Aroma ARC-530 User Manual

Stainless Steel Rice Cooker with

Stainless Steel Interior and Exterior

Instruction Manual &

Cooking Guide

Model:ARC-530

Congratulations on your purchase of the Electronic Rice Cooker &
Food Steamer. It will surely become one of the most practical appliances in
your kitchen.

Please read all instructions before first use.

Published By:
Aroma Housewares Co.

6469 Flanders Drive
San Diego, CA 92121
U.S.A.
1-800-276-6286
www.aromaco.com

© 2004 Aroma Housewares Company All rights reserved.

IMPORTANT SAFEGUARDS

1. Important:Read all instructions carefully before first use.

2. Make sure the appliance is OFF when not in use, before putting on or taking off
parts, and before cleaning.

3. To protect against electricalshock, do not immersecord, plug or the appliance
itself in water or other liquid.

4. Keep the appliance away from the children to avoid accidents.

5. Unplug from outlet when not in use and before cleaning.Allow unit to cool
before puttingon or taking off parts, and before cleaning the appliance.

6. Do not operate any appliance with a damaged cord or plug or after the
appliancemalfunctions or has been damaged in any manner. Return appliance
to the nearest authorized service facility for examination, repair or adjustment.

7. Do not use attachments or accessories other than those supplied or
recommendedby the manufacturer. Incompatible parts create a hazard.

8. Do not use outdoors.

9. Do not let cord hang over edge of table or counter, or touch hot surfaces.

10. Do not place on or near a hot gas or electric burner or in a heated oven.

11. Do not use the appliance for other than intended use.

12. Extremecaution must be used when moving the apliance containing rice or
liquids.

13. Alwaysunplug from the base of the wall outlet. Never pull on the cord.

14. The rice cooker should be operated on a separate electrical circuit from other
operatingappliances. If the electric circuit is overloadedwith other appliances,
this appliancemay not operate properly.

15. Maximumrice capacity is 1.8 Liters (volume capacity is 4.0 Liters).

16. Avoidsudden temperature changes when using the rice cooker.

17. Use only with 120VAC power outlet.

18. Alwaysmake sure the outside of the inner cooking pot is dry prior to use. If
cooking pot is returned to cooker when wet, it will damage this product causing
it to malfunction.

19. Use extreme caution when opening the lid during or after cooking. Hot steam
will escape and could cause burns.

20. Duringthe cooking & slow cooking stage, you may notice steam coming from
the vents on the lids. This is normal.

SAVE THESE INSTRUCTIONS

1

SHORT CORD INSTRUCTIONS

1. A short power-supply cord is provided to reduce risk resulting from becoming
entangled in or tripping over a longer cord.

2. Longer extension cords are available and may be used if care is exercised in their
use.

3. If a longer extension cord is used:
a. The marked electrical rating of the extension cord should be at least as great as

the electrical rating of the appliance.

b. The longer cord should be arranged so that it will not drape over the counter top

or tabletop where it can be pulled by children or tripped over unintentionally.

POLARIZED PLUG

This appliance has a polarized plug (one blade is wider than the other); follow the
instructions below:

To reduce the risk of electric shock, this plug is intended to fit into a polarized outlet
only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does
not fit, contact a qualified electrician. Do not attempt to modify the plug in any way.

This appliance is for household use only.

2

ABOUT RICE & SENSOR LOGIC

Rice is a valuable source of low fat, complex carbohydrates and is abundant in thiamin,
niacin and iron. It is an essential ingredient for a healthy diet.

There are many different varieties of rice available in the market. YourAroma Rice
Cooker can cook any type perfectly every time. Following are the commonly available
varieties of rice and their characteristics:

Long Grain Rice

Typicallythis rice is not starchy and has loose, individual grains after cooking. The
"California" rice is soft; "Carolina" is a little firmer, and "Jasmine" is the firmest of the
long grain variety and is flavorful and aromatic.

Short Grain Rice

Short grain is characteristically soft, sticky and chewy. This is the rice used to make
sushi. "California Rice" is soft; "Sweet Rice", often called "pearl" rice for its round shape,
is extra sticky and is excellent for making rice pudding.

Brown Rice

Brown rice is often considered the most healthy variety. It has bran layers on the rice
grains and contains more B-complex vitamins, iron, calcium, and fiber than polished
(white) rice. The most popular brown rice is long grain and has a chewy texture.

Wild Rice

Wild Rice comes in many delicious varieties and mixes. Often it is mixed with long grain
rice for its firmer texture and rich brown to black color. Wild rice makes wonderful
stuffing for poultry when cooked with broth and mixed with your favorite dried fruits.

