USB VGA and DVI Dual Port External Video Adapter
Product ID: USB2VGADVI
The USB2VGADVI USB to VGA/DVI-I adapter turns a USB 2.0 port into both a DVI-I and VGA video output
port. Similar to our existing USB video adapters, the USB2VGADVI offers a convenient and cost-effective
solution for adding multiple monitors to your computer without having to open the computer case for
typical video card installation.
The video output ports on the USB to DVI/VGA adapter can be used simultaneously to extend your
desktop or clone an image on two displays - essentially turning a USB connection into a dual head
external video card.
The adapter features one DVI-I (out) port, one VGA (out) port, and two built-on USB ports that can be
used as a USB hub, not only delivering simple external video but also allowing more USB peripherals to be
installed on the host computer.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Add multiple monitors / projectors to your computer without the
hassle of upgrading to a new video card
• In the office: View large or multiple spreadsheets across two screens
Features
• Offers a VGA and DVI-I (analog or digital) port for a dual monitor
solution right out of the box.
• Supports resolutions up to 1680x1050 in 32bits.
• Works as a dual display hub and a 2 port USB hub.
• Works with laptops and desktop computers.
• Easy to use drivers and software enabling dual display applications
www.startech.com
1 800 265 1844
Warranty 2 Years
Hardware Chipset ID MCT - Trigger 1+
USB Pass-Through No
Performance Supported Resolutions 1600x1200, 1680x1050, 1440x900, 1400x1050, 1360x768,
1280x1024, 1280x960, 1280x768, 1280x720, 1152x864,
1024x768 @ 16/32 bit
Connector(s) Connector A 1 - USB A (4 pin) Male
Connector B 1 - DVI-I (29 pin) Female
1 - VGA (15 pin, High Density D-Sub) Female
2 - USB A (4 pin) Female
Software OS Compatibility Windows 8/8.1 (32/64)
Windows 7(32/64)
Windows Vista (32/64)
Windows XP (32/64)
Drivers are WHQL certified
Special Notes /
Requirements
System and Cable Requirements One available USB 2.0 port
Indicators LED Indicators 1 - Power (Green)
Power Center Tip Polarity Positive
Input Voltage 110V-240V AC
Output Voltage 5 DC
Plug Type M
Power Source AC Adapter Included
Environmental Operating Temperature 0-70 degrees C
Storage Temperature 15-30 degrees C
Physical
Characteristics
Color Black
Product Height 0.7 in [18 mm]
Product Length 3.4 in [86 mm]
Product Weight 6.1 oz [172 g]
Product Width 5.3 in [135 mm]
Packaging
Information
Shipping (Package) Weight 1.5 lb [0.7 kg]
What's in the Box Included in Package 1 - USB to VGA and DVI Adapter
1 - 3ft Mini USB to USB Cable
www.startech.com
1 800 265 1844
1 - Universal Power Adapter (US/UK/EU)
1 - Driver CD
1 - Instruction Manual
Product appearance and specifications are subject to change without notice.
