arTech SDOCKU33EBV User Manual

eSATA / USB 3.0 SATA III Hard Drive Docking Station SSD / HDD with UASP
Product ID: SDOCKU33EBV
The versatile SDOCKU33EBV UASP-enabled USB 3.0 / eSATA docking station makes it easy for you to
connect and swap 2.5in or 3.5in SATA III hard drives (HDD) and solid state drives (SSD), with the option
to connect through either USB or eSATA.
For convenient compatibility and time-saving performance, the SDOCKU33EBV docking station can be
connected through USB 3.0, with support for full USB 3.0 bandwidth (5 Gbps) as well as UASP, which
controller. For fast performance and efficient data transfers, the dock also supports the full SATA III
bandwidth of 6 Gbps when connected through eSATA. See our UASP testing results below for further
details.
With support for large capacity SATA I/II/III drives (tested up to 6TB), as well as 2.5in or 3.5in drives,
this HDD/SSD docking station makes it easy to maximize the storage/backup capabilities of your
computer using virtually any SATA drive.
www.startech.com
1 800 265 1844
Extend the value of this hard drive docking station further with the addition of our SATA to IDE Hard Drive
Adapter (SAT2IDEADP), allowing easy insertion of any 2.5 or 3.5in IDE hard drive into a SATA hard drive
dock.
To ensure compatibility with your computer system, the SDOCKU33EBV supports all of the leading
operating systems, including: Microsoft Windows® (8/7/Vista/XP/Server 2008/Server 2003), Apple® OSX
(10.9/10.8/10.7/10.6), Linux, and Google Chrome OS™.
The SDOCKU33EBV is backed by a 2-year StarTech.com warranty and free lifetime technical support.
Improved Performance with UASP
UASP is supported in Windows 8, Mac OSX (10.8 or above), and Linux. In testing, UASP performs with a
70% faster read speed and 40% faster write speed over traditional USB 3.0 at peak performance.
At the same peak in testing UASP also shows an
80% reduction in required processor resources.
Testing results were obtained using an Intel® Ivy
Bridge system, a UASP-enabled StarTech.com
Enclosure, and a SATA III solid state drive.
www.startech.com
1 800 265 1844
Certifications, Reports and Compatibility
Applications
Add quick access to drives for data recovery or retrieval
Backup data quickly to an external data archiving
Test or benchmark different hard drives and swap between them
Quickly access drives for imaging
Features
Supports SATA III & UASP for optimal performance
eSATA or USB 3.0 interface options
Supports 2.5in and 3.5in form factor SATA hard drives (HDD) and solid state drives (SSD)
Compatible with USB 3.0/2.0/1.1 (5 Gbps / 480 Mbps / 1.5 Mbps)
Compatible with SATA revision I/II/III (1.5/3.0/6.0 Gbps) drives
Plug-and-Play and Hot-Swap compatible
www.startech.com
1 800 265 1844
Warranty 2 Years
Hardware Bus Type USB 3.0 & eSATA
Chipset ID JMicron – JMS561
Compatible Drive Types SATA
Drive Installation Removable
Drive Size 2.5in & 3.5in
Fan(s) No
Interface USB 3.0 & eSATA
Number of Drives 1
Performance Hot Swap Capability Yes
Max Drive Capacity Currently tested with hard drives up to 6TB 7200 RPM
Maximum Data Transfer Rate 6 Gbps (eSATA)
5 Gbps (USB 3.0)
Type and Rate USB 3.0 - 5 Gbit/s
SATA III (6 Gbps)
UASP Support Yes
Connector(s) Drive Connectors 1 - SATA Data & Power Combo (7+15 pin) Receptacle
Host Connectors 1 - USB Type-B (9 pin) USB 3.0 Female
1 - eSATA (7 pin, Data) Female
Software OS Compatibility OS independent; No software or drivers required
Indicators LED Indicators 1 - Power/Activity
Power Input Current 0.8 A
Input Voltage 100 ~ 240 AC
Output Current 2.0 A
Output Voltage 12 DC
Power Consumption (In Watts) 24
Power Source AC Adapter Included
Environmental Humidity 20%RH ~ 80%RH
Operating Temperature 5°C to 35°C (41°F to 95°F)
Storage Temperature -20°C to 50°C (-4°F to 122°F)
Physical Characteristics
Color Black
www.startech.com
1 800 265 1844
Product Height 2.1 in [53 mm]
Product Length 5.5 in [139 mm]
Product Weight 11.5 oz [325 g]
Product Width 3.6 in [92 mm]
Packaging Information
Shipping (Package) Weight 1.7 lb [0.8 kg]
What's in the Box Included in Package 1 - USB 3.0/eSATA to SATA III Hard Drive Dock w/UASP
1 - USB 3.0 Cable
1 - eSATA Cable
1 - Universal Power Adapter (NA / EU / UK)
1 - Instruction Manual
Product appearance and specifications are subject to change without notice.
