Argos ZTSDT-DW-AR ASSEMBLY INSTRUCTIONS

MADE IN
BRITAIN
New Sywell - Dresser and Stool
Assembly Instructions - Please keep for future reference
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 2 - 25/09/14
Important - Please read these instructions fully before starting assembly
239/6994
247/9684
258/7040
259/7975
Dresser
Dimensions
Width - 77.5cm
Depth - 40cm
Height - 74.5cm
Stool
Dimensions
Width - 43cm
Depth - 35.5cm
Height - 48cm
Safety and Care Advice
Important - Please read these instructions fully before starting assembly
Warning: This unit weighs approximately 24kgs. Please lift with care.
• Check you have all the components and tools listed on pages 2 and 3.
• Remove all fittings from the plastic bags and separate them into their groups.
• Keep children and animals away from the work area, small parts could choke if swallowed.
• Parts of the assembly will be easier with 2 people.
• Make sure you have enough space to layout the parts before starting.
• Do not stand or put weight on the product, this could cause damage.
• Assemble the item as close to its final position (in the same room) as possible.
• Assemble on a soft level surface to avoid damaging the unit or your floor (use opened out unit carton).
1
Care and maintenance
• Only clean using a damp cloth and mild detergent, do no use bleach or abrasive cleaners.
• From time to time check that there are no loose screws on this unit.
• This product should not be discarded with household waste. Take to your local authority waste disposal centre.
Note: If required the next page can be cut out and used as reference throughout the assembly. Keep this page with these instructions for future reference.
• We do not recommend the use of power drill/drivers for
inserting screws, as this could damage the unit. Only use hand screwdrivers.
Safety note: It is recommended that this unit is secured to a wall using the bracket supplied.
• Dispose of all packaging carefully and responsibly.
Components - Panels
Please check you have all the panels listed below
2
1
2 3
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
4
Left Side (DF745)
(745 x 396mm)
Modesty (DF748)
(715 x 243mm)
Rail (DF753)
(715 x 97mm)
Divider (DF887)
(128 x 376mm)
Drawer Front (DF888)
(344 x 122mm) x 2
Top (DF1348)
(745 x 396mm)
Right Side (DF746)
(745 x 396mm)
7
5 6
8
Left Drawer Side (W320-95LH)
(320 x 95mm) x 2
Drawer Base (T328-317)
(328 x 317mm) x 2
Right Drawer Side (W320-95RH)
(320 x 95mm) x 2
9
Drawer Back (W317-95)
(317 x 95mm) x 2
10
11
Stool Base (D0997A)
(400 x 348mm)
Stool Rail (D0998A)
(400 x 144mm) x 2
Stool Side (D0996A)
(451 x 352mm) x 2
Seat Pad (FMANPAD)
(398 x 348mm)
12 13 14 15
Please check you have all the fittings listed below
Tools required
3
Components - Fittings
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
A
Wooden dowel (F22) x 11
B
Metal dowel (F901) x 28
C
D E F
G H I
L
Rule Scissors Hammer
Eye protection (when using a hammer or drill)
Cross-head screwdriver
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
M
J K
9mm Screw (F74) x 4
9mm Screw (F73) x 8
Drawer runner (F1004) x 4
Electric drill (do not use for fitting screws)
Knock-in Peg (F171) x 8
13mm Screw (F79) x 1
Small locking nut (F3) x 4
Large locking nut (F900) x 24
Bracket (F327) x 1
Handle (F315) x 2
25mm Screw (F95) x 4
O
Plastic Nail (F91) x 8
N
Wedgefix (F639) x 4
25mm Screw (F50) x 4
7
Assembly Instructions
4
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Step 1
B
B
B
E
E
E
E
8
9
Step 2
Prepare the 2 drawer fronts
Screw 2 metal dowels into each of the 2 drawer fronts .
Note: Tighten the metal dowels up fully against the panels.
B
7
Prepare the drawer sides
Insert a small locking nut into the hole shown on the left drawer side and the right drawer side .
Note: The arrow on the locking nut must point towards the hole in the edge of the panel.
Step 3
E
8
9
Attach the drawer sides to the drawer fronts
Push the left drawer sides . and right drawer sides . onto the back of the drawer fronts .
