Arthur martin AMN2001AOW User Manual

AMN2001AOW

EN	Refrigerator		User Manual	2
FR	Réfrigérateur		Notice d'utilisation	15
DE	Kühlschrank		Benutzerinformation	29

2

CONTENTS

Safety information	2	Care and cleaning	7
Safety instructions	3	Troubleshooting	8
Operation	5	Installation	11
First use	5	Noises	12
Daily use	5	Technical data	13
Hints and tips	6

Subject to change without notice.

SAFETY INFORMATION

Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.

Children and vulnerable people safety

•This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.

•Do not let children play with the appliance.

•Children shall not carry out cleaning and user maintenance of the appliance without supervision.

•Keep all packaging away from children and dispose of it appropriately.

General Safety

•This appliance is intended to be used in household and similar applications such as:

–Farm houses; staff kitchen areas in shops, offices and other working environments

–By clients in hotels, motels, bed and breakfast and other residential type environments

3

•Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.

•Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.

•Do not damage the refrigerant circuit.

•Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.

•Do not use water spray and steam to clean the appliance.

•Clean the appliance with a moist soft cloth. Only use neutral detergents. Do not use abrasive products, abrasive cleaning pads, solvents or metal objects.

•Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.

•If the supply cord is damaged, it must be replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons in order to avoid a hazard.

SAFETY INSTRUCTIONS

Installation

WARNING! Only a qualified person must install this appliance.

•Remove all the packaging and the transit bolts.

•Do not install or use a damaged appliance.

•Follow the installation instruction supplied with the appliance.

•Always take care when moving the appliance as it is heavy. Always use safety gloves and enclosed footwear.

•Make sure the air can circulate around the appliance.

•Wait at least 4 hours before connecting the appliance to the power supply. This is to allow the oil to flow back in the compressor.

•Do not install the appliance close to radiators or cookers, oven or hobs.

•The rear of the appliance must stand against the wall.

•Do not install the appliance where there is direct sunlight.

•Do not install this appliance in areas that are too humid or too colds, such as the construction appendices, garages or wine cellars.

•When you move the appliance, lift it by the front edge to avoid scratching the floor.

Electrical connection

WARNING! Risk of fire and electrical shock.

•The appliance must be earthed.

•Make sure that the electrical information on the rating plate agrees with the power supply. If not, contact an electrician.

•Always use a correctly installed shockproof socket.

4

•Do not use multi-plug adapters and extension cables.

•Make sure not to cause damage to the electrical components (e.g. mains plug, mains cable, compressor). Contact the Authorised Service Centre or an electrician to change the electrical components.

•The mains cable must stay below the level of the mains plug.

•Connect the mains plug to the mains socket only at the end of the installation. Make sure that there is access to the mains plug after the installation.

•Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.

Use

WARNING! Risk of injury, burns, electrical shock or fire.

•Do not change the specification of this appliance.

•Do not put electrical appliances (e.g. ice cream makers) in the appliance unless they are stated applicable by the manufacturer.

•Be careful not to cause damage to the refrigerant circuit. It contains isobutane (R600a), a natural gas with a high level of environmental compatibility. This gas is flammable.

•If damage occurs to the refrigerant circuit, make sure that there are no flames and sources of ignition in the room. Ventilate the room.

•Do not let hot items to touch the plastic parts of the appliance.

•Do not store flammable gas and liquid in the appliance.

•Do not put flammable products or items that are wet with flammable products in, near or on the appliance.

•Do not touch the compressor or the condenser. They are hot.

Internal light

•The type of lamp used for this appliance is not suitable for household room illumination

Care and cleaning

WARNING! Risk of injury or damage to the appliance.

•Before maintenance, deactivate the appliance and disconnect the mains plug from the mains socket.

•This appliance contains hydrocarbons in the cooling unit. Only a qualified person must do the maintenance and the recharging of the unit.

•Regularly examine the drain of the appliance and if necessary, clean it. If the drain is blocked, defrosted water collects in the bottom of the appliance.

Disposal

WARNING! Risk of injury or suffocation.

•Disconnect the appliance from the mains supply.

•Cut off the mains cable and discard it.

•Remove the door to prevent children and pets to be closed inside of the appliance.

•The refrigerant circuit and the insulation materials of this appliance are ozonefriendly.

•The insulation foam contains flammable gas. Contact your municipal authority for information on how to discard the appliance correctly.

