Ceiling TV Mount - 3.5' to 5' Pole
Hardware
Warranty
2 Years
Product ID: FLATPNLCEIL
This ceiling TV mount supports VESA mount compatible TVs from 32" to 75" in size, with a weight capacity of up to
110 lb. (50 kg). It lets you save wall and floor space by hanging your flat-panel LCD, LED or plasma TV from the
ceiling in a prominent area.
The ceiling mount is ideal for use in corporate boardrooms, lobbies, entrances, restaurants, bars and meeting places.
With a telescopic pole, the TV mount lets you suspend a display at your desired distance from the ceiling. This works
well with a range of ceiling heights. The steel pole can extend from 42" to 61" (1060 to 1560 mm) , with a total lift
(height extension) of 19.7" (500 mm).
The flat-screen ceiling mount accommodates a wide variety of ceiling types. You can swivel the TV to work with
virtually any type of ceiling for level viewing, including sloped ceilings (up to 60 degrees), and pitched or horizontal
(flat) ceilings.
You can adjust your TV to create a comfortable viewing angle, by tilting it up to -25 degrees down towards your
audience for optimum visibility. Plus, the full-motion mount lets you swivel your display around the pole + 180 / - 180
degrees, without using tools.
Simply attach the included vertical brackets, with built-in hooks, to the back of your TV. Once attached, hang your TV
securely onto the ceiling mount. The +/-3 degree post-installation leveling adjustments ensure ideal positioning after
hanging.
FLATPNLCEIL is backed by a StarTech.com 5-year warranty and free lifetime technical support.
Certifications, Reports and Compatibility
Applications
• Suspend a flat-screen TV from the ceiling for easy viewing
• Ideal for boardrooms, lobbies, entrances, meeting spaces, classrooms
• Keep your guests informed and entertained
Features
• Save space by suspending your 32 to 75" flat-screen TV from the ceiling
• Min-max pole length extension of 42" to 61" (1060 to 1560 mm)
• Durable steel mount supports TVs up to 110 lb. (50 kg)
• Ceiling TV mount swivels +60 /-60 degrees to adjust to sloped or level ceilings
• Full-motion mount lets you swivel the display +180 /-180 degrees around the pole and tilt downwards -25 degrees,
without using tools
• Easy setup, with a hook-and-mount design
Wallmountable
Cable Management
# of Displays Supported
Mounting Options
VESA Hole Pattern(s)
VESA Hole Pattern(s)
VESA Hole Pattern(s)
VESA Hole Pattern(s)
VESA Hole Pattern(s)
No
Yes
1
Ceiling Mount
200x200 mm
300x300 mm
400x200 mm
400x400 mm
600x400 mm
Performance
General Specifications
Weight Capacity (Per
Display)
Minimum Display Size
Maximum Display Size
Fits Curved Display
Video Wall
Height Adjustment
Minimum Height
Maximum Height
Display Tilt
Swivel / Pivot
Display Rotation
Anti-theft
Post-Installation Leveling Adjustment: +/-3
110.5 lb [50 kg]
32"
75"
Yes
No
Yes
3.5 ft [1.1 m]
5.1 ft [1.6 m]
+0 / -25
+180 to -180
360
No
Physical
Characteristics
Color
Product Length
Product Width
Product Height
Weight of Product
Black
26.8 in [6.8 cm]
5.5 in [1.4 cm]
5.8 ft [1.8 m]
13.2 lb [6.0 kg]
Packaging
Information
Package Length
Package Width
37.1 in [9.4 cm]
12.3 in [3.1 cm]
