Aristo AM-235 User Manual

Electronic Emission Notices

Federal Communications Commission (FCC) Statement (41532C)

This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with instructions contained in this manual, may cause harmful interference
to radio and television communications. However, there is no guarantee that interference
will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:

- REORIENT OR RELOCATE THE RECEIVING ANTENNA

- INCREASE THE SEP ARATION BETWEEN THE EQUIPMENT AND THE RECEIVER

- CONNECT THE EQUIPMENT INTO AN OUTLET ON A CIRCUIT DIFFERENT FROM
THAT OF THE RECEIVER

- CONSULT THE DEALER OR AN EXPERIENCED AUDIO/TELEVISION TECHNICIAN

NOTE: Connecting this device to peripheral devices that do not comply with Class B

requirements, or using an unshielded peripheral data cable, could also result in
harmful interference to radio or television reception.

1

The user is cautioned that any changes or modifications not expressly approved
by the party responsible for compliance could void the user’s authority to operate
this equipment.

To ensure that the use of this product does not contribute to interference, it is
necessary to use shielded I/O cables.

Copyright

This manual is copyrighted with all rights reserved. No portion of this manual may be
copied or reproduced by any means.

While every precaution has been taken in the preparation of this manual, no responsibility
for errors or omissions is assumed. Neither is any liability assumed for damages resulting
from the use of the information contained herein.

Trademarks

All brand names, logos and registered trademarks mentioned are property of their
respective owners.

2

Table of Contents

HARDWARE CONFIGURATION .................................................................... 3

Key Features ............................................................................................................... 3

Motherboard Layout .................................................................................................... 5

Jumper Settings ........................................................................................................... 6

CPU Speed Selection ............................................................................................ 6

EDS1 - On Board AC97 Codec Sound ................................................................. 6

J8H1 - CMOS Clear ............................................................................................... 6

JVSB1 - Keyboard Power Select......................................................................... 6

Pin Assignment ..................................................................................................... 6

HARDWARE SETUP ...................................................................................... 8

T o Install DIMMs ........................................................................................................... 8

Installing a New Processor ......................................................................................... 8

To Install a Processor to ZIF Socket ........................................................................... 9

Connect the processor Fan Connector ...................................................................... 9

Setting the Processor Speed ...................................................................................... 9

BIOS SETUP .................................................................................................. 10

Starting Setup .............................................................................................................. 1 0

Main Menu.................................................................................................................... 11

Standard CMOS Features ........................................................................................... 12

Advanced BIOS Features ........................................................................................... 14

Advanced Chipset Features ....................................................................................... 14

Integrated Peripherals ................................................................................................. 14

Power Management Setup.......................................................................................... 14

PNP/PCI Configurations................................................................................................ 14

PC Health Status.......................................................................................................... 14

Frequency/Voltage Control ......................................................................................... 1 4

Set Supervisor/User Password .................................................................................. 14

Flash Update Procedure ............................................................................................. 16

APPENDIX .................................................................................................... 17

AC97 Sound Driver Installation for Windows NT 4.0 and

Windows 2000 ............................................................................................................ 17

Technical Reference Booklet

HARDWARE CONFIGURATION

Key Features :
Chipset

• Intel® 845 Chipset.

Processor

• Support Intel® Pentium® 4 processors and the Northwood processors in the
478-pin package.

• Support Intel® Pentium® 4 processors system bus at 400MHz.

VRM 9.0 (Voltage Regulator Modules) on Board

• Flexible motherboard design with on board VRM 9.0.

System Memory

• A total of three 168-pin DIMM sockets.

• Supports 133MHz SDRAM Devices.

• Configurable optional ECC operation (Single bit Error Correction and multiple bit

Error Detection).

• Supports 64MB,128MB,512MB and 512MB technologies for X8 and X16
devices.

• Max of 3 Double-Sided DIMMs(6 rows populated)with Unbuffered PC133 (with
or without ECC).

• Maximum memory bandwidth of 1GB/s with PC133.

• No registered DIMM support.

• Support for DIMM Serial Presence Detect(SPD) scheme via SMBUS interface.

• Memory size up to 1.5GB.

System BIOS

• Firmware Hub with security feature.

• PnP, APM, ATAPI and Windows® 95/98/2000.

