Page 1
USB 3.1 (10 Gbps) Enclosure for 2.5” SATA Drives
Product ID: S251BMU313
Now, access your data in record time with the superior performance of USB 3.1 Gen 2 (10 Gbps). This
single-drive enclosure gives you a powerful external storage solution.
www.startech.com
1 800 265 1844
Page 2
Ultra fast, ultra portable data storage
The enclosure turns your 2.5in SATA solid-state or hard drive into ultra-fast, ultra portable data
storage. Its lightweight, compact design allows it to be tucked easily into a laptop bag or carrying case.
Engineered with a durable and sleek brushed aluminum housing, it’s equipped to keep your data safe and
secure wherever you go.
Harness the speed of USB 3.1 Gen 2
USB 3.1 Gen 2 gives you greater bandwidth and
speed with file transfer rates of up to 10 Gbps -
twice the speed of USB 3.0 (USB 3.1 Gen 1)
technology. It lets you leverage the high
performance of the latest SSDs and hard drives,
while alleviating bottlenecks in your data
transfers.
Powered directly from the USB port
The enclosure connects easily to a host computer through USB 3.1 Gen 2, with no external power
required. It is equipped with a USB A to Micro B cable, providing backward compatibility with existing USB
ports or hardware. It also provides UASP support for enhanced performance.
The S251BMU313 is backed by a StarTech.com 2-year warranty and free lifetime technical support.
www.startech.com
1 800 265 1844
Page 3
Certifications, Reports
and Compatibility
Applications
• Take advantage of new laptops and desktops with ultra-fast USB 3.1
Gen 2 (10 Gbps) connectivity
• Create a fast, portable external storage solution for desktops, laptops
or netbooks with this metal enclosure, providing durable performance
in demanding environments
• Use your SATA SSD/HDDs at maximum speed
• Back up important data to an external storage device
• Share large files between computers quickly and securely without a
network
• Retrieve data from old SATA drive, or turn the unused drive into
additional external storage space
Features
• Create an ultra-fast USB 3.1 Gen 2 (10 Gbps) storage solution for a
single 2.5” SSD or HDD drive
• Supports SATA I, II and III (up to 6 Gbps)
• Compact, portable design in a sleek brushed aluminum enclosure
• UASP support for enhanced performance
• Powered directly from the USB port
• USB A to Micro B cable for easy compatibility
• Backward compatible with USB 3.0, 2.0 and 1.x
www.startech.com
1 800 265 1844
Page 4
Warranty 2 Years
Hardware Bus Type USB 3.1 Gen 2
Chipset ID ASMedia - ASM1351
Compatible Drive Types (Type and
Rate)
SATA
Drive Installation Fixed
Drive Size 2.5in
Fan(s) No
Interface USB 3.1 Gen 2
Number of Drives 1
Performance Max Drive Capacity Currently tested with hard drives up to 2TB at 7200 RPM
Maximum Data Transfer Rate 10 Gbps
Type and Rate USB 3.1 Gen 2 - 10 Gbit/s
SATA III (6 Gbps)
UASP Support Yes
Connector(s) Drive Connectors 1 - SATA Data & Power Combo (7+15 pin) Female
Host Connectors 1 - USB 3.1 USB Type Micro-B (10 pin, Gen 2, 10 Gbps)
Female
Software OS Compatibility OS independent; No software or drivers required
Indicators LED Indicators 1 - Power & Activity
Power Power Source USB-Powered
Environmental Humidity Operation Humidity: 10% ~ 90% RH
Storage Humidity: 5% ~ 95% RH
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -10°C to 65°C (14°F to 149°F)
Physical
Characteristics
Color Black
Enclosure Type Aluminum
Max Drive Height 0.4 in [9.5 mm]
Product Height 0.5 in [12 mm]
Product Length 4.8 in [123 mm]
Product Weight 2.8 oz [80 g]
Product Width 3 in [75 mm]
www.startech.com
1 800 265 1844
Page 5
Packaging
Information
Shipping (Package) Weight 5.8 oz [163 g]
What's in the Box Included in Package 1 - USB 3.1 to SATA enclosure
1 - USB cable
1 - 7mm - 9.5mm SSD spacer
1 - protective case
4 - assembly screws
1 - screwdriver
1 - quick start guide
Product appearance and specifications are subject to change without notice.
