MADE IN
BRITAIN
Dimensions
Width - 118.5cm
Depth - 40.5cm
Height - 150cm
Zig Zag - Desk
Assembly Instructions - Please keep for future reference
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 2 - 06/01/15
Important - Please read these instructions fully before starting assembly
357/0551
Safety and Care Advice
Important - Please read these instructions fully before starting assembly
• Warning: This unit weighs
approximately 31.5kgs.
Please lift with care.
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Parts of the assembly will be
easier with 2 people.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor (use opened
out unit carton).
1
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
Note: If required the next page
can be cut out and used as
reference throughout the
assembly. Keep this page with
these instructions for future
reference.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Safety note: It is
recommended that this unit is
secured to a wall using the
overbalance kit supplied.
• Dispose of all packaging
carefully and responsibly.
Components - Panels
Please check you have all the panels listed below
2
1
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Tall Upright (DF1485)
(396 x 388mm)
Back (DF1489)
(1498 x 394mm)
Top Shelf (DF1487)
(390 x 390mm)
Fly End (DF1484)
(774 x 386mm)
2
6
3 4
97
10
Desktop (DF1483)
(1189 x 390mm)
Modesty (DF1492)
(764 x 243mm) x 2
Small Upright (DF1486)
(308 x 388mm) x 3
Base (DF2051)
(390 x 390mm)
Bottom Upright (DF2794)
(308 x 388mm)
Mid Shelf (DF2741)
(390 x 390mm) x 2
5
8
Please check you have all the fittings listed below
3
Components - Fittings
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Note: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may be supplied than are required.
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
A B
D E
F
C
40mm Screw (F910) x 10
Large locking
nut (F900) x 8
Metal dowel (F901) x 8
Tools required
Rule Scissors Hammer
Eye protection
(when using a
hammer or drill)
Cross-head
screwdriver
Electric drill
(do not use for
fitting screws)
Short cross-head
screwdriver
Hollow core
locking nut
(F892) x 22
Small metal dowel
(F893) x 22
Strap Screw Washer x 2
Overbalance protector kit (F269) x 1
Finished
front edge
Finished
front edge
Assembly Instructions
4
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Step 1
Step 2
Prepare the desktop
Screw 2 small metal
dowels into the holes
shown on the desktop .
Note: Tighten the small
metal dowels up fully
against the panels.
Turn the desktop over
Screw 4 small metal
dowels into the
desktop .
D
D
1
D
1
Turn the
desktop over
E
E E
E
E
E
E
Prepare the tall
upright
a: Push 4 hollow core
locking nuts into the
tall upright , making
sure that they are flush
against the panel’s
surface.
Using a hammer, tap in
the pin on the hollow
core locking nut .
Note: The pin should be
tapped in flush with the
top surface of the hollow
core locking nut .
Turn the tall upright over
b: Screw 2 metal
dowels into the tall
upright .
Note: Tighten the metal
dowels up fully against
the panels.
3
A
A
E
3
E
E
3
A
A
Finished
front edge
b:
a:
Turn the tall
upright over
Finished
front edge
D
D
D
D
D
D
1
1
Assembly Instructions
5
Step 3
Step 4
Fit the tall upright to
the desktop
Push the tall upright
onto the desktop .
The 2 hollow core
locking nuts fitted to
the tall upright must
slide over the 2 small
metal dowels fitted to
the desktop .
Insert a screwdriver into
the 2 hollow core locking
nuts and turn the nuts
inside as far as they will
go.
E
3
D
1
E
1
3
E E
D
Prepare the 3 small
uprights
Push 4 hollow core
locking nuts into the
each of the 3 small
uprights , making sure
that they are flush
against the panel’s
surface.
Using a hammer, tap in
the pin on the hollow
core locking nut .
E
4
E
E
E
E
E
Finished
front edge
4
x 3
Step 5
Prepare 1 mid shelf
Screw 4 small metal
dowels into a mid
shelf .
Turn the mid shelf over
Screw 2 small metal
dowels into the mid
shelf .
D
8
D
8
D
Finished
front edge
D
D
D
D
Finished
front edge
8
8
Turn the
mid shelf
over
D
Important:
The mid shelves and base panel are very similar.
For identification, the mid shelves have 2 through-holes.
Important:
The small uprights and the bottom shelf are very similar.
For identification, the 3 small uprights DO NOT have 2
through-holes drilled near the back edge.
The holes on
this side are
through-holes.
Finished
front edge
Finished
front edge
1
3
Assembly Instructions
6
Step 6
Step 7
Finished
front edge
Finished
front edge
Fit a small upright to
the mid shelf
Push a small upright
onto the mid shelf .
The 2 hollow core
locking nuts fitted to
the small upright
must slide over the 2
small metal dowels
fitted to the mid shelf .
Insert a screwdriver into
the 2 hollow core locking
nuts and turn the nuts
inside as far as they will
go.
8
4
E
4
8
Important:
The top surface of the mid shelf
has the 2 small metal dowels
E
4
D
8
Prepare the base
Screw 4 small metal
dowels into the base
. .
D
D
7
D
D
D
Finished
front edge
7
Finished
front edge
Fit the base onto the
small upright
Push the base onto
the small upright .
The 2 hollow core
locking nuts fitted to
the small upright
must slide over the 2
small metal dowels
fitted to the base .
Insert a screwdriver into
the 2 hollow core locking
nuts and turn the nuts
inside as far as they will
go.
7
4
E
4
7
E
4
D
7
Step 8
Assembly Instructions
7
Step 9
Step 10
Finished
front edge
Fit the bottom upright
Push the bottom upright
. onto the base
and mid shelf .
The 4 hollow core
locking nuts fitted to
the small upright
must slide over the 4
small metal dowels
fitted to the base
and mid shelf .
