For over 70 years, Arrowhead Brass
BUY
has manufactured the Highest Quality
American Made Products available anywhere
in the world. We take pride in using only
top quality materials utilizing red brass,
RROW-BREAKER™
NEW
No-kink Hose Bibb with Built-In Vacuum Breaker
(Thread-On Vacuum Breaker NOT required)
A
NEW
Quality Rough Brass Products
(New O-Ring Bonnet Seal)
stainless steel handles & seat washer screws,
and state-of-the-art seals. Also featured in
this catalog we have added high-quality
Champion brass products
Arrowhead line-up.
to the
Look inside!
NEW
All Brass Pressure Reducing Valves
NEW
Frost Free Hydrants
Now Available with ARROW-BREAKER™
& Rubberized Coated Handles
Now, Better Than Ever!
Reliable – Proven – Trusted – Since 1936
Arrowhead Brass Products is a subsidiary of Champion-Arrowhead, LLC
BRASS PRODUCTS, LLC
®
NEW PRODUCTS
NEW
NEW
NEW
MORE INNOVATION FROM THE COMPANY YOU TRUST
Arrowhead Brass Products continues its reputation as a company that
introduces new products focused on productivity and reduction of the
“Total Cost of Each Job” like the NEW Arrow-Breaker.™
261
262CC
264CC
BETTER PRODUCTS
O-Ring Bonnet
An exciting improvement has replaced packing nut products with our
n
ew-style one-piece “O-Ring” bonnet seal significantly improving the
reliability and operation of these products. No more over-tightening
to stop leaks!
AN ARROWHEAD EXCLUSIVE:
Now many of our Frost Free Hydrants are available
w
ith the SHARKBITE
®
P
ush-Fittings™ option
pre-installed making it the fastest, easiest way to connect our hydrants
to copper, CTS, CPVC and PEX pipe with no soldering, clamps
unions or glue.* Available in 1/2” and 3/4” connection sizes.
ARROW-BREAKER™ HOSE BIBB WITH INTEGRATED (BUILT-IN)
VACUUM BREAKER:
• Thread-on vacuum breaker not required.
• Guards against destructive water hammer.
e Flow than a standard Hose Bibb.
• Mor
• No annoying noise when operating or connected to a hose.
• Made in USA.
SEE PRODUCTS FROM OUR CHAMPION BRASS DIVISION:
• Manual Straight and Angle Valves.
• Manual and Automatic (Electric) Anti-Siphon Valves.
• Replacement Actuators for Automatic Anti-Siphon Valves.
• Actuators to convert Manual Valves to Automatic Operation.
• In-Line Automatic (Electric) Globe Valves.
• Brass Vacuum Breakers, Coupler Valves & Accessories.
• Hose & Pipe Adapters and Brass Slip Joints.
501
510
520
PRESSURE REDUCING VALVES
Arrowhead Brass pressure reducing valve reduces excessive
incoming water pressure to appropriate, safe levels. ASSE-1003,
CSA-B356, ANSI/NSF 61-8.
501 Single Union 1/2”
502 Single Union 3/4”
503 Single Union 1”
510 Single Union Compact with Tap 1/2”
511 Single Union Compact with Tap 3/4”
512
520 Double Union Compact with Tap 1/2”
521 Double Union Compact with Tap 3/4”
522
2
Single Union Compact with T
Double Union Compact with T
ap 1”
ap 1”
*SHARKBIT
®
E
is a r
2
63
O-Ring Bonnet
ARROW-BREAKER
row-Breaker No-Kink Hose Bibbs feature an integral (built-in)
Ar
vacuum breaker. Listed with the City of Los Angeles, IAPMO
and ASSE-1011 listed. At an additional charge, specify LK for
Loose Key Lockshield.
261
No-Kink 1/2” MIP x 3/4” Hose Thread
ARROW-BREAKER
361 No-Kink 3/4” MIP x 3/4” Hose Thread
ARROW-BREAKER
262CC No-Kink 1/2” or 3/4” Copper Sweat x 3/4”
Hose Thread ARROW-BREAKER
264CC No-Kink 1/2” Copper Compression x 3/4”
Hose Thread ARROW-BREAKER
263 No-Kink 1/2” FIP x 3/4” Hose Thread
ARROW-BREAKER
363 No-Kink 3/4” FIP x 3/4” Hose Thread
ARROW-BREAKER
265 Sillcock 1/2” FIP x 3/4” Hose Thread
ARROW-BREAKER
365 Sillcock 3/4” FIP x 3/4” Hose Thread
ARROW-BREAKER
265SW Sillcock 1/2” Copper Sweat x 3/4” Hose
Thread ARROW-BREAKER
365SW Sillcock 3/4” Copper Sweat x 3/4” Hose
Thread ARROW-BREAKER
269 Sillcock PEX Connection x 3/4” Hose
Thread ARROW-BREAKER
MORE NEW PRODUCTS...
SRH & SYH Series Frost Free Sanitary Roof &
Yard Hydrants.
• Does not require a drain.
f- contained.
Sel
•
t contaminate water supply
on’
W
•
see page 11 for details.
ed trademark of Cash Acme.
egister
265
269
265SW
™
,
NEW
BRASS PRODUCTS, LLC
®
NEW
O-Ring Bonnet
NEW
ARROW-BREAKER™FROST FREE
Arrow-Breaker Frost Free Valves feature an integral (built-in)
vacuum breaker. Listed with the City of Los Angeles, IAPMO and
ASSE-1019 listed.
4
65-04 1/2” FIP or 3/4” MIP ARROW-BREAKER
465-06 1/2” FIP or 3/4” MIP ARROW-BREAKER
465-08 1/2” FIP or 3/4” MIP ARROW-BREAKER
465-10 1/2” FIP or 3/4” MIP ARROW-BREAKER
465-12 1/2” FIP or 3/4” MIP ARROW-BREAKER
465-14 1/2” FIP or 3/4” MIP ARROW-BREAKER
466-04 1/2” Copper Sweat or 1/2”
466-06 1/2” Copper Sweat or 1/2”
466-08 1/2” Copper Sweat or 1/2”
466-10 1/2” Copper Sweat or 1/2”
466-12 1/2” Copper Sweat or 1/2”
466-14 1/2” Copper Sweat or 1/2”
469-04 PEX ARROW-BREAKER Anti-Siphon Frost Free
469-06 PEX ARROW-BREAKER Anti-Siphon Frost Free
469-08 PEX ARROW
469-10 PEX ARROW-BREAKER Anti-Siphon Frost Free
469-12 PEX ARROW-BREAKER Anti-Siphon Frost Free
469-14 PEX ARROW-BREAKER Anti-Siphon Frost Free
463-04
463-06
463-08 3/4” Shark Bite ARROW-BREAKER Anti-Siphon Frost
463-10 3/4” Shark Bite ARROW-BREAKER Anti-Siphon Frost
463-12 3/4” Shark Bite ARROW-BREAKER Anti-Siphon Frost
463-14
464-04 1/2” Shark Bite ARROW-BREAKER Anti-Siphon Frost
464-06 1/2” Shark Bite ARROW-BREAKER Anti-Siphon Frost
464-08
A
nti-Siphon Frost Free Hydrant x 4”
Anti-Siphon Frost Free Hydrant x 6”
Anti-Siphon Frost Free Hydrant x 8”
Anti-Siphon Frost Free Hydrant x 10”
Anti-Siphon Frost Free Hydrant x 12”
Anti-Siphon Frost Free Hydrant x 14”
Anti-Siphon Frost Free Hydrant x 4”
Anti-Siphon Fr
Anti-Siphon Frost Free Hydrant x 8”
Anti-Siphon Frost Free Hydrant x 10”
Anti-Siphon Frost Free Hydrant x 12”
Anti-Siphon Frost Free Hydrant x 14”
Hydrant x 4”
Hydrant x 6”
Hydrant x 8”
Hydrant x 10”
Hydrant x 12”
Hydrant x 14”
3/4” Shark Bite ARROW
ee Hydrant x 4”
Fr
3/4” Shark Bite ARROW
Free Hydrant x 6”
Free Hydrant x 8”
Free Hydrant x 10”
Free Hydrant x 12”
3/4” Shark Bite ARROW
ee Hydrant x 14”
Fr
ee Hydrant x 4”
Fr
ee Hydrant x 6”
Fr
1/2” Shark Bite ARROW
Free Hydrant x 8”
460 SERIES
MIP ARROW-BREAKER
MIP ARROW-BREAKER
ost Free Hydrant x 6”
MIP ARROW-BREAKER
MIP ARROW-BREAKER
MIP ARROW-BREAKER
MIP ARROW-BREAKER
-BREAKER Anti-Siphon Frost Free
-BREAKER Anti-Siphon Frost
-BREAKER Anti-Siphon Fr
-BREAKER Anti-Siphon Frost
-BREAKER Anti-Siphon Fr
ost
ost
464-10 1/2” Shark Bite ARROW-BREAKER Anti-Siphon
Frost Free Hydrant x 10”
464-12 1/2” Shark Bite ARROW-BREAKER Anti-Siphon
Frost Free Hydrant x 12”
464-14 1/2” Shark Bite ARROW-BREAKER Anti-Siphon
Frost Free Hydrant x 14”
301BV
302BV
2
53BV
353BV
251BV
351BV
255BV
355BV
2
52CCBV
BALL VALVES
Arrowhead has ADA (American Disabilities Act) Ball Valve Hose
Bibbs with coated handles and bi-directional operation.
