KVM Docking Station for Two Laptops - Share
Keyboard, Mouse, Dual Monitors, and Files - USB
3.0
Product ID: USB3DDOCKFT
This KVM docking station for two laptops is the first of its kind. It functions similar to a KVM switch, letting
you share your keyboard, video, and mouse between two computers.
Plus, it provides dual-monitor outputs, so you can add two extra displays to your workstation, and then
share them with each laptop.
This dock eliminates the frustrations of working with multiple computers. You can save money and desk
space by using the same peripheral set with each computer, plus you can easily transfer files between
your two laptops. It’s a simple yet ultra-efficient method for working with more than one laptop.
The dual-monitor KVM dock supports Windows® or Mac laptops, or a combination of both. And for a faster
workflow and additional convenience, this specialty docking station lets you share and exchange data
between your two computers.
www.startech.com
1 800 265 1844
It's perfect for a range of users such as
professionals and office workers with multiple
laptops, students, and IT technicians. It’s ideal for
collaboration in classrooms, labs, and boardrooms,
as well as many other specialized applications.
Shared docking revolutionizes the way you work
This cutting-edge docking station is designed for users with multiple laptops or Windows based tablets.
Like a KVM switch, it lets you share your peripherals between two computers, with the added benefit of
offering extra monitor connections. With shared docking you can get more work done in less time and
avoid the nuisance of plugging and unplugging your laptops while you’re using them both at your
workstation.
When you’re in a hurry, switching control to either computer is effortless using the switch button that’s
conveniently located on the side of the dock.
www.startech.com
1 800 265 1844
You can create a dual-monitor workstation that
connects with two laptops if you have
DisplayPort™ and HDMI® displays, making it easy
to display applications or browsers from either
laptop. Alternatively the dock supports a single 4K
DP monitor, for 4K x 2K (3840 x 2160p - 30Hz)
cinema-quality resolution and vivid picture quality.
Maximum Supported Resolutions*
Video Output
Configuration
Max
DisplayPort
Resolution
Max HDMI
Resolution
DisplayPort and
HDMI
(Two Displays)
2048 x 1152p
2048 x
1152p
DisplayPort
(Single Display)
3840 x 2160p
(4K)
N/A
HDMI
(Single Display)
N/A
2560 x
1440p
*Lower resolutions are also supported. For example, if the max is 3840 x 2160p (4K), it also supports
2560 x 1600p and 2560 x 1440p.
Plenty of ports gives you everything you need
In addition to connecting two laptops, this full-featured KVM dock lets you connect up to nine peripherals,
and provides all the ports you need. And, with five USB 3.0 ports you can connect more USB devices than
most docking stations allow. Plus, every port can be easily shared between each connected laptop.
It’s easy to charge your mobile device quickly using the always-on fast-charge port. With several USB 3.0
ports, Gigabit Ethernet, and a headset jack, you can connect multiple peripherals and control them from
either laptop.
Unlike some docks, this easy-to-use docking station offers seamless, error-free driver installation which
makes it easy to create a dynamic and high-performance workstation.
www.startech.com
1 800 265 1844
Direct file sharing between laptops makes life easier
For an uninterrupted workflow and streamlined convenience this dock integrates file sharing capabilities.
Laptop-to-laptop file sharing is faster, more secure, and easier to use than cloud or external storage
solutions, plus, you can skip the aggravation of configuring your network to support file sharing.
Using Windows Easy Transfer, or the included PCLinq software, you can easily create files and
presentations on your primary laptop, and quickly transfer them to your portable Ultrabook™, MacBook,
or tablet. Plus, with two laptops connected to just one dock, the file sharing dock makes it easy to
collaborate with colleagues or classmates.
The built-in file transfer software is easy to use
and data transfers are lightning quick, using USB
3.0 technology. (USB 3.0 is also known as USB
3.1 Gen 1 - 5Gbps.)
The unique file exchange technology creates
endless application possibilities, and the dock
especially caters to developers, as well as network
and systems administrators.
www.startech.com
1 800 265 1844
Universally supported
Unlike some proprietary docking stations designed only to work with specific laptop models, this universal
laptop dock works with multiple brands. All you need is your laptop’s USB 3.0 port and you can be up and
running quickly. With universal support, you can use this dock with different laptops now, or in the future.
The USB3DDOCKFT is backed by a StarTech.com 3-year warranty and free lifetime technical support.