Turn the small locking nuts on the left drawer side and right drawer side .
Note: Turn the locking nuts clockwise to secure panels - more than 1/2 a turn.
8 9
7
E
E
8 9
8
9
B
B
7
x 2
x 2
x 2
x 2
Assembly Instructions
5
Step 4
C
C
Fit the drawer bases
Slide the drawer base down the grooves in the drawer sides and and down into the groove in the drawer front .
Step 5
Fit the drawer backs
Fit the drawer back between the drawer sides and . Make sure that the drawer base fits into the groove in the drawer back .
Hold the drawer back in position and tap the knock-in pegs through the holes in the drawer sides and .
Step 6
11
8 9
7
10
8 9
11
10
10
C
Attach the handles
Attach a handle to each drawer front using 2 screws .
Note: Do not overtighten the screw.
L
F
7
8 9
Step 7
Fit the wedgefixes
Turn the drawer assemblies over and slide 2 wedgefixes into the front and back grooves, as shown, and tighten up the screws.
N
C
C
N
N
N
11
8
10
8
9
11
9
7
7
F
F
L
x 2
x 2
x 2
x 2
Prepare the left side
a: Place a runner on
the left side . Slide back the top of the runner and use the 2nd hole from the front to fit the 1st screw .
b: Slide the runner
back the other way and fit the 2nd screw into the corresponding hole in the left side .
c: Screw 5 metal
dowels into the left side .
Finished
front edge
Assembly Instructions
6
Step 8
Profiled
front edge
J
M
J
M
a:
b:
c:
1
J
B
1
1
Finished
front edge
Finished
front edge
J
B
B
B
B
1
1
1
B
J
M
Assembly Instructions
7
Step 9
Prepare the right side
a: Place a runner on
the right side . Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw .
b: Slide the runner
back the other way and fit the 2nd screw into the corresponding hole on the right side .
c: Screw 5 metal
dowels into the right side .
2
J
J
M
M
2
B
2
a:
b:
c:
J
Finished
front edge
Finished
front edge
Finished
front edge
J
M
J
M
B
B
B
B
B
Finished
front edge
2
2
2
Finished
front edge
Finished
front edge
A
Prepare the top
Tap 2 wooden dowels into the top .
Note: Wooden dowels must not stick out from the edge by more than 10mm or they may damage other panels.
Screw 2 metal dowels into the top .
Insert 4 large locking nuts into the top .
Note: The arrow on the locking nut must point towards the hole in the edge of the panel.
Assembly Instructions
8
Step 10
D
D
D
10mm
A
A
D
D
B
B
A
3
3
B
D
3
3
Finished
front edge
Fit the top
Push the top onto the right side .
Use a screwdriver to tighten the 2 large locking nuts fitted to the right side .
Note: Turn the large locking nuts as far as they will go - more than 1/2 a turn.
2
3
D
D
2
B
D
Step 11
2
3
A
Finished
front edge
Assembly Instructions
9
Step 12
Finished
front edge
Prepare the divider
a: Place a runner on
the divider as shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw .
b: Slide the runner
back the other way and fit the 2nd screw into the corresponding hole in the divider .
Tap a wooden dowel into the divider .
Insert 2 large locking nuts into the divider . .
Turn the divider over
c: Place a runner on
the divider as shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw .
d: Slide the runner
back the other way and fit the 2nd screw into the corresponding hole in the divider .
6
J
J
D
6
6
6
M
M
6
J
J
6
M
M
c: d:
Note: Due to the manufacturing process, the 2 holes for
the large locking nut can be on either surface of the divider.
Turn the divider over
Finished
front edge
J
M
Finished
front edge
J
M
J
M
J
D
D
Finished
front edge
Finished
front edge
J
M
J
6 6
6 6
A
Finished
front edge
A
Finished
front edge
Assembly Instructions
10
Step 13
Step 14
3
Fit the divider
Push the divider onto the top .
Use a screwdriver to tighten the 2 large locking nuts fitted to the divider .
3
6
D
6
6
Prepare the rail
Tap 2 wooden dowels into the rail .
Insert 2 large locking nuts into the rail .
Step 15
A
5
D
5
Finished
front edge
D
D
A
Fit the rail
Push the rail onto the right side .