251BV No-Kink Hose Bibb Ball Valve 1/2” MIP
351BV No-Kink Hose Bibb Ball Valve 3/4” MIP
253BV No-Kink Hose Bibb Ball Valve 1/2” FIP
353BV No-Kink Hose Bibb Ball Valve 3/4” FIP
252CCBV
No-Kink Hose Bibb Ball Valve 1/2” Copper Sweat
255BV Sillcock Ball Valve 1/2” FIP
355BV Sillcock Ball Valve 3/4” FIP
301BV Standard Hose Bibb Ball Valve 1/2” MIP
302BV Standard Hose Bibb Ball Valve 3/4” MIP
251LK
351LK
253LK
353LK
O-Ring Bonnet
NO-KINK HOSE BIBBS (LOOSE KEY)
y installed Loose K
actor
F
251LK 1/2” MIP x 3/4” Hose Thread, Loose Key
351LK
3/4” MIP x 3/4” Hose Thr
253LK 1/2” FIP x 3/4” Hose Thread, Loose Key
353LK 3/4” FIP x 3/4” Hose Thread, Loose Key
ABBREVIA
– Bulk
of
ed P
ed no pac
k
ac
DEFINITION
B – Boxed
BC – Bar Coded
BFP – Vacuum Breaker
ULK
B
CC – Copper Connection
CHR – Chrome
K – Kit
LK – Loose Key
LLB – Log Lighter Bar
LS – Less Key
OH – Oval Handle
ey Lockshield. Key Optional.
TIONS
kaging
after model n
umber
PB – Polished Brass
PE – Plain End
RB – Rough Brass Finish
SAT– Satin
SC – Self-Closing
SD – Self-Dr
SW – Sweat Connection
TH – Tee Handle
V – Vertical
Wheel Handle
WH –
ead, Loose Key
s
aining
3
2
NEW
NEW
NEW
BRASS PRODUCTS, LLC
®
53
353
251
351
2
52CC
O-Ring Bonnet
NO-KINK HOSE BIBBS
Arrowhead Hose Bibbs feature heavy pattern rough brass,
o-ring seal bonnet and coated tee handles.
251 1/2” MIP x 3/4” Hose Thread
351 3/4” MIP x 3/4” Hose Thread
253 1/2” FIP x 3/4” Hose Thread
353 3/4” FIP x 3/4” Hose Thread
252CC 1/2” or 3/4” Copper Sweat x 3/4”
254CC 1/2” Copper Compression x 3/4”
Hose Thread
Hose Thread
251BFP
351BFP
253BFP
2
01
202
301
302
O-Ring Bonnet
STANDARD HOSE BIBBS
Arrowhead Hose Bibbs feature heavy pattern rough brass, o-ring
s
eal bonnet and coated tee handles.
201 1/2” MIP x 3/4” Hose Thread S.O.T.
2
02 3/4” MIP x 3/4” Hose Thread S.O.T.
301 1/2” MIP x 3/4” Hose Thread S.S.S.
302 3/4” MIP x 3/4” Hose Thread S.S.S.
301SC
302SC
STANDARD HOSE BIBBS (SELF CLOSING)
Ideal for public water access applications.
301SC 1/2” MIP x 3/4” Hose Thread S.S.S.,
Self-Closing
302SC 3/4” MIP x 3/4” Hose Thr
Self-Closing
ead S.S.S.,
O-Ring Bonnet
NO-KINK HOSE BIBBS (ANTI-SIPHON)
IAPMO & ASSE 1011 listed.
251BFP 1/2” MIP x 3/4” Hose Thread, VB
351BFP 3/4” MIP x 3/4” Hose Thread, VB
253BFP
353BFP 3/4” FIP x 3/4” Hose Thread, VB
252CCBFP 1/2” or 3/4” Copper Sweat x 3/4” Hose
254CCBFP 1/2” Copper Compression x 3/4” Hose
DEFINITION of ABBREVIATIONS after model numbers
ed
x
B – Bo
BC – Bar Coded
BFP – Vacuum Breaker
BULK – Bulked Packed no packaging
CC – Copper Connection
CHR – Chrome
K – Kit
LK – Loose Key
LLB – Log Lighter Bar
LS – Less K
OH – Oval Handle
4
y
e
254CCBFP
1/2” FIP x 3/4” Hose Thr
Thread, VB
Thread, VB
olished Br
PB – P
PE – Plain End
RB – Rough Brass Finish
SAT – Satin
SC – Self-Closing
SD – Self-Draining
eat Connection
SW – Sw
TH – Tee Handle
tical
er
V
V –
WH – Wheel Handle
ead, VB
ass
252CCBFP
700CC
725CC
702CC
727CC
COPPER COMPRESSION STOP VALVES
700CC 1/2”
725CC 3/4”
702CC
727CC
802
827
1/2” Stop & Waste
3/4” Stop & W
800
825
aste
802SW
827SW
STRAIGHT STOP VALVES
800 1/2” FIP Straight Stop
825 3/4” FIP Straight Stop
800SW 1/2” Copper Sweat Straight Stop
825SW
802 1/2” FIP Straight Stop and Waste
827 3/4” FIP Straight Stop and Waste
802SW
827SW 3/4” Copper Sweat Straight Stop and Waste
3/4” Copper Sweat Straight Stop
1/2” Copper Sweat Straight Stop & Waste
800SW
825SW
BRASS PRODUCTS, LLC
®
221CC
NEW
NEW
NEW
NEW
-Ring Bonnet
O
249
247
2
50
2
48
SATIN WASHING MACHINE VALVES
221CC 1/2” Copper Compression x 3/4” Hose
247 1/2” FIP x 3/4” Hose, Front Handle
248 1/2” FIP x 1/2” MIP with Rev. Bypass with
249 1/2” FIP x 3/4” Hose, Top Handle
250 1/2” FIP x 1/2” MIP with 3/4” Hose on bottom
Thread, Satin
3/4” Hose Thread
258
EVAPORATIVE COOLER FAUCETS
240 3/4” FIP Inlet x 3/4” Hose
2
45 3/4” Hose Inlet x 3/4” Hose
255
355
O-Ring Bonnet
with 1/8” Tap
with 1/8” Tap
SOLID FLANGE SILL FAUCETS
OPTIONS: At an additional charge, specify SAT for Satin or
or Chrome after part number.