• Full support of ACPI & DMI.

• Auto detects and supports LBA harddisks with capacities over 8.4GB.

• Easy to upgrade BIOS by end-user.

On-board I/O

• On board two PCI fast IDE ports supporting up to 4 ATA, ATA2 , Ultra ATA33/
66/100 IDE HDDs, CD-ROMs, ZIP drives and LS-120 drives as boot drive.

• Support Bus Master IDE, Read transfers up to 100MB/s,Writes to 89MB/s.

• One ECP/EPP parallel port.

• Two 16550 Compatible UART serial ports.

• One floppy port supports two FDD of 360KB, 720KB, 1.2MB , 1.44MB and

2.88MB capacity.

• Four USB ports .

• PS/2 keyboard connector.

• PS/2 mouse is supported.

• One Front Panel Sound Connector.

• Infrared (IrDA) is supported via a header.

3

Hardware Configuration

4

Plug-and-Play

• Supports Plug and Play specification 1.1.

• Plug and Play for DOS, Windows® 3.X, Windows® 95/98 as well as
Windows® 2000.

• Fully steerable PCI interrupts.

On-board AC97 Sound

• Integrated AC97 controller with standard AC97 Codec.

• Direct Sound and Sound Blaster compatible.

• Full-Duplex 16-bit record and play back.

• PnP and APM 1.2 support.

• Win® 95/98/2000, NT drivers ready.

• Line-in, Line-out, Mic-in and MIDI/Game port.

Power Management

• Supports SMM, APM and ACPI.

• Break switch for instant suspend/resume on system operations.

• Energy star “Green PC” compliant.

• Hardware monitoring circuit is supported, provide voltage, temperature, fan
speed, etc. monitoring (optional).

• WOL (Wake-On-Lan) header support.

• External Modem Ring-in Wake-up support.

Expansion Slots

• 1 CNR slot (shares 1 PCI slot).

• 1 AGP slot.

• 6 PCI bus master slots - ver. 2.1 compliant (1 PCI shares with CNR slot) (When for
PCI sound on board, bus master card can not use PCI6 slot).

CAUTION

Static electricity can harm delicate components of the motherboard. To prevent
damage caused by static electricity, discharge the static electricity from your
body before you touch any of the computers electronic components.

Technical Reference Booklet

Motherboard Layout

The following diagrams show the relative positions of the jumpers, connectors, major
components and memory banks on the motherboard.

5

# The LAN Connector is optional.
# If you are using standard ATX power supply (without P4 12V power

connector), you MUST connect a peripheral power plug (the plug
supplying power to HDD / CDROM) into JP4. Thus you can use either
ATX 12V power supply or standard ATX power supply for this motherboard
(Noted : NOT all kinds of standard ATX power supply are guaranteed to be
applicable in this motherboard.).

NOTE 1) Be sure to check the cable orientation in order to match the colored strip to the pin

1 end of the connector.

2) When you start up the system, please wait for 5 seconds after you power on AC.

Hardware Configuration

6

Jumper Settings

This chapter explains how to configure the motherboard’s hardware. Before using your
computer, make sure all jumpers and DRAM modules are set correctly. Refer to this
chapter whenever in doubt.

JVSB1

1

EDS1

J8H1

CPU Speed Selection

In this motherboard, jumperless feature is implemented such that no jumper is required to
be set for different type of CPU installed.

Notice:

1. Be sure to save the CMOS setting when exit the CMOS.

2. The CPU is frequency multiplier locked, no CPU speed change will be seen
even if the frequency multiplier setting in CMOS setup is changed.