Use a screwdriver to tighten the large locking nut fitted to the rail .
2
5
D
5
5
5
2
Note: The large locking nuts can
be on either surface of the divider.
Assembly Instructions
9
Step 16
Prepare the modesty
Insert 4 arge locking nuts into the modesty . .
D
4
D
D
D
D
4
2
Step 17
Fit the rail
Push the modesty onto the right side .
Use a screwdriver to tighten the large locking nut fitted to the modesty .
2
4
D
4
4
Step 18
Fit the left side
Push the left side onto the assembly.
Use a screwdriver to tighten the 5 large locking nuts fitted to the top , modesty and rail .
1
D
3 4
5
4
1
3
5
Assembly Instructions
12
Step 19
Step 20
Fit the drawers
Slide both of the runners . forward and locate the drawer sides and . between them, lining up the holes in the drawer sides with the 2nd 'threaded' holes in the runners.
Working from the inside of the drawer, insert 2 screws through the drawer sides and out into the 2nd threaded hole in the runner.
Note: Do not overtighten the screws. If they catch on the runner you may need to loosen them slightly.
I
M
2nd threaded
hole
M
I
10
11
I
I
8
9
Fit the plastic nails
Tap 2 plastic nails into the bottom edge of each of the sides and . as shown.
1
2
O
1
2
O
O
O
O
Assembly Instructions
13
Step 21
Fit the bracket
To prevent possible overbalancing we recommend that this unit is secured to a suitable wall using the bracket , fitted just below the modesty, on one of the side panels with the screw .
Fixings are not supplied as they will need to suit the wall type, and the length of screw will depend on the distance of the back of the unit to the wall.
Warning: Take care when drilling the wall that you do not drill into any pipes, wires etc. If in doubt, consult an expert.
The assembly of the dresser is complete
K
H
The Bracket can be fitted to either the Left Side or the Right Side.
K
H
Assembly Instructions
14
Step 22
Prepare the 2 stool sides
Screw 6 metal dowels into each of the 2 stool sides , as shown.
Step 23
B
Prepare the stool base
Insert 4 large locking nuts into the holes in the stool base .
Tap 2 wooden dowels into the ends of the stool base .
Step 24
12
13
13
D
Fit a stool side to the stool base
Fit one of the stool sides to the stool base .
Use a screwdriver to tighten the 2 large locking nuts fitted to the stool base .
Note: Turn the large locking nuts as far as they will go - more than 1/2 a turn.
12
13
D
D
13
Step 25
Prepare the 2 stool rails
Insert 4 large locking nuts into each of the 2 stool rails .
Tap 2 wooden dowels into each stool rail .
D
14
A
B
12
D
D
D
D
A
13
D
D
D
D
A
x 6
14
14
x 2
x 2
12
13
A
A
A
Assembly Instructions
15
Step 26
Step 27
Fit the 2 stool rails
Push the 2 stool rails down onto the stool side . , as shown.
Use a screwdriver to tighten the 2 large locking nuts fitted to each stool rail .
14
12
D
14
12
14
Fit the other stool side
a: Push the other stool
side down onto the assembly, as shown.
Use a screwdriver to tighten the 2 large locking nuts fitted to the stool base .
b: Use a screwdriver to
tighten the 2 large locking nuts fitted to each of the stool rails .
14
12
13
12
D
13
b:
a:
D
14
14
14
Assembly Instructions
16
Step 28
Fit the seat pad
Position the seat pad onto the assembly and make sure that its 4 edges line up with the stool base .
Hold the seat pad in position and screw up through the 4 holes in the stool base using screws .
Note: Make sure that you screw into the hard surface of the seat pad.
15
13
G
15
13
15
13
Hard surface
Soft surface
Step 29
Fit the plastic nails
Tap 2 plastic nails into the bottom edge of each of the stool sides as shown.
G
G
G
G
O
O
O
O
12
O
12
12
Assembly Instructions
17
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
and quote the reference numbers on the component pages.
Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW
Step 30
Assembly is complete
ALR3017
MADE IN
BRITAIN
New Sywell - Dresser and Stool
Assembly Instructions - Please keep for future reference
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Issue 4 - 19/02/15
Important - Please read these instructions fully before starting assembly
239/6994
247/9684
258/7040
259/7975
Dresser
Dimensions
Width - 77.5cm
Depth - 40cm
Height - 74.5cm
Stool
Dimensions
Width - 43cm
Depth - 35.5cm
Height - 48cm
Safety and Care Advice
Important - Please read these instructions fully before starting assembly
Warning: This unit weighs approximately 24kgs. Please lift with care.
• Check you have all the components and tools listed on pages 2 and 3.
• Remove all fittings from the plastic bags and separate them into their groups.
• Keep children and animals away from the work area, small parts could choke if swallowed.
• Parts of the assembly will be easier with 2 people.
• Make sure you have enough space to layout the parts before starting.
• Do not stand or put weight on the product, this could cause damage.
• Assemble the item as close to its final position (in the same room) as possible.
• Assemble on a soft level surface to avoid damaging the unit or your floor (use opened out unit carton).
1
Care and maintenance
• Only clean using a damp cloth and mild detergent, do no use bleach or abrasive cleaners.
• From time to time check that there are no loose screws on this unit.
• This product should not be discarded with household waste. Take to your local authority waste disposal centre.
Note: If required the next page can be cut out and used as reference throughout the assembly. Keep this page with these instructions for future reference.
• We do not
recommend the
use of power
drill/drivers for
inserting screws, as this could damage the unit. Only use hand screwdrivers.
Safety note: It is recommended that this unit is secured to a wall using the bracket supplied.
• Dispose of all packaging carefully and responsibly.
Components - Panels
Please check you have all the panels listed below
2
1
2 3
If you have damaged or missing components, call the
Customer Helpline: 03456 400800 quoting the reference
numbers below
4
Left Side (DF745)
(745 x 396mm)
Modesty (DF748)
(715 x 243mm)
Rail (DF753)
(715 x 97mm)
Divider (DF887)
(128 x 376mm)
Drawer Front (DF888)
(344 x 122mm) x 2
Top (DF1348)
(745 x 396mm)
Right Side (DF746)
(745 x 396mm)
7
5 6
8
Left Drawer Side (W516GLH)
(320 x 95mm) x 2
Drawer Base (T328-317)
(328 x 317mm) x 2
Right Drawer Side (W516GRH)
(320 x 95mm) x 2
9
Drawer Back (W317-95)
(317 x 95mm) x 2
10
11
Stool Base (D0997A)
(400 x 348mm)
Stool Rail (D0998A)
(400 x 144mm) x 2
Stool Side (D0996A)
(451 x 352mm) x 2
Seat Pad (FMANPAD)
(398 x 348mm)
12 13 14 15
Please check you have all the fittings listed below
Tools required
3
Components - Fittings
If you have damaged or missing components, call the
Customer Helpline: 03456 400800 quoting the reference
numbers below
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
A
Wooden dowel (F22) x 11
B
Metal dowel (F901) x 28
C
D E F
G H I
L
Rule Scissors Hammer
Eye protection (when using a hammer or drill)
Cross-head screwdriver
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
M
J K
9mm Screw (F74) x 4
9mm Screw (F73) x 8
Drawer runner (F1004) x 4
Electric drill (do not use for fitting screws)
Knock-in Peg (F171) x 8
Small locking nut (F3) x 4
Large locking nut (F900) x 24
Handle (F315) x 2
25mm Screw (F95) x 4
Plastic Nail (F91) x 8
N
Wedgefix (F639) x 4
25mm Screw (F50) x 4
Strap Screw Washer x 2
Overbalance protector kit (F269) x 1
7
Assembly Instructions
4
If you have damaged or missing components, call the
Customer Helpline: 03456 400800 quoting the reference
numbers below
Step 1
B
B
B
E
E
E
E
8
9
Step 2
Prepare the 2 drawer fronts
Screw 2 metal dowels into each of the 2 drawer fronts .
Note: Tighten the metal dowels up fully against the panels.
B
7
Prepare the drawer sides
Insert a small locking nut into the hole shown on the left drawer side and the right drawer side .
Note: The arrow on the locking nut must point towards the hole in the edge of the panel.
Step 3
E
8
9
Attach the drawer sides to the drawer fronts
Push the left drawer sides . and right drawer sides . onto the back of the drawer fronts .
