24 Autosensing 1/2.5/5GBaseT ports PoE+
Additional ports and
1 Dual Personality (RJ-45 or USB Micro-B) serial console port
1 100BASE-T Out of Band Management Port
1 Uplink Slot
1 Stacking Module Slot
2 Power Supply Slots (power supplies not included)
Physical characteristics
Dimensions
1.73" (Height) x 17.42" (Width) x 12.77" (Depth) (4.39cm x 44.25cm x
32.43cm)
Weight
9.92 lbs 4.50 kg
Memory and processor
Dual Core ARM Cortex A9 @ 1016 MHz
1 GB DDR3 SDRAM
Packet Buffer Size: 12.38MB and 4.5MB Ingress/7.875MB Egress
4GB eMMC
Performance
IPv6 Ready certified
10 Mbps Latency
n/a
100 Mbps Latency
n/a
1000 Mbps Latency
< 3.1µs (FIFO 64-byte packets)
2.5 Gbps Latency
< 6.5µs (FIFO 64-byte packets)
5 Gbps Latency
4.2µs (FIFO 64-byte packets)
Dissipation
150 kJ/hr
JL086A PSU:
100-127/200-240 VAC
JL087A PSU:
connected. Maximum power rating and maximum heat dissipation are the
worst case theoretical maximum numbers provide for planning the
infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports
145 BTU/hr
slots
1 USB B port for uploading/downloading files
Page
QuickSpecs
Aruba 2930M Switch Series
Technical Specifications
22
10 Gbps Latency
< 3.4µs (FIFO 64-byte packets)
Throughput
112 Mpps
Stacking Performance
100 Gbps
Switching Capacity
320 Gbps
Switching Capacity
(including Stacking)
420 Gbps
Routing table Size
2,000 IPv4, 1,000 IPv6 in hardware, 200 OSPF, 256 Static, 10,000 RIP
Mac Address Table Size
32768 entries
Environment
Operating temperature
32°F to 113°F (0°C to 45°C) up to 5000ft, 32°F to 122°F (0°C to 45°C).
Derate -1 degree C for every 1000 ft from 5000 ft to 10000 ft
Operating relative
humidity
15% to 95%
Nonoperating/Storage
temperature
-40°C to +70°C
Nonoperating/Storage
relative humidity
90% at 65C
Acoustic
Sound Power LWaD=4.8 Bel, Sound Pressure LpAm, Bystander = 31.2 dB
Primary Airflow
direction
Port to Power
Electrical Characteristics
Frequency
50/60Hz
Maximum Heat
162 kJ/hr
Voltage
Current
JL086A PSU (each): 5.9A/3A
JL087A PSU (each): 10A/5.1A
Maximum power rating
JL086A PSU (each): 554W
JL087A PSU (each): 957W
Idle Power
95W
PoE Power
(Max Possible)
860 Watts
Hibernate Power
7W
Notes
Idle power is the actual power consumption of the device with no ports
plugged in, and all modules populated.
The operating temperature range for an Aruba 2930M switch is 0°C to 50°C (32°F to 122°F) if any of the following transceivers
are installed in the switch:
HPE X132 10G SFP+ LC SR Transceiver
J9150A
HPE X132 10G SFP+ LC LR Transceiver
J9151A
HPE X132 10G SFP+ LC LRM Transceiver
J9152A
HPE X132 10G SFP+ LC ER Transceiver
J9153A
(Non-condensing) 10,000 ft
up to 15000 ft
(non-condensing); 15,000 ft
Dissipation
150 BTU/hr
JL086A PSU:
100-127/200-240 VAC
JL087A PSU:
110-127/200-240 VAC
connected. Maximum power rating and maximum heat dissipation are the
worst case theoretical maximum numbers provide for planning the
infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports
Page
QuickSpecs
Aruba 2930M Switch Series
Technical Specifications
23
Aruba 40G QSFP+ LC Bidirectional 150m MMF 2-strand Transceiver
JL308A
HPE X142 40G QSFP+ MPO SR4 Transceiver
JH231A
HPE X142 40G QSFP+ LC LR4 SM Transceiver
JH232A
HPE X142 40G QSFP+ MPO eSR4 300M Transceiver
JH233A
General Specifications
Safety
UL 60950-1, 2nd Edition
Emissions
VCCI Class A
Immunity
Generic
EN 55024:2010/CISPR 24
ESD
IEC 61000-4-2
Radiated
IEC 61000-4-3
EFT/Burst
IEC 61000-4-4
Surge
IEC 61000-4-5
