USB 3.1 (10Gbps) Adapter Cable for 2.5" SATA
Drives
Product ID: USB312SAT3CB
Here’s a fast, easy way to access data on a 2.5" solid-state or hard drive. This cable-style adapter lets you
connect your laptop or desktop computer directly to a solid-state drive and access it through ultra-fast
USB 3.1 Gen. 2 (up to 10 Gbps).
www.startech.com/m
1 800 265 1844
Convenient drive access
With the adapter cable, you can quickly swap hard drives without having to install your drives into an
enclosure. You can copy or retrieve data from a 2.5" SSD/HDD quickly with no additional accessories
required. It gives you easy drive access for data migration, drive cloning and data backup applications,
with the fast performance of USB 3.1 Gen 2.
Harness the speed of USB 3.1 Gen 2
USB 3.1 Gen 2 gives you greater bandwidth and speed with rates of up to 10 Gbps - twice the speed of
USB 3.0 (USB 3.1 Gen 1) technology. It lets you leverage the high performance of the latest SSDs and
hard drives, while alleviating bottlenecks in your data transfers.
Ultra-portable with no external power required
This cable-style adapter features a compact, lightweight design that tucks easily into a laptop bag or
carrying case. Use it wherever you go to access valuable data quickly - with no external power required.
www.startech.com/m
1 800 265 1844
The USB312SAT3CB is backed by a StarTech.com 2-year warranty and free lifetime technical support.
www.startech.com/m
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Technicians who need a quick, easy way to access data on 2.5” hard
drives
• Take advantage of the faster speed of USB 3.1 Gen 2 (10 Gbps)
• Access any 2.5" hard drive or solid-state drive from any USB enabled
computer, for data migration or drive cloning
• Back up important data to an external storage device
• Retrieve data from an old SATA drive
Features
• Get fast, temporary access to data with a USB 3.1 Gen 2 (10 Gbps)
cable-style adapter
• Connects to a 2.5” SATA SSD/HDD with no accessories required
• Supports SATA I, II, III (up to 6 Gbps)
• Powered directly from the USB port
• UASP support for enhanced performance
• Backward compatible with USB 3.0, 2.0 and 1.x
www.startech.com/m
1 800 265 1844
Warranty 2 Years
Hardware Bus Type USB 3.1 Gen 2
Chipset ID ASMedia - ASM1351
Compatible Drive Types SATA
Drive Size 2.5in
Interface USB 3.1 Gen 2
Number of 2.5 inch bays 1
Number of Drives 1
Performance Hot Swap Capability Yes
Max Drive Capacity Currently tested with hard drives up to 2TB at 7200 RPM
Maximum Data Transfer Rate 10 Gbps
Trim Supported Yes
Type and Rate USB 3.1 Gen 2 - 10 Gbit/s
UASP Support Yes
Connector(s) Drive Connectors 1 - SATA Data & Power Combo (7+15 pin) Receptacle
Host Connectors 1 - USB 3.1 USB Type-A (9 pin, Gen 2, 10 Gbps) Male
Software OS Compatibility OS independent; No software or drivers required
Power Power Source USB-Powered
Environmental Humidity 40% ~ 50% RH
Operating Temperature 0°C to 70°C (32°F to 158°F)
Storage Temperature -10°C to 55°C (14°F to 131°F)
Physical
Characteristics
Color Black
Enclosure Type Plastic
Product Height 0.3 in [8 mm]
Product Length 20.3 in [515 mm]
Product Weight 1.5 oz [43 g]
Product Width 1.8 in [45 mm]
Packaging
Information
Shipping (Package) Weight 2 oz [56 g]
What's in the Box Included in Package 1 - USB 3.1 to SATA 2.5" HDD adapter cable
1 - quick start guide
www.startech.com/m
1 800 265 1844
Product appearance and specifications are subject to change without notice.
