Argos ZNODTS-DLO-AR ASSEMBLY INSTRUCTIONS

MADE IN

BRITAIN

Dimensions

Width - 100cm

Depth - 40cm

Height - 74cm

Normandy - Dressing Table and Stool

Assembly Instructions - Please keep for future reference

If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800

Issue 1 - 29/09/14

Important - Please read these instructions fully before starting assembly

325/6208

331/1837

356/1962

Safety and Care Advice

Important - Please read these instructions fully before starting assembly

• Warning: This unit weighs approximately 31.5kgs. Please lift with care.

• Check you have all the components and tools listed on pages 2 and 3.

• Remove all fittings from the plastic bags and separate them into their groups.

• Keep children and animals away from the work area, small parts could choke if swallowed.

• Parts of the assembly will be easier with 2 people.

• Make sure you have enough space to layout the parts before starting.

• Do not stand or put weight on the product, this could cause damage.

• Assemble the item as close to its final position (in the same room) as possible.

• Assemble on a soft level surface to avoid damaging the unit or your floor (use opened out unit carton).

1

Care and maintenance

• Only clean using a damp cloth and mild detergent, do no use bleach or abrasive cleaners.

• From time to time check that there are no loose screws on this unit.

• This product should not be discarded with household waste. Take to your local authority waste disposal centre.

Note: If required the next page can be cut out and used as reference throughout the assembly. Keep this page with these instructions for future reference.

• We do not recommend the use of power drill/drivers for

inserting screws, as this could damage the unit. Only use hand screwdrivers.

• Safety note: It is recommended that this unit is secured to a wall using the overbalance kit supplied.

• Dispose of all packaging carefully and responsibly.

Components - Panels

Please check you have all the panels listed below

2

1

2

If you have damaged or missing components, call the

Customer Helpline: 08456 400800 quoting the reference

numbers below

Top (DF631)

(999 x 396mm)

Left Side (DF632)

(718 x 372mm)

Left Upright (DF635)

(125 x 356mm)

Right Side (DF633)

(718 x 372mm)

Right Upright (DF636)

(125 x 356mm)

Drawer Front (DF637)

(496 x 122mm)

Rail (DF640)

(503 x 78mm)

Drawer Base (T482-347)

(482 x 347mm)

Drawer Back (W471-95)

(471 x 95mm)

Left Drawer Side (W350-95LH)

(350 x 95mm)

Right Drawer Side (W350-95RH)

(350 x 95mm)

15

19

16 17

20

Stool Right Drawer Side

(W300-124RH)

(300 x 124mm)

Stool Seat Pad (FHALPAD)

(458 x 300mm)

18

21 22 23

24

25

Stool

3

4

7

8

9

5

6

10

14

11 12 13

Dresser

Stool Left Side (DF342A)

(395 x 328mm)

Stool Base (DF347A)

(478 x 306mm)

Stool Right Side (DF343A)

(395 x 328mm)

Stool Top (DF344A)

(510 x 352mm)

Stool Drawer Back (W441-124)

(441 x 124mm)

Modesty (DF634)

(966 x 244mm) x 2

Left Blanking Panel (DF638)

(242 x 125mm)

Right Blanking Panel (DF639)

(242 x 125mm)

Stool Rail (DF346A)

(478 x 160mm) x 2

Stool Drawer Base (T452-297)

(452 x 297mm)

Stool Drawer Front (DF345A)

(495 x 157mm)

Stool Left Drawer Side

(W300-124LH)

(300 x 124mm)

3

mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170

Ruler - Use this ruler to help correctly identify the screws

Please check you have all the fittings listed below

Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.

