65x60x45mm Socket 7/370 CPU Cooler Fan w/
Heatsink & TX3 connector
Product ID: FAN370PRO
Measuring 65x60x45mm, this Socket 7/370 CPU Cooler/Fan is a combination heatsink and fan designed to
cool high performance CPUs.
The Socket 7/370 CPU Cooler offers an extra-large heatsink combined with a quiet running 6x2 cm
brushless ball bearing DC motor. The fan features a high-efficiency blade design capable of moving 21.46
CFM, providing enough cooling capacity for Pentium III and Celeron CPUs up to 1.4 GHz.
The Socket 7/370 CPU Cooler is powered through a TX3 (3-pin) connection to the computer power supply,
and is a suitable cooling solution for Intel Pentium III and Celeron CPUs up to 1.4 GHz and AMD K6
processors at any speed.
Please note: to power the Socket 7/370 CPU cooler using an LP4 (4-pin) connection to the power supply,
please see our TX3 to 2x LP4 Power Y Splitter Cable (CPUFANADAPT).
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Replace a noisy/failing Socket 370/7/A CPU cooler
• Compatible with Socket 370/7 Intel Pentium III and Celeron CPUs up
to 1.4 GHz and AMD K6 processors
• Compatible with Socket A AMD Duron processors up to 1.2 GHz
Features
• 60mm ball bearing cooling fan
• Aluminum heatsink construction
• Standard 3-pin Molex fan connector
www.startech.com
1 800 265 1844
Warranty 2 Years
Hardware Fan Bearing Type Ball Bearing
Fan Dimensions (Number /
Dimensions)
58 x 58 x 20mm (2.3 x 2.3 x 0.7in)
Fans 1 - 58 mm
Heatsink Dimensions 58 x 63 x 20mm (2.3 x 2.5 x 0.78in)
Heatsink Type Aluminum
Performance Air Flow Rate 20.2 CFM
Fan RPM 4000
Noise Level 31 dBA
Connector(s) Connector Type(s) 1 - Molex Fan (3 pin, TX3) Female
Power Input Voltage 12 DC
Physical
Characteristics
Color Black
Enclosure Type Aluminum and Plastic
Product Weight 4.8 oz [136 g]
Packaging
Information
Shipping (Package) Weight 0.4 lb [0.2 kg]
What's in the Box Included in Package 1 - Socket 7/370 CPU Cooler
1 - Packet of Thermal Compound
Product appearance and specifications are subject to change without notice.
