Nuda 100 bilateral floor white
T083908
SPECIFICATIONS
Colors & Finishes
White RAL9002
Materials
• Body in aluminum
• UV resistant diffuser in shock resistant polycarbonate
Design By
Ernesto Gismondi
Collection
Outdoor
Specifications
Delivered lumens 250lm
Light output ratio 14.71lm/W
Power consumption 17W
Led type 6X14.7W Array*
CCT (Correlated Color Temperature) 3000K
CRI (Color Rendering Index) >80
Life expectancy 50000Hrs
Control type On/Off
Input Voltage 120-277V
Driver MAGTECH - 1 x LP1026-36-C0700
BUG Rating B0-U3-G1
Features & Accessories
• Provided with IP65 cables and connector for the main connections
• Mounting plate contains holes for ground fixing by means of included lock bolts and dowels
• Electronic driver integrated in body
• Standard non dimmable
Dimensions
Light distribution
Direct
Red = Max Cd. Through Vertical plane
Blue = Max Cd. Through Horizontal plane
Packaging
1 Box
1 x 46-1/8" x 11-7/8" x 8-3/16" / 16.62 lbs - 117 cm x 30 cm x 20.5 cm / 7.54 kg
Luminaire weight
11.49 lbs / 5.21 kg
Warranty
5 year limited warranty
last updated: 2021-10-04 We reserve the right to change specifications of our products.
For the latest product information please visit www.artemide.net