Insert a screwdriver into
the 4 hollow core locking
nuts and turn the nuts
inside as far as they will
go.
7
8
5
E
5
7
8
E
5
D
7
8
Finished
front edge
Prepare the bottom
upright
Push 4 hollow core
locking nuts into the
bottom upright ,
making sure that they are
flush against the panel’s
surface.
Using a hammer, tap in
the pin on the hollow
core locking nut .
Turn the bottom
upright over
Screw 2 metal dowels
into the bottom upright
. .
E
5
E
E
E
E
E
Finished
front edge
5
Turn the
bottom upright
over
A
A
5
A
5
Finished
front edge
Finished
front edge
Assembly Instructions
8
Step 11
8
3
Join the mid shelf
to the tall upright
Push the mid shelf
onto the tall upright .
The 2 hollow core
locking nuts fitted to
the tall upright must
slide over the 2 small
metal dowels fitted to
the mid shelf .
Insert a screwdriver into
the 2 hollow core locking
nuts and turn the nuts
inside as far as they will
go.
E
E
3
D
8
3
8
Step 12
B
B
B
Prepare the 2
modesty panels
Insert 4 large locking
nuts into each of the
modesty panels .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
B
B
B
6
6
x 2
Prepare the fly end
Screw 4 metal dowels
into the fly end .
Push 2 hollow core
locking nuts into the
fly end , making sure
that they are flush
against the panel’s
surface.
Using a hammer, tap in
the pin on the hollow
core locking nut .
2
A
E
2
E
E
E
A
A
2
Step 13
A
A
Finished
front edge
Assembly Instructions
9
Step 14
Step 15
Fit the fly end
Push the fly end onto
the assembly.
The 2 hollow core
locking nuts fitted to
the fly end must slide
over the 2 small metal
dowels fitted to the
desktop .
Insert a screwdriver into
the 2 hollow core locking
nuts and turn the nuts
inside as far as they will
go.
Use a screwdriver to
tighten the 4 large
locking nuts fitted to
the 2 modesty panels .
Fit the 2 modesty
panels
One at a time, push the
modesty panels , onto
the tall upright and
the bottom upright .
Use a screwdriver to
tighten the 4 large
locking nuts fitted to
the 2 modesty panels.
Note: Turn the large
locking nuts as far as
they will go - more than
1/2 a turn.
6
3
5
B
6
2
E
E
D
2
1
E
6
2
1
6
6
6
6
3
5
Note: Support the
modesty panels until the
fly end has been fitted in
the next step.
Note: The finished edges
of the modesty panels
must be facing each other.
B
A
Assembly Instructions
10
Step 16
Step 17
Fit a small upright
Push a small upright
onto the desktop .
The 2 hollow core
locking nuts fitted to
the small upright
must slide over the 2
small metal dowels
fitted to the desktop .
Insert a screwdriver into
the 2 hollow core locking
nuts and turn the nuts
inside as far as they will
go.
1
4
E
4
1
E
4
D
1
Prepare a mid shelf
Screw 2 small metal
dowels into a mid
shelf .
Turn the mid shelf over
Screw 2 small metal
dowels into the mid
shelf .
D
8
D
8
D
Finished
front edge
D
D
Finished
front edge
8
8
Turn the
mid shelf
over
D
4
Assembly Instructions
11
Step 18
Step 19
Fit a small upright
Push a small upright
onto the mid shelf .
The 2 hollow core
locking nuts fitted to
the small upright
must slide over the 2
small metal dowels
fitted to the mid shelf .
Insert a screwdriver into
the 2 hollow core locking
nuts and turn the nuts
inside as far as they will
go.
8
4
E
E
4
D
8
Fit the mid shelf onto
the small upright
Push the mid shelf
onto the small upright .
The 2 hollow core
locking nuts fitted to
the small upright
must slide over the 2
small metal dowels
fitted to the mid shelf .
Insert a screwdriver into
the 2 hollow core locking
nuts and turn the nuts
inside as far as they will
go.
8
4
E
E
4
D
8
4
8
8
Note: Please make sure that the mid shelf is fitted the
correct way around with its holes and small metal
dowels positioned as shown.
8
9
Assembly Instructions
12
Step 20
Step 21
Fit the top shelf
Push the top shelf
onto the small upright .
The 2 hollow core
locking nuts fitted to
the small upright
must slide over the 2
small metal dowels
fitted to the top shelf .
Insert a screwdriver into
the 2 hollow core locking
nuts and turn the nuts
inside as far as they will
go.
9
4
E
E
4
D
9
Prepare the top shelf
Screw 2 small metal
dowels into the top
shelf .
D
9
D
D
Finished
front edge
9
4
Assembly Instructions
13
Step 22
Fit the back
Attach the back to
the assembly using
screws .
Carefully stand the
unit up for the next
step.
10
C
Warning: The
unit is heavy.
Lift with care.
C
10
C
C
C
C
C
C
C
C
C
Assembly Instructions
14
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
and quote the reference numbers on the component pages.
Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW
Step 23
Fit the overbalance
protector
To prevent possible
overbalancing we
recommend that this unit
is secured to a suitable
wall by use of the
overbalance protector kit
. fitted to the unit or, an
alternative fixing method
of your choice.
Wall fixings are not
supplied as they will
need to suit the wall
type.
Note: Take care when
drilling the wall that you
do not drill into any
pipes, wires etc.
If in doubt, consult an
expert.
Assembly is complete
F
Attach the
strap to the unit
Attach the
strap to the wall
Wall fixing
(not supplied)
Washer
Strap
Strap
F
F
Example
Screw
(not supplied)
Washer
Screw
UNIT
Warning: The
unit is heavy.
Lift with care.
ALR3104
Loading...