•Do not cause damage to the part of the cooling unit that is near the heat exchanger.

5

OPERATION

Switching on

1.Insert the plug into the wall socket.

2.Turn the Temperature regulator clockwise to a medium setting.

Switching off

To turn off the appliance, turn the temperature regulator to the "O" position.

Temperature regulation

The temperature is automatically regulated.

To operate the appliance, proceed as follows:

•turn the Temperature regulator towards lower settings to obtain the minimum coldness.

•turn the Temperature regulator towards higher settings to obtain the maximum coldness.

A medium setting is generally the most suitable.

However, the exact setting should be chosen keeping in mind that the temperature inside the appliance depends on:

•room temperature

•how often the door is opened

•the quantity of food stored

•the location of the appliance.

CAUTION! If the ambient temperature is high or the appliance is fully loaded, and the appliance is set to the lowest temperatures, it may run continuously causing frost to form on the rear wall. In this case the dial must be set to a higher temperature to allow automatic defrosting and therefore reduced energy consumption.

FIRST USE

Cleaning the interior

Before using the appliance for the first time, the interior and all internal accessories should be washed with lukewarm water and some neutral soap to remove the typical smell of a brand-new product, then dried thoroughly.

CAUTION! Do not use detergents, abrasive powders, chlorine or oil-based cleaners as they will damage the finish.

DAILY USE

WARNING! Refer to Safety chapters.

Movable shelves

The walls of the refrigerator are equipped with a series of runners so that the shelves can be positioned as desired.

6

Do not move the glass shelf above the vegetable drawer to ensure correct air circulation.

Positioning the door shelves

To permit storage of food packages of various sizes, the door shelves can be placed at different heights.

1.Gradually pull the shelf in the direction of the arrows until it comes free.

2.Reposition as required.

Temperature indicator

For proper storage of food the refrigerator is equipped with the temperature indicator.

The symbol on the side wall of the appliance indicates the coldest area in the refrigerator.

If OK is displayed (A), put fresh food into area indicated by symbol, if not (B), adjust the temperature controller to a colder setting and wait 12 hours before checking the temperature indicator again.

AOK

BOK

After putting fresh food into the appliance or after opening the door repeatedly or for a long period, it is normal for the indicator not to show OK; wait at least 12 hours before readjusting the temperature controller.

HINTS AND TIPS

Normal operating sounds

The following sounds are normal during operation:

•A faint gurgling and bubbling sound from coils sound when refrigerant is pumped.

•A whirring and pulsating sound from the compressor when refrigerant is pumped.

•A sudden cracking noise from inside appliance caused by thermic dilatation (a natural and not dangerous physical phenomenon).

•A faint click noise from the temperature regulator when the compressor switches on or off.

Hints for energy saving

•Do not open the door frequently or leave it open longer than absolutely necessary.

•If the ambient temperature is high and the Temperature Regulator is set to low temperature and the appliance is fully loaded, the compressor may run continuously, causing frost or ice on the evaporator. If this happens, set the Temperature Regulator toward warmer settings to allow automatic defrosting and so a saving in electricity consumption.

Hints for fresh food refrigeration

To obtain the best performance:

•do not store warm food or evaporating liquids in the refrigerator

•do cover or wrap the food, particularly if it has a strong flavour

•position food so that air can circulate freely around it

Hints for refrigeration

Useful hints:

•Meat (all types): wrap in a suitable packaging and place it on the glass shelf above the vegetable drawer. Store meat for at most 1-2 days.

7

•Cooked foods, cold dishes: cover and place on any shelf.

•Fruit and vegetables: clean thoroughly and place in a special drawer. Bananas, potatoes, onions and garlic must not be kept in the refrigerator if not packed.

•Butter and cheese: place in a special airtight container or wrap in an aluminium foil or a polythene bag to exclude as much air as possible.

•Bottles: close with a cap and place on the door bottle shelf, or (if available) on the bottle rack.

CARE AND CLEANING

WARNING! Refer to Safety chapters.

General warnings

CAUTION! Unplug the appliance before carrying out any maintenance operation.

This appliance contains hydrocarbons in its cooling unit; maintenance and recharging must therefore only be carried out by authorized technicians.

The accessories and parts of the appliance are not suitable for washing in a dishwasher.

Periodic cleaning

CAUTION! Do not pull, move or damage any pipes and/or cables inside the cabinet.