Note: PCLinq can be used in any operating system that the dock supports. Windows Easy Transfer can only be used in
Windows 8.1, 8, and 7.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Save money, time, and space by using just one workstation for two
computers — just like a KVM switch, but with less cable clutter
• Deploy in classrooms, computer labs, boardrooms, and other areas
where one workstation is used by multiple users or multiple laptops
• Expand the connectivity of your laptop — compatible with Ultrabook,
MacBook, Microsoft® Surface™ Pro 3, Lenovo® Yoga, and other
Windows based tablets
• Ideal for users with multiple devices such as software and hardware
developers, programmers, IT administrators
Features
• Works like a KVM switch, but with less clutter, and the added benefit
of offering extra dual-monitor outputs
• Create a dual-laptop workstation that can share up to nine devices
using a range of ports, such as dual displays (DP and HDMI), five
USB 3.0, Gigabit Ethernet, and headset
• Transfer and share data between your laptops at up to 5Gbps
throughput — supports Windows and Mac
• Supports DisplayPort plus HDMI dual video, or a single DP display at
4K Ultra HD resolutions (3840 x 2160p)
• Always-on USB fast-charge port charges devices without a laptop
connection and supports USB Battery Charging Specification 1.2
• Universal compatibility, works with virtually all USB 3.0 equipped
laptop brands
• Side-panel 3.5mm 4-position TRRS headset port (audio plus
microphone)
• Gigabit Ethernet RJ45 Port with Wake-on-LAN (WOL) support
• Easy-access button to switch control between laptops
• Integrated security lock
• Supports DisplayPort 1.2
• Small and flat footprint provides an elevated typing surface when
tucked under your laptop
• Includes two USB 3.0 host cables
www.startech.com
1 800 265 1844
Warranty 3 Years
Hardware 4K Support Yes
Bus Type USB 3.0
Chipset ID DisplayLink - DL-5900 (Display, LAN, Audio)
VLI - VL812 (USB 3.0 w/ Charge)
Displays Supported 2
Fast-Charge Port(s) Yes
Industry Standards USB Battery Charging Specification Rev. 1.2
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
USB 3.0 - Backward compatible with USB 2.0/1.1
Performance Auto MDIX Yes
Compatible Networks 10/100/1000 Mbps
Full Duplex Support Yes
Maximum Data Transfer Rate 5 Gbps (USB 3.0)
2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions 3840 x 2160 @ 30Hz (DisplayPort - Single Display)
2560 x 1440 (HDMI - Single Display)
2048 x 1152 and 2048 x 1152 (DisplayPort and HDMI - Two
Displays)
Lower resolutions are also supported. For example, if the
max is 3840 x 2160p (4K), it also supports 2560 x 1600p
and 2560 x 1440p.
Type and Rate USB 3.0 - 5 Gbit/s
UASP Support Yes
Connector(s) Connector Type(s) 1 - DisplayPort (20 pin) Female
1 - HDMI (19 pin) Female
1 - USB 3.0 A (Fast-Charge, 9 pin, SuperSpeed) Female
4 - USB Type-A (9 pin) USB 3.0 Female
1 - RJ-45 Female
1 - 3.5 mm Mini-Jack (4 Position) Female
2 - USB Type-B (9 pin) USB 3.0 Female
1 - Security Lock Slot Female
Software OS Compatibility Windows® 7, 8, 8.1, 10
Mac OS® 10.8 to 10.12
www.startech.com
1 800 265 1844
Special Notes /
Requirements
Note A 4K-capable DisplayPort display is required to achieve
4Kx2K resolutions
If connected to a USB 2.0 host port, or if using a USB 2.0
host connection cable, performance may be limited (USB 3.0
host cables included)
USB 3.0 is also known as USB 3.1 Gen 1; this connectivity
standard offers speeds up to 5Gbps
PCLinq can be used in any operating system that the dock
supports. Windows Easy Transfer can only be used in
Windows 8.1, 8, and 7
System and Cable Requirements Two USB-enabled computers with an available USB 3.0 port
on each computer (host)
Indicators LED Indicators 1 - Link (Green)
1 - Activity (Amber)
Power Center Tip Polarity Positive
Input Current 1.5 A
Input Voltage 100 ~ 240 AC
Output Current 6.5 A
Output Voltage 5 DC
Plug Type N
Power Consumption (In Watts) 32.5
Power Source AC Adapter Included
Environmental Humidity 0~90% RH
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -10°C to 80°C (14°F to 176°F)
Physical
Characteristics
Color Black & Silver
Enclosure Type Plastic
Product Height 1.3 in [34 mm]
Product Length 10.6 in [270 mm]
Product Weight 13.1 oz [372 g]
Product Width 3.2 in [82 mm]
Packaging
Information
Shipping (Package) Weight 2.5 lb [1.1 kg]
What's in the Box Included in Package 1 - laptop docking station
www.startech.com
1 800 265 1844
2 - USB 3.0 host cables
1 - universal power adapter (NA/EU/UK/AU)
1 - instruction manual
Product appearance and specifications are subject to change without notice.
