1 Port PCI Express PCIe Gigabit NIC Server
Adapter Network Card - Low Profile
Product ID: ST1000SPEX2L
The ST1000SPEX2L Low-Profile PCIe Gigabit Network Card adds a 10/100/1000 Mbps compatible RJ45
Ethernet port to a PCI Express-enabled client, server or workstation, providing a convenient addition or
replacement networking interface.
Compliant with IEEE 802.3/u/ab standards, and with support for 9K Jumbo Frames, VLAN tagging and
Wake on LAN (WOL), this versatile Gigabit NIC/Server Adapter offers effective network performance.
The card comes pre-configured with a low-profile/half-height installation bracket and includes a standard
profile bracket for installation in a wide range of computer/server chassis, regardless of form factor.
Backed by a 2-year StarTech.com warranty and free lifetime technical support.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Upgrade from 10/100 Ethernet capability to Gigabit capability
• Add an Ethernet port to a workstation or server computer, for
redundancy or bridging
• Add networking capabilities to an old system with no Ethernet port
Features
• A single 10/100/1000Mbps compatible RJ45 Ethernet port
• Gigabit detection and Link/Activity LED indicators
• Fully Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3x and IEEE
802.3ab standards
• Supports IEEE 802.1Q VLAN tagging, IEEE 802.1P Layer 2 Priority
Encoding and IEEE 802.3x Full Duplex Flow Control
• Jumbo frame support
• Full and half duplex support
• Supports Wake-on-LAN function
• Crossover Detection & Auto-Correction (Auto MDI/MDI-X)
www.startech.com
1 800 265 1844
Warranty 2 Years
Hardware Bus Type PCI Express
Card Type Low Profile (SP bracket incl.)
Chipset ID Realtek - RTL8111E
Industry Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab
Interface RJ45 (Gigabit Ethernet)
Ports 1
Performance Auto MDIX Yes
Compatible Networks 10/100/1000 Mbps
Full Duplex Support Yes
Jumbo Frame Support 9K max.
Maximum Data Transfer Rate 1000 Mbps
Supported Protocols CSMA/CD
Connector(s) Connector Type(s) 1 - PCI Express x1
External Ports 1 - RJ-45
Software OS Compatibility Windows® 2000, XP, Vista, 7, 8, 8.1, 10
Windows Server® 2003, 2008 R2, 2012, 2012 R2, 2016
Mac OS X® 10.6 to 10.9
Linux 2.4.x to 4.11.x LTS Versions Only
Special Notes /
Requirements
System and Cable Requirements Available PCI Express expansion card slot
Indicators LED Indicators 1 - Gigabit Detect (Yellow)
1 - Link/Activity (Green)
Environmental Humidity 10% ~ 90% RH
Operating Temperature 0°C to 70°C (32°F to 158°F)
Storage Temperature 0°C to 100°C (32°F to 212°F)
Physical
Characteristics
Product Height 1.9 in [49 mm]
Product Length 2.8 in [70 mm]
Product Weight 1.1 oz [30 g]
Product Width 0.7 in [18 mm]
Packaging
Information
Shipping (Package) Weight 4.5 oz [127 g]
What's in the Box Included in Package 1 - Gigabit Ethernet PCI Express Card
www.startech.com
1 800 265 1844
1 - Standard Profile Bracket
1 - Driver CD
1 - Instruction Manual
Product appearance and specifications are subject to change without notice.