CAUTION! Take care of not to damage the cooling system.

CAUTION! When moving the cabinet, lift it by the front edge to avoid scratching the floor.

The equipment has to be cleaned regularly:

1.Clean the inside and accessories with lukewarm water and some neutral soap.

2.Regularly check the door seals and wipe clean to ensure they are clean and free from debris.

3.Rinse and dry thoroughly.

4.If accessible, clean the condenser and the compressor at the back of the appliance with a brush.

This operation will improve the performance of the appliance and save electricity consumption.

Defrosting of the refrigerator

Frost is automatically eliminated from the evaporator of the refrigerator compartment every time the motor compressor stops, during normal use. The defrost water drains out through a trough into a special container at the back of the appliance, over the motor compressor, where it evaporates.

It is important to periodically clean the defrost water drain hole in the middle of the refrigerator compartment channel to prevent the water overflowing and dripping onto the food inside.

8

Defrosting the freezer

CAUTION! Never use sharp metal tools to scrape off frost from the evaporator as you could damage it. Do not use a mechanical device or any artificial means to speed up the thawing process other than those recommended by the manufacturer. A temperature rise of the frozen food packs, during defrosting, may shorten their safe storage life.

About 12 hours prior to defrosting, set a lower temperature, in order to build up sufficient chill reserve for the interruption in operation.

A certain amount of frost will always form on the freezer shelves and around the top compartment.

Defrost the freezer when the frost layer reaches a thickness of about 3-5 mm.

1.Switch off the appliance, or pull out electrical plug from the wall socket.

2.Remove any stored food, wrap it in several layers of newspaper and put it in a cool place.

WARNING! Do not touch frozen goods with wet hands. Hands can freeze to the goods.

3. Switch on the appliance.

After three hours reload the previously removed food into the freezer compartment.

Periods of non-operation

When the appliance is not in use for long periods, take the following precautions:

1.Disconnect the appliance from electricity supply.

2.Remove all food.

3.Defrost (if necessary) and clean the appliance and all accessories.

4.Clean the appliance and all accessories.

5.Leave the door/doors open to prevent unpleasant smells.

WARNING! If you want to keep the appliance switched on, ask somebody to check it once in a while to prevent the food inside from spoiling in case of a power failure.

TROUBLESHOOTING

WARNING! Refer to Safety chapters.

What to do if...

Problem	Possible cause	Solution
The appliance does not oper-	The appliance is switched off.	Switch on the appliance.
ate.

		9
Problem	Possible cause	Solution
	The mains plug is not con-	Connect the mains plug to
	nected to the mains socket	the mains socket correctly.
	correctly.
	There is no voltage in the	Connect a different electrical
	mains socket.	appliance to the mains sock-
		et. Contact a qualified electri-
		cian.
The appliance is noisy.	The appliance is not suppor-	Check if the appliance stands
	ted properly.	stable.
The lamp does not work.	The lamp is in stand-by.	Close and open the door.
	The lamp is defective.	Refer to "Replacing the
		lamp".
The compressor operates	Temperature is set incorrect-	Refer to "Operation" chapter.
continually.	ly.
	Many food products to be	Wait a few hours and then
	frozen were put in at the	check the temperature again.
	same time.
	The room temperature is too	Refer to climate class chart
	high.	on the rating plate.
	Food products placed in the	Allow food products to cool
	appliance were too warm.	to room temperature before
		storing.
	The door is not closed cor-	Refer to "Closing the door".
	rectly.
There is too much frost and	The door is not closed cor-	Refer to "Closing the door".
ice.	rectly or the gasket is de-
	formed/dirty.
	The water drainage plug is	Position the water drainage
	not correctly positioned.	plug in the correct way.
	Food products are not wrap-	Wrap the food products bet-
	ped properly.	ter.
	Temperature is set incorrect-	Refer to "Operation" chapter.
	ly.
Water flows on the rear plate	During the automatic defrost-	This is correct.
of the refrigerator.	ing process, frost melts on
	the rear plate.
Water flows into the refrigera-	The water outlet is clogged.	Clean the water outlet.
tor.

