7.1 USB Audio Adapter External Sound Card with
SPDIF Digital Audio
Product ID: ICUSBAUDIO7D
This versatile External USB Sound Card/Audio Adapter offers a high quality solution for upgrading desktop
or laptop sound.
Providing a robust USB audio experience, the USB sound card connects to a host computer through a
single USB 2.0 connection, to deliver impressive external audio capability that can instantly be swapped
between systems, without having to open the computer case for installation.
Supporting analog and digital audio for 2 to 7.1 channel audio applications, the external USB sound card
provides a cost-saving upgrade from built-in/on-board sound that turns desktop/laptop sound into a home
theater-ready audio solution.
The external USB sound card features easy-to-use volume control and two external microphone inputs - a
convenient solution for any audio application requiring high quality sound with multi-input capability with
support for 44.1 KHz and 48 KHz sampling rates for analog playback and recording or 48 KHz for SPDIF.
www.startech.com
1 800 265 1844
A more than suitable solution for home theater, gaming or multi-media presentations, the External USB
Sound Card is easy to install with plug and play support in Windows XP and Windows Vista operating
systems.
Designed to deliver a long-lasting and dependable sound solution, the External USB Sound Card/Audio
Adapter is backed by our 2-year warranty and free lifetime technical support.
Note: The audio adapter’s SPDIF optical pass-through port supports two-channel audio, this port does not support 5.1 or 7.1
audio.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Add 7.1 audio support to laptop or small form factor system with no
internal expansion options
• Replace or upgrade the existing integrated audio on a laptop or
portable computer
• Connect your computer to an home theater audio receiver through
optical S/PDIF
Features
• Full 7.1 audio outputs via 3.5mm mini-jacks
• Optical S/PDIF input (pass through) and output
• Dual microphone input
• Built-in volume control buttons
• Full-duplex recording and playback
• Supports 44.1 and 48 KHz sampling rates for analog playback and
recording or 48 KHz for SPDIF
• High Speed USB 2.0 compliant host interface, with transfer rates up
to 480 Mbps
www.startech.com
1 800 265 1844
Warranty 2 Years
Hardware Chipset ID C-Media - CM6206
Performance Audio Specifications 8 16-bit DAC Channels (7.1 Surround Sound)
Supports 44.1 and 48 KHz sampling rates for analog
playback and recording or 48 KHz for SPDIF
3.5mm output connectors for Front, Surround, Rear,
Centre/bass
Connector(s) Connector Type(s) 1 - USB B (4 pin) Female
External Ports 2 - Toslink (SPDIF, Optical) Female
8 - 3.5 mm Mini-Jack (3 Position) Female
Software OS Compatibility Windows® 10 (32/64), 8 / 8.1 (32/64), 7 (32/64), Vista
(32/64), XP (32/64), 2000
Windows Server® 2008 R2, 2003 (32/64)
Special Notes /
Requirements
Note The audio adapter’s SPDIF optical pass-through port
supports two-channel audio, this port does not support 5.1
or 7.1 audio.
Indicators LED Indicators 1 - Microphone Mute
1 - Power/Activity
Environmental Humidity 20 to 80% NC RH
Operating Temperature 0°C to 55°C (32°F to 131°F)
Storage Temperature 0°C to 70°C (32°F to 158°F)
Physical
Characteristics
Color Silver
Product Height 1 in [25 mm]
Product Length 3.9 in [100 mm]
Product Weight 3.5 oz [100 g]
Product Width 2.4 in [60 mm]
Packaging
Information
Shipping (Package) Weight 0.5 lb [0.2 kg]
What's in the Box Included in Package 1 - USB to Audio Adapter
1 - USB Cable
1 - Installation CD
1 - Instruction Manual
Product appearance and specifications are subject to change without notice.
