Led Net line 125 suspension
1578058A
SPECIFICATIONS
Design By
Michele De Lucchi
Alberto Nason
Collection
Design
Colors & Finishes
White
Materials
• Structure in painted aluminum
• Each LED is fitted with a methacrylate lens and satin finish methacrylate lens-holder
Specifications
Delivered lumens 1851lm
Light output ratio 61.7lm/W
Power consumption 30W
Led type 28W C.O.B.*
CCT (Correlated Color Temperature) 3000K
CRI (Color Rendering Index) >80
Life expectancy 50000Hrs
Control type Dimmable 0-10V
Input Voltage 120-277V
Driver ROAL - 1 x RSLD035-16
Features & Accessories
• Custom applications available
• Extended cable length
• Dimmer Adaptor 0-10V to Wireless (W001-00355)
Dimensions
Light distribution
Direct
Red = Max Cd. Through Vertical plane
Blue = Max Cd. Through Horizontal plane
Packaging
1 Box
1 x 61-1/8" x 18-3/16" x 4-7/16" / 13.23 lbs - 155 cm x 46 cm x 11 cm / 6 kg
Luminaire weight
5.11 lbs / 2.32 kg
Warranty
5 year limited warranty
last updated: 2021-10-04 We reserve the right to change specifications of our products.
For the latest product information please visit www.artemide.net
