arTech HSB220SAT25B operation manual
2 Drive 2.5in Trayless Hot Swap SATA
Mobile Rack Backplane
HSB220SAT25B
Rev 1
*actual product may vary from photos
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 05/19/2016
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not
represent an endorsement of a product or service by StarTech.com, or an endorsement of the
product(s) to which this manual applies by the third-party company in question. Regardless
of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby
acknowledges that all trademarks, registered trademarks, service marks, and other protected
names and/or symbols contained in this manual and related documents are the property of
their respective holders.
Instruction Manual
Table of Contents
Introduction ............................................................................................1
Features ........................................................................................................................................................1
Packaging Contents ................................................................................................................................. 1
Installation and Usage...........................................................................2
Hardware Installation .............................................................................................................................. 2
Drive Installation ....................................................................................................................................... 3
Drive Removal ............................................................................................................................................ 5
Specications ..........................................................................................6
Technical Support .................................................................................. 7
Warranty Information ............................................................................7
Instruction Manual
i
Introduction
Thank you for purchasing a StarTech.com 3.5” Dual SATA Hard Drive Hot-Swap Bay the ideal solution for simplifying drive removals and insertions as part of the system
building process. Also a perfect addition for operating system image deployment and
any task that requires being able to quickly access large volumes of data on the y, the
HSB220SAT25B Dual SATA Hard Drive Hot-Swap Bay provides everything you need to
expedite important projects.
Features
• Driverless operation, tool-less hard drive installation
• Supports Hot Swapping
• Supports data transfer rates of up to 6.0 Gbps (SATA III), 3Gbps (SATA II),
and 1.5Gbps (SATA I)
• Swinging, latchable door simplies drive insertion and removal
Packaging Contents
• 1 x dual SATA hot-swap bay
• 2 x LP4 to SATA and LED adapter cable
• 1 x 15-pin SATA power and LED Y cable
• 2 x 7-pin SATA data cable
• 2 x hard drive protector lm
• 1 x screw kit
• 1 x instruction manual
Instruction Manual
1
