Led Net circle ceiling
1594058A
SPECIFICATIONS
Design By
Michele De Lucchi
Alberto Nason
Collection
Design
Colors & Finishes
White
Materials
• Structure in painted aluminum
• Each LED is fitted with a methacrylate lens and satin finish methacrylate lens-holder
Specifications
Delivered lumens 1883lm
Light output ratio 62.77lm/W
Power consumption 30W
Led type 28W C.O.B.*
CCT (Correlated Color Temperature) 3000K
CRI (Color Rendering Index) >80
Life expectancy 50000Hrs
Control type Dimmable 0-10V
Input Voltage 120-277V
Driver ROAL - 1 x RSLD035-16
Features & Accessories
• Custom applications available
• Dimmer Adaptor 0-10V to Wireless (W001-00355)
Dimensions
Light distribution
Direct
Red = Max Cd. Through Vertical plane
Blue = Max Cd. Through Horizontal plane
Packaging
1 Box
1 x 29-5/8" x 29-5/8" x 4-13/16" / 11.9 lbs - 75 cm x 75 cm x 12 cm / 5.4 kg
Luminaire weight
4.74 lbs / 2.15 kg
Warranty
5 year limited warranty
last updated: 2021-10-03 We reserve the right to change specifications of our products.
For the latest product information please visit www.artemide.net