Turn the small locking nuts on the left drawer side and right drawer side .
Note: Turn the locking nuts clockwise to secure panels - more than 1/2 a turn.
8 9
7
E
E
8 9
8
9
B
B
7
x 2
x 2
x 2
x 2
Assembly Instructions
5
Step 4
C
C
Fit the drawer bases
Slide the drawer base down the grooves in the drawer sides and and down into the groove in the drawer front .
Step 5
Fit the drawer backs
Fit the drawer back between the drawer sides and . Make sure that the drawer base fits into the groove in the drawer back .
Hold the drawer back in position and tap the knock-in pegs through the holes in the drawer sides and .
Step 6
11
8 9
7
10
8 9
11
10
10
C
Attach the handles
Attach a handle to each drawer front using 2 screws .
Note: Do not overtighten the screw.
L
F
7
8 9
Step 7
Fit the wedgefixes
Turn the drawer assemblies over and slide 2 wedgefixes into the front and back grooves, as shown, and tighten up the screws.
H
C
C
H
H
H
11
8
10
8
9
11
9
7
7
F
F
L
x 2
x 2
x 2
x 2
Prepare the left side
a: Place a runner on
the left side . Slide back the top of the runner and use the 2nd hole from the front to fit the 1st screw .
b: Slide the runner
back the other way and fit the 2nd screw into the corresponding hole in the left side .
c: Screw 5 metal
dowels into the left side .
Finished
front edge
Assembly Instructions
6
Step 8
Profiled
front edge
J
M
J
M
a:
b:
c:
1
J
B
1
1
Finished
front edge
Finished
front edge
J
B
B
B
B
1
1
1
B
J
M
Assembly Instructions
7
Step 9
Prepare the right side
a: Place a runner on
the right side . Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw .
b: Slide the runner
back the other way and fit the 2nd screw into the corresponding hole on the right side .
c: Screw 5 metal
dowels into the right side .
2
J
J
M
M
2
B
2
a:
b:
c:
J
Finished
front edge
Finished
front edge
Finished
front edge
J
M
J
M
B
B
B
B
B
Finished
front edge
2
2
2
Finished
front edge
Finished
front edge
A
Prepare the top
Tap 2 wooden dowels into the top .
Note: Wooden dowels must not stick out from the edge by more than 10mm or they may damage other panels.
Screw 2 metal dowels into the top .
Insert 4 large locking nuts into the top .
Note: The arrow on the locking nut must point towards the hole in the edge of the panel.
Assembly Instructions
8
Step 10
D
D
D
10mm
A
A
D
D
B
B
A
3
3
B
D
3
3
Finished
front edge
Fit the top
Push the top onto the right side .
Use a screwdriver to tighten the 2 large locking nuts fitted to the right side .
Note: Turn the large locking nuts as far as they will go - more than 1/2 a turn.
2
3
D
D
2
B
D
Step 11
2
3
A
Finished
front edge
Assembly Instructions
9
Step 12
Finished
front edge
Prepare the divider
a: Place a runner on
the divider as shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw .
b: Slide the runner
back the other way and fit the 2nd screw into the corresponding hole in the divider .
Tap a wooden dowel into the divider .
Insert 2 large locking nuts into the divider . .
Turn the divider over
c: Place a runner on
the divider as shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw .
d: Slide the runner
back the other way and fit the 2nd screw into the corresponding hole in the divider .
6
J
J
D
6
6
6
M
M
6
J
J
6
M
M
c: d:
Note: Due to the manufacturing process, the 2 holes for
the large locking nut can be on either surface of the divider.
Turn the divider over
Finished
front edge
J
M
Finished
front edge
J
M
J
M
J
D
D
Finished
front edge
Finished
front edge
J
M
J
6 6
6 6
A
Finished
front edge
A
Finished
front edge
Assembly Instructions
10
Step 13
Step 14
3
Fit the divider
Push the divider onto the top .
Use a screwdriver to tighten the 2 large locking nuts fitted to the divider .
3
6
D
6
6
Prepare the rail
Tap 2 wooden dowels into the rail .
Insert 2 large locking nuts into the rail .
