USB 3.0 Video Capture Device - HDMI / DVI / VGA
/ Component HD Video Recorder - 1080p 60fps
Product ID: USB3HDCAP
This USB 3.0 external video capture device lets you record 1080p HD video and stereo audio to your
computer system. With multiple video inputs including HDMI, DVI, VGA and component, the capture card
can record original content from various sources such as computers, camcorders, security systems, POS
terminals, and servers. With a framerate of 60 FPS (frames per second) and H.264 encoding, this is the
perfect solution for capturing high-definition video for editing, compiling, and archiving.
Seamless picture quality at 60 FPS
Record lossless video at 60 FPS ensuring every frame of content is saved, unlike 30-frame-per-
second capture devices that only catch half the action. 60 FPS exactly matches the output of
most computer video cards, which is great for recording the output from your PC, server, or POS
station when creating software training and tutorial videos.
www.startech.com
1 800 265 1844
H.264 encoding for wide device compatibility
The included software encodes in H.264, the most widely adopted video codec in the world, ensuring your
video captures will be compatible with almost any device platform such as PC, Mac®, iOS® and Android™
with no editing or converting required. H.264 is also widely supported by most software titles
including Adobe Premiere® and Windows Media® Encoder. Plus, the software not only lets you capture
and export videos, but it also lets you take screenshots, schedule recordings and instantly stream your
video source over the Internet using online services such as Twitch or Justin.TV.
This USB capture card is capable of capturing lossless raw video making it compatible with Microsoft®
DirectShow. With raw video capture you can record video using your preferred third party
DirectShow software such as Open Broadcaster Software (OBS).
Flexible Input Solutions for Convenient Compatibility
With multiple A/V input options you can capture from a wide variety of sources including HDMI, DVI, VGA,
and component. You can also use this capture card with A/V adapters to record other video sources such
as SDI using our SDI to HDMI converter (SDI2HD). Support for a variety of A/V devices is ideal
for archiving analog video footage into a digital database.
The device also includes easy-to-use software that’s compatible with NTSC and PAL systems, making it a
must for professional video archiving applications where source media can change from project to project.
The USB3HDCAP is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Notes:
• A computer that supports USB 3.0 or higher is required. This product will not work with USB 2.0 or 1.1
controllers.
• Will not record digitally encrypted content.
• Not compatible with ASmedia, or Etron USB 3.0 host controllers. If your system has one of these nonsupported controllers you can alternatively add a PCI-express USB 3.0 controller card such as the
StarTech.com PEXUSB3S4V, PEXUSB3S400 or PEXUSB3S4.
Computer System Requirements:
• Operating System: Microsoft® Windows® Vista / 7 / 8 / 8.1 / 10 (32/64-bit)
• CPU: i3 Dual Core 2.8GHz or higher
• Memory: 2 GB
• USB 3.0 host controller (Confirmed support with: Intel, Renesas (NEC), VIA, AMD, Fresco FL1100)
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Record video for training and tutorial purposes from varying video
output technologies
• Stream live video feeds online with streaming services such as twitch
• Use with ST122HDMILE HDMI splitter to capture HD video game play
at 60 frames per second, while playing on a different display
• Convert analog video to digital in professional video archiving
applications
Features
• Seamless picture quality with USB 3.0 bandwidth enabling you to
capture 1080p video at 60fps
• Record from virtually any device, with support for HDMI, DVI, VGA,
and Component video input sources
• Supports 2-channel stereo audio (HDMI / RCA)
• NTSC and PAL systems supported
• Supports 16:9 and 4:3 aspect ratio
www.startech.com
1 800 265 1844
Warranty 2 Years
Hardware Audio Yes
Converter Type Format Converter
Industry Standards NTSC, PAL-M, PAL-60, PAL Video Encoding: MPEG4/H.264
NTSC, PAL-M, PAL-60, PAL
Video Encoding: MPEG4/H.264
Performance Audio Specifications HDMI or Component RCA Stereo
General Specifications This product is not compatible with Etron USB controllers, or
ASMedia 1042 / 1042A USB controllers.
Maximum Analog Resolutions 1920x1080 (1080p/30/50/60)
Maximum Digital Resolutions Video input: 1920x1080 (1080p/30/50/60)
Video Output: 1920x1080 (1080p/60)
Supported Resolutions 1080i/p, 720p, 576i/p, 480i/p
Wide Screen Supported Yes
Connector(s) Connector B 1 - USB Type-B (9 pin) USB 3.0 Female Output
1 - HDMI (19 pin) Female Input
1 - DVI-I (29 pin) Female Input
1 - Stereo Audio (2 x RCA) Female Input
1 - Component Video (3 x RCA) Female Input
1 - Composite Video (1 x RCA) Female Input
1 - VGA (15 pin, High Density D-Sub) Female Input
1 - S-Video (4 pin, Mini-DIN) Female Input
Software OS Compatibility Windows® 10 (32/64), 8/8.1 (32/64), 7 (32/64), Vista
(32/64), XP (32/64)
Special Notes /
Requirements
Note Confirmed compatible USB 3.0 host controllers: Intel,
Renesas (NEC), VIA, AMD, Fresco FL1100
Incompatible USB 3.0 host controllers: ASmedia, Etron
A computer that supports USB 3.0 or higher is required. This
product will not work with USB 2.0 or 1.1 controllers.
Will not record digitally encrypted content.
Environmental Humidity 20-80% RH Non-Condensing
Operating Temperature 0°C to 35°C (32°F to 95°F)
Storage Temperature -5°C to 40°C (23°F to 1604°F)
www.startech.com
1 800 265 1844
Physical
Characteristics
Product Height 1 in [24.5 mm]
Product Length 4.5 in [114.4 mm]
Product Weight 3.7 oz [106 g]
Product Width 3 in [75.5 mm]
Packaging
Information
Shipping (Package) Weight 14.5 oz [410 g]
What's in the Box Included in Package 1 - USB 3.0 HD Video Capture Device
1 - A/V breakout cable
1 - DVI to VGA adapter
1 - USB 3.0 Cable
1 - Instruction manual
Product appearance and specifications are subject to change without notice.