CHR f
255 1/2”
355 3/4”
255SW 1/2” or 3/4” Copper Sweat x 3/4” Hose
FIP x 3/4” Hose Thread with Oval Handle
FIP x 3/4” Hose Thread with Oval Handle
Thread with Oval Handle
240
245
255SW
259
GAS LOG LIGHTER VALVES
All Arrowhead Log Lighter Valves come with Adjustable Chrome
Plated Flange, 2-1/4" Loose Key, with Rough Brass Body. CSA listed
in the U.S. and Canada. IAPMO listed.
258 Log Lighter Valve 1/2” FIP Straight Valve with
259 Log Lighter Valve 1/2” FIP Angle Valve with
258LLB Log Lighter Bar
44PB
51PB Part (Polished Brass Log Lighter Key)
HEARTHLIGHT LOG LIGHTER KITS
The Arrowhead HearthLIGHT log lighter kits come with our Log
Lighter
Key, and our 12" Heavy Duty Cast Iron Log Lighter Bar with ledged
design to elimina
has thr
CSA listed in the U
258K
259K
Chrome Flange & Key
Chrome Flange & Key
t (Polished Brass Flange)
Par
le Chrome Plated Flange, 2-1/4" Loose
b
Adjusta
e with
alv
V
alling ashes fr
te f
ee 1/2" I.P
.S. inlets to fit most applications. For natural gas only.
.S. and Canada. IAPMO listed.
.I.P. Straight Pattern Valve with Trim
1/2” F
and Log Lighter Bar
1/2” F.I.P. Angle Pattern Valve with Trim and
Log Lighter Bar
om blocking the orifices. Each bar
258LLB
258K
255LK
355LK
O-Ring Bonnet
SOLID FLANGE SILL FAUCETS (LOOSE KEY)
Factory installed Loose Key Lockshield. Key Optional.
OPTIONS: At an additional charge, specify SAT for Satin, CHR
for Chrome, or BFP for Backflow Preventer after part number.
255LK
355LK 3/4” FIP x 3/4” Hose Thread, Loose Key
1/2” FIP x 3/4” Hose Thr
255BFP
355BFP
ead, Loose Key
O-Ring Bonnet
ANTI-SIPHON SILL FAUCETS
Factory Installed Vandal-Resistant Vacuum Breakers with
Protective Plastic Cap. IAPMO & ASSE 1011 listed.
, specify SAT for Satin, CHR
e
g
OPTIONS: At an ad
ome, or LK for Loose Key Lockshield after part number.
or Chr
f
255BFP 1/2” FIP x 3/4” Hose Thread with Oval
355BFP 3/4” FIP x 3/4” Hose Thread with Oval
255SWBFP 1/2” or 3/4” Copper Sweat x 3/4” Hose
ditional c
Handle, VB
Handle, VB
Thread with Oval Handle, VB
har
5
BRASS PRODUCTS, LLC
®
255BFPSD
NEW
NEW
355BFPSD
O-Ring Bonnet
SELF DRAINING SILL FAUCETS
(SELF DRAINING ANTI-SIPHON)
IAPMO & ASSE 1011 listed.
255BFPSD 1/2” FIP x 3/4” Hose Thread with Oval
Handle, Self-Draining VB
3
55BFPSD 3/4” FIP x 3/4” Hose Thread with Oval
Handle, VB, Self-Draining
METER VALVES
F
lared Angle Pattern Stop and Waste Valves.
851 3/4” Flared Tube x 3/4” FIP
Stop and W
871 1” Flared Tube x 3/4” FIP
Stop and W
aste
aste
851
871
BENT NOSE GARDEN VALVES
(LOOSE KEY)
OPTIONS: At an additional charge, specify
SAT for Satin, CHR for Chrome, or BFP for
Backflow Preventer after part number.
900LK 1/2” FIP x 3/4” Hose
925LK 3/4” FIP x 3/4” Hose
930LK 1” FIP x 3/4” Hose Thread,
Thread, Loose Key
Thread, Loose Key
Loose Key
BENT NOSE GARDEN VALVES
(ANTI-SIPHON)
OPTIONS: A
SAT for Satin, CHR for Chrome, or LK for
Loose Key Lockshield after part number.
900BFP 1/2” FIP x 3/4” Hose
925BFP 3/4” FIP x 3/4” Hose
930BFP 1” FIP x 3/4” Hose
t an additional charge, specify
Thread, VB
Thread, VB
Thread, VB
900LK
925LK
930LK
900BFP
925BFP
930BFP
BENT NOSE GARDEN VALVES
6
900
925
935
940
OPTIONS: At an additional charge, specify SAT for Satin or
CHR for Chrome after part number.
900 1/2” FIP x 3/4” Hose Thread
901 1/2” FIP x 3/4” Hose Thread
925 3/4” FIP x 3/4” Hose Thread
926
930
931
935
936
940
950 1/2” FIP x 3/4” Hose Thread with
951
975
976
980
981 1” FIP x 3/4” Hose Thread with Inverted Nose
2-PIECE FLOATING STEM
3/4” FIP x 3/4” Hose Thread
2-PIECE FLOATING STEM
1” FIP x 3/4” Hose Thr
1” FIP x 3/4” Hose Thread
2-PIECE FLOA
1” FIP x 1” Hose Thread
1” FIP x 1” Hose Thr
2-PIECE FLOA
1” FIP x 1” Hose Thr
ted Nose
Inver
1/2” FIP x 3/4” Hose Thr
Nose 2-PIECE FLOA
3/4” FIP x 3/4” Hose Thr
3/4” FIP x 3/4” Hose Thr
1” FIP x 3/4” Hose Thr
ted Nose
Inver
Nose 2-PIECE FLOA
2-PIECE FLOA
ead
TING STEM
ead
TING STEM
ead FULL POR
ead with Inver
TING STEM
ead with
ead with Inver
TING STEM
ead with Inver
TING STEM
950
975
980
T
ted
ted
ted Nose
221
223
222
220
O-Ring Bonnet
BOILER DRAINS
221
223 3/4” MIP x 3/4” Hose Thread
222
220
221CC ROUGH 1/2” Copper Compression x
58ABP
1/2” MIP x 3/4” Hose Thread
1/2” FIP x 3/4” Hose Thread
3/4” FIP x 3/4” Hose Thr
3/4” Hose Thread, Rough Brass
59ABP
ead
VACUUM BREAKERS
ASSE 1011 and IAPMO listed.
specify CHR f
,
e
g
acuum Br
ew
har
eaker with Br
acuum Breaker with
OPTIONS: At an ad
after part number.
58ABP 3/4” Female Hose Connection Add-On
59ABP
ditional c
V
Set Scr
Female Hose Connection Add-On
3/4”
SELF-DRAINING V
Breakaway Set Screw
or Chr
eakaway
221CCRB
ome
BRASS PRODUCTS, LLC
BRASS PRODUCTS, LLC
®
450 SERIES
NEW
NEW
-Ring Bonnet
O
STANDARD FROST FREE
LAWN FAUCETS (450 SERIES)
OPTIONS: At an additional charge, specify LK for Loose Key
Lockshield.
