Surf micro LED wall 3000K dimming 0-10V white
1646018ADIMTV
SPECIFICATIONS
Colors & Finishes
White
Materials
• Body in extruded painted aluminum
Design By
Neil Poulton
Collection
Design
Specifications
Delivered lumens 2137lm
Light output ratio 82.19lm/W
Power consumption 26W
Led type 24W C.O.B.*
CCT (Correlated Color Temperature) 3000K
CRI (Color Rendering Index) >80
Life expectancy 50000Hrs
Control type Dimmable 0-10V
Input Voltage 120-277V
Driver ROAL - 1 x RSLD035-12
Features & Accessories
• Integrated driver in J-Box (minimum deph 1.5inch - 38mm)
Dimensions
Light distribution
Indirect
Red = Max Cd. Through Vertical plane
Blue = Max Cd. Through Horizontal plane
Packaging
1 Box
1 x 11-7/8" x 11-7/8" x 3-13/16" / 2.43 lbs - 30 cm x 30 cm x 9.5 cm / 1.1 kg
Luminaire weight
1.43 lbs / .65 kg
Warranty
5 year limited warranty
last updated: 2021-10-04 We reserve the right to change specifications of our products.
For the latest product information please visit www.artemide.net