Sensor Logic™

Traditional electric rice cookers heat only from the bottom at one set temperature and
turn off when the water has been absorbed. Aroma's Sensor Logic™ Rice Cooker uses
advanced technology and an all around heating system that maintains the optimal
cooking environment.

This technology automatically regulates the temperature throughout the cooking process.
Based on the amount of rice and water, the temperature will adjust to create quality
results every time. During the process, the rice cooks as the water is absorbed into each
grain. After the boiling stage, the cooker will have one last heat surge where excess
water and steam will be burned off. The complete process ensures that the rice will be
perfect for as little as one cup or as much as 10 cups of uncooked rice!

3

PARTS IDENTIFICATION

4

3

2

1

1. Rice cooker base

2. Lid

3. Handle

4. Steam vent

5. Control panel

6. Inner pot

7. Steam tray

8. Steam rack

9. Measuring cup

10. Rice paddle

11.Ladle

5

6

7

8

9

10

11

4

HOW TO USE

Before First Use:

1. Read all instructionsand importantsafeguards.

2. Remove all packaging materials and make sure items are receivedin good condition.

3. Tear up all plastic bags as they can pose a risk to children.

4. Washaccessories in warm soapy water. Rinse and dry thoroughly.

5. Remove inner pot from rice cooker and clean with warm soapy water. Rinse and dry
thoroughlybefore returning to cooker.

6. Wipe body clean with a damp cloth.

 Do not use abrasive cleaners or scouring pads.
 Do not immerse the rice cooker,cord or plug in water at any time.

To Cook Rice:

1. Using the measuring cup provided,measure and add rice to the pot. One levelAroma
measuringcup equals one cup on the rice/water measurementchart included on page

8.

2. Rinse rice in the inner pot until water becomes relatively clear,then drain.

3. Using the water measurementlines inside or the measuringcup, add appropriate
amount of water.

4. Replace lid and plug power cord into outlet.

5. Press menu button until the light next to the desired setting is illuminated. Choose
from white rice, brown rice, quick cook (see quick cook on next page) or porridge.

6. Press start button.

7. Rice cooker will automaticallyswitch to keep warm mode when complete.

NOTE:

• Average cooking time for a full pot white rice is 50-60 minutes. For brown rice,

cooking time is slightly increased. And for smaller portions, the cooking time for
brown or white rice is decreased. For a quicker cookingtime, and to bypass
Sensor Logic, use the quick cook directions on the following page.

To Slow Cook:

1. Add ingredientsto inner pot, and place pot in rice cooker.

2. Press the menu button until desired setting’slight is illuminated. Choose between 2­hour slow cook or 3-hour slow cook.

3. Functionwill automatically switch to keep warm mode when complete.

5

HOW TO USE

To Steam Food:

1. Measure the desired amount of water into the inner pot. Aconvenient steaming guide
has been included on page 8

2. Place steam tray inside rice cooker.

3. Place food in tray and press steam button. The timer and start light will illuminate.

4. When timer has reached the appropriate time, press the off button. If not turned off
manually, the rice cooker will switch to warm mode after forty minutes.

To Use Delay Timer:

1. Select desiredfunction with the menu button.

2. Select the number of hours in which you would like your cooking to begin. (1 to 10
hours).

3. Press start.

4. Rice cooker will automaticallyswitch to warm mode when complete.

To Use Quick Cook:

Use this function to bypass Sensor Logic cooking and reduce cooking time.

1. Follow the directionson how to cook rice for appropriate method of adding rice to the
pot.

2. Press the menu button until quick cook light illuminates. LED display will show the
letters “FA”, abbreviatedfrom the word “FAST”.

3. Press start.

4. Rice will automaticallyswitch to warm mode when complete.

.

To Use Warm Mode:

Althoughrice cooker automatically switches to warm after cooking functions, you may
also use this function independentlyto keep a meal warm after rice cooker is turned off.

1. Add food to be warmed to inner pot and place in the rice cooker.

2. Press warm/offbutton until green light illuminates.

3. Press warm/offbutton when finished warming.

CAUTION:

• Do not open lid when in use as it will delay cooking time and will release hot
steam, which may cause burns.

• If cooking pot is returnedto cooker when wet, it will damage this product
causing it to malfunction.

6

HOW TO CLEAN

Always unplug unit and allow to cool completely before cleaning.

1. Remove the inner cooking pot. Wash it in warm, soapy water using a sponge or
dishcloth.

2. Rinse and dry thoroughly.

3. Repeat process with steam tray, and other provided accessories.

4. Wipe the body of the rice cookerclean with a damp cloth.

To Clean Condensation Collector:

Condensationcollector should be cleaned after every use.

