IP67 Certified 2T2R 2.4GHz Outdoor Wireless-N
Access Point - PoE-Powered 300 Mbps
802.11b/g/n WiFi AP
Product ID: R300WN22ODG
The R300WN22ODG Outdoor Wireless Access Point lets you add 2.4GHz Wireless-N network coverage to
an outdoor area, through a ruggedized industrial access point.
This outdoor access point features an IP67 certified, die-cast metal enclosure with heavy-duty cable
grommets so it can withstand the outdoor elements and offers pole and wall-mounting options. Plus, the
PoE-powered AP includes a passive Power-over-Ethernet injector, enabling you to install it in locations
where a typical power outlet is unavailable. PoE pass-through via the secondary LAN port lets you connect
data and power to a PoE-capable device near the access point.
For optimal wireless coverage, the AP broadcasts a signal through a high-powered 800mW internal 10dBi
2T2R antenna, with 802.11b/g/n compatibility to easily connect most wireless devices new or old.
www.startech.com
1 800 265 1844
The device offers support for several different operating modes (AP, WDS and WISP), which help you to
create a wireless network from a wired connection, bridge multiple APs together or extend the range of an
existing wireless network. The AP supports Wireless-N data rates up to 300Mbps with security through
WEP, WPA, or WPA2 authentication, all configurable through an easy-to-use web-based utility.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Create an outdoor Wireless-N access point from an existing wired or
wireless connection to eliminate network dead spots and allow
wireless devices to connect across large open spaces
• Use WDS (Wireless Distribution System) to mesh multiple Access
Points together
• Connect smartphones, tablets or laptops to a Wireless B/G/N access
point
• Use the secondary LAN port to deploy remote PoE-Powered devices
such as switches or IP cameras
Features
• IEEE 802.11b/g/n (Wireless-N) compliant with speeds up to 300
Mbps @ 2.4GHz
• Metal, IP67 certified pole and wall-mountable housing
• PoE-powered access point with included PoE injector and PoE passthrough
• Supports AP, WDS and WISP operating modes
• 800mW internal 10dBi 2T2R antenna
• Supports WEP, WPA and WPA2 security with TKIP/AES encryption
• Integrated MAC address control and QoS support
• Built-in configuration utility (web-based)
• +/-15kV air and +/-8kV contact ESD (Electrostatic Discharge)
Protection
www.startech.com
1 800 265 1844
Warranty 2 Years
Hardware Antenna Configuration 2x2:2 (TxR:S)
Chipset ID Atheros - AR9341
Industry Standards IEEE 802.3, IEEE 802.3u IEEE 802.11b/g/n
IP67 certified
Interface Wireless Ethernet
Performance Bandwidth 20/40 MHz
Frequency Range 2.4 ~ 2.4835 GHz
Full Duplex Support Yes
Max Distance 3.7 km (2.3 mi)
Maximum Data Transfer Rate 300 Mbps
Modulation OFDM, DSSS
Security Features TKIP/AES
WEP Data Encryption
WPA and WPA2-PSK Data Encryption
WPA and WPA2 Enterprise Data Encryption
Supported Protocols CSMA/CA
Connector(s) Connector Type(s) 1 - Wireless N (IEEE 802.11n)
Internal Ports 2 - RJ-45 Female
Special Notes /
Requirements
System and Cable Requirements Available indoor AC electrical outlet
Cat 5 (or better) network cabling from PoE Injector to
Wireless AP and PoE Injector to LAN Switch/router (no more
than 100m total)
Indicators LED Indicators 3 - Wireless Signal Strength
1 - Power
2 - LAN Link / Activity
Power Center Tip Polarity Positive
Input Current 1 A
Input Voltage 100 ~ 240 AC
Output Current 0.5 A
Output Voltage 48 DC
Plug Type N
www.startech.com
1 800 265 1844
Power Consumption (In Watts) 13.5
Power Source AC Adapter Included
Environmental Humidity 100% RH Non-Condensing
Operating Temperature -30°C to 60°C (-22°F to 140°F)
Storage Temperature -30°C to 85°C (-22°F to 185°F)
Physical
Characteristics
Color Gray
Enclosure Type Aluminum and Plastic
Product Height 58 mm [2.3 in]
Product Length 161 mm [6.3 in]
Product Weight 686 g [24.2 oz]
Product Width 100 mm [3.9 in]
Packaging
Information
Shipping (Package) Weight 1248 g [44.1 oz]
What's in the Box Included in Package 1 - Outdoor Wireless Access Point
1 - PoE Injector
1 - Pole Mounting Kit
1 - Power Adapter
1 - Quick Start Guide
Product appearance and specifications are subject to change without notice.