455-04 1/2” FIP or 3/4” MIP x 4”
455-06 1/2” FIP or 3/4” MIP x 6”
455-08 1/2” FIP or 3/4” MIP x 8”
455-10 1/2” FIP or 3/4” MIP x 10”
455-12 1/2” FIP or 3/4” MIP x 12”
455-14 1/2” FIP or 3/4” MIP x 14”
456-04 1/2” Copper Sweat or 1/2” MIP x 4”
456-06 1/2” Copper Sweat or 1/2” MIP x 6”
456-08 1/2” Copper Sweat or 1/2” MIP x 8”
456-10
456-12 1/2” Copper Sweat or 1/2” MIP x 12”
456-14 1/2” Copper Sweat or 1/2” MIP x 14”
459-04 PEX x 4”
459-06 PEX x 6”
459-08 PEX x 8”
459-10 PEX x 10”
459-12 PEX x 12”
459-14 PEX x 14”
453-04 3/4” Shark Bite x 4”
453-06 3/4” Shark Bite x 6”
453-08 3/4” Shark Bite x 8”
453-10 3/4” Shark Bite x 10”
453-12 3/4” Shark Bite x 12”
453-14 3/4” Shark Bite x 14”
454-04 1/2” Shark Bite x 4”
454-06 1/2” Shark Bite x 6”
454-08 1/2” Shark Bite x 8”
454-10 1/2” Shark Bite x 10”
454-12 1/2” Shark Bite x 12”
454-14 1/2” Shark Bite x 14”
DEFINITION
B – Boxed
BC – Bar Coded
BFP – Vacuum Breaker
ULK
B
– Bulk
CC – Copper Connection
CHR – Chrome
K – Kit
LK – Loose K
LLB – Log Lighter Bar
LS – Less Key
OH – Oval Handle
1/2” Copper Sweat or 1/2” MIP x 10”
of ABBREVIATIONS after model numbers
acked no packaging
ed P
y
e
PB – Polished Brass
PE – Plain End
RB – Rough Brass Finish
SAT– Satin
SC – Self-Closing
SD – Self-Dr
SW – Sweat Connection
TH –
V – Vertical
WH – Wheel Handle
ee Handle
T
aining
496BFP
496BFPV
O-Ring Bonnet
HOT & COLD ANTI-SIPHON
FROST FREE LAWN FAUCETS
Perfect for washing lawn furniture, decks and siding in time for
summer. During winter months install in your garage to wash
your pets and cars! IAPMO & ASSE 1019 listed.
OPTION: Specify V for Vertical Model after part number.
496BFP04 Hot/Cold 1/2” Copper Sweat or
496BFP06 Hot/Cold 1/2” Copper Sweat or
496BFP08 Hot/Cold 1/2” Copper Sweat or
496BFP10 Hot/Cold 1/2” Copper Sweat or
496BFP12 Hot/Cold 1/2” Copper Sweat or
496BFP14 Hot/Cold 1/2” Copper Sweat or
499BFP04 Hot/Cold PEX x 4”
499BFP06 Hot/Cold PEX x 6”
499BFP08 Hot/Cold PEX x 8”
499BFP10 Hot/Cold PEX x 10”
499BFP12 Hot/Cold PEX x 12”
499BFP14 Hot/Cold PEX x 14”
493BFP04 3/4” Shark Bite Hot/Cold x 4”
493BFP06 3/4” Shark Bite Hot/Cold x 6”
493BFP08
493BFP10
493BFP12
493BFP14 3/4” Shark Bite Hot/Cold x 14”
494BFP04 1/2” Shark Bite Hot/Cold x 4”
494BFP06 1/2” Shark Bite Hot/Cold x 6”
494BFP08 1/2” Shark Bite Hot/Cold x 8”
494BFP10 1/2” Shark Bite Hot/Cold x 10”
494BFP12 1/2” Shark Bite Hot/Cold x 12”
494BFP14 1/2” Shark Bite Hot/Cold x 14”
1/2” MIP x 4”
1/2” MIP x 6”
1/2” MIP x 8”
1/2” MIP x 10”
1/2” MIP x 12”
1/2” MIP x 14”
3/4” Shark Bite Hot/Cold x 8”
3/4” Shark Bite Hot/Cold x 10”
3/4” Shark Bite Hot/Cold x 12”
7
BRASS PRODUCTS, LLC
®
420BFP SERIES
NEW
NEW
NEW
O-Ring Bonnet
ANTI-SIPHON FROST FREE
LAWN FAUCETS (420 SERIES)
With Integral Vacuum Breaker and Vandal-Resistant Vented Cap.
ASSE 1019 and IAPMO listed. New Rubberized Coated Handle.
OPTIONS: At an additional charge, specify LK for Loose Key
Lockshield.
425BFP04 1/2” FIP or 3/4” MIP x 4”
425BFP06 1/2” FIP or 3/4” MIP x 6”
425BFP08 1/2” FIP or 3/4” MIP x 8”
425BFP10 1/2” FIP or 3/4” MIP x 10”
425BFP12 1/2” FIP or 3/4” MIP x 12”
425BFP14
426BFP04 1/2” Copper Sweat or 1/2” MIP x 4”
426BFP06 1/2” Copper Sweat or 1/2” MIP x 6”
426BFP08
426BFP10 1/2” Copper Sweat or 1/2” MIP x 10”
426BFP12 1/2” Copper Sweat or 1/2” MIP x 12”
426BFP14 1/2” Copper Sweat or 1/2” MIP x 14”
429BFP04
429BFP06 PEX x 6”
429BFP08 PEX x 8”
429BFP10 PEX x 10”
429BFP12 PEX x 12”
429BFP14 PEX x 14”
423BFP04 3/4” Shark Bite x 4”
423BFP06 3/4” Shark Bite x 6”
423BFP08 3/4” Shark Bite x 8”
423BFP10 3/4” Shark Bite x 10”
423BFP12 3/4” Shark Bite x 12”
423BFP14 3/4” Shark Bite x 14”
424BFP04
424BFP06 1/2” Shark Bite x 6”
424BFP08 1/2” Shark Bite x 8”
424BFP10
424BFP12 1/2” Shark Bite x 12”
424BFP14 1/2” Shark Bite x 14”
1/2” FIP or 3/4” MIP x 14”
1/2” Copper Sweat or 1/2” MIP x 8”
PEX x 4”
1/2” Shark Bite x 4”
1/2” Shark Bite x 10”
480BFP SERIES
O-Ring Bonnet
ANTI-SIPHON FROST FREE
LAWN FAUCETS (480 SERIES)
Similar to our 455BFP & 456BFP series, this valve has less
p
arts and still incorporates our factory installed vacuum breaker
and self-draining features. ASSE 1019 and IAPMO listed. New
Rubberized Coated Handle.
OPTIONS: At an additional charge, specify LK for Loose Key
Lockshield.