Conducted
IEC 61000-4-6
Power frequency
magnetic field
IEC 61000-4-8
Voltage dips and
IEC 61000-4-11
Harmonics
EN 61000-3-2, IEC 61000-3-2
Flicker
EN 61000-3-3, IEC 61000-3-3
Management
Aruba AirWave Network Management
Standards and Protocols
(applies to all products in series)
EN 60950-1:2006 +A11:2009 : A1:2010 +A12:2011 +A2:2013
IEC60950-1:2005 +A1:2009 +A2:2013
CSA 22.2 No. 60950-1-07 2nd
EN60825-1:2007 /IEC 60825-1:2007 Class 1
CNS 13438
ICES-003 Class A
FCC CFR 47 Part 15, Class A
EN 55022: 2010/CISPR-22, Class A
interruptions
IMC—Intelligent Management Center
Command-line interface
Web browser
Configuration menu
REST interface
SNMP manager
Telnet
RMON1
FTP
Out-of-band management (serial RS-232C, micro USB, Ethernet)
Page
QuickSpecs
Aruba 2930M Switch Series
Technical Specifications
24
Denial of service
• CPU DoS Protection
Device Management
• RFC 1155 Structure and Mgmt Information (SMIv1)
General protocols
• IEEE 802.1AX-2008 Link Aggregation
• IEEE 1588v2 Precision Time Protocol(Transparent Clock Mode)
protection
• RFC 1157 SNMPv1/v2c
• RFC 1591 DNS (client)
• RFC 1901 (Community based SNMPv2)
• RFC 1901-1907 SNMPv2c, SMIv2 and Revised MIB-II
• RFC 1908 (SNMP v1/2 Coexistence)
• RFC 2576 (Coexistence between SNMP V1, V2, V3)
• RFC 2578-2580 SMIv2
• RFC 2579 (SMIv2 Text Conventions)
• RFC 2580 (SMIv2 Conformance)
• RFC 2819 (RMON groups Alarm, Event, History and Statistics only)
• RFC 3416 (SNMP Protocol Operations v2)
• RFC 3417 (SNMP Transport Mappings)
• HTML and telnet management
• HTTP, SSHv1, and Telnet
• Multiple Configuration Files
• Multiple Software Images
• SNMP v3 and RMON RFC support
• SSHv1/SSHv2 Secure Shell
• TACACS/TACACS+
• Web UI
• IEEE 802.1D MAC Bridges
• IEEE 802.1p Priority
• IEEE 802.1Q VLANs
• IEEE 802.1s Multiple Spanning Trees
• IEEE 802.1v VLAN classification by Protocol and Port
• IEEE 802.1w Rapid Reconfiguration of Spanning Tree
• IEEE 802.3ab 1000BASE-T
• IEEE 802.3ad Link Aggregation Control Protocol (LACP)
• IEEE 802.3af Power over Ethernet
• IEEE 802.3at PoE+
• IEEE 802.3az Energy Efficient Ethernet
• IEEE 802.3bz 2.5Gb/s and 5Gb/s interfaces
• IEEE 802.3x Flow Control
• RFC 768 UDP
• RFC 783 TFTP Protocol (revision 2)
• RFC 792 ICMP
• RFC 793 TCP
• RFC 826 ARP
• RFC 854 TELNET
• RFC 868 Time Protocol
• RFC 951 BOOTP
• RFC 1058 RIPv1
• RFC 1256 ICMP Router Discovery Protocol (IRDP)
• RFC 1350 TFTP Protocol (revision 2)
• RFC 1519 CIDR
• RFC 1542 BOOTP Extensions
Page
QuickSpecs
Aruba 2930M Switch Series
Technical Specifications
25
• RFC 1918 Address Allocation for Private Internet
Network Management Protocol
IP Multicast
• RFC 1112 IGMP
IPV6
• RFC 1981 IPv6 Path MTU Discovery
• RFC 3513 IPv6 Addressing Architecture
• RFC 2030 Simple Network Time Protocol (SNTP) v4
• RFC 2131 DHCP
• RFC 2236 IGMP Snooping
• RFC 2453 RIPv2
• RFC 2865 Remote Authentication Dial In User Service (RADIUS)
• RFC 2866 RADIUS Accounting
• RFC 3046 DHCP Relay Agent Information Option
• RFC 3411 An Architecture for Describing Simple Network Management Protocol (SNMP)
Management Frameworks
• RFC 3412 Message Processing and Dispatching for the Simple Network Management Protocol
(SNMP)
• RFC 3413 Simple Network Management Protocol (SNMP) Applications
• RFC 3414 User-based Security Model (USM) for version 3 of the Simple Network Management
Protocol (SNMPv3)
• RFC 3415 View-based Access Control Model (VACM) for the Simple
(SNMP)
