Page 1
1,8m Cat5e UTP Netzwerkkabel - Grau
Product ID: M45PATCH3GR
The M45PAT10GR Cat5e Patch Cable (3 ft) meets or exceeds all Cat 5e specifications to ensure reliable Ethernet
network connections, and features a durable gray PVC jacket that enables you to color code your network cable runs
as needed.
To ensure long-lasting performance, this high quality Cat5e patch cable features molded PVC strain relief that
prevents the RJ45 connector termination points from bending at sharp angles - reducing the risk of cable damage,
which could decrease network performance.
Constructed of only top quality materials, this Cat5e Patch Cord delivers reliable performance and is backed by our
Lifetime Warranty. <br />
StarTech.com Cat5e cables are manufactured using high-quality copper conductors. While many cable
manufacturers offer a "cheaper" cable, based on a copper-coated aluminum core, we make no compromises on
quality to ensure you receive top value and performance for your network cable investment. <br /> <br />
This Cat 5e cable is constructed with 24 gauge copper wire, to support a broad range of Ethernet applications such
as Power over Ethernet (PoE). Because we use a high quality copper wire, our cables easily sustain the power
required for Power over Ethernet applications, whereas the inferior quality offered by copper-coated aluminum cables
may be subject to insufficient power delivery, heat buildup, equipment damage and potentially, fire.<br /> <br />
This molded patch cable offers high quality connectors comprised of 50-micron gold, to deliver optimum conductivity
while eliminating signal loss due to oxidation or corrosion.
Certifications, Reports and Compatibility
Page 2
Applications
Hardware
Warranty
Anzahl von Leitern
Typ der
Kabelummantelung
Feuerwiderstandssklasse
Kabeltyp
Verkabelungsstandard
90 Days
4 Pair UTP
PVC - Polyvinyl Chloride
CMG Rated (General Purpose)
Molded
TIA/EIA-568-B.1-2001 T568B
Leistung
Kabelnennwerte
CAT5e - 350 MHz
Steckverbinder
Steckverbinder A
Steckverbinder B
RJ-45
RJ-45
Physische
Eigenschaften
Farbe
Drahtstrke
Leitungstyp
Kabellnge
Produktlnge
Produktgewicht
Gray
24 AWG
Stranded Copper
36.0 in [9.1 cm]
36.0 in [9.1 cm]
1.3 oz [37 g]
Verpackungsin
formationen
Package Length
Package Width
Package Height
Versandgewicht
(Verpackung)
8.7 in [2.2 cm]
7.9 in [2 cm]
0.5 in [13 mm]
1.6 oz [46 g]
• Designed for use with Fast Ethernet networks
• Patches from hub to distribution panel
• Connects workstation to wall outlet
Features
• Molded RJ45 connectors
• Carefully constructed and tested, to keep Near End Crosstalk (NEXT) well within acceptable limits
• Colored hoods for departmental color coding
• Constructed with top quality components
• High quality 24 AWG copper wire
Page 3
Verpackungsin
halt
Im Paket enthalten
3 ft. Cat5e Patch Cable - Gray
*Product appearance and specifications are subject to change without notice.