485BFP04 1/2” FIP or 3/4” MIP x 4”
485BFP06
485BFP08 1/2” FIP or 3/4” MIP x 8”
485BFP10 1/2” FIP or 3/4” MIP x 10”
485BFP12 1/2” FIP or 3/4” MIP x 12”
485BFP14 1/2” FIP or 3/4” MIP x 14”
486BFP02 1/2” Copper Sweat or 1/2” MIP x 2”
486BFP04 1/2” Copper Sweat or 1/2” MIP x 4”
486BFP06 1/2” Copper Sweat or 1/2” MIP x 6”
486BFP08 1/2” Copper Sweat or 1/2” MIP x 8”
486BFP10 1/2” Copper Sweat or 1/2” MIP x 10”
486BFP12 1/2” Copper Sweat or 1/2” MIP x 12”
486BFP14 1/2” Copper Sweat or 1/2” MIP x 14”
489BFP04 PEX x 4”
489BFP06 PEX x 6”
489BFP08 PEX x 8”
489BFP10 PEX x 10”
489BFP12 PEX x 12”
489BFP14 PEX x 14”
483BFP04 3/4” Shark Bite x 4”
483BFP06 3/4” Shark Bite x 6”
483BFP08 3/4” Shark Bite x 8”
483BFP10 3/4” Shark Bite x 10”
483BFP12 3/4” Shark Bite x 12”
483BFP14
484BFP04 1/2” Shark Bite x 4”
484BFP06
484BFP08
484BFP10 1/2” Shark Bite x 10”
484BFP12 1/2” Shark Bite x 12”
484BFP14
1/2” FIP or 3/4” MIP x 6”
3/4” Shark Bite x 14”
1/2” Shark Bite x 6”
1/2” Shark Bite x 8”
1/2” Shark Bite x 14”
ARROW-BREAKER™FROST FREE
See New Products on Page 3 for a complete listing of
ow-Br
r
Ar
8
O-Ring Bonnet
eaker™ Fr
ost Fr
460 SERIES
ee Hydrants
BRASS PRODUCTS, LLC
®
450BFP SERIES
NEW
-Ring Bonnet
O
ANTI-SIPHON FROST FREE
LAWN FAUCETS (450 APACHE SERIES)
With Integral Vacuum Breaker with Vandal-Resistant Vented Cap,
Self-Draining. ASSE 1019 and IAPMO listed.
OPTIONS: At an additional charge, specify LK for Loose Key
Lockshield.
455BFP04 Apache 1/2” FIP or 3/4” MIP x 4”
455BFP06 Apache 1/2” FIP or 3/4” MIP x 6”
455BFP08 Apache 1/2” FIP or 3/4” MIP x 8”
455BFP10 Apache 1/2” FIP or 3/4” MIP x 10”
455BFP12 Apache 1/2” FIP or 3/4” MIP x 12”
455BFP14 Apache 1/2” FIP or 3/4” MIP x 14”
456BFP04 Apache 1/2” Copper Sweat or 1/2” MIP x 4”
456BFP06 Apache 1/2” Copper Sweat or 1/2” MIP x 6”
456BFP08 Apache 1/2” Copper Sweat or 1/2” MIP x 8”
456BFP10 Apache 1/2” Copper Sweat or 1/2” MIP x 10”
456BFP12 Apache 1/2” Copper Sweat or 1/2” MIP x 12”
456BFP14 Apache 1/2” Copper Sweat or 1/2” MIP x 14”
459BFP04 Apache PEX x 4”
459BFP06 Apache PEX x 6”
459BFP08 Apache PEX x 8”
459BFP10 Apache PEX x 10”
459BFP12 Apache PEX x 12”
459BFP14 Apache PEX x 14”
453BFP04 3/4” Shark Bite Apache x 4”
453BFP06 3/4” Shark Bite Apache x 6”
453BFP08 3/4” Shark Bite Apache x 8”
453BFP10 3/4” Shark Bite Apache x 10”
453BFP12 3/4” Shark Bite Apache x 12”
453BFP14
454BFP04 1/2” Shark Bite Apache x 4”
454BFP06 1/2” Shark Bite Apache x 6”
454BFP08
454BFP10 1/2” Shark Bite Apache x 10”
454BFP12 1/2” Shark Bite Apache x 12”
454BFP14 1/2” Shark Bite Apache x 14”
DEFINITION of ABBREVIATIONS after model numbers
B – Boxed
BC – Bar Coded
BFP – Vacuum Breaker
BULK – Bulked Packed no packaging
CC – Copper Connection
CHR – Chrome
K – Kit
LK – Loose K
LLB – Log Lighter Bar
LS – Less Key
OH – Oval Handle
3/4” Shark Bite Apache x 14”
1/2” Shark Bite Apache x 8”
y
e
PB – Polished Brass
PE – Plain End
RB – Rough Brass Finish
SAT – Satin
SC – Self-Closing
SD – Self-Draining
eat Connection
SW – Sw
TH – Tee Handle
tical
er
V
V –
WH –
Wheel Handle
A
CCC
COMMERCIAL NARROW WALL HYDRANT BOX
Arrowhead's Stainless Steel Light Commercial Recessed Hose
B
ibb Box for mild climate is the perfect fit for a 4" wall
installation. Model ACCC comes complete for those narrow
installations, incorporating an all bronze body and interior
p
arts, with replaceable seat washer, screwdriver supply stop so
this valve can be worked on without a building shut down, key
ated main valve, and a stainless steel box and cover with a
oper
locking key. Comes with a 3/4" FIP inlet.
ACCC Commercial Close Coupled Valve & Box
ACCCBFP Commercial Close Coupled Valve & Box with
Vacuum Breaker
ACHB
AC4H
COMMERCIAL FROST FREE HYDRANTS
rowhead commercial anti-siphon, automatic draining,
Ar
non-freeze wall hydrant complete with integral backflow
pr
non-tur
ning oper
ting r
a
copper casing
,
enter
v
e
closure valve. Includes stainless steel face plate and key.
es and v
OPTIONS: Bo
AC4H
x
Commer
3/4” MIP x 4”
AC6H
Commer
3/4” MIP x 6”
AC8H
Commer
3/4” MIP x 8”
AC10H
Commer
3/4” MIP x 10”
AC12H
Commer
3/4” MIP x 12”
ACHB
Commer
onze interior parts,
all br
,
od with fr
alv
ee-floating compression
es are sold separately.
cial 3/4” Female Solder or
cial 3/4” Female Solder or
cial 3/4” Female Solder or
cial 3/4” Female Solder or
cial 3/4” Female Solder or
cial Hydrant Box
9
BRASS PRODUCTS, LLC
®
COMMERCIAL SILLCOCK BOX
The Arrowhead commercial sillcock box eliminates the hazards
of protruding hose bibbs. They are recommended for installation
in interior or exterior building walls where they are not subject
t
o freezing conditions. All boxes are chrome plated rough cast
bronze with doors that have a key operated lock and concealed
hinges. IAPMO & ASSE 1011 listed.
OPTIONS: Boxes and valves are sold separately.
ACSB Commercial Sillcock Box
AFA7501
ACSB
CA1000
CA1000 SERIES FROST FREE
YARD HYDRANT
Arrowhead medium duty CA1000 Frost Proof
Yard Hydrants gives you year round water
s
ervice, even in freezing weather. Drains below
the frostline when shut off.
CA7501 Yard Hydrant 1'
CA7502 Yard Hydrant 2'
CA7503 Yard Hydrant 3'
CA7504
CA7505 Yard Hydrant 5'
CA7506 Yard Hydrant 6'
CA7507 Yard Hydrant 7'
CA7508 Yard Hydrant 8'
CA7510 Yar
Yard Hydrant 4'
d Hydrant 10'
ANYFLOW FROST FREE
YARD HYDRANT
Arrowhead heavy duty ANYFLOW Frost Proof
Yard Hydrants gives you year round water
service, even in freezing weather. Drains below
the frostline when shut off.
AFA7501 Any Flow Yard Hydrant 1'
AFA7502 Any Flow Yard Hydrant 2'
AFA7503 Any Flow Yard Hydrant 3'
AFA7504 Any Flow Yard Hydrant 4'
AFA7505 Any Flow Yard Hydrant 5'
AFA7506 Any Flow Yard Hydrant 6'
A7507
AF
A7508
AF
AFA7510 Any Flow Yard Hydrant 10'
Any Flow Yard Hydrant 7'
d Hydrant 8'
Any Flow Y
ar
EA5000
EA5000 SERIES FROST FREE
YARD HYDRANT
whead economical EA5000 Frost Proof
o
r
Ar
Yard Hydrants gives you year round water
service, even in freezing weather. Drains below
the frostline when shut off.
EA7501 3/4” x 1' Bury 1” Galv.
EA75015 3/4” x 1-1/2' Bury 1” Galv.