EDS1 - On Board AC97 Codec Sound

EDS1 Function

2-3 AC97 Sound Disable
1-2* AC97 Sound Enable*

J8H1 - CMOS Clear

J8H1 Selection

1-2* Normal*
2-3 CMOS Clear

JVSB1 - Keyboard Power Select

JVSB1 Select

2-3* Powered by +5V*
1-2 Powered by +5V Standby

(Allows Keyboard Power On)

Pin Assignment

Internal Audio Connector

AUX1 : AUX-IN

1

Technical Reference Booklet

Pin Assignment

1AUX-L
2 GND
3 GND

4AUX-R

CDS1 : CD-IN

1

Pin Assignment

1 CD-L
2 GND
3 GND
4 CD-R

7

CDS2 : CD-IN

R G L G

USB Connector

2

1

8

7

JP4

GND 24
KEYLOCK- 22
GND 20

KEYLOCK+ 16

VCC

IRTX 10
GND 8

IRRX 6
GND 4

SUS+ 2

Pin Assignment

1 CD-R
2 GND
3 CD-L
4 GND

Pin Assignment

1 VCC
2 GND
3 USBP1­4 USBP0+
5 USBP1+
6 USBP0­7 GND
8 VCC

Pin Assignment

1 12V
2 GND
3 GND
4 VCC

FRONT PANEL HEADER

HEADER 2x12

­S

-

18

X

NC
+

14

X

12

+
TX

­RX

- SW
+SUS

CDS3 : CD-IN

G L G R

LINEOUTL

FP1

SPKER

KEYLOCK

RST+

IrDA

LED -

HDD+

LED -

PWR+

PWR+

Front Panel

Sound Connector

10 9

X

MICIN

GND

21

23

+

21 GND

-

19

NC

17 SPEAK

S

SW -

SW -

15 GND
13 RST+
11 HDDLED­9 HDDLED+
7 PWRLED-

5 PWRLED+
3 GND

1 PWR+

Pin Assignment

1 GND
2 CD-L
3 GND
4 CD-R

CN1

LINEOUTR
GND
BIAS
GND
LINEINRLINEINL

VCC

X

Close Open * = Default setting.

Hardware Configuration

8

Hardware Setup

To Install DIMMs

1. Locate the DIMM sockets.

2. Holding the DIMM by the edges, remove it from its antistatic package.

3. Make sure the clips at either end of the socket are pushed away from the socket.

Clip

DIMM Socket

Notch

4. Position the DIMM above the socket. Align the two small notches in the bottom
edge of the DIMM with the keys in the socket.

5. Insert the bottom edge of the DIMM into the socket.

6. When the DIMM is seated, push down on the top edge of the DIMM until the retaining
clips at the ends of the socket snap into place. Make sure the clips are firmly in
place.

Turn system power off before installing and removing any
device, otherwise you’ll cause the system damage.

DIMM

Clip

Technical Reference Booklet

Installing a New Processor

An upgrade processor can dramatically increase general system speed and performance.
Most microprocessor upgrade kits include the following items:

• Microprocessor chip

• Installation instructions and technical data

Before installing the processor, please refer to the installation notes that
available with the CPU package.

To Install a Processor to ZIF Socket

To install the processor, follow these steps:

1. If the system microprocessor is already on the motherboard socket, you need to
remove it from the motherboard socket. The socket is a Zero Insertion Force (ZIF)
socket which has a metal arm at one side. Carefully grasp this arm, move it horizontally
away from the socket and lift it up. Eventually you will be able to lift the chip straight
up out of the socket. Be careful not to bend any pins.

Be careful not to bend any of the pins when removing the microprocessor
chip from its socket. The microprocessor chip can be permanently damaged.

2. Unpack the new microprocessor chip.

3. Carefully align the processor with the correct orientation to the socket on the
motherboard.

4. Carefully insert the processor into the socket, and move the metal arm downward to
replace it in its original position.

9

Connect the Cooling Fan Connector

The CPU should always have a Heat Sink and cooling fan attached to prevent
overheating.

Please follow the setup to install the Heat Sink and cooling fan. Then connect the
processor fan cable to the fan connector that located on the motherboard near the
processor and ensure the fan can operate. Otherwise the CPU can overheat and cause

damage to both CPU and motherboard.

Setting the Processor Speed

After you install the processor into the motherboard, set the processor speed by CMOS
setup.

Hardware Setup

10

BIOS Setup

This chapter discusses Award’s Setup Program built into the ROM BIOS. The Setup
Program allows users to modify the basic system configuration. This special information
is then stored in battery-backed RAM, which retains the setup information when the
power is turned off.

Starting Setup

The Award BIOS is immediately activated when you turn on the computer. The BIOS
reads the system information contained in the CMOS and begins the process of checking
out the system and configuring it. When it finishes, the BIOS will seek an operating
system on one of the disks and then launch and turn control over to the operating
system.

