1 Port PCI Express IDE Controller Adapter Card
Product ID: PEX2IDE
This PCI Express IDE Controller Adapter Card provides a cost-effective way to use legacy drives with
modern computers, by converting a PCI Express port into an IDE port.
Providing data burst transfer rates of up to 133MBps and support for PIO 0/1/2/3/4 and UDMA
33/66/100/133 operating modes, the IDE controller card offers an efficient way to add an IDE channel
with support for two IDE drives on the same channel.
A complete dual profile solution, the PCI Express IDE controller card provides both standard and low
profile brackets for adapting to slimline or small form factor system applications.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Add an additional IDE port to a computer system
• Replace a failed IDE port
• Add an IDE port for connecting legacy ATA devices such as old hard
drives and tape drives
Features
• 2-channel IDE port supports two drives
• 48-bit LBA support
• Supports ATA/ATAPI commands
• Supports UDMA 6 mode which supports transfer rates up to 133
MBps
• Includes a low profile installation bracket
www.startech.com
1 800 265 1844
Warranty Lifetime
Hardware Bus Type PCI Express
Card Type Standard Profile (LP bracket incl.)
Chipset ID JMicron - JMB368
Interface IDE
Ports 1
Performance LBA support 48-bit
Connector(s) Connector Type(s) 1 - PCI Express x1 Male
Internal Ports 1 - IDE (40 Pin, EIDE/PATA) Male
Software OS Compatibility Windows® 2000, XP, Vista, 7, 8, 8.1, 10
Windows Server® 2008 R2, 2012, 2016
Special Notes /
Requirements
System and Cable Requirements Available PCI Express expansion slot
Physical
Characteristics
Product Weight 4.2 oz [120 g]
Packaging
Information
Shipping (Package) Weight 0.4 lb [0.2 kg]
What's in the Box Included in Package 1 - PCI Express IDE Controller Card
1 - IDE Cable
1 - Low Profile Bracket
1 - Instruction Manual
Product appearance and specifications are subject to change without notice.
