Page 1
ABBQ1B
built-in gas barbecue
ALFRESCO RANGE
built-in barbecue
ABBQ1B
built-in barbecue (barbecue lid sold separately)
1046W x 540D x 177H
CUTOUT: 1025W x 505D
• matte black enamel
• 3.5kWh each burner
• matte black enamel
• automatic Piezo ignition
• stainless steel burners
• cast-iron at plate
• cast-iron griddle plate
• side control knobs
• oil/fat reservoir
• ame failure device
• double-skin hood
• 5/8” connection tting
• hose and regulator assembly included
MADE IN ITALY
FLAME FAILURE
DEVICE
WARRANTY
24
MONTHS
Rangehood Options:
ABHOOD - Roasting dome BBQ hood
ABFLAT - Slimline Flat BBQ lid
Pictured: ABBQ1B built-in barbecue with
ABHOOD hooded lid
Pictured: ABBQ1B built-in barbecue with
ABFLAT flat lid
Page 1/4
ABBQ1B: EAN 9347777001795
DISCLAIMER
Eurolinx PTY LTD is continually seeking ways to improve the design specifications, aesthetics and production techniques of its products. As a result alterations to
our products and designs take place continually. Whilst every effort is made to produce information and literature that is up to date, this brochure should not be
regarded as an infallible guide to the current specifications, nor does it constitute an offer for the sale of any particular product. Product dimensions indicated in
our literature is indicative only. Actual product only should be used to define dimension cutouts. Distributors, and retailers are not agents of Eurolinx and are not
authorized to bind Eurolinx by any express or implied undertaking or representation.
ABHOOD: EAN 9347777001801
ABFLAT:EAN 9347777001818
A R111 017
Page 2
ABBQ1B
•
177
•
•
BACK VIEW ABBQ1BH
•
1046
built-in gas barbecue dimensions
1008
1025
•
540
•
•
••
•
•
•
•
•
•
135
•
•
25
•
•
•
•
•
TOP VIEW ABBQ1BH
NB: drawings are not to scale — they are to be used as a guide only. For detailed
installation instructions, please refer to user guide.
Page 2/4
ABBQ1B: EAN 9347777001795
DISCLAIMER
Eurolinx PTY LTD is continually seeking ways to improve the design specifications, aesthetics and production techniques of its products. As a result alterations to
our products and designs take place continually. Whilst every effort is made to produce information and literature that is up to date, this brochure should not be
regarded as an infallible guide to the current specifications, nor does it constitute an offer for the sale of any particular product. Product dimensions indicated in
our literature is indicative only. Actual product only should be used to define dimension cutouts. Distributors, and retailers are not agents of Eurolinx and are not
authorized to bind Eurolinx by any express or implied undertaking or representation.
A R111 017
Page 3
ABHOOD &
48.7
ABFLAT
ABBQ1BH Dimensions
•
814.2
35.7
•
•
•
built-in barbecue hooded & flat lid dimensions
52
•
212.7
177
• •
•
••
•
31.2
•
•
ABBQ1BF Dimensions
•
722.6
•
177
46
•
•
63.5
• •
•••
•
409.5
505
489.5
505
70
••
•
•
•
•
48.7
••
489.5
505
••
•
NB: drawings are not to scale — they are to be used . For detailed installation
instructions, please refer to user guide.
Page 3/4
ABHOOD: EAN 9347777001801
DISCLAIMER
Eurolinx PTY LTD is continually seeking ways to improve the design specifications, aesthetics and production techniques of its products. As a result alterations to
our products and designs take place continually. Whilst every effort is made to produce information and literature that is up to date, this brochure should not be
regarded as an infallible guide to the current specifications, nor does it constitute an offer for the sale of any particular product. Product dimensions indicated in
our literature is indicative only. Actual product only should be used to define dimension cutouts. Distributors, and retailers are not agents of Eurolinx and are not
authorized to bind Eurolinx by any express or implied undertaking or representation.
ABFLAT:EAN 9347777001818
A R111 017
Page 4
ACH12BBQ &
ABC1B
Alfresco Companion Products
Minimise grease and smoke when
cooking on your barbecue with the Artusi
twin-motor rangehood. Twin turbo motors
combined with a custom-designed
ventilation system. Suitable for any size
barbecue (up to 120cm wide).
ACH12BBQ
120cm barbecue rangehood
Designed for today’s entertaining
household, the Artusi outdoor bar fridge is
the perfect party starter. Featuring ‘party’
and ‘super cool’ mode, your beverages
can get as cool as -5°C.
ABC1B
Bar Fridge
• black glass door
• stainless steel
• 2 x 1000m³/hr airow
• dual motors with 3 powerful
air extraction speeds
• full stainless steel construction
• installation kit provided
• removable stainless steel bae
lters designed for maximum
performance and easy cleaning
• 6 x LED lights will perfectly
illuminate the cooking area
• wallmount installation
• twin duct outlets (one for each motor)
for maximum performance
motor: 2 x 218W
Page 4/4
• triple glazed glass door
• black body
• 108 litres net
• 330ml bottles: 190
• 500ml bottles: 110
• facing per shelf: 10 freestanding
• -5–10°C temperature range climate type: T,
• 43°C ambient R600A refrigerant
• ventilated cooling, auto defrost
3 retractable shelves
• touch control
• LED lighting
• heated glass door
• handle moulded onto door frame
• ‘party’ mode
• ‘super cool’ mode
• door open alarm
For information on the above products, please visit artusi.com.au
