Page 1
Dual mSATA SSD to 2.5” SATA RAID Adapter
Converter
Product ID: 25SAT22MSAT
Vastly increase system performance by adding a dual mSATA SSD RAID array into any 2.5" SATA HDD
application with the 25SAT22MSAT mSATA to SATA adapter.
Utilize the full potential of your SATA III controller, with mSATA SSDs reducing your data transfer
bottleneck with file transfer speeds up to 6 Gbps. mSATA SSDs also save you money by reducing your
power consumption over regular platter drives.
You can achieve greater SSD capacity, or data redundancy with the Dual SSD controller supporting
multiple RAID modes (RAID 0, 1, BIG). The SSD adapter also supports non-RAID operation (JBOD) when
paired with a port-multiplying SATA controller, so both drives can be used independent of one another.
Help protect the health of your drive with an open-frame design ensuring maximum heat dissipation.
The 25SAT22MSAT is backed by a StarTech.com 2-year warranty, and lifetime technical support.
www.startech.com
1 800 265 1844
Page 2
Certifications, Reports
and Compatibility
Applications
• Add data redundancy to your SSD system, by adding an additional
SSD in a RAID array (RAID1)
• Increase the capacity of your SSD system by adding an additional
SSD in a RAID array (RAID 0/BIG)
• Turn two unused mSATA SSD drives into a hardware RAID 2.5in
SATA solid state drive
Features
• Dual full size mSATA SSD bays
• Supports RAID0, RAID1, JBOD, BIG
• Open-frame steel mounting bracket
• 2.5in SATA form factor housing
• Compatible with SATA revision I/II/III (1.5/3.0/6.0 Gbps) drives and
controllers
www.startech.com
1 800 265 1844
Page 3
Warranty 2 Years
Hardware Chipset ID JMicron JMS562
Compatible Drive Types mSATA (Mini SATA)
Drive Installation Fixed
Drive Size mSATA (Full Size & Half Size)
Interface SATA
Number of Drives 2
Performance Hot Swap Capability No
Maximum Data Transfer Rate 6 Gbps
MTBF 5,101,299 Hours
Port Multiplier Yes
RAID Yes
Supported RAID Modes BIG (Spanning or Concatenation)
JBOD - (Just a Bunch of Disks)
RAID 0 (Striped Disks)
RAID 1 (Mirrored Disks)
Type and Rate SATA III (6 Gbps)
Connector(s) Drive Connectors 2 - mSATA (52 pin, Mini SATA) Receptacle
Host Connectors 1 - SATA Data & Power Combo (7+15 pin) Receptacle
Software OS Compatibility OS independent; No software or drivers required
Indicators LED Indicators 1 - Drive #1 Activity
1 - Drive #1 Failure
1 - Drive #2 Activity
1 - Drive #2 Failure
Environmental Operating Temperature -40°C to 85°C (-40°F to 185°F)
Physical
Characteristics
Enclosure Type Steel, Aluminum and Plastic
Product Height 0.3 in [7 mm]
Product Length 3.8 in [97 mm]
Product Weight 1.4 oz [39 g]
Product Width 2.8 in [70 mm]
www.startech.com
1 800 265 1844
Page 4
Packaging
Information
Shipping (Package) Weight 3.8 oz [108 g]
What's in the Box Included in Package 1 - Dual mSATA to 2.5in SATA Adapter
1 - Mounting screw kit
1 - Install Guide
Product appearance and specifications are subject to change without notice.
