arTech FPWMNB User Manual

Triple-Display TV Wall Mount - Menu Board Mount - Landscape

Product ID: FPWMNB

Create a perfectly aligned menu board with this triple-display TV wall mount for 40” to 50” displays. The modular
wall-mounting system is easy to set up. Adjust the tilt for all three displays at the same time, and fine-tune the screen
level with ease.

Digital menu boards are a great way to increase customer sales, promote new offerings, and inform customers at the
point of sale. Ideal for restaurants, retail stores and many other businesses, this professional-grade menu board
mount supports three 40” to 50” VESA mount TVs in landscape position. It supports a weight capacity of 110 lb. (50
kg) per display, and is compatible withVESA 200x200, 300x200, 300x300, 400x200, 400x300, 400x400, and
600x400.

For optimum viewing, you can adjust the tilt of all three displays to the same angle simultaneously, without using
tools. The multi-screen mount has five fixed tilt settings: 0/-5/-10/-15/-20.

To ensure precise alignment of all three TVs, you can fine-tune the level of the displays +3 to -3 using the micro
height adjustment feature.

With its heavy-duty steel construction, the triple-monitor wall bracket provides durable performance.

Save time on setup. The hook-and-mount design of the triple-display wall mount makes installation fast and easy.

FPWMNB is backed by a StarTech.com 5-year warranty and free lifetime technical support.

Certifications, Reports and Compatibility

Applications

• Ideal for digital menu boards in restaurants and retail stores

Hardware

Warranty
Wallmountable
Cable Management
VESA Hole Pattern(s)
VESA Hole Pattern(s)
VESA Hole Pattern(s)
VESA Hole Pattern(s)
VESA Hole Pattern(s)
VESA Hole Pattern(s)
VESA Hole Pattern(s)

2 Years
Yes
No
200x200 mm
300x300 mm
400x200 mm
400x300 mm
600x400 mm
300x200 mm
400x400 mm

Performance

General Specifications
Weight Capacity (Per

Display)
Minimum Display Size
Maximum Display Size
Fits Curved Display
Video Wall
Display Tilt
Anti-theft

Screen Level Adjustment: +3 to -3

110.5 lb [50 kg]
40"
50"
No
No
0 / -5 / -10 / -15 / -20
No

Physical
Characteristics

Color
Material
Product Length

Black
Steel

9.5 ft [2.9 m]

• Create digital signage in customer-facing areas in business lobbies, airports and hospitality centers

• Communicate with visitors in schools, health care centers and other institutional settings

Features

• Create a digital menu board, mounting three 40” to 50” TVs in landscape position

• Tilt all displays to the same angle easily, with five fixed-tilt settings: 0/-5/-10/-15/-20

• Align your displays with micro height adjustment, fine-tuning the screen level +3 to -3

• 3.0” (76 mm) profile to wall, and fast and easy installation

• Steel mount supports VESA 200x200, 300x200, 300x300, 400x200, 400x300, 400x400, 600x400, and up to 110 lb.
(50 kg) weight per display
