USB 3.0 to SATA Hard Drive Docking Station for
2.5/3.5 HDD
Product ID: SATDOCKU3S
The SATDOCKU3S USB 3.0 Hard Drive Docking Station delivers full, instant access to any 2.5in or 3.5in
SATA (SATA, SATA II, SATA III) hard drive (HDD) or solid state drive (SSD), without having to mount the
drive in a computer or install it in an external enclosure. Large capacity drives (tested with up to 4TB 3.5"
and 1TB 2.5" drives) can be used to greatly enhance your computer's storage/backup capabilities.
Connected to the host computer through a single USB 3.0 SuperSpeed or USB 2.0 connection, the hard
drive docking station provides a convenient, plug-and-play storage solution that delivers instant access to
the hard drive without requiring a reboot.
Relying on the outstanding data throughput support of USB 3.0, the HDD docking station is capable of
transfer speeds of up to 5Gbps, making it the fastest way to access data from an external drive. Double
the value of this hard drive docking station, using a SATA to IDE hard drive adapter (SAT2IDEADP), which
enables you to use any 2.5 or 3.5in IDE hard drive in a SATA hard drive dock slot.
www.startech.com
1 800 265 1844
To ensure compatibility with your computer system, the SATDOCKU3S supports all of the leading
operating systems, including: Microsoft Windows® (8/7/Vista/XP/Server 2008/Server 2003), Apple® OSX
(10.9/10.8/10.7/10.6), Linux, and Google Chrome OS™.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Data recovery specialists who need quick access to drives for imaging
• Backup data quickly to an external drive for archiving
• Technicians who test or benchmark multiple hard drives
• Take advantage of new laptops and desktops with USB 3.0
connectivity
• Upgrade from a USB 2.0 drive dock to faster USB 3.0
Features
• SuperSpeed USB 3.0 compliant host interface, with transfer rates up
to 5Gbps
• High Speed USB 2.0 compliant host interface, with transfer rates up
to 480Mbps
• Patented drive ejection mechanism
• Combined power switch and status LED
• Compatible with SATA revision 1/2/3 (1.5/3.0/6.0 Gbps) drives
• Supports 2.5" and 3.5" form factor SATA hard drives (HDD) and solid
state drives (SSD)
• Built-in short circuit protection
• Compact, desktop-style form factor
• Plug-and-Play and Hot-Swap compatible
www.startech.com
1 800 265 1844
Warranty 2 Years
Hardware Chipset ID ASMedia ASM1053
Compatible Drive Types SATA
Drive Size 2.5in & 3.5in
Fan(s) No
Interface USB 3.0
Number of Drives 1
Performance Insertion Rating 15,000 Cycles
Max Drive Capacity Currently tested with up to 4TB 5400 RPM 3.5" hard drives
and 1TB 5400 RPM 2.5" hard drive
Type and Rate USB 2.0 - 480 Mbit/s
USB 3.0 - 5 Gbit/s
SATA II (3 Gbps)
UASP Support No
Connector(s) Drive Connectors 1 - SATA Data & Power Combo (7+15 pin) Receptacle
Host Connectors 1 - USB Type-B (9 pin) USB 3.0 Female
Software OS Compatibility OS independent; No software or drivers required
Indicators LED Indicators 1 - Power and Activity (Solid - Power, Blinking - Activity)
Power Center Tip Polarity Positive
Input Voltage 110V-240V AC
Output Current 2.5A
Output Voltage 12 DC
Plug Type M
Power Consumption (In Watts) 30
Power Source AC Adapter Included
Environmental Humidity 8~80% RH
Operating Temperature 5°C to 80° (41°F to 176°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Physical
Characteristics
Color Black
Enclosure Type Plastic
Product Height 2.6 in [65 mm]
www.startech.com
1 800 265 1844
Product Length 5.7 in [145 mm]
Product Weight 0.9 lb [0.4 kg]
Product Width 3.7 in [93 mm]
Packaging
Information
Shipping (Package) Weight 25.7 oz [728 g]
What's in the Box Included in Package 1 - USB 3.0 HDD Dock
1 - USB 3.0 Cable
1 - Universal Power Adapter (NA,EU,UK,ANZ)
1 - Instruction Manual
Product appearance and specifications are subject to change without notice.
