Nuda 50 unilateral floor white
T083608
SPECIFICATIONS
Colors & Finishes
White RAL9002
Materials
• Body in aluminum
• UV resistant diffuser in shock resistant polycarbonate
Design By
Ernesto Gismondi
Collection
Outdoor
Specifications
Delivered lumens 180lm
Light output ratio 22.5lm/W
Power consumption 8W
Led type 6X6.8W Array*
CCT (Correlated Color Temperature) 3000K
CRI (Color Rendering Index) >80
Life expectancy 50000Hrs
Control type On/Off
Input Voltage 120V
Driver MAGTECH - 1 x LA1012-36-C0350
BUG Rating B0-U2-G0
Features & Accessories
• Provided with IP65 cables and connector for the main connections
• Mounting plate contains holes for ground fixing by means of included lock bolts and dowels
• Electronic driver integrated in body
• Standard non dimmable
Dimensions
Light distribution
Direct
Red = Max Cd. Through Vertical plane
Blue = Max Cd. Through Horizontal plane
Packaging
1 Box
1 x 11-1/2" x 11-1/2" x 25-5/16" / 11.6 lbs - 29 cm x 29 cm x 64 cm / 5.26 kg
Luminaire weight
7.94 lbs / 3.6 kg
Warranty
5 year limited warranty
last updated: 2021-10-04 We reserve the right to change specifications of our products.
For the latest product information please visit www.artemide.net