While the BIOS is in control, the Setup Program can be activated :

1. By pressing <Del> immediately after switching the system on, or

2. By pressing the <Del> key when the following message appears briefly at
the bottom of the screen during the POST (Power On Self Test )

Press DEL to enter SETUP

If the message disappears before you can respond and you still wish to enter Setup,
restart the system to try again by turning it OFF then ON or pressing the “RESET” button
on the system case. You may also restart by simultaneously pressing the <Ctrl>, <Alt>,
and <Delete> keys. If you do not press the keys at the correct time and the system does
not reset, an error message will be displayed and you will again be asked to ...

PRESS F1 TO CONTINUE, DEL TO ENTER SETUP

Getting Help

Press F1 to pop up a small help window that describes the appropriate keys to use and
the possible selections for the highlighted item. To exit the Help Window press <Esc> or
the F1 key again.

In Case of Problems

If, after making and saving system changes with the Setup Program, you discover that
your computer does not reset, use the Award BIOS defaults to override the CMOS
settings.

Technical Reference Booklet

11

Main Menu

Once you enter the Award BIOS CMOS Setup Utility, the Main Menu will appear on the
screen. The Main Menu allows you to select from various setup functions and two exit
choices. Use the arrow keys to select among the items and press <Enter> to accept and
enter the sub-menu.

CMOS Setup Utility - Copyright (C) 1984-2001 Award Software

Standard CMOS Features



Advanced BIOS Features Load Fail-Safe Defaults



Advanced Chipset Features Load Optimized Defaults



Integrated Peripherals Set Supervisor Password



Power Management Setup Set User Password



PnP/PCI Configurations Save & Exit Setup



PC Health Status Exit Without Saving



Esc : Quit ÏÐÎÍ : Select Item
F10 : Save & Exit Setup

Time, Date, Hard Disk Type ... ...

(Note : The figures of BIOS Setup Menu included here only show a typical
case, and may not be exactly the same as the one on your unit.)

Note that a brief description of each highlighted item will appear at the bottom of the
screen.

Standard This setup page includes all the items of Award™ special standard
CMOS Features features.

Frequency/Voltage Control



Advanced BIOS This setup page includes all the items of Award™ special enhanced
Features features.

Advanced This setup page includes all the items of chipset special features.
Chipset Features

Integrated This section page includes all the items of IDE hard drive and
Peripherals Programmed Input / Output features.

Power This entry only appears if your system supports Power
Management Management “Green PC” standards.
Setup

PNP/PCI This entry appears if your system supports PNP/PCI.
Configurations

PC Health Status Display CPU and Case Fan Speed.
Frequency/ CPU speed setting are settings of CPU speed. You should refer to

Voltage Control your CPU marking.

BIOS Setup

12

Load Fail-Safe The BIOS defaults have been set by the manufacturer and represent
Defaults settings which provide the minimum requirements for your system

Load Optimized The chipset defaults are settings which provide for maximum
Defaults system performance. While Award has designed the

Set Supervisor/ Changes, sets, or disables password. It allows you to limit
User Password access to the system and the Setup Program.

Save & Exit Saves value changes to CMOS and exits setup.
Setup

Exit Without Abandons all CMOS value changes and exits setup.
Saving

Standard CMOS Features

The items in Standard CMOS Setup Menu are divided into 10 categories. Each category
includes one or more setup items. Use the arrow keys to highlight the item and then use
the <PgUp> or <PgDn> key to select the desired value in each item.

to operate.

custom BIOS to maximize performance, the manufacturer
has the right to change these defaults to meet its needs.

CMOS Setup Utility - Copyright (C) 1984-2001 Award Software

Date (mm :dd :yy) Mon. May 21 2001 Item Help
Time (hh :mm:ss ) 11 : 1 : 35

IDE Primary Master [Press Enter 4303 MB]



IDE Primary Slave [None] Change the day, month,



IDE Secondary Master [None] year and century



IDE Secondary Slave [None]



Drive A [1.44M, 3.5 in.]
Drive B [None]

Video [EGA/VGA]
Halt on [All, but keyboard]

Base M emory 640K
Extended Memory 30720K
Total Memory 31744K

ÏÐÎÍMove Enter: Select +/-/PU/PD : Value F10 : Save ESC : Exit F1 :General Help
F5 : Previous Values F6 : Fail-Safe Defaults F7 : Optimized Defaults

(Note : The figures of BIOS Setup Menu included here only show a typical
case, and may not be exactly the same as the one on your unit.)