1. Remove collector by gently pulling straight out.

2. Washwith warm soapy water. Rinse and dry thoroughly.

5. Return collector to original position by clicking back into the groovesof the rice cooker.

 Do not use harsh abrasive cleaners or products that are not considered safe to

use on nonstick coatings.

 Do not immerse rice cooker base in water or any other liquid. This appliance is

NOT dishwasher safe. Inner pot is NOT dishwasher safe.

7

COOKING GUIDES

Rice/Water Measurement Chart:

UNCOOKED

RICE

2 Cups 2-1/2 Cups LIne 2 4 Cups
3 Cups 3-1/2 Cups LIne 3 6 Cups
4 Cups 4-1/2 Cups Line 4 8 Cups
5 Cups 5-1/2 Cups Line 5 10 Cups
6 Cups 6-1/2 Cups Line 6 12 Cups
7 Cups 7-1/2 Cups Line 7 14 Cups
8 Cups 8-1/2 Cups Line 8 16 Cups
9 Cups 9-1/2 Cups Line 9 18 Cups

10 Cups 10-1/2 Cups Line 10 20 Cups

NOTE

• When cooking brown or wild rice, add an additional 3/4 cup water.

• The measuringcup included is not an exact cup. Chart refers to cups of rice/water
based on the measuring cup provided.

• This is only a general measuring guide. As there are many differentkinds of rice
available(see About Rice on page 3), rice/water measurementmay vary slightly.

Porridge Chart:

WATER WITH

MEASURING CUP

UNCOOKED

RICE

1/2 Cup 3 Cups

1 Cup 6 Cups

2 Cups 12 Cups

INNER POT

WATER LINE

WATER WITH

MEASURING CUP

APPROX COOKED

RICE YIELD

HELPFUL HINTS:

1. Rinse rice to remove excess bran and starch. This will help reduce browning and
stickingto the bottom of the pot, but it may also reduce nutrientsin rice.

2. If you have experienced any sticking due to the type of rice you are using, try adding a
light coating of vegetableoil to the bottom of the inner pot before adding rice.

3. For softer rice, allow rice to soak for 10-20 minutes prior to cooking.

8

COOKING GUIDES

Steaming Chart:

VEGETABLE AMOUNT OF WATER STEAMING TIME

Asparagus 1/2 Cup 10 Minutes

Broccoli 1/4 Cup 5 Minutes

Cabbage 1 Cup 15 Minutes

Carrots 1 Cup 15 Minutes

Cauliflower 1 Cup 15 Minutes

Corn 1 Cup 15 Minutes

Eggplant 1-1/4 Cup 20 Minutes

Green Beans 1 Cup 15 Minutes

Peas 1/2 Cup 10 Minutes

Spinach 1/2 Cup 10 Minutes

Squash 1/2 Cup 10 Minutes

Zucchini 1/2 Cup 10 Minutes

HELPFUL HINTS:

1. Since most vegetablesonly absorb a small amount of water,there is no need to
increasethe amount of water with a larger serving of vegetables.

2. Always keep the lid on the cooker during the entire steaming process. Opening the
lid causes a loss of heat and steam, resulting in a slower cooking time, and may
cause burns. If you find it necessaryto open the lid, use caution. Youmay want to
add a small amount of water to help restore the cooking time.

3. Altitude,humidity and outside temperature will affect cooking times.

4. The steaming chart is for reference only. Actual cooking time may vary.

9

LIMITED WARRANTY

Aroma HousewaresCompany warrants this product free from defects in material and
workmanshipfor one year from provabledate of purchase in continentalUnited States.

Within this warrantyperiod, Aroma HousewaresCompany will repair or replace, at its
option, defective parts at no charge, provided the product is returned,freight prepaid with
proof of purchase and U.S. $6.00 for shipping and handling charges payable toAroma
HousewaresCompany. Before returningan item, please call the toll free number below
for return authorizationnumber.Allow 2-4 weeks for return shipping.

This warranty does not cover improper installation, misuse, abuse or neglect on the part
of the owner.Warranty is also invalid in any case that the product is taken apart or
servicedby an unauthorizedservice station.

This warranty gives you specificlegal rights and which may vary from state to state and
does not cover areas outside the United States.

AROMAHOUSEWARESCOMPANY

6469 Flanders Drive

San Diego, California92121

1-800-276-6286

M-F, 8:30AM - 5:00 PM, PacificTime

Website:www.aromaco.com

FOR ORDERING PARTS OR IF YOU HAVEANY COMMENTS

ABOUTTHIS PRODUCT, PLEASE CONTACTAROMA

CUSTOMERSERVICE DEPARTMENTAT1-800-276-6286.