10
Problem	Possible cause	Solution
	Food products prevent that	Make sure that food prod-
	water flows into the water	ucts do not touch the rear
	collector.	plate.
Water flows on the floor.	The melting water outlet is	Attach the melting water out-
	not connected to the evapo-	let to the evaporative tray.
	rative tray above the com-
	pressor.
The temperature in the appli-	The temperature regulator is	Set a higher/lower tempera-
ance is too low/too high.	not set correctly.	ture.
	The door is not closed cor-	Refer to "Closing the door".
	rectly.
	The food products' tempera-	Let the food products tem-
	ture is too high.	perature decrease to room
		temperature before storage.
	Many food products are stor-	Store less food products at
	ed at the same time.	the same time.
	The thickness of the frost is	Defrost the appliance.
	greater than 4-5 mm.
	The door has been opened	Open the door only if neces-
	often.	sary.
	There is no cold air circula-	Make sure that there is cold
	tion in the appliance.	air circulation in the appli-
		ance.
There is too much con-	Door was opened too fre-	Open the door only when
densed water on the rear wall	quently.	necessary.
of the refrigerator.
	Door was not closed com-	Make sure the door is closed
	pletely.	completely.
	Stored food was not wrap-	Wrap food in suitable pack-
	ped.	aging before storing it in the
		appliance.
Door does not open easily.	You attempted to re-open	Wait a few seconds between
	the door immediately after	closing and re-opening of the
	closing.	door.

If the advice does not lead to the desired result, call the nearest Authorized Service Centre.

Replacing the lamp

The appliance is equipped with a longlife LED interior light.

11

CAUTION! Disconnect the plug from the mains socket.

1.At the same time, with the fingers expand up and down the transparent cover and unhook it in the direction of the arrows.

1

2

1

INSTALLATION

2.Replace the lamp with one of the same power and shape, specifically designed for household appliances. The maximum power is shown on the light bulb cover.

3.Reassemble the lamp cover.

4.Connect the plug to the mains socket.

5.Open the door.

Make sure that the light comes on.

Closing the door

1.Clean the door gaskets.

2.If necessary, adjust the door. Refer to assembly instructions.

3.If necessary, replace the defective door gaskets. Contact the Authorised Service Centre.

WARNING! Refer to Safety chapters.

Location

Refer to the assembly instructions for the installation.

To ensure best performance, install the appliance well away from sources of heat such as radiators, boilers, direct sunlight etc. Make sure that air can circulate freely around the back of the cabinet.

Positioning

Install the appliance in a dry, well ventilated indoors where the ambient temperature corresponds to the climate class indicated on the rating plate of the appliance.

Cli-	Ambient temperature
mate
class
SN	+10°C to + 32°C
N	+16°C to + 32°C

Cli-	Ambient temperature
mate
class
ST	+16°C to + 38°C
T	+16°C to + 43°C

Some functional problems might occur for some types of models when operating outside of that range. The correct operation can only be guaranteed within the specified temperature range. If you have any doubts regarding where to install the appliance, please turn to the vendor, to our customer service or to the nearest Authorised Service Centre.

Ventilation requirements

The airflow behind the appliance must be sufficient.

12
5 CM	MIN.
	200 CM2
	MIN.
	200 CM2

Electrical connection

rating plate correspond to your domestic power supply.

•The appliance must be earthed. The power supply cable plug is provided with a contact for this purpose. If the domestic power supply socket is not earthed, connect the appliance to a separate earth in compliance with current regulations, consulting a qualified electrician.

•The manufacturer declines all responsibility if the above safety precautions are not observed.

•This appliance complies with the E.E.C. Directives.

•Before plugging in, ensure that the voltage and frequency shown on the

NOISES

There are some sounds during normal running (compressor, refrigerant circulation).

OK

SSSRRR!

HISSS! BLUBB!

CLICK! BRRR!

CRACK!

SSSRRR! SSSRRR!

CLICK!

CLICK!

13

HISSS! HISSS!

BRRR!

BRRR!

BLUBB!

BLUBB!

CRACK!

CRACK!

TECHNICAL DATA

Technical data

Height	mm	1219
Width	mm	540
Depth	mm	550
Voltage	Volts	230 - 240
Frequency	Hz	50

The technical information is situated in the rating plate, on the external or internal side of the appliance and in the energy label.

14

ENVIRONMENTAL CONCERNS

Recycle the materials with the symbol . Put the packaging in applicable containers to recycle it. Help protect the environment and human health and to recycle waste of electrical and electronic appliances. Do not

dispose appliances marked with the symbol

with the household waste. Return the product to your local recycling facility or contact your municipal office.