Technical Reference Booklet

Standard CMOS Features

Menu Level



Date The date format is <day-of-the-week>. <month> <day> <year>.

13

Time The time format is <hour> <Minute> <second> displayed in

Primary These categories identify the types of the two channels that
Master/Primary have been installed in the computer.
Slave/Secondary
Master/SecondaryIf the controller of the HDD interface is SCSI, the selection shall

Drive A Type / This category identifies the types of floppy disk drive A or drive
Drive B Type B that has been installed in the computer.

Video The default setting is EGA/VGA.

Halt on You can select which type of error will cause the system to halt.

24-hour military-time clock. For example, 1 p. m. is displayed
as 13:00:00.

be “None”.

BIOS Setup

14

Advanced BIOS Features

This section allows you to configure your system for basic operation. You have the
opportunity to select the system’s default speed, boot-up sequence, keyboard operation,
shadowing and security.

Advanced Chipset Features

The Chipset Features Setup option is used to change the values of the chipset registers.
These registers control most of the system options in the computer.

This section allows you to configure the system based on the specific features of the
installed chipset. This chipset manages bus speeds and access to system memory
resources, such as DRAM and the external cache. It must be stated that these items
should not be altered. The default settings have been chosen because they provide the
best operating conditions for your system.

Integrated Peripherals

The Integrated Peripherals Setup allows the user to configure the onboard IDE controller,
floppy disk controller, the printer port and the serial ports.

Power Management Setup

The Power Management Setup Menu allows you to configure your system to most save
energy while operating in a manner consistent with your own style of computer use.

PNP/PCI Configurations

This section describes how to configure the PCI bus system. This section covers some
very technical items and it is recommended that only experienced users should make
any changes to the default settings.

PC Health Status

The PC Health Status display CPU and Case Fan Speed.

Frequency/Voltage Control

This section allows you to set CPU Speed.

Set Supervisor/User Password

You can set either supervisor or user password, or both of them. The difference
between them are:

Supervisor Password : You can enter the Setup Program and change

the options of the setup menus.

User Password : You can enter the Setup Program but can not

change the options of the setup menus.

Technical Reference Booklet

15

When you select this function, the following message will appear at the center of the
screen to assist you in creating a password.

ENTER PASSWORD:

Type the password, up to eight characters in length, and press<Enter>. The new password
will clear the previously entered password from the CMOS memory. You will be asked to
confirm the password. Type the password again and press <Enter>. You may also
press <Esc> to abort the selection and operate without a password.

T o disable a password, just press <Enter> when you are prompted to enter the password.
A message will be displayed to confirm that the password is disabled.

PASSWORD DISABLED.

Once the password is disabled, the system will reset and you can enter the Setup
Program freely.

When a password is enabled, you will be prompted to enter it every time you try to enter
setup. This prevents an unauthorized person from changing any setting of your system
configuration.

In addition, when a password is enabled, you can require the BIOS to request a password
every time your system is rebooted. This would further prevent unauthorized use of
your computer.

The password requirement is defined by the Security Option of the BIOS Features Setup
Menu. If the Security Option is set to “System”, the password will be required both at
resetting and at entering setup. If the option is set to “Setup”, the prompt only appears
when you try to enter setup.

BIOS Setup

16

Flash Update Procedure

A program AWDFLASH.EXE is included in the utility diskette or CD (X:\Utility\
AWDFLASH.EXE). The user is recommended to follow the procedure below to update
the flash BIOS.
(X: your CD driver letter).

1. Create a DOS-bootable floppy diskette. Copy the new BIOS file (just obtained or
downloaded) and the utility program AWDFLASH.EXE to the diskette.

2. Allow the PC system to boot from the DOS diskette.

3. At the DOS prompt, key in

AWDFLASH

and hit <ENTER>

4. Enter the file name of the new BIOS.

5. The question: “Do you want to save BIOS (Y/N)” is displayed.

Key in “N” if there is no need to save the existing BIOS content..
Key in “Y” if a backup copy of the existing BIOS is needed.
(A file name has to be assigned to the existing BIOS binary file.)