EA7502
EA7503 3/4” x 3' Bury 1” Galv.
EA7504 3/4” x 4' Bury 1” Galv.
EA7505 3/4” x 5' Bury 1” Galv.
EA7506
EA7507
EA7508
3/4” x 2' Bury 1” Galv.
3/4” x 6' Bury 1” Galv.
3/4” x 7' Bur
3/4” x 8' Bur
y 1” Galv.
y 1” Galv
.
10
BRASS PRODUCTS, LLC
®
SRH SERIES FROST FREE
NEW
NEW
BRASS PRODUCTS, LLC
®
SANITARY ROOF HYDRANT (BFP)
NEW PRODUCT! Arrowhead Sanitary Roof
H
ydrant does not require a drain and can be
located anywhere a water supply is accessible.
Drains below the roofline into a canister when
shut off. Self-Contained and does NOT
contaminate water supply. ASSE 1052 and 1057
Approved. IAPMO Listed.
SRH7501BFP Sanitary Roof Hydrant
1’ Drop Depth (into
heated space) with ASSE
1052 Vacuum Breaker
SYH SERIES FROST FREE
SANITARY YARD HYDRANT (BFP)
Meets ASSE 1057 Sanitary Yard Hydrant Standard.
Prevents Cross-Contamination, does not
contaminate Water supply. Fully Self-Contained.
No ground Preparation required. Stainless Steel
Canister. ASSE 1052 and 1057 Approved.
IAPMO Listed
SYH7512BFP Sanitary Yard Hydrant 2’
SYH7513BFP Sanitary Yard Hydrant 3’
SYH7514BFP Sanitary Yard Hydrant 4’
SYH7515BFP Sanitary Yard Hydrant 5’
SYH7516BFP Sanitary Yard Hydrant 6’
SYH7517BFP Sanitar
.
Bury Depth with ASSE 1052
Vacuum Breaker
Bury Depth with ASSE 1052
Vacuum Breaker
Bury Depth with ASSE 1052
Vacuum Breaker
Bury Depth with ASSE 1052
acuum Breaker
V
y Depth with ASSE 1052
Bur
Vacuum Breaker
y Yard Hydrant 7’
Bury Depth with ASSE 1052
Vacuum Breaker
56CC
5
5CC
SHOWER HEAD ADAPTERS
55CC Copper Sweat with Brass Nuts - Straight
56CC Copper Sweat with Brass Nuts - Angle
6001A
DRAINAGE CONNECTIONS (TRAP ADAPTERS)
600-1 1-1/2” MIP x 1-1/2” Tube, Brass Nut, Brass
600-1A 1-1/2” MIP x 1-1/2” Tube, Brass Nut, Brass
600-2
600-3 1-1/2” MIP x 1-1/2” Tube, Die-Cast Nut,
600-4 1-1/2” MIP x 1-1/2” Tube, Die-Cast Nut,
601-2 1-1/2” MIP x 1-1/4” Tube, Brass Nut,
601-4 1-1/2” MIP x 1-1/4” Tube, Die-Cast Nut,
602-1 1-1/2” FIP x 1-1/2” Tube, Brass Nut,
602-1A 1-1/2” FIP x 1-1/2” Tube, Brass Nut, Brass
602-2 1-1/2” FIP x 1-1/2” Tube, Brass Nut,
602-3 1-1/2” FIP x 1-1/2” Tube, Die-Cast Nut,
602-4 1-1/2” FIP x 1-1/2” Tube, Die-Cast Nut,
603-2 1-1/2” FIP x 1-1/4” Tube, Brass Nut,
603-4 1-1/2” FIP x 1-1/4” Tube, Die-Cast Nut,
DEFINITION of ABBREVIATIONS after model numbers
B – Boxed
BC – Bar Coded
acuum Break
V
BFP –
BULK – Bulked Packed no packaging
CC – Copper Connection
CHR – Chrome
K – Kit
LK – Loose Key
LLB – Log Lighter Bar
LS – Less K
OH – Oval Handle
y
e
Ferrule
Ferrule with Stop
1- 1/2” MIP x 1-1/2” T
Nylon Ferrule
Brass Ferrule
Nylon Ferrule
Nylon Ferrule
Nylon Ferrule
Brass Ferrule
ule, with Stop
r
Fer
ule
Nylon Fer
Brass Fer
Nylon Fer
Nylon Fer
Nylon Fer
er
r
ule
r
ule
r
ule
r
ule
r
PB – P
PE – Plain End
RB – Rough Br
SAT – Satin
SC – Self-Closing
SD – Self-Draining
SW – Sw
TH – Tee Handle
V – Vertical
WH – Wheel Handle
ube, Brass Nut,
olished Brass
ass Finish
eat Connection
11
BRASS PRODUCTS, LLC
®
ARROWHEAD PART KITS
Model No. Description For products on page number(s)
PK1100 Complete O-Ring Seal One-Piece Bonnet Stem Assembly for Standard, No-Kinks, Boilers and Sillcocks 4, 5, 6
PK1110 Complete O-Ring Seal One-Piece Bonnet Stem Assembly for Standard, No-Kinks, Boilers and Sillcocks, Nickel Plated 4, 5, 6
PK1120 Stem Assembly & Packing Nut for Compression Stops 4
PK1130 Stem Assembly & Packing Nut for Garden Valves 6
PK1150 Loose Key O-Ring Seal One-Piece Bonnet Stem Assembly & Key for Standard, No-Kinks, Boilers and Sillcocks 3, 5
PK1155 Loose Key O-Ring Seal One-Piece Bonnet Stem Assembly & Key for Standard, No-Kinks, Boilers and Sillcocks, Nickel Plated 3, 5
P
K1170 1/2” Copper Compression Kit, Nickel Plated 5
P
K1180 1/2” Copper Compression Kit 4
PK1190 3/4” Copper Compression Kit 4
P
K1200 Plug & Hose Connection Kit for #248 Washing Machine Valve 5
PK1210 Bleeder Cap & Fibre Disk for Compression Stops 4
PK1220 Base Nut & Washer for 1/2” Garden Valve 6
PK1230 Base Nut & Washer for 3/4” Garden Valve 6
PK1240 Base Nut & Washer for 1” Garden Valve 6
PK1250 Green Wheel Handle & Screw 6
PK1270 Green T-Handle & Screw 2, 4, 6
PK1280 Chrome T-Handle & Screw 5
PK1290 Green Oval Handle & Screw 2, 4, 5, 6, 7
PK1295 Green Rubber
PK1300 Loose Key Handle for all Arrowhead Loose Key Valves 3, 5
PK1320 Flange & Key 2-1/4” for Log Lighter Valve, Chrome 5
PK1330 Flange & K
PK1340
PK1345
PK1350
PK1360 Replacement Vacuum Breaker 58BFP for Models with BFP after Part Number 4, 5
PK1370 Replacement Vacuum Breaker 58BFPCHR for Models with BFPCHR after Part Number, Nickel Plated 9
PK1380
PK1390 Replacement Self-Draining Vacuum Breaker 59BFPCHR for Models with BFPSD after Part Number & 480 Series, Nickel Plated 7, 8
PK1430 Green Capped Air Vent Complete Assembly for 420 Series & 450BFP Series 8, 9
Log Lighter Key 2-1/4”, Polished Brass 5
Standard Log Lighter K
Log Lighter K
Replacement Self-Draining Vacuum Breaker 59BFP for Models with BFPSD after Part Number 6
ized Coated Oval Handle & Screw 3, 8, 9
ey 2-1/4” for Log Lighter Valve, Polished Brass 5
ey 2-1/4”, Chrome 5
y 9”, P
e
olished Br
ass
5
PK1440 Complete Drain Assembly for 450BFP Series 9
PK1450 Replacement Grey Gap Spacer for all Frost Free Hydrants 3, 7, 8, 9
PK1600 Arrow-Breaker Complete Stem Assembly for Arrow-Breaker No-Kinks and Sillcocks 2
PK2004 4” O-Ring Seal One-Piece Bonnet Stem Assembly for 420 Series 8
PK2004LK 4” O-Ring Seal One-Piece Bonnet Stem Assembly for 420 Series, Loose Key 8
PK2006 6” O-Ring Seal One-Piece Bonnet Stem Assembly for 420 Series 8
12
BRASS PRODUCTS, LLC
®
ARROWHEAD PART KITS Cont.