• RFC 3416 Protocol Operations for SNMP
• RFC 3417 Transport Mappings for the Simple Network Management Protocol (SNMP)
• RFC 3418 Management Information Base (MIB) for the Simple Network Management Protocol
(SNMP)
• RFC 3575 IANA Considerations for RADIUS
• RFC 3576 Ext to RADIUS (CoA only)
• RFC 4541 Considerations for Internet Group Management Protocol (IGMP) and Multicast Listener
Discovery (MLD) Snooping Switches
• RFC 4675 RADIUS VLAN & Priority
• RFC 4861 Neighbor Discovery for IP version 6 (IPv6)
• RFC 4862 IPv6 Stateless Address Autoconfiguration
• RFC 5905 Network Time Protocol Version 4: Protocol and Algorithms Specification
• UDLD (Uni-directional Link Detection)
• RFC 2236 IGMPv2
• RFC 2710 Multicast Listener Discovery (MLD) for IPv6
• RFC 3376 IGMPv3
• RFC 3973 PIM Dense Mode
• RFC 4601 PIM Sparse Mode
• RFC 4541 Considerations for Internet Group Management Protocol (IGMP) and Multicast Listener
Discovery (MLD) Snooping Switches
• RFC 5059 Bootstrap Router—Except for scope zones
• RFC 7761 PIM Sparse Mode
• RFC 2080 RIPng for IPv6
• RFC 2081 RIPng Protocol Applicability Statement
• RFC 2082 RIP-2 MD5
• RFC 2460 IPv6 Specification
• RFC 2464 Transmission of IPv6 over Ethernet Networks
• RFC 2710 Multicast Listener Discovery (MLD) for IPv6
• RFC 2925 Definitions of Managed Objects for Remote Ping, Traceroute, and Lookup Operations
(Ping only)
• RFC 2925 Remote Operations MIB (Ping only)
• RFC 3019 MLDv1 MIB
• RFC 3315 DHCPv6 (client and relay)
• RFC 3484 Default Address Selection for IPv6
Page
QuickSpecs
Aruba 2930M Switch Series
Technical Specifications
26
• RFC 3596 DNS Extension for IPv6
MIBs
• IEEE 802.1ap (MSTP and STP MIB’s only)
Network Management
• IEEE 802.1AB Link Layer Discovery Protocol (LLDP)
• RFC 2578 Structure of Management Information Version 2 (SMIv2)
• RFC 3810 MLDv2 for IPv6
• RFC 4022 MIB for TCP
• RFC 4113 MIB for UDP
• RFC 4251 SSHv6 Architecture
• RFC 4252 SSHv6 Authentication
• RFC 4253 SSHv6 Transport Layer
• RFC 4254 SSHv6 Connection
• RFC 4291 IP Version 6 Addressing Architecture
• RFC 4293 MIB for IP
• RFC 4419 Key Exchange for SSH
• RFC 4443 ICMPv6
• RFC 4541 IGMP & MLD Snooping Switch
• RFC 4861 IPv6 Neighbor Discovery
• RFC 4862 IPv6 Stateless Address Auto-configuration
• RFC 5095 Deprecation of Type 0 Routing Headers in IPv6
• RFC 6620 FCFS SAVI
• draft-ietf-savi-mix
• IEEE 8021-Bridge-MIB (2008)
• IEEE 8021-Q-Bridge-MIB (2008)
• RFC 1155 Structure & ID of Mgmt Info for TCP/IP Internets
• RFC 1156 (TCP/IP MIB)
• RFC 1157 A Simple Network Management Protocol (SNMP)
• RFC 1213 MIB II
• RFC 1493 Bridge MIB
• RFC 1724 RIPv2 MIB
• RFC 2021 RMONv2 MIB
• RFC 2578 Structure of Management Information Version 2 (SMIv2)
• RFC 2579 Textual Conventions for SMIv2
• RFC 2580 Conformance Statements for SMIv2
• RFC 2613 SMON MIB
• RFC 2618 RADIUS Client MIB
• RFC 2620 RADIUS Accounting MIB
• RFC 2665 Ethernet-Like-MIB
• RFC 2668 802.3 MAU MIB
• RFC 2674 802.1p and IEEE 802.1Q Bridge MIB
• RFC 2737 Entity MIB (Version 2)
• RFC 2819 RMON MIB
• RFC 2863 The Interfaces Group MIB
• RFC 2925 Ping MIB
• RFC 2932 IP (Multicast Routing MIB)
• RFC 2933 IGMP MIB
• RFC 3414 SNMP-User based-SM MIB
• RFC 3415 SNMP-View based-ACM MIB
• RFC 3417 Simple Network Management Protocol (SNMP) over IEEE 802 Networks
• RFC 3418 MIB for SNMPv3
• RFC 4836 Managed Objects for 802.3 Medium Attachment Units (MAU)
• RFC 1155 Structure of Management Information