6. The question : “Are you sure to program (Y/N)” is displayed.

Key in “Y”

7. Wait until the flash-update is completed.

8. Power down the PC system.

9. Restart the PC.

Warning:

DO not turn off or RESET the computer during the flash process.
If you are unsure how to upgrade the BIOS, it is best to take your

computer to an Authorized Service Center and have a trained
technician do the work for you.

Technical Reference Booklet

APPENDIX

AC97 Sound Driver Installation for Windows NT 4.0 and
Windows 2000

Please identify the IC of AC97 Codec of your motherboard before install the sound
driver from CD.

Note : This manual assumes that your CD-ROM device drive letter is D:.

““

Installing the Sound Driver for
Windows NT 4.0 - D:\Intel Chipset\AC97Sound\AD1881\Winnt40\
Windows 2000 - D:\Intel Chipset\AC97Sound\AD1881\Win2000\

Installing the Sound Driver for
Windows NT 4.0 - D:\Intel Chipset\AC97Sound\ALC100\Winnt40\
Windows 2000 - Please use the following steps to complete the Installation.

- Insert the CD Driver disk into the CD-ROM driver, click START.

- Select SETTINGS, and then open the CONTROL PANEL.

- Double Click the SYSTEM item.

- Select HARDWARE.

- Select DEVICE MANAGER.

- Click MULTIMEDIA AUDIO CONTROLLER item.

- Click right button of the mouse, then select PROPERTIES.

- Select the DRIVER item and UPDATE DRIVER.

- The UPDATE DEVICE DRIVER WIZARD will appear. Press the NEXT.

- Click DISPLAY A LIST OF THE KNOW DEVICE, then click NEXT.

- Click SOUND, VIDEO, AND GAME, CONTROLLER, then click NEXT.

- Select HAVE DISK.

- Click BROWSE (Select Path “D:\Intel Chipset\AC97Sound\

ALC100\Win2000\”).

- Select ALCICH.INF.

- Click OPEN.

- Click OK, then select AVANCE AC’97 DRIVER FOR INTEL® 82801BA

CONTROLLER.

- Select NEXT, click YES.

- Select YES.

- When complete, press the Finish button.

- Close the windows of AVANCE AC’97 DRIVER.

- Restart your computer.

AD1881”AD1881”

“

AD1881” AC97 Codec.

““

AD1881”AD1881”

““

ALAL

C100”C100”

“

AL

C100” AC97 Codec.

““

ALAL

C100”C100”

17

APPENDIX

18

Installing the Sound Driver for
Windows NT 4.0 - D:\Intel Chipset\AC97Sound\CS4299\Winnt40\
Windows 2000 - Please use the following steps to complete the Installation.

- Insert the CD Driver disk into the CD-ROM driver, click START.

- Select SETTINGS, and then open the CONTROL PANEL.

- Double Click the SYSTEM item.

- Select HARDWARE.

- Select DEVICE MANAGER.

- Click MULTIMEDIA AUDIO CONTROLLER item.

- Click right button of the mouse, then select PROPERTIES.

- Select the DRIVER item and UPDATE DRIVER.

- The UPDATE DEVICE DRIVER WIZARD will appear. Press the NEXT.

- Click DISPLAY A LIST OF THE KNOW DEVICE, then click NEXT.

- Click SOUND, VIDEO, AND GAME, CONTROLLER, then click NEXT.

- Select HAVE DISK.

- Click BROWSE (Select Path “D:\Intel Chipset\AC97Sound\

CS4299\Win2000\”).

- Select CWAAUDIO.INF.

- Click OK, then click NEXT to install CRYSTAL WDM AUDIO CODEC.

- Select YES, then Click NEXT.

- Select YES.

- When complete, press the Finish button.

- Close the windows of CRYSTAL WDM AUDIO CODEC.

- Restart your computer.

“CS4299”“CS4299”

“CS4299” AC97 Codec.

“CS4299”“CS4299”

Technical Reference Booklet

19

20

Technical Reference Booklet

01532C