Components - Fittings

If you have damaged or missing components, call the

Customer Helpline: 0870 112 1928 or email: Help@ClickSpares.co.uk (quoting your original order number

and the reference numbers below)

B C

D E F

G

Small locking nut (F3) x 4

I

A

Wooden dowel (F22) x 2 Metal dowel (F901) x 38

Large locking nut (F900) x 34

Knock-in Peg (F171GY) x 8

M

Plastic Nail (F91) x 8

K

Wedgefix (F639) x 4

Mini block (F25) x 4

H

9mm Screw (F73) x 8

9mm Screw (F74) x 4

25mm Screw (F50) x 4

JL

JN

Handle (FBARHANDLE ) x 1

a

L b

J

Drawer runner (F1004) x 4

Strap Screw Washer x 2

Overbalance protector kit (F269) x 1

19mm Screw (F461) x 2

Assembly Instructions

4

If you have damaged or missing components, call the

Customer Helpline: 08456 400800 quoting the reference

numbers below

Step 1

B

C

11

12

Step 2

Prepare the drawer front

Screw 2 metal dowels into the drawer front .

Note: Tighten the metal dowels up fully against the panels.

B

10

Prepare the drawer sides

Insert a small locking nut into the hole shown on the left drawer side and the right drawer side .

Note: The arrow on the locking nut must point towards the hole in the edge of the panel.

Step 3

C

11

12

Attach the drawer sides to the drawer front

Push the left drawer sides . and right drawer sides . onto the back of the drawer front .

Turn the small locking nuts on the left drawer side and right drawer side .

Note: Turn the locking nuts clockwise to secure panels - more than 1/2 a turn.

11 12

10

C

11 12

11

12

B

10

Assembly Instructions

5

Step 4

E

Fit the drawer base

Slide the drawer base down the grooves in the drawer sides and and down into the groove in the drawer front .

Step 5

Fit the drawer back

Fit the drawer back between the drawer sides and . Make sure that the drawer base fits into the groove in the drawer back .

Hold the drawer back in position and tap the knock-in pegs through the holes in the drawer sides and .

Step 6

14

11 12

10

13

11 12

14

13

E

11 12

Step 7

Fit the wedgefixes

Turn the drawer assemby over and slide 2 wedgefixes into the front and back grooves, as shown, and tighten up the screws.

K

E

K

14

11

13

11

12

14

12

10

L b

L a

Attach the handle

Attach the handle to the drawer front using 2 screws .

10

L a

L b

10

Finished

front edge

Assembly Instructions

6

Step 8

Prepare the left side

Screw 4 metal dowels into the left side .

Note: Tighten the metal dowels up fully against the panels.

Insert 2 large locking nuts into the left side . .

Note: The arrow on the locking nut must point towards the hole in the edge of the panel.

Gently tap a mini block into the left side , orientated as shown.

B

1

B

D

F

D

1

F

1

D

B

F

Finished

front edge

Step 9

Prepare the right side

Screw 4 metal dowels into the right side .

Insert 2 large locking nuts into the right side .

Gently tap a mini block into the right side , orientated as shown.

B

2

D

2

Step 10

Prepare the 2 modesty panels

Insert 4 large locking nuts into each of the 2 modesty panels .

D

8

F

2

D

8

B

x 2

Finished

edge

Fit the right side

Push the right side into the 2 modesty panels .

Use a screwdriver to tighten the 2 large locking nuts fitted to each modesty .

Assembly Instructions

7

Step 11

Join the 2 modesty panels to the left side

Push the 2 modesty panels onto the left side .

Use a screwdriver to tighten the 2 large locking nuts fitted to each modesty .

Note: Turn the large locking nuts as far as they will go - more than 1/2 a turn.

D

8

1

D

8

2

8

Step 12

8

1

8

B

D

8

Note: Support this modesty until the left side has been fitted in the next step.

Important:

The finished edges on

the modesty panels must

be facing each other

8

2

1

Assembly Instructions

8

Step 13

Finished

front edge

Finished

front edge

Finished

front edge

Finished

front edge

Finished

front edge

H

J

Prepare the left upright

a: Place a runner on

the left upright as shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw .

b: Slide the runner

back the other way and fit the 2nd screw into the corresponding hole in the left upright .

c: Screw a metal dowel

. into the left upright .

Insert 2 large locking nuts into the left upright .

Note: The arrow on the locking nuts must point towards the hole in the edge of the panel.

