arTech SATDOCK5U3ER User Manual

USB 3.0 / eSATA 6-Bay Hard Drive Duplicator Dock
- 1:5 HDD / SSD Cloner and Eraser
Product ID: SATDOCK5U3ER
The SATDOCK5U3ER Hard Drive Duplicator & Docking Station lets you clone a 2.5in or 3.5in SATA hard
drive (HDD) or solid-state drive (SSD) to five other SATA drives simultaneously, as a standalone
device. The duplicator also lets you erase up to 5 drives, without a host connection.
You can also use the duplicator as a 5-bay HDD / SSD docking station, by connecting it to a host
computer system through either USB 3.0 or eSATA. With support for high-capacity drives (tested with up
Optimized Productivity
By copying data from one drive to five drives simultaneously, the hard drive cloner helps boost your
productivity by avoiding the hassle of repeatedly swapping drives in and out during high volume
duplication projects.
www.startech.com
1 800 265 1844
Plus, the dock supports erasing up to five drives simultaneously with multiple operating modes,
including Quick Erase as well as Multipass Overwriting (DoD) -- the ideal solution for permanently erasing
confidential information and helping to protect your business and your clients from identity theft.
Hassle-free Performance
With a built-in LCD display, the SATDOCK5U3ER makes it easy to monitor duplication progress and review
copy/erase results and drive diagnostics during standalone operation.
The housing has also been specifically designed with ease-of-use in mind. The drive slots feature a dual-
profile design to support hassle-free swapping between 2.5in and 3.5in hard drives and solid-state drives
without having to use additional brackets or adapters.
Maximum Versatility
With the option to connect the docking station through either eSATA or USB 3.0, the SATDOCK5U3ER
provides a versatile solution for expanding the storage capability of almost any laptop or desktop
computer. For fast performance, you can connect the docking station to your computer through eSATA for
efficient data transfer speeds up to 3 Gbps. For broader system compatibility, you can connect the dock
through USB 3.0, which is also backward compatible with USB 2.0/1.1 host connections.
The SATDOCK5U3ER also provides two charge-only, fast-charge USB ports, that you can use to keep your
iPhone®, iPad®, and Android™ tablets or smartphones charged.
You can also duplicate, erase or access other drive types in duplication and quick-erase applications using
a drive adapter. The following StarTech.com adapters have been tested to ensure compatibility with this
drive duplicator:
2.5/3.5in IDE drives - SAT2IDEADP
mSATA drives - SAT2MSAT25
M.2 (NGFF) drives - SAT32M225
Built for dependable, long-term performance the SATDOCK5U3ER is durably constructed and backed by a
StarTech.com 2-year warranty and free lifetime technical support.
www.startech.com
1 800 265 1844
Certifications, Reports and Compatibility
Applications
Create multiple exact replicas of a source drive onto a new drive for large deployment of identical computer systems
Make exact copies of original hard drives for testing or investigation in law enforcement and forensic applications
Quickly access external hard drives
Clone data for disk recovery
Securely erase multiple drives simultaneously to protect yourself against identity theft
Features
Save time with 1:5 mass drive duplication & 5-drive mass erasing
Hassle-free standalone operation with built-in digital LCD display
Maximize versatility with eSATA & USB 3.0 host connections, charge only USB fast-charge ports, plus docking station, eraser and duplicator in a single device
Sector-by-sector drive duplication at 7 GBs per minute
Erase up to five drives simultaneously with single-pass and multi­pass overwriting / DoD erasing
eSATA and USB 3.0 host interface connections
Supports 2.5in or 3.5in form factor hard drives (HDD) or solid-state drives (SSD)
Supports SATA revision I/II/III (1.5/3.0/6.0 Gbps) drives
Compatible with USB 3.0/2.0/1.1 (5 Gbps / 480 Mbps / 1.5 Mbps)
Built-in dual cooling fans with speed control
www.startech.com
1 800 265 1844
Warranty 2 Years
Hardware Chipset ID SunplusIT - SPIF260A
ASMedia – ASM1453 JMicron – JMB393
Compatible Drive Types SATA
Drive Size 2.5in / 3.5in
Fans 2 - 60 mm
Number of Drives 5
Performance General Specifications 7 GB per minute duplication speed
Max Drive Capacity Currently tested with up to 6TB 7200 RPM
Maximum Data Transfer Rate 5 Gbps
Port Multiplier Yes
Type and Rate USB 3.0 - 5 Gbit/s
SATA II (3 Gbps)
Connector(s) Drive Connectors 6 - SATA Data & Power Combo (7+15 pin) Receptacle
Host Connectors 1 - eSATA (7 pin, Data) Receptacle
1 - USB Type-B (9 pin) USB 3.0 Female
Software OS Compatibility OS independent; No software or drivers required
Indicators LED Indicators 1 - Docking station power
1 - Source Drive Power and Activity
5 - Target Drive Power / Activity
Power Center Tip Polarity Positive
Input Current 2 A
Input Voltage 100 ~ 240 AC
Output Current 5 A
Output Voltage 19V DC
Power Consumption (In Watts) 95
Power Source AC Adapter Included
Environmental Humidity 20%~80% RH
Operating Temperature 5°C to 35°C (41°F to 95°F)
Storage Temperature -20°C to 50°C (-4°F to 122°F)
Physical Characteristics
Product Height 3 in [75 mm]
www.startech.com
1 800 265 1844
Product Length 12.4 in [315 mm]
Product Weight 52.9 oz [1500 g]
Product Width 6 in [151.8 mm]
Packaging Information
Shipping (Package) Weight 88.3 oz [2500 g]
What's in the Box Included in Package 1 - USB 3.0\eSATA 1:5 SATA HDD duplicator dock
1 - USB 3.0 cable
1 - eSATA cable
4 - rubber feet (installed)
1 - universal power adapter (NA, UK, EU, ANZ)
1 - instruction manual
Product appearance and specifications are subject to change without notice.