Model No. Description For products on page number(s)
PK2006LK 6” O-Ring Seal One-Piece Bonnet Stem Assembly for 420 Series, Loose Key 8
PK2008 8” O-Ring Seal One-Piece Bonnet Stem Assembly for 420 Series 8
PK2008LK 8” O-Ring Seal One-Piece Bonnet Stem Assembly for 420 Series, Loose Key 8
PK2010 10” O-Ring Seal One-Piece Bonnet Stem Assembly for 420 Series 8
PK2010LK 10” O-Ring Seal One-Piece Bonnet Stem Assembly for 420 Series, Loose Key 8
PK2012 12” O-Ring Seal One-Piece Bonnet Stem Assembly for 420 Series 8
PK2012LK 12” O-Ring Seal One-Piece Bonnet Stem Assembly for 420 Series, Loose Key 8
PK2014 14” O-Ring Seal One-Piece Bonnet Stem Assembly for 420 Series 8
PK2014LK 14” O-Ring Seal One-Piece Bonnet Stem Assembly for 420 Series, Loose Key 8
PK2016 SpringLESS Check Assembly for 420 Series Stem 8
PK5004 Apache 4” O-Ring Seal One-Piece Bonnet Stem Assembly for 450BFP Series 9
PK5006
Apache 6” O-Ring Seal One-Piece Bonnet Stem Assembly for 450BFP Series 9
PK5008 Apache 8” O-Ring Seal One-Piece Bonnet Stem Assembly for 450BFP Series 9
PK5010 Apache 10” O-Ring Seal One-Piece Bonnet Stem Assembly for 450BFP Series 9
PK5012 Apache 12” O-Ring Seal One-Piece Bonnet Stem Assembly for 450BFP Series 9
PK5014 Apache 14” O-Ring Seal One-Piece Bonnet Stem Assembly for 450BFP Series 9
PK6004 Arrow-Breaker Frost Free Stem Assembly 4” for 460 Series 3
PK6006
Arrow-Breaker Frost Free Stem Assembly 6” for 460 Series 3
PK6008 Arrow-Breaker Frost Free Stem Assembly 8” for 460 Series 3
PK6010 Arrow-Breaker Frost Free Stem Assembly 10” for 460 Series 3
PK6012 Arrow-Breaker Frost Free Stem Assembly 12” for 460 Series 3
PK6014 Arrow-Breaker Frost Free Stem Assembly 14” for 460 Series 3
PK8004 4”
PK8004LK
PK8006
O-Ring Seal One-Piece Bonnet Stem Assembly for 480 Series 8
O-Ring Seal One-Piece Bonnet Stem Assemb
4”
O-Ring Seal One-Piece Bonnet Stem Assemb
6”
ly for 480 Series, Loose Key 8
or 480 Ser
ly f
ies
PK8006LK 6” O-Ring Seal One-Piece Bonnet Stem Assembly for 480 Series, Loose Key 8
PK8008 8” O-Ring Seal One-Piece Bonnet Stem Assembly for 480 Series 8
8
PK8008LK 8” O-Ring Seal One-Piece Bonnet Stem Assembly for 480 Series, Loose Key 8
PK8010 10” O-Ring Seal One-Piece Bonnet Stem Assembly for 480 Series 8
PK8010LK 10” O-Ring Seal One-Piece Bonnet Stem Assembly for 480 Series, Loose Key 8
PK8012 12” O-Ring Seal One-Piece Bonnet Stem Assembly for 480 Series 8
O-Ring Seal One-Piece Bonnet Stem Assembly for 480 Series, Loose Key 8
PK8012LK
12”
PK8014 14” O-Ring Seal One-Piece Bonnet Stem Assembly for 480 Series 8
PK8014LK 14” O-Ring Seal One-Piece Bonnet Stem Assembly for 480 Series, Loose Key 8
DEFINITION of ABBREVIATIONS after model numbers
B – Boxed
BC – Bar Coded
Vacuum Breaker
BFP –
B
ULK
– Bulk
ed P
ed no pac
k
ac
kaging
CC – Copper Connection
CHR – Chrome
K – Kit
LK – Loose K
y
e
LLB – Log Lighter Bar
LS – Less K
OH – Ov
PB – P
y
e
al Handle
olished Br
ass
PE – Plain End
RB – Rough Br
SAT – Satin
SC – Self-Closing
ass Finish
SD – Self-Draining
eat Connection
SW – Sw
TH – Tee Handle
tical
er
V
V –
WH – Wheel Handle
13
5F
6F
7F 8F
200RS-100
9F
10F
12F
13F
BRASS FITTINGS HOSE/PIPE
5F Swivel Fitting 3/4” Female Hose Thread to
6F Non-Swivel Fitting 3/4” Male Hose Thread to
7F Swivel Fitting 3/4” Female Hose Thread to
8F Non-Swivel Fitting 3/4” Male Hose Thread to
9F Non-Swivel Fitting 3/4” Female Hose Thread to
10F Non-Swivel Fitting 3/4” Male Hose Thread to
12F
13F Swivel Fitting 3/4” Female Hose Thread to
14HC Brass Hose End Cap 3/4” Female Hose Thread
1/2” Male Pipe Thread
3/4” Male Pipe Thread
3/4” Female Pipe Thread
3/4” Male Pipe Thread or 1/2” Female
Pipe Thread
3/4” Male Pipe Thread or 1/2” Female
Pipe Thread
1/2” Male Pipe Thread
Non-Swivel Fitting 3/4” Female Hose Thr
3/4” Female Pipe Thread"
1/2” Female Pipe Thread
14HC
ANGLE VALVES LESS UNION
Quality Red Brass construction features full-flow waterway for
low pressure loss to effectively regulate water supply. Easily
converts to Automatic operation. Available with fixed stem or
rising swivel (RS). Rated at 150 PSI.
200-075 3/4” less Union Red Brass
200-100 1” less Union Red Brass
200RS-075 3/4” less Union Rising Swivel - Red Bras
200RS-100 1” less Union Rising Swivel - Red Brass
200RS-125 1-1/4” less Union Rising Swivel - Red Brass
200RS-150 1-1/2” less Union Rising Swivel - Red Brass
200RS-200 2” less Union Rising Swivel - Permanent
Seal - Red Brass
ead to
300RS-100
100RS-100
STRAIGHT VALVE
eatures full-flow waterway for
Quality Red Br
w pressure loss to effectively regulate water supply. Easily
lo
converts to Automatic operation. Available with fixed stem or
rising swivel (RS). Rated at 150 PSI.
100-075 3/4” Red Brass
100-100 1” Red Brass
100RS-075
100RS-100 1” Rising Swivel - Red Brass
100RS-125 1-1/4” Rising Swivel - Red Brass
100RS-150 1-1/2” Rising Swivel - Red Brass
100RS-200 2” Rising Swivel - Red Brass
14
ass constr
3/4” Rising Swivel - Red Brass
uction f
ANGLE VALVES WITH UNION
Quality Red Brass construction features full-flow waterway for
low pressure loss to effectively regulate water supply. Easily
erts to Automatic operation. Available with fixed stem or
v
con
rising swivel (RS). Rated at 150 PSI.
