arTech HB30C4AIB User Manual

4-Port USB-C Hub - 4x USB-A with Individual On/Off Switches
Product ID: HB30C4AIB
This portable USB-C™ hub gives you an easy way to add four USB 3.0 Type-A ports to your USB-C
equipped laptop, tablet or smartphone, with individual power switches to conserve power. The USB-C to
USB 3.0 hub plugs easily into your laptop’s USB Type-C™ or Thunderbolt™ 3 port. Plus, it’s bus-powered
for easy portability.
Connect Your Current USB Devices
port USB 3.0 hub converts your computer’s USB-C port into four USB 3.0 (Type-A ports), and it’s
backward compatible with your older USB 2.0 devices. (USB 3.0 is also known as USB 3.1 Gen 1.)
www.startech.com
1 800 265 1844
Individual On/Off Switches
Each USB port on the USB Type-C™ hub has its own power switch so you can turn off devices when
they’re not in use. That means you can better manage power consumption for your USB devices, without
having to physically disconnect the device or cable.
Easy Portability
With its compact, lightweight design, this USB hub is designed for portable use. The versatile USB-C to
USB hub is bus-powered, which means it draws its power directly from your computer’s USB-C port, with
no need for an external power adapter. You can travel lighter with fewer cables to carry with you.
Plug and Play
The 4-Port USB-C hub installs automatically once you connect it to your laptop, so you can be up and
running in seconds.
HB30C4AIB is backed by a StarTech.com 2-year warranty and free lifetime technical support.
www.startech.com
1 800 265 1844
Certifications, Reports and Compatibility
Applications
Take the hub with you when you travel, to connect your USB devices
Switch unused ports off when using high power-consuming USB equipment
Perfect for office, hot-desk, home office and bring-your-own-device environments
Features
Add four USB 3.0 (Type-A) ports to your USB-C laptop, tablet or smartphone with this USB-C hub
Save power with On/Off power switches for each USB port
USB bus-powered, with no external powered required
Compact, portable design with attached cable (9.8 in./25 cm)
Save time with plug-and-play installation
www.startech.com
1 800 265 1844
Warranty 2 Years
Hardware Bus Type USB 3.0
Chipset ID VIA/VLI - VL817
Fast-Charge Port(s) No
Industry Standards USB 3.1 Gen 1 (USB 3.0) - Backward compatible with USB
2.0 and 1.1
Interface USB 3.0
Ports 4
USB-C Device Port(s) No
USB-C Host Connection Yes
Performance Maximum Data Transfer Rate 5 Gbps
Type and Rate USB 3.0 - 5 Gbit/s
UASP Support Yes
Connector(s) Connector Type(s) 4 - USB Type-A (9 pin) USB 3.0 Female
1 - USB Type-C (24 pin) USB 3.0 (5Gbps) Male
Software OS Compatibility OS Independent; No additional drivers or software required
Special Notes / Requirements
System and Cable Requirements Available USB Type-C port - USB 3.0 (5Gbps)
The total available power output of the HB30C4AIB is based on the available input power and is shared between all downstream facing ports.
Indicators LED Indicators 4 - Port Power
Power Power Source USB-Powered
Environmental Humidity 20~80% RH (Non-condensing)
Operating Temperature 0°C to 55°C (32°F to 131°F)
Storage Temperature -10°C to 70°C (14°F to 158°F)
Physical Characteristics
Cable Length 9.8 in [250 mm]
Color Black
Enclosure Type Plastic
Form Factor Compact
Product Height 0.8 in [19.2 mm]
Product Length 3.3 in [85 mm]
www.startech.com
1 800 265 1844
Product Weight 1.5 oz [42 g]
Product Width 1.4 in [34.9 mm]
Packaging Information
Shipping (Package) Weight 3.7 oz [106 g]
What's in the Box Included in Package 1 - hub
1 - quick-start guide
Product appearance and specifications are subject to change without notice.
