USB 3.0 to HDMI External Multi Monitor Video
Graphics Adapter for Mac & PC - DisplayLink
Certified - HD 1080p
Product ID: USB32HDPRO
The USB32HDPRO USB 3.0 to HDMI Adapter lets you add an HDMI display to your computer through a
USB 3.0 port, providing a cost-effective and convenient way to expand the video capabilities of your
Mac® or PC computer system.
USB 3.0 Bandwidth, High Definition Performance
With USB 3.0 support, this external video adapter delivers the bandwidth needed for accelerated High-
Definition video performance, capable of outputting video resolutions up to 1920x1200 / 1080p. Even if
your current computer doesn’t have a USB 3.0 port available, the USB32HDPRO is backward compatible
with USB 2.0, so you’ll be able to connect your HDMI monitor to your computer and be ready for when
you upgrade to a USB 3.0-equipped system.
www.startech.com
1 800 265 1844
Easier Multitasking, More Productivity
Add the screen space you need to simplify multitasking and maximize productivity, without even opening
your computer case. Some computer systems, including MacBook® and Ultrabook™ laptops and small
form-factor desktops, are too compact to install an internal video card. A USB display adapter offers an
easy workaround, performing as an external video card that only requires an available USB port to mirror
or extend your desktop onto another display.
DisplayLink Plug-and-Display Certified
Installation has never been easier. When you connect this DisplayLink Plug and Display certified adapter
to a web-enabled Windows® 10, Windows® 8 or Windows® 7 computer, it automatically downloads and
installs the most up-to-date drivers for you, so you won’t have to manually download or install any
software.
The USB32HDPRO is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Recommended System Requirements:
CPU: Quad Core 2.4GHz or Higher (i5 recommended)
RAM: 4GB or higher
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Add a secondary DisplayPort display and extend your desktop,
without taking apart your computer to install a new video card
• Add multi-monitor capability to a single computer, to enhance
multimedia presentations
• Great for researchers and writers, offering the ability to have
reference material on one display while working on a separate
document on another
• Increase productivity by running multiple applications on different
screens - check your email on one display and search the web on the
other
• View large or several spreadsheets across multiple displays
• A compact, lightweight solution for traveling business associates
using USB 3.0-capable laptop PCs, enabling connection to a
secondary display/projector
• Add an additional video output to computer systems with no room for
expansion, such as laptops, ultrabooks, MacBooks, and compact form
factor desktops (point of sale workstations)
Features
• USB 3.0 host connection provides maximum bandwidth for superior
performance
• Increase productivity by mirroring or extending your desktop onto
another display
• DisplayLink Plug-and-Display certified - automatic driver installation
and updates
• Works with Mac® & PC
• USB-powered - No external power adapter required
• Supports 5.1 channel audio
• Supports video resolutions up to 1920x1200 / 1080p
• Backward compatible with USB 2.0
www.startech.com
1 800 265 1844
Warranty 2 Years
Hardware Audio Yes
Chipset ID DisplayLInk - DL3500
Memory 512MB DDR II
Output Signal HDMI
USB Pass-Through No
Performance Audio Specifications 5.1-Channel Surround (48Khz)
General Specifications This USB video adapter uses a DisplayLink family chipset. If
you’re connecting this device to a computer along with
additional USB video adapters or docking stations, please
avoid using devices with a Trigger or Fresco family chipset.
Maximum Digital Resolutions 1920x1200 / 1080p
Note If using OS X 10.8, Apple update 10.8.3 must be installed
before installing DisplayLink software. 10.8.3 fixes several
serious OS X bugs exposed when DisplayLink software is
installed.
Supported Resolutions Widescreen(16/32 bit):
1920x1200, 1920x1080, 1680x1050, 1600x900, 1440x900,
1360x768, 1280x800, 1280x768, 1280x720
Standard(16/32 bit):
1600x1200, 1400x1050, 1280x1024, 1280x960, 1152x864,
1024x768, 800x600
Wide Screen Supported Yes
Connector(s) Connector A 1 - USB Type-A (9 pin) USB 3.0 Male
Connector B 1 - HDMI (19 pin) Female
Software OS Compatibility Windows® 2000, XP, Vista, 7, 8, 8.1, 10
Mac OS® 10.6 to 10.12
Ubuntu 14.04, 16.04
Special Notes /
Requirements
System and Cable Requirements 1~2 USB Displays
Office Application:
CPU: i3 Dual core 2.8GHz
RAM: 2GB or higher
Full HD Video:
CPU: Quad Core 2.4GHz or Higher (i5 recommended)
RAM: 4GB or higher
Not intended for gaming
Power Power Source USB-Powered
Environmental Humidity 20°C to 80°C (68°F to 176°F)
www.startech.com
1 800 265 1844
Operating Temperature 0°C to 35°C (32°F to 95°F)
Storage Temperature -5°C to 40°C (23°F to 104°F)
Physical
Characteristics
Cable Length 3 ft [0.9 m]
Color Black
Enclosure Type Plastic
Product Height 0.8 in [20 mm]
Product Length 3.5 in [90 mm]
Product Weight 2.1 oz [59 g]
Product Width 2.2 in [55 mm]
Packaging
Information
Shipping (Package) Weight 0.5 lb [0.2 kg]
What's in the Box Included in Package 1 - USB 3.0 to HDMI Adapter
1 - Software installation disc
1 - Instruction Manual
Product appearance and specifications are subject to change without notice.
