USB 3.0 SATA Hard Drive Duplicator & Eraser Dock
- Standalone 2.5/3.5in HDD & SSD Eraser and
Cloner
Product ID: SATDOCK2REU3
The SATDOCK2REU3 USB 3.0 Standalone Duplicator and Eraser Dock lets you connect your 2.5in/3.5in
SATA HDDs or SSDs through SuperSpeed USB 3.0, with the ability to swap drives in and out as needed.
The dock also functions as a standalone drive duplicator and eraser – an efficient and versatile solution for
external drive management.
Featuring standalone Sector by Sector hard drive duplication with built-in LED progress bar, and support
for 2 drive single pass over writing the SATDOCK22EU3 is a user-friendly all-in-one solution for any
application requiring hard drive duplication or erasing.
With support for SATA I/II/III, and large capacity drives (tested up to 4TB) this HDD/SSD docking
station is compatible with virtually any SATA hard drive, and greatly increases the
storage/backup capabilities of your computer.
www.startech.com
1 800 265 1844
Extend the value of this hard drive docking station further with the addition of our SATA to IDE Hard Drive
Adapter (SAT2IDEADP), allowing easy insertion of any 2.5 or 3.5in. IDE hard drive into a SATA hard drive
dock.
The SATDOCK2REU3 is backed by a 2-year StarTech.com warranty and free lifetime technical support.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• System administrators who need quick access to drives for imaging
• Data Archiving
• Technicians who regularly test or benchmark different hard drives
and need to swap between them
• Forensic investigators who require disk sector imaging/cloning to
create an exact replica of a source drive onto a different drive
• Professionals who require identical backups for when data integrity is
crucial, such as data recovery
• Cloning hard drives that contain hidden partitions, that some
software disk cloning programs may skip
• IT administrators that wish to quickly clear/erase a drive in
preparation for use in other applications
• Data recovery specialists who need quick access to drives to
recover/retrieve data
Features
• Supports 2.5in and 3.5in form factor SATA hard drives (HDD) and
solid state drives (SSD)
• Standalone Sector-by-Sector hard drive duplication
• Stand alone single pass overwrite erase
• SuperSpeed USB 3.0 compliant host interface, with up to 5 Gbps of
data bandwidth
• High Speed USB 2.0 compliant host interface, with transfer rates up
to 480Mbps
• Supports SATA revision I/II/III (1.5/3.0/6.0 Gbps) drives
• Plug-and-Play and Hot-Swap compatible
• Universal Power Adapter (NA/UK/EU)
• Built-in LED progress bar
www.startech.com
1 800 265 1844
Warranty 2 Years
Hardware Chipset ID Prolific - PL2775
Compatible Drive Types SATA
Drive Installation Removable
Drive Size 2.5in & 3.5in
Interface USB 3.0
Number of Drives 2
Performance Max Drive Capacity Currently tested with up to 4TB 7200 RPM 3.5" hard drives
and 1TB 7200 RPM 2.5" hard drives
Type and Rate USB 3.0 - 5 Gbit/s
SATA II (3 Gbps)
Connector(s) Drive Connectors 2 - SATA Data & Power Combo (7+15 pin)
Host Connectors 1 - USB Type-B (9 pin) USB 3.0
Software OS Compatibility OS independent; No software or drivers required
Special Notes /
Requirements
Note Destination drive must be the same size or larger than the
source drive
Indicators LED Indicators 1 - HDD1 / 75%
1 - HDD2 / 100%
1 - Link / 25%
1 - Power / 50%
Power Center Tip Polarity Positive
Input Current 1.2A
Input Voltage 110V-240V AC
Output Current 3000mA
Output Voltage 12 DC
Plug Type M
Power Consumption (In Watts) 36
Power Source AC Adapter Included
Environmental Humidity 5-90%
Operating Temperature 0°C to 85°C (32°F to 185°F)
Storage Temperature -10°C to 95°C (14°F to 203°F)
Physical
Characteristics
Product Height 2.4 in [62 mm]
www.startech.com
1 800 265 1844
Product Length 5 in [128 mm]
Product Weight 21.5 oz [610 g]
Product Width 4.1 in [103 mm]
Packaging
Information
Shipping (Package) Weight 25.1 oz [710 g]
What's in the Box Included in Package 1 - HDD Dock
1 - USB 3.0 Cable
1 - Universal power adapter: comes ready for NA/EU/UK
only when you buy in NA/EU/UK; comes ready for Australia
and New Zealand only when you buy in Australia and New
Zealand
1 - User Manual
Product appearance and specifications are subject to change without notice.
