1
All contents are subject to change. Please refer to the dealer extranet for the most up-to-date information and specific model fit up references.
ACCESSORIES
AND ATTACHMENTS
TIRE
CHAINS
CAST
IRON
GEAR
CASE
DISPLAY
Show your customers why and how an Ariens is superior to all other brands. Showcase the power, design and manufacture of the gear case with this cut-out gear case display. Includes stand.
FEATURES:
■Actual heavy-duty cast iron gear case used on Ariens deluxe and larger Sno-Thro machines
■Displays internal workings of gears
■Demonstrates superior product craftsmanship and engineering
72101500
2 | www.ariens.com
Ariens Sno-Thro tire chains are
a heavy twist link design intended for deeper lug tires. Superior Two Link
spaced cross chains provide added traction.
72000900
For use on Ariens® 920013 and 920014 Sno-Thro Models and Sno-Tek 920402 and 920404 models
72601800
For use on Ariens® Sno-Thro models 92102800, 92102900, 92103200, 92103500, 92603800, 92603900,
92604000, 92605300, 92605400 and 92605500. Ariens Power Brush models 92604500 and 92605700.
Gravely Power Brush models 92604600, 92605800 and 92605900
72001100
For use on Sno-Tek 920403 model
72101600
For use on Ariens 92101300, 92101700, 92101800, 92102200, 92102400, 92102700, 92103000 and 92103100.
Ariens Power Brush model 92102500. Gravely Power Brush model 92102600
AUTO-TURN
DISPLAY
Shows the control, precise turning ability and smooth operation of the AutoTurn Steering feature on select
Deluxe, Platinum, Professional and Hydro-Pro models.
72102000
SHEAR BOLT
KITS
Shear bolts protect your most expensive Ariens® Sno-Thro component — the gear box. Ariens shear bolts are engineered to exact specifications (unknown to anyone else in the
industry) and are specifically designed to rupture at the designed load limit every time. Manufactured
to ensure the greatest uniformity, they are quality tested using proprietary equipment and procedures. They are made specifically for use in Ariens equipment, so using any other kind would jeopardize your Ariens.
FEATURES:
■Engineered to exacting design specifications
■Ultimate strength, accuracy and uniformity
■Assured load limit rupture
■Proprietary testing
■Use assures warranty
53108100
831 SERIES/AMP SHEAR BOLT/NUT KIT
One (03188800) shear bolt and one (06529800) nut. Must order in multiples of three.
53200500
COMPACT/SNO-TEK SHEAR BOLT/NUT KIT
One (03204300) shear bolt and one (06529700) nut. Must order in multiples of three.
51001500
PROFESSIONAL/DELUXE SHEAR BOLT/NUT KIT
One (01019500) shear bolt and one (06529800) nut. Must order in multiples of three.
52100100
BLACK PROFESSIONAL/DELUXE SHEAR BOLT/NUT KIT
One (00659100) shear bolt and one (06529800) nut. Must order in multiples of three.
SNO -THRO®
SHEAR BOLT CADDY
This handy caddy keeps two extra shear bolts and nuts on the machine for easy access. Easy to install. Simply clip on the machine pedestal.
FEATURES:
■Keeps shear bolts close and easy to find
■Assures quick repair
72101700*
For use on Ariens Deluxe and Pro models
72001200*
For use on Ariens AMP, Compact and Sno-Tek models
*Please Note: Caddy is standard equipment on models built after 9/1/11.
POINT OF SALE BOXES
Increase awareness. Boost sales. Put your Ariens® shear bolts on display with these durable display boxes.
72100100
BLACK DELUXE/PRO SHEAR BOLT/NUT KIT
Kit includes 50 packages with: 3 Shear Bolts (00659100) and 3 Nuts (06529800)
72405900
PROFESSIONAL/DELUXE SHEAR BOLT/NUT KIT
Kit includes 50 packages with: 3 Shear Bolts (01019500) and 3 Nuts (06529800)
73203800
SNO-TEK/ARIENS COMPACT/AMP/SINGLE SPEED SHEAR BOLT KIT
Kit includes 50 packages with: 1 Shear Bolt (03204300) and 1 Nut (06529700)
72100500
DELUXE/PLATINUM/PRO SHEAR BOLT KIT
Kit includes 50 packages with: 1 Bolt (00659100) and 1 Nut (06529800)
3
All contents are subject to change. Please refer to the dealer extranet for the most up-to-date information and specific model fit up references.
ACCESSORIES
AND ATTACHMENTS
GENERATOR ACCESSORIES
FEATURES:
■Keeps dirt, debris and weather out of the motor
■Weather-X™ fabric with water-resistant backing for maximum strength, abrasion and weather protection
■Fast protection when storing or on the job
■Protects against UV damage, rain, dirt, birds and tree sap
■Integrated storage bag
78602700
For use on Ariens and Gravely Inverter Generator
78602800
For use on Ariens and Gravely 5000 Watt Generator
78602900
For use on Ariens and Gravely 7500 Watt Generator
78603200 WHEEL KIT
For use on Ariens and Gravely Inverter Generator
4 | www.ariens.com
MAINTENANCE
KITS
Your machine is engineered to run for years. It’ll run even longer with proper maintenance. Keep your Ariens powering through winter after winter with this kit.
INCLUDES:
■3 Shear Bolts and Nuts — made especially for Ariens® Sno-Thro® models
■Ultra-Fresh™ Fuel Stabilizer — keep gasoline fresh with this safe, non-toxic granular formula
■Snow-Jet, 4.25 oz. — spray it on; snow won’t stick
■Ariens 5W30 engine oil, 32 oz. — keep engine running smoothly, even in the coldest weather
72000800
For use on all Ariens® Compact Sno-Thro® and Sno-Tek models
72101300
For use on all Ariens® Deluxe, Platinum and Professional Sno-Thro® models
PATH-PRO SCRAPER
REPLACEMENT KIT
Contains scraper bar and hardware for replacement.