Turn the left upright over

d: Gently tap a mini

block into the left upright , orientated as shown.

3

H

D

3

J

B

3

H

J

H

D

B

D

F

a:

b:

c:

d:

Turn the left upright over

F

3

Assembly Instructions

9

Step 14

Finished

front edge

Finished

front edge

Prepare the right upright

a: Place a runner on

the right upright as shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw .

b: Slide the runner

back the other way and fit the 2nd screw into the corresponding hole in the right upright .

c: Screw a metal dowel

. into the right upright . .

Insert 2 large locking nuts into the right upright .

Turn the right upright over

d: Gently tap a mini

block into the left upright , orientated as shown.

4

H

D

4

J

B

4

a:

b:

c:

d:

Turn the right

upright over

F

4

Finished

front edge

H

J

H

J

H

D

B

F

Finished

front edge

Finished

front edge

4

A

Assembly Instructions

10

Step 15

Prepare the top

Screw 8 metal dowels into the top .

Note: Tighten the metal dowels up fully against the panels.

B

7

Prepare the rail

Insert 2 large locking nuts into the rail .

Tap 2 wooden dowels into the rail .

Note: Wooden dowels must not stick out from the edge by more than 10mm or they may damage other panels.

D

9

D

A

10mm

A

9

Step 16

Join the rail to the uprights

Push the left upright and the right upright into the rail .

Use a screwdriver to tighten the 2 large locking nuts fitted to the rail .

Step 17

3

4

9

D

Rounded

front edge

7

9

3

4

Finished

front edge

Finished

front edge

Finished

front edge

Finished

front edge

Fit the sides to the top

Lower the left side and right side down onto the top .

Use a screwdriver to tighten the 4 large locking nuts fitted to the left side and right side .

Assembly Instructions

11

Step 18

Fit the uprights to the top

Lower the left upright and right upright down onto the top .

Use a screwdriver to tighten the 4 large locking nuts fitted to the uprights and .

3

4

7

3 4

D

3

4

7

Step 19

1

2

7

D

1

2

1

Shaped

edge

Assembly Instructions

12

Step 20

Step 21

Shaped

edge

Finished

top edge

Finished

top edge

Shaped

edge

6

5

Fit the blanking panels

Position the holes on the back surface of each blanking panel and . over the screws on the mini blocks .

Tighten up the screws in the 4 mini blocks into the holes in the blanking panels and .

5

6

F

5 6

F

Fit the 4 plastic nails

Tap 2 plastic nails into the bottom edge of each of the sides and . .

Carefully stand the unit up for the next step.

M

1

2

M

Warning: The unit is heavy. Lift with care.

2

1

Assembly Instructions

13

Step 22

Fit the drawers

Starting with the bottom drawer, slide both the runners forward and locate the drawer sides and between them, lining up the holes in the drawer wrap with the 2nd 'threaded' holes in the runners .

Working from the inside of the drawer, insert 2 screws through the drawer sides and out into the 2nd threaded hole in the runner.

Note: Do not overtighten the screws . If they catch on the runner you may need to loosen them slightly.

The dressing table assembly is complete

G

J

G

2nd threaded

hole

J

G

11 12

G

11

12

Prepare the stool drawer front

Screw 2 metal dowels into the stool drawer front .

B

20

B

20

Step 23

22

Assembly Instructions

14

Step 24

Step 25

Step 26

Prepare the stool drawer sides

Insert a small locking nut into the hole shown on the stool left drawer side and stool right drawer side .

Note: Arrow on locking nut must point towards hole in edge of panel.

C

21

22

Attach the stool drawer sides to the stool drawer front

Push the stool left drawer side and stool right drawer side onto the back of the stool drawer front .

Turn the small locking nuts on the stool left drawer side and stool right drawer side .

21

22

20

C

21

22

Fit the stool drawer base

Slide the stool drawer base down the grooves in the stool drawer sides and and down into the groove in the stool drawer front .

25

21 22

20

B

C

20

21

C

21

C

22

21

22

25