• RFC 1157 SNMPv1
• RFC 2021 Remote Network Monitoring Management Information Base Version 2 using SMIv2
• RFC 2576 Coexistence between SNMP versions
Page
QuickSpecs
Aruba 2930M Switch Series
Technical Specifications
27
• RFC 2579 Textual Conventions for SMIv2
the Simple Network Management Protocol
QoS/CoS
• IEEE 802.1p (CoS)
Security
• IEEE 802.1X Port Based Network Access Control
• RFC 3576 Dynamic Authorization Extensions to RADIUS
• RFC 2580 Conformance Statements for SMIv2
• RFC 2819 Four groups of RMON: 1 (statistics), 2 (history), 3 (alarm) and 9 (events)
• RFC 2819 Remote Network Monitoring Management Information Base
• RFC 2856 Textual Conventions for Additional High Capacity Data Types
• RFC 2925 Definitions of Managed Objects for Remote Ping, Traceroute, and Lookup Operations
• RFC 3164 BSD syslog Protocol
• RFC 3176 sFlow
• RFC 3411 SNMP Management Frameworks
• RFC 3412 Message Processing and Dispatching for the Simple Network Management Protocol
(SNMP)
• RFC 3413 Simple Network Management Protocol (SNMP) Applications
• RFC 3414 User-based Security Model (USM) for version 3 of the Simple Network Management
Protocol (SNMPv3)
• RFC 3415 View-based Access Control Model (VACM) for
(SNMP)
• RFC 3418 Management Information Base (MIB) for the Simple Network Management Protocol
(SNMP)
• RFC 5424 Syslog Protocol
• ANSI/TIA-1057 LLDP Media Endpoint Discovery (LLDPMED)
• SNMPv1/v2c/v3
• XRMON
• RFC 2474 DiffServ Precedence, including 8 queues/port
• RFC 2475 DiffServ Architecture
• RFC 2597 DiffServ Assured Forwarding (AF)
• RFC 2598 DiffServ Expedited Forwarding (EF)
• Ingress Rate Limiting
• RFC 1321 The MD5 Message-Digest Algorithm
• RFC 1334 PPP Authentication Protocols (PAP)
• RFC 1492 An Access Control Protocol, Sometimes Called TACACS
• RFC 1492 TACACS+
• RFC 1994 PPP Challenge Handshake Authentication Protocol (CHAP)
• RFC 2082 RIP-2 MD5 Authentication
• RFC 2104 Keyed-Hashing for Message Authentication
• RFC 2138 RADIUS Authentication
• RFC 2139 RADIUS Accounting
• RFC 2246 Transport Layer Security (TLS)
• RFC 2548 Microsoft Vendor-specific RADIUS Attributes
• RFC 2618 RADIUS Authentication Client MIB
• RFC 2620 RADIUS Accounting Client MIB
• RFC 2698 A Two Rate Three Color Marker
• RFC 2716 PPP EAP TLS Authentication Protocol
• RFC 2818 HTTP Over TLS
• RFC 2865 RADIUS (client only)
• RFC 2865 RADIUS Authentication
• RFC 2866 RADIUS Accounting
• RFC 2867 RADIUS Accounting Modifications for Tunnel Protocol Support
• RFC 2868 RADIUS Attributes for Tunnel Protocol Support
• RFC 2869 RADIUS Extensions
• RFC 2882 NAS Requirements: Extended RADIUS Practices
• RFC 3162 RADIUS and IPv6
Page
QuickSpecs
Aruba 2930M Switch Series
Technical Specifications
28
• RFC 3579 RADIUS Support For Extensible Authentication Protocol (EAP)
• RFC 3580 IEEE 802.1X RADIUS
• RFC 3580 IEEE 802.1X Remote Authentication Dial In User Service (RADIUS) Usage Guidelines
• RFC 4576 RADIUS Attributes
• Access Control Lists (ACLs)
• draft-grant-tacacs-02 (TACACS)
• Guest VLAN for 802.1X
• MAC Authentication
• MAC Lockdown
• MAC Lockout
• Port Security
• Secure Sockets Layer (SSL)
• SSHv2 Secure Shell
• Web Authentication
Refer to Hewlett Packard Enterprise website http://www.hpe.com/networking/services
on the service level descriptions and product numbers. For details about services and response times
in your area, please contact your local Hewlett Packard Enterprise sales office.