53803100
For use on all Ariens® Path-Pro models
PATH-PRO
PADDLE/AUGER KIT
A convenient all-in-one kit to replace your augers and paddles.
53802900
For use on all Ariens® Path-Pro models
PATH-PRO
MAINTENANCE KIT
Maintain your Path-Pro Sno-Thro with this handy kit to keep your machine running strong when you need it most.
INCLUDES:
■1 Spark Plug
■Ultra-Fresh™ Fuel Stabilizer — keep gasoline fresh with this safe, non-toxic granular formula
■Snow-Jet, 4.25 oz. — spray it on; snow won’t stick
■Ariens 5W30 engine oil, 16 oz. — keep engine running smoothly, even in the coldest weather
73801000
For use on all Ariens® Path-Pro models
5
All contents are subject to change. Please refer to the dealer extranet for the most up-to-date information and specific model fit up references.
ACCESSORIES
AND ATTACHMENTS
FENDER KIT
Protects the log splitter wheels from falling wood debris and also protects your vehicle from road debris while towing.
71703000
For use on 22 ton Log Splitter
LOG SPLITTER
MUFFLER GUARD
Protects the engine muffler against damage from wood and debris.
71701900
For use on 27 and 34 ton Log Splitters
6 | www.ariens.com
LOG SPLITTER
COVERS
Protects from rain, snow, sun damage, dust, tree sap and birds when splitter is stored or on the job. Heavy-duty polyester fabric is coated for maximum water resistance and repellancy and will not shrink or stretch.
71701500 ENGINE COVER
For use on 22, 27 and 34 ton Log Splitters
71702000
LOG SPLITTER COVER
For use on 22, 27 and 34 ton Log Splitters
LOG SPLITTER
LICENSE PLATE
HOLDER
Mount a license plate or personalized novelty plate to your log splitter with the Log Splitter License Plate Holder. It is designed with durability in mind and includes a light for enhanced visibility.
71701400 (requires 71701300)
For use on 27 and 34 ton Log Splitters
71703200 (requires 71701300)
For use on 22 ton Log Splitters
LOG SPLITTER
TABLE
Increase your workspace with this sturdy Ariens Log Splitter Work Table. This is an excellent addition to your log splitter to provide additional space for staging logs that need further splitting or any other necessary items or equipment.
71702900
For use on 22, 27 and 34 ton Log Splitters
LOG SPLITTER
HYDRAULIC CYLINDER HANDLE
This Log Splitter Hydraulic Cylinder Handle provides a convenient and cool grasp location for converting the log splitter between horizontal and vertical operating positions.
71701800
For use on 27 and 34 ton Log Splitters
LOG SPLITTER
JACK STAND
Helps support the tongue of your Log Splitter when uncoupled from the tow vehicle. Side-mounted crank with a comfortable grip easily raises and lowers the jack.
71702200
For use on 27 ton Log Splitters
LOG SPLITTER
TAIL LIGHT KIT
Give yourself enhanced visibility to those traveling the road with you. The Log Splitter Tail Light Kit provides rear lighting visibility and fulfills trailer lighting required by some state DOT’s.
717013000
For use on 22, 27 and 34 ton Log Splitters (22 ton requires mounting bracket 7170330)
7
All contents are subject to change. Please refer to the dealer extranet for the most up-to-date information and specific model fit up references.
ACCESSORIES
AND ATTACHMENTS
FRONT WEIGHT KIT
NON-ABRASIVE
SKID SHOE KIT
Enhance snow blower balance. Get a cleaner surface. Be more comfortable. The Front Weight kit adds 10 lbs. to the front of your Sno-Thro to equalize weight distribution.
FEATURES:
■Holds scraper blade closer to ground
■Assures cleaner scraping and clearing
72406500
For use on Ariens® 916, 920, 921, 924, 926, 932 and 939 Series Sno-Thro® models (except for 20" housings)
Protect decorative surfaces as well as the integrity of the blade. Two skid shoes and hardware included.
FEATURES:
■Engineered with Ultra High Molecular Weight Polyethylene materials to resist wear
■Protects surfaces from scratching and marring
72600300
For use on Ariens® 916, 920, 921, 924, 926, 932, and 939 Series Sno-Thro® models (except for 20" and 22" housings)
72001300
For use on Sno-Tek models with serial numbers above 75000
72001500
For use on Sno-Tek models 92040200 and 92040300 with serial numbers 75000 and up
CLEAN-OUT KIT
Easily and safely remove snow and ice from the discharge chute and impeller. Installation is easy. Mounting bracket and hardware included.
FEATURES:
■Long reach handle for digging in deep while keeping hands out
■Durable construction to dig out even the most tightly packed snow
■Contoured handle to keep gloves from losing their grip
72407100
For use on Ariens® 2-Stage Sno-Thro® models
8 | www.ariens.com
CLEAN-OUT
KIT WITH BRUSH
It’s a shovel, a scraper and a brush all in one. Removing snow, ice, and buildup has never been easier. It’s easy to install, too, even on competitor’s snow throwers. Mounting bracket and hardware is included.
EACH KIT INCLUDES:
■Brush allows for sweeping of snow without damaging finish
■Scraper lets you chip and scrape ice buildup
■Scoop easily and safely removes snow and ice from the discharge chute and impeller
72408100
For use on Ariens® 2-Stage Sno-Thro® models
