eSATA / USB 3.0 Hard Drive Duplicator Dock –
Standalone HDD Cloner with SATA 6Gbps for fastspeed duplication
Product ID: SDOCK2U33RE
The SDOCK2U33RE Dual 2.5/3.5" SATA HDD/SSD duplicator dock lets you duplicate/clone an existing
hard drive without the use of a host computer system -- or dock and swap drives from your desktop or
laptop computer simultaneously, using a single USB or eSATA port.
Versatile Features
The SDOCK2U33RE offers convenient dual-function performance. As a hard drive duplicator, the
SDOCK2U33RE lets you create an exact sector-by-sector clone from one hard drive to another, including
partitions and boot sector information -- ensuring data integrity and consistency for sensitive operations,
such as data recovery. As an external hard drive dock the SDOCK2U33RE lets you connect your drives
through either eSATA or USB, with each drive slot individually supporting high capacity 2.5/3.5" hard
drives or solid state drives, tested up to 4 TB.
www.startech.com
1 800 265 1844
Fast Performance
With support for SATA III (6 Gbps) you can maximize efficiency with duplication speeds up to 22 GB per
minute, and eSATA docking speeds up to 6 Gbps. The Dock can also be connected through USB 3.0 with
UASP for transfer speeds up 5 Gbps (70% faster than conventional USB 3.0). See our UASP testing results
below for further details.
Hassle-free Operation
With push button operation and plug-and play installation, the duplicator dock has been specially designed
for hassle-free operation. The SDOCK2U33RE lets you quickly dock your hard drives or start duplicating
hard drives with the push of a button. Plus, the built-in LED progress bar saves you time by letting you
easily monitor the entire duplication process, so you'll know exactly when it's time to start your next
operation.
For added compatibility with different drive types in duplication and docking applications, the
SDOCK2U33RE supports the use of various drive adapters. The below list of StarTech.com adapters have
been specifically tested, to ensure compatibility with this drive duplicator:
2.5/3.5in IDE drives - SAT2IDEADP
mSATA drives - SAT2MSAT25
M.2 (NGFF) drives - SAT32M225
SDOCK2U33RE is backed by a StarTech.com 2-year warranty and free lifetime technical support.
www.startech.com
1 800 265 1844
Improved Performance with UASP
UASP is supported in Windows 8, Mac OSX (10.8 or above), and Linux. In testing, UASP performs with a
70% faster read speed and 40% faster write speed over traditional USB 3.0 at peak performance.
At the same peak in testing UASP also shows an
80% reduction in required processor resources.
Testing results were obtained using an Intel® Ivy
Bridge system, a UASP-enabled StarTech.com
Enclosure, and a SATA III solid state drive.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Disc sector imaging/cloning to create an exact replica of a source
drive onto a different drive
• Create identical backups for system builds that require the same
drive image
• Quickly access or swap bare hard drives for easy data
backup/recovery
Features
• Standalone sector-by-sector hard drive duplication with speeds up to
22GB per minute
• Supports both 2.5" and 3.5" form factor hard drives (HDD) and solid
state drives (SSD)
• eSATA and USB 3.0 host interface connections
• 1:1 hard drive duplicator and docking station
• Support SATA III (6 Gbps) and UASP for optimal performance
• Supports dual drive capacity up to 4 TB per slot (8 TB in total)
• Compatible with SATA revision I/II/III (1.5/3.0/6.0 Gbps) drives
• Compatible with USB 3.0/2.0/1.1 (5 Gbps / 480 Mbps / 1.5 Mbps)
• Dual bay, top slot-loading design with drive doors
www.startech.com
1 800 265 1844
Warranty 2 Years
Hardware Chipset ID JMicron - JMS562
Compatible Drive Types SATA
Drive Installation Removable
Drive Size 2.5in & 3.5in
Interface USB 3.0 & eSATA
Number of Drives 2
Performance Max Drive Capacity Currently tested with up to 4TB 7200 RPM 3.5" hard drives
per bay (8TB total) and 2TB 5900 RPM 2.5" hard drives (2TB
total)
RAID No
Type and Rate USB 3.0 - 5 Gbit/s
SATA III (6 Gbps)
UASP Support Yes
Connector(s) Drive Connectors 2 - SATA Data & Power Combo (7+15 pin) Receptacle
Host Connectors 1 - USB Type-B (9 pin) USB 3.0 Female
1 - eSATA (7 pin, Data) Female
Software OS Compatibility OS independent; No software or drivers required
Indicators LED Indicators 2 - Drive Status
1 - Power Indicator
1 - Mode Indicator
1 - Progress Indicator
Power Input Current 1.3 A
Input Voltage 100 ~ 240 AC
Output Current 3000 mA
Output Voltage 12 DC
Power Consumption (In Watts) 36
Power Source AC Adapter Included
Environmental Humidity 20%RH ~ 80%RH
Operating Temperature 5°C - 35°C (41°C to 95°C)
Storage Temperature -20°C - 50°C (-4°C to 122°C)
Physical
Characteristics
Color Black
www.startech.com
1 800 265 1844
Product Height 2.8 in [70 mm]
Product Length 5.8 in [147 mm]
Product Weight 17.6 oz [500 g]
Product Width 5.2 in [132 mm]
Packaging
Information
Shipping (Package) Weight 36 oz [1020 g]
What's in the Box Included in Package 1 - SATA HDD duplicator dock
1 - USB 3.0 cable
1 - eSATA cable
1 - universal power adapter (NA,UK,EU)
1 - instruction manual
Product appearance and specifications are subject to change without notice.