for details
Page
QuickSpecs
Aruba 2930M Switch Series
Accessories
29
Aruba 2930M Switch Series accessories
Modules
Aruba 2930 2-port Stacking Module
JL325A
Aruba 3810M/2930M 1-port QSFP+ 40GbE Module
JL078A
Aruba 3810M/2930M 4-port 100M/1G/10G SFP+ MACsec Module
JL083A
Aruba 3810M 4 HPE Smart Rate PoE+ Module
JL081A
Transceivers
Aruba 100M SFP LC FX 2km MMF Transceiver
J9054D
Aruba 1G SFP RJ45 T 100m Cat5e Transceiver
J8177D
Aruba 1G SFP LC SX 500m OM2 MMF Transceiver
J4858D
Aruba 1G SFP LC LX 10km SMF Transceiver
J4859D
Aruba 1G SFP LC LH 70km SMF Transceiver
J4860D
Aruba 10G SFP+ LC SR 300m OM3 MMF Transceiver
J9150D
Aruba 10G SFP+ LC LR 10km SMF Transceiver
J9151D
Aruba 10G SFP+ LC LRM 220m OM2 MMF Transceiver
J9152D
Aruba 10G SFP+ LC ER 40km SMF Transceiver
J9153D
Aruba 10G SFP+ to SFP+ 1m Direct Attach Copper Cable
J9281D
Aruba 10G SFP+ to SFP+ 3m Direct Attach Copper Cable
J9283D
Aruba 10G SFP+ to SFP+ 7m Direct Attach Copper Cable
J9285D
Aruba 40G QSFP+ LC Bidirectional 150m MMF 2-strand Transceiver
JL308A
HPE X142 40G QSFP+ MPO SR4 Transceiver
JH231A
HPE X142 40G QSFP+ LC LR4 SM Transceiver
JH232A
HPE X142 40G QSFP+ MPO eSR4 300M Transceiver
JH233A
HPE X242 40G QSFP+ to QSFP+ 1m Direct Attach Copper Cable
JH234A
HPE X242 40G QSFP+ to QSFP+ 3m Direct Attach Copper Cable
JH235A
HPE X242 40G QSFP+ to QSFP+ 5m Direct Attach Copper Cable
JH236A
Stacking Cables
Aruba 2920/2930M 0.5m Stacking Cable
J9734A
Aruba 2920/2930M 1m Stacking Cable
J9735A
Aruba 2920/2930M 3m Stacking Cable
J9736A
Power Supplies
Aruba X371 12VDC 250W 100-240VAC Power Supply
JL085A
Aruba X372 54VDC 680W 100-240VAC Power Supply
JL086A
Aruba X372 54VDC 1050W 110-240VAC Power Supply
JL087A
Mounting Kit
HPE X410 1U Universal 4-post Rackmount Kit
J9583A
Cables
Aruba X2C2 RJ45 to DB9 Console Cable
JL448A
HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 1m Cable
QK732A
HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 2m Cable
QK733A
HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 5m Cable
QK734A
HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 15m Cable
QK735A
Page
QuickSpecs
Aruba 2930M Switch Series
Acessories
30
HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 30m Cable
QK736A
HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 50m Cable
QK737A
Page
QuickSpecs
Aruba 2930M Switch Series
Summary of Changes
31
Date
Version History
Action
Description of Change
02-Jul-2018
Version 8
Changed
Software feature update
05-Feb-2018
Version 7
Changed
Configuration section updated
08-Jan-2018
Version 6
Changed
Software feature update
11-Sep-2017
Version 5
Changed
Family product image updated
04-Sep-2017
Version 4
Added
Model added: JL323A, JL324A
SKUs added: JL308A
07-Aug-2017
Version 3
Added
SKU added: JL308A
03-Jul-2017
Version 2
Added
SKU added:
01-May-2017
Version 1
Created
Document creation.
Sign up for updates
© Copyright 2018 Hewlett Packard Enterprise Development LP. The information contained herein is
subject to change without notice. The only warranties for Hewlett Packard Enterprise products and
services are set forth in the express warranty statements accompanying such pro
Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise
shall not be liable for technical or editorial errors or omissions contained herein.
To learn more, visit
a00004551
JL448A
ducts and services.
: http://www.hpe.com/networking
enw - 15887 - Worldwide - V8 - 2-July-2018
Page
Loading...
