8 Port 1U Rackmount USB KVM Switch with OSD
Product ID: SV831DUSBU
The SV831DUSBU 8 Port 1U Rack Mount USB KVM Switch with OSD offers a dependable computer
management tool that allows you to control up to 8 USB-connected computers from a single keyboard,
mouse and monitor.
The KVM switch offers maximum control, allowing you to switch computers using hotkey commands or
front panel push-buttons, and offers added configuration options and convenience through an On Screen
Display (OSD).
A suitable addition to server room operations, the 8 port switch can be rack mounted into 1U of cabinet
space, and can be cascaded with multiple KVM switches to deliver control of up to 64 computers from this
single switch.
Backed by a StarTech.com 3-year warranty and free lifetime technical support.
www.startech.com
1 800 265 1844
Page 2
Certifications, Reports
and Compatibility
Applications
• Add single console administration to your Co-location/ISP facility
saving you time and money
• Create a scalable, streamlined access solution in your Datacenter or
Server Farm
• Perfect for manufacturing line computer control, simplifying access to
multiple systems
• Great for PC test/burn-in computer control saving the desk space
required for multiple monitors, keyboards and mice
• Monitor multiple systems simultaneously in Software QA labs
Features
• Rugged, rack mountable, all-metal 1U chassis for use in harsh
environments and space-saving cabinets
• Supports Hotkey and front panel push-button switching
• OSD security allows each PC to be password protected
• Identify and select computers by names assigned via the OSD menu
• Auto-scan function automatically selects computer sequentially
• Cascade configuration expands system capability
• USB console interface
• Plug-and-play system configuration
• Supported Wide Screen Resolutions: 1920x1200, 1920x1080,
1680x1050, 1400x1050, 1440x900, 1360x768
• Supported 4 : 3 Resolutions: 1920x1440, 1600x1200, 1280x1024,
1024x768
• USB Keyboard and Mouse combo supported on one USB connection
www.startech.com
1 800 265 1844
Page 3
Warranty 3 Years
Hardware Audio No
Cables Included No
Daisy-Chain Yes
KVM Ports 8
Number of Monitors Supported 1
PC Interface USB
PC Video Type VGA
Rack-Mountable Yes
Performance Hot-Key Selection Yes
IP Control No
Maximum Analog Resolutions 1920 x 1440@60Hz (1920 x 1200@60Hz - Wide Screen)
Maximum Cascaded Computers 64
Maximum Number of Users 1
MTBF 75,000 hours
On-Screen Display Yes
Port Selection Support Push Button, Hotkeys, and OSD (On Screen Display)
Wide Screen Supported Yes
Connector(s) Console Interface(s) 1 - VGA (15 pin, High Density D-Sub) Female
2 - USB A (4 pin) Female
Host Connectors 8 - VGA (15 pin, High Density D-Sub) Female
Software OS Compatibility OS independent; No software or drivers required
Indicators LED Indicators 1 - Green - Power
8 - Green - Online PC
8 - Red - Selected PC
Power Center Tip Polarity Positive
Input Current 0.8A
Input Voltage 110V-240V AC
Output Current 1.5A
Output Voltage 12 DC
Plug Type M
Power Consumption (In Watts) 18
www.startech.com
1 800 265 1844
Page 4
Power Source AC Adapter Included
Environmental Humidity 80% RH
Operating Temperature 5°C to 40°C (41°F to 104°F)
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Physical
Characteristics
Color Black
Enclosure Type Steel
Product Depth 7.1 in [180 mm]
Product Height 1.8 in [45 mm]
Product Weight 102.4 oz [2900 g]
Product Width 21.3 in [540 mm]
Packaging
Information
Shipping (Package) Weight 7.3 lb [3.3 kg]
What's in the Box Included in Package 1 - 8 Port USB KVM Switch
2 - Mounting Brackets
1 - Bag of Screws
1 - Pack Rubber Feet
1 - Universal Power Adapter (NA/UK/EU)
1 - User Manual
Product appearance and specifications are subject to change without notice.
