arTech ARMBARDUOG User Manual

Desk-mount Dual-Monitor Arm - Cross Bar - Grommet/Desk Clamp Mount
Product ID: ARMBARDUOG
Thisdeskmount dual-monitor arm lets youmount two 13” to 27” VESA mount monitors, each weighing up to 17.6 lb. (8 kg),onto a single low-profile base. It gives you flexible desk-clamp or grommet-hole mounting, letting you save space while creating an ergonomic workspace in anyoffice environment.
With a stable dual-arm design, the double-monitor mountlets you create more usable work space by mounting your monitors side by side on a single base. The screen mount features a flat low-profileback thatlets you position your displaysagainst a wall or cubicle wall.
<br />The dual-monitor arm is easy to install, with the desk-clamp or grommet mount (hardware included). Integrated cable management keeps your workspace organized. It works well with most desks, including sit-stand workstations.
<br />Adding two monitors gives you the extra screen space you need to simplify multitasking and maximize your productivity.
ARMBARDUOG is backed by a 5-yearStarTech.com warranty and free lifetime technical support.
Certifications, Reports and Compatibility
Applications
• Mount two monitors on a single base to save desk space
• Maximize office space, creating a dual-monitor workstation against a wall or cubicle wall
Hardware
Warranty Wallmountable Cable Management Articulating # of Displays Supported Mounting Options VESA Hole Pattern(s) VESA Hole Pattern(s) Mounting Surface
Thickness
2 Years No Yes No 2 Desk & Grommet Clamp 75x75 mm 100x100 mm Desk Clamp: Table Thickness 0.39 - 3.14 in. (10 - 80 mm) Grommet Clamp: Table Thickness 0.39 - 3.14 in. (10 - 80 mm) Grommet Mount Hole Size: 0.41 - 1.96 in. (10.5 - 50 mm)
Performance
General Specifications General Specifications Weight Capacity (Per
Display) Minimum Display Size Maximum Display Size Height Adjustment Maximum Height Display Tilt Swivel / Pivot Display Rotation
Pole Height: 14.2" (360 mm) Dual-Arm Span: 32.87" (835 mm)
17.7 lb [8 kg] 13" 27in Yes
14.3 in [3.6 cm] + 30 / - 30 +30/ -30 360
Physical Characteristics
Color
Black
• Works with sit-stand workstations, using the desk clamp or grommet mount
Features
• Save space by mounting two monitors up to 27” onto a single base (max. weight 17.6 lb. / 8 kg)
• Landscape-to-portrait display rotation (for use in portrait position, the mount supports ultrawide displays with max width of 23"/58.4 cm)
• Work comfortably with adjustable height, +/- 30tilt, +/- 30swivel and 360 rotation
• Versatile use with desk-clamp or grommet-hole mounting
• Place monitors close to a wall/cubicle wall, with a low-profile design
Material Product Length Product Width Product Height Weight of Product
Steel, Aluminum and Plastic
34.3 in [8.7 cm]
5.3 in [1.4 cm]
20.3 in [5.2 cm]
10.8 lb [4.9 kg]
Packaging Information
Package Length Package Width Package Height Shipping (Package)
Weight
18.8 in [4.8 cm]
9.8 in [2.5 cm]
4.7 in [1.2 cm]
12.5 lb [5.6 kg]
What's in the Box
Included in Package Included in Package Included in Package Included in Package Included in Package Included in Package Included in Package Included in Package Included in Package Included in Package Included in Package Included in Package Included in Package Included in Package Included in Package Included in Package Included in Package
Column VESA Adapters Cable-Management Clips (Column) Monitor Arms End Caps Cable-Management Clips (Monitor Arm) End-Cap Screws Desk-Mount Clamp Hex Key Hex Key Screwdriver M4x14 Screws M5x14 Screws Flat Washers Grommet-Mounting Adapter Rubber Pads Instruction Manual Grommet-Mount Plate
*Product appearance and specifications are subject to change without notice.