Step 15
A
5
D
5
Finished
front edge
D
D
A
Fit the rail
Push the rail onto the right side .
Use a screwdriver to tighten the large locking nut fitted to the rail .
2
5
D
5
5
5
2
Note: The large locking nuts can
be on either surface of the divider.
Assembly Instructions
9
Step 16
Prepare the modesty
Insert 4 arge locking nuts into the modesty . .
D
4
D
D
D
D
4
2
Step 17
Fit the rail
Push the modesty onto the right side .
Use a screwdriver to tighten the large locking nut fitted to the modesty .
2
4
D
4
4
Step 18
Fit the left side
Push the left side onto the assembly.
Use a screwdriver to tighten the 5 large locking nuts fitted to the top , modesty and rail .
1
D
3 4
5
4
1
3
5
Assembly Instructions
12
Step 19
Step 20
Fit the drawers
Slide both of the runners . forward and locate the drawer sides and . between them, lining up the holes in the drawer sides with the 2nd 'threaded' holes in the runners.
Working from the inside of the drawer, insert 2 screws through the drawer sides and out into the 2nd threaded hole in the runner.
Note: Do not overtighten the screws. If they catch on the runner you may need to loosen them slightly.
I
M
2nd threaded
hole
M
I
10
11
I
I
8
9
Fit the plastic nails
Tap 2 plastic nails into the bottom edge of each of the sides and . as shown.
1
2
K
1
2
K
K
K
K
Assembly Instructions
13
Step 21
Fit the overbalance protector kit
To prevent possible overbalancing we recommend that this unit is secured to a suitable wall by fitting of the overbalance protector kit . to the unit, or an alternative fixing method of your choice.
Wall fixings are not supplied as they will need to suit the wall type.
Note: Take care when drilling the wall that you do not drill into any pipes, wires etc. If in doubt, consult an expert.
The assembly of the dresser is complete
N
Attach the
strap to the unit
Attach the
strap to the wall
Wall fixing
(not supplied)
Washer
Strap
Strap
N
N
Example
Screw
(not supplied)
Washer
Screw
UNIT
Assembly Instructions
14
Step 22
Prepare the 2 stool sides
Screw 6 metal dowels into each of the 2 stool sides , as shown.
Step 23
B
Prepare the stool base
Insert 4 large locking nuts into the holes in the stool base .
Tap 2 wooden dowels into the ends of the stool base .
Step 24
12
13
13
D
Fit a stool side to the stool base
Fit one of the stool sides to the stool base .
Use a screwdriver to tighten the 2 large locking nuts fitted to the stool base .
Note: Turn the large locking nuts as far as they will go - more than 1/2 a turn.
12
13
D
D
13
Step 25
Prepare the 2 stool rails
Insert 4 large locking nuts into each of the 2 stool rails .
Tap 2 wooden dowels into each stool rail .
D
14
A
B
12
D
D
D
D
A
13
D
D
D
D
A
x 6
14
14
x 2
x 2
12
13
A
A
A
Assembly Instructions
15
Step 26
Step 27
Fit the 2 stool rails
Push the 2 stool rails down onto the stool side . , as shown.
Use a screwdriver to tighten the 2 large locking nuts fitted to each stool rail .
14
12
D
14
12
14
Fit the other stool side
a: Push the other stool
side down onto the assembly, as shown.
Use a screwdriver to tighten the 2 large locking nuts fitted to the stool base .
b: Use a screwdriver to
tighten the 2 large locking nuts fitted to each of the stool rails .
14
12
13
12
D
13
b:
a:
D
14
14
14
Assembly Instructions
16
Step 28
Fit the seat pad
Position the seat pad onto the assembly and make sure that its 4 edges line up with the stool base .
Hold the seat pad in position and screw up through the 4 holes in the stool base using screws .
Note: Make sure that you screw into the hard surface of the seat pad.
15
13
G
15
13
15
13
Hard surface
Soft surface
Step 29
Fit the plastic nails
Tap 2 plastic nails into the bottom edge of each of the stool sides as shown.
G
G
G
G
K
K
K
K
12
K
12
12
Assembly Instructions
17
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
and quote the reference numbers on the component pages.
Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW
Step 30
Assembly is complete
ALR3017
Loading...
