1U 60x10mm Socket 7/370 CPU Cooler Fan w/
Copper Heatsink & TX3
Product ID: FAN3701U
This 60x10mm Socket 7/370 CPU Cooler helps keep your 1U servers running smoothly, by providing a
reliable, cost-effective server cooling solution.
The server CPU cooler features a copper base and socket-type CPU fan, ensuring rapid heat dissipation in
the reduced space of a 1U server environment.
The CPU cooler is powered through a simple TX3 connection to the server power supply, and is suitable
for all Intel Celeron/PIII processors and AMD Athlon/Duron processors up to 1GHz.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Slim design CPU fan and heatsink cooler for 1U servers
• Suitable for all Intel Celeron/PIII processors and AMD Athlon/Duron
processors up to 1GHz.
www.startech.com
1 800 265 1844
Warranty 2 Years
Hardware Gebläse 1 - 60 mm
Lüfterlagertyp Kugellager
Lüftermaße 60 x 60 x 10mm (2.36 x 2.36 x 0.39in)
Wärmeableitungsmaße 64 x 63 x 10mm (2.52 x 2.48 x 0.39in)
Wärmeableitungstyp Kupfer
Leistung Geräuschpegel 31 dBA
Lüfterdrehzahl 5000
Luftzirkulationsrate 13.48 CFM
Steckverbinder Steckverbindertyp(en) 1 - Molex-Lüfter (3-polig, TX3) Buchse
Strom Eingangsspannung 12 DC
Physische Eigenschaften Farbe Schwarz
Gehäusetyp Kunststoff
Produktgewicht 7 oz [199 g]
Verpackungsinformationen Versandgewicht (Verpackung) 0.5 lb [0.2 kg]
Verpackungsinhalt Im Paket enthalten 1 - 6cm Copper CPU Fan for 1U Servers
1 - Packet of Thermal Compound
Product appearance and specifications are subject to change without notice.
