arTech FPWTLTBAT User Manual

Low-Profile TV Wall Mount - Tilting

Product ID: FPWTLTBAT

Save space while improving the appearance of your work area, with this low-profile TV wall mount. The mount sits
close to the wall to support a VESA Mount compliant TV from 37” to 75”, and offers theft deterrence as well as titling
capability that makes it easy to find the perfect viewing position.

Mount your flat-screen TV or monitor in a location that's convenient for visitors, clients or employees. The wall mount
safely and securely supports your TV about two inches (51 mm) from the wall to provide a sleek, low-profile look.

It’s ideal for lobbies, hallways, boardrooms, works areas, customer-facing areas or for creating digital signage. The
wall mount supports most 37" to 75" (940 to 1905 mm) LED or LCD flat panel TVs weighing up to 88 lb. (40 kg).

This TV wall mount tilts -10 to +5 degrees, so you can adjust the angle of your display with ease to customize your
viewing experience.

Engineered with heavy-duty steel, the robust steel TV wall mount securely supports your flat-screen TV, to protect
your investment. Ideal for areas with high trafficand minimal supervision, the TV mount features a steel bar that can
be locked into place with a padlock (purchased separately) to deter theft of your equipment.

A built-in level helps to ensure your TV is aligned in a straight position on your wall, to ensure optimum viewing.

The FPWTLTBAT is backed by a StarTech.com 5-year warranty and free lifetime technical support.

Certifications, Reports and Compatibility

Applications

• Securely wall-mount a TV

Hardware

Warranty
Cable Management
Articulating
# of Displays Supported
Mounting Options
Minimum Profile from

Wall
VESA Hole Pattern(s)
VESA Hole Pattern(s)
VESA Hole Pattern(s)
VESA Hole Pattern(s)
VESA Hole Pattern(s)
VESA Hole Pattern(s)

2 Years
No
No
1
Wall-Mount

2.0 in [51 mm]
200x200 mm
300x300 mm
400x200 mm
400x400 mm
600x400 mm
800x400 mm

Performance

Weight Capacity (Per
Display)

Minimum Display Size
Maximum Display Size
Fits Curved Display
Video Wall
Anti-theft

88.4 lb [40 kg]
37"
75"
Yes
No
Yes

Physical
Characteristics

Product Length
Product Width
Product Height

39.3 in [10.0 cm]

2.0 in [51.000 mm]

17.3 in [4.4 cm]

• Keep guests informed and entertained

• Ideal for classrooms, lecture halls or customer-facing areas

• Deter theft of your TV or monitor

Features

• Save space with this flat-screen TV wall mount for 37" to 75" TVs (fits curved TVs, with compatible VESA mount)

• Low profile TV mount sits only 2" (51 mm) from the wall

• Heavy-duty steel TV wall mount (tool-less assembly) supports up to 88 lb. (40 kg)

• Tilts -10 to +5 degrees for optimal viewing

• Lockable bar securely holds TV and provides theft deterrence (padlock required)