300-075 3/4” with Union Red Brass
300-100 1” with Union Red Brass
300RS-075
300RS-100 1” with Union Rising Swivel - Red Brass
300RS-125 1-1/4” with Union Rising Swivel - Red Brass
300RS-150
300RS-200 2” with Union Rising Swivel - Red Brass
3/4” with Union Rising Swivel - Red Brass
1-1/2” with Union Rising Swivel - Red Brass
BG-100
CL466-075
BRASS INLINE VALVES
F
eatures True Red Brass construction, EPDM Diaphragm, reverse
flow design ensures diaphragm fails in the closed position, manual
On/Off operation with internal & external bleed, flow adjustment stem
and the Reclaimed Water Series (RW) has a purple bonnet signifying
non-potable water.
BG-075 3/4” Globe Valve - Red Brass with Reverse Flow
BG-100 1” Globe Valve - Red Brass with Reverse Flow
BG-125 1-1/4” Globe Valve - Red Brass with Reverse Flow
BG-150
BG-200 2” Globe Valve - Red Brass with Reverse Flow
BG-075RW 3/4”
BG-100RW 1” Reclaimed Water Red Brass with Reverse Flow
BG-125RW 1-1/4” Reclaimed Water Red Brass with Reverse
BG-150RW 1-1/2” Reclaimed Water Red Brass with Reverse
BG-200RW 2” Reclaimed Water Red Brass with Reverse Flow
1-1/2” Globe Valve - Red Brass with Reverse Flow
Reclaimed Water Red Brass with Reverse Flow
Flow
Flow
466-100
V-19-466P-100
AUTOMATIC CONTROL VALVE
(CLASSIC SERIES)
Features Professional Quality, Red Brass Actuator with Red Brass
Anti-Siphon Valve. Manual flow control and external bleed, AntiSiphon prevents backflow of foul water into household water supply.
Optimal Operating Pressure - 25 to 100 PSI. Rated to 150 PSI.
CL466-075 3/4" Classic with Union - Red Brass
CL466-100 1" Classic with Union - Red Brass
CL466P-075 3/4" Classic less Union - Red Brass
CL466P-100 1" Classic less Union - Red Brass
CL-075
AA-075
ANTI-SIPHON VALVE
Features Red Brass construction, atmospheric vacuum breaker that
prevents backflow of foul water into the household water supply, full
size water ways for low pressure loss, durable seals. Tested and
listed with the City of Los Angeles, IAPMO and ASSE. They are not
designed for constant pressure applications.
466-075 3/4" Valve with Union - Red Brass
466-100 1" Valve with Union - Red Brass
alve less Union - Red Brass
466P-075
466P-100
V-19-466-075 3/4" Body Assembly with Union - Red Brass
V-19-466-100 1" Body Assembly with Union - Red Brass
V-19-466P-075 3/4" Body Assembly less Union - Red Brass
V-19-466P-100 1" Body Assembly less Union - Red Brass
3/4" V
alve less Union - Red Brass
1" V
AUTOMATIC ACTUATORS
(CONVERTS MANUAL TO AUTOMATIC)
Quality Red Brass construction. Easily converts Champion Manual
es to Automatic operation. Rated to 150 PSI.
alv
v
CL-075
CL-100
AA-075 3/4" Compact Automatic Actuator - Red Brass
AA-100 1" Compact Automatic Actuator - Red Brass
DEFINITION
B – Boxed
BC – Bar Coded
BFP – Vacuum Breaker
ULK
B
CC – Copper Connection
CHR – Chrome
K – Kit
LK – Loose Key
LLB – Log Lighter Bar
LS – Less Key
OH – Oval Handle
3/4" Classic Automatic Actuator - Red Brass
1" Classic Automatic Actuator - Red Brass
after model n
– Bulk
ABBREVIA
of
ac
ed P
ed no pac
k
TIONS
kaging
PB – Polished Brass
PE – Plain End
RB – Rough Brass Finish
SAT– Satin
SC – Self-Closing
SD – Self-Draining
SW – Sweat Connection
TH – Tee Handle
V – Vertical
Wheel Handle
WH –
umber
s
15
262-100
362-100
CK-100
ATMOSPHERIC VACUUM BREAKERS
Features True Red Brass construction, prevents backflow of water
into potable water line, full size waterways for low pressure loss,
d
urable seals, tested and listed with the City of Los Angeles, IAPMO
and ASSE. Not designed for constant pressure applications.
2
62-075 3/4" less Union - Red Brass
262-100 1" less Union - Red Brass
262-125 1-1/4" less Union - Red Brass
262-150 1-1/2" less Union - Red Brass
262-200 2" less Union - Red Brass
362-075 3/4" with Union - Red Brass
362-100 1" with Union - Red Brass
362-125
1-1/4" with Union - Red Brass
362-150 1-1/2" with Union - Red Brass
362-200 2" with Union - Red Brass
COUPLER VALVES,
KEYS & SWIVELS
Reclaimed water valves available by special
order. Keys are interchangeable with most
manufacturer's coupler valves. Swivel easily
attaches hose to quick coupler. Swivel rotates
360 degrees.
QCV-075 3/4" Single Lug with Metal
QCV-075V 3/4" Single Lug with Vinyl
QCV-075VL 3/4" Single Lug/Locking
-100 1" Single Lug with Metal
QCV
-100V 1" Single Lug with Vinyl
QCV
-100VL 1" Single Lug/Locking
QCV
Cover - Red Brass
Cover
QCV-100
Vinyl Cover
Cover - Red Brass
Cover
Vinyl Cover
QUICK COUPLER KEYS
CK-075 3/4" Male, 1/2" Female - Red Brass
CK-100 1" Male, 3/4" Female - Red Brass
COUPLER SWIVEL CONNECTIONS
QCS-1 3/4" FIP to 3/4" Hose
QCS-2 1" FIP to 3/4" Hose
QCS-3 1" FIP to 1" Hose Thread Valve
Thread Valve
Thread Valve
SJT-9
SJU-1
BRASS SLIP JOIN COMPRESSION
UNIONS & TEES
Quality Red Brass construction. Used to repair broken pipe or to
attache threaded pipe to non-threaded pipe.
SJU-1 1/2" PVC, Iron Pipe, Galv. or 3/4" Copper
SJU-2
SJU-51
SJU-52
-9
SJT
-10
SJT
x 3" Length Union
3/4" PVC, Ir
on Pipe, Galv
. or 1" Copper
x 3" Length Union
1/2" PVC, Ir
on Pipe, Galv
. or 3/4" Copper
x 5" Length Union
3/4" PVC, Ir
on Pipe, Galv. or 1" Copper
x 5" Length Union
1/2" PVC, Iron Pipe, Galv. or 3/4" Copper
x 3/4" FPT Tee
3/4" PVC, Iron Pipe, Galv. or 1" Copper
x 1" FPT Tee
QCS-3
DEFINITION of ABBREVIATIONS after model numbers
B – Boxed
BC – Bar Coded
BFP – Vacuum Breaker
BULK – Bulked Packed no packaging
16
5147 Alhambra Ave., Los Angeles, CA 90032 323 221-9137, fax 323 221-2579
Now, Better Than Ever! Reliable – Proven – Trusted – Since 1936
CC – Copper Connection
CHR – Chrome
K – Kit
LK – Loose K
LLB – Log Lighter Bar
LS – Less Key
OH – Oval Handle
y
e
PB – Polished Brass
PE – Plain End
RB – Rough Brass Finish
SAT – Satin
SC – Self-Closing
SD – Self-Draining
SW – Sweat Connection
TH – Tee Handle
V – Vertical
WH – Wheel Handle
Loading...
