Aries Filterworks AF-10-3621, AF-10-3621-BB, AF-20-3621, AF-20-3621-BB Data Sheet

KEY FEATURES

•

RESINTECH® SBACR MEDIA HAS HIGH CAPACIT Y FOR ORGANICS

•

SUPERIOR PHYSICAL STABILITY TO RESIST BEAD BREAKAGE

•

IMPROVES THE COLOR AND TASTE OF POTABLE WATER SUPPLIES

TANNINS/ORGANICS REMOVAL CARTRIDGES

®

Aries FilterWorks uses ResinTech

SBACR anion exchange resin to remove
Tannins and other organics. This media is a high capacity, strongly basic anion
resin, supplied in chloride or hydroxide form. The high water content and acrylic
structure contribute to its greater capacity for removal in applications where
elevated levels or organics are expected.

APPLICATIONS

COMMERCIAL USE -

Tannin removal is highly recommended for use in multiple and mixed bed
deionizers, wherever complete ion removal and organic fouling resistance
is required. Tannins can prevent iron oxidation. Water softeners, aeration
systems, and iron filters may not perform to capacity.

RESIDENTIAL USE -

Tannins and similar naturally occurring organics cause most of the color in
potable water. They tend to discolor water and give it a bitter taste. They are
not toxic and are harmless to humans. However, their presence can make well
water unpleasant to drink and stain laundry. For this reason, people seek to
treat their water supply for this issue.

LABORATORY • COMMERCIAL • RESIDENTIAL

AF SERIES

TANNINS/ORGANICS REMOVAL

COMPONENT

ABOUT TANNINS/ORGANICS

Tannins are organic matter that cause a yellow to dark tea color in water and may impart taste and odor. This effect is caused by a variety of humic
and fulvic organic acids, which are found in waters influenced by rainfall, and runoff from natural soil and peats into streams, rivers and lakes. Tannins
have also been found in deep groundwater wells.

The structure of the tannin varies from location to location, depending on the vegetation in the area. Tannins are not directly regulated by a govern­mental agency, however there is a secondary drinking water standard of 15 alpha units for color. A secondary drinking water standard is not federally
enforced. Tannins are not a health issue; however, they are aesthetically displeasing.

FEATURES & BENEFITS

• USE OF RESINTECH SBACR

®

ANION EXCHANGE RESIN

High water content and acrylic structure gives greater capacity in applications where high organic levels are expected

• FITS STANDARD RESIDENTIAL AND INDUSTRIAL SIZE HOUSING

AF Series cartridges are double-open end cartridges that fit standard residential and industrial housings

• OVERSIZED CARTRIDGE FOR MAXIMUM MEDIA FILL

AF Series cartridges have up to 50% higher capacity and extend cartridge life, due to the use of larger cartridges

• QUALITY PRODUCED AND MADE IN THE USA

Cartridges are produced by Aries FilterWorks, a division of ResinTech®. Strict quality control over all aspects of cartridge and media production
allows complete traceability of every filter

160 Cooper Road • Building #2, Suite A • West Berlin, NJ 08091-9243, USA • p: 856.626.1550 • f: 856.626.1551 • [e-mail] • ariesfilterworks.com

A Division of ResinTech • Innovations in Ion Exchange

AF SERIES - TANNINS/ORGANICS REMOVAL

1

2

4

TECHNICAL DATA

10” SLIM 20” SLIM 10” SUPER BLUE 20” SUPER BLUE

Diameter (in.) 3.0” 2.9” 4.6” 4.6”

3

Length (in.) 9.9” 20.0” 10.0” 20.0”
Temperature (˚F.)

Min. 40˚ 40˚ 40˚ 40˚
Max 100˚ 100˚ 100˚ 100˚

Pressure (psi)
Min. 20 20 20 20
Max. 125 125 125 125

Micron Rating (µ) 25 25 25 25
Materials of Construction

1. Gasket TPE TPE TPE TPE

2. End Caps PP ABS ABS ABS

3. Pads PE PE PE PE

4. Body / Tube PP ABS ABS ABS

5. Media*

PP Polypropylene
ABS Acrylonitrile Butadiene Styrene

ResinTech

®

Premium SBACR Strong Base Anion Resin

PE Polyester
TPE Thermoplastic Elastomer

TANNINS/ORGANICS DELTA P

5

15.0

12.5

10.0

Delta P (psi)

7.5

5.0

2.5

0

0.200.4 0.60.8

1.0

10” Slim Line

20” Slim Line

10” Super Blue

20” Super Blue

Flow (gpm)

MEDIA

As a division of ResinTech, Inc.®, Aries FilterWorks is the only integrated water filtration media and
cartridge manufacturer providing a premium product at the most competitive cost. Aries builds
technology and knowledge of ion exchange and specialty adsorbents into each cartridge. Strict
quality control over all aspects of cartridge production allows complete traceability of every filter.

3

ORDERING GUIDE

2

MEDIAPART NUMBER STANDARD HOUSING

DIAMETER X LENGTH

SERVICE FLOW

RATE (GPM)

GALLONS

CAPACITY

GRAINS

AF-10-3621 2.5” x 10” 0.3 150 930
AF-20-3621 2.5” x 20” 0.6 280 1,654
AF-10-3621-BB 4.5” x 10” 0.5 300 1,880

ResinTech® SBACR

Strong Base
Anion Resin

AF-20-3621-BB 4.5” x 20” 1.5 700 4,142

COMPONENT

NSF/ANSI Standard 42 and NSF/ANSI Standard 61

Filter cartridge Certified to NSF/ANSI Standard 372

Filter cartridge Certified to

for material requirement(s) only.

for low lead compliance.

Notes: Ordering information subject to change without notice. Please verify all specifications prior to ordering.

To place an order call [phone] or e-mail [e-mail]

The following is made in lieu of all other warranties expressed or implied. Manufacturer’s and Seller’s only obligation shall be to issue credit against the purchase or replacement of the equipment proved to be defective in material or workmanship. Neither Manufacturer nor Seller
shall be liable for any injury, loss or damage, direct or indirect, special or consequential, arising out of the use of, misuse, or the inability to use such product. The information contained herein is based on technical data and tests which we believe to be reliable and is intended for
use by persons having technical skill at their discretion and risk. Since conditions of use are outside ResinTech’s control, we can assume no liability whatsoever for results obtained or damages incurred through the application of the data presented. This information is not intended
as a license to operate under, or a recommendation to infringe upon, any patent of ResinTech’s or others covering any material or use. The foregoing may not be altered except by written agreement signed by officers of the manufacturer.

IMPORTANT NOTICE TO USER:

DS-AFTannins/Organics-rev1.5
