Argos ZCP32D-BO-AR, ZCP32D-W-AR, ZCP32D-WO-AR ASSEMBLY INSTRUCTIONS

MADE IN
BRITAIN
Dimensions
Width - 63cm
Depth - 39cm
Height - 75cm
Capella - 3+2 Drawer Chest
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 1 - 28/11/14
Important - Please read these instructions fully before starting assembly
357/7097
330/7559
339/2344
Safety and Care Advice
Important - Please read these instructions fully before starting assembly
Warning: This unit weighs approximately 24kgs. Please lift with care.
• Check you have all the components and tools listed on pages 2 and 3.
• Remove all fittings from the plastic bags and separate them into their groups.
• Keep children and animals away from the work area, small parts could choke if swallowed.
• Parts of the assembly will be easier with 2 people.
• Make sure you have enough space to layout the parts before starting.
• Do not stand or put weight on the product, this could cause damage.
• Assemble the item as close to its final position (in the same room) as possible.
• Assemble on a soft level surface to avoid damaging the unit or your floor (use opened out unit carton).
• We do not recommend the use of power drill/drivers for
inserting screws, as this could damage the unit. Only use hand screwdrivers.
Safety note: If there is any chance of this unit being pulled over by children etc. it is recommended that the unit is secured to a wall using suitable fixings (not supplied).
• Dispose of all packaging carefully and responsibly.
1
Care and maintenance
• Only clean using a damp cloth and mild detergent, do no use bleach or abrasive cleaners.
• From time to time check that there are no loose screws on this unit.
• This product should not be discarded with household waste. Take to your local authority waste disposal centre.
Note: If required the next page can be cut out and used as reference throughout the assembly. Keep this page with these instructions for future reference.
Components - Panels
Please check you have all the panels listed below
2
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Large Drawer Front (D1010A)
(592 x 157mm) x 3
Back (X647-622A)
(647 x 622mm)
12
5
13
15
Large Drawer Base (T575-367)
(575 x 367mm) x 3
8 9
Small Drawer Back (W259 -124)
(259 x 124mm) x 2
Left Drawer Side (W370-124LH)
(370 x 124mm) x 5
Right Drawer Side (W370-124RH)
(370 x 124mm) x 5
1
2
6
Left Side (D1039A)
(744 x 390mm)
Small Left Drawer Front
(DF1852A) (294 x 157mm)
Right Side (D1040A)
(744 x 390mm)
Small Right Drawer Front
(DF1853A) (294 x 157mm)
7
3
Top (DF1848A)
(596 x 369mm)
Rail (D1009A)
(596 x 103mm) x 2
4
14
Small Drawer Base (T270-367)
(270 x 367mm) x 2
11
Large Drawer Back (W564 -124)
(564 x 124mm) x 3
Divider (DF1851A)
(368 x 155mm)
10
Please check you have all the fittings listed below
Tools required
3
Components - Fittings
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
A
Wooden dowel (F22) x 8
B
Metal dowel (F901) x 20
D E
Large locking nut (F900) x 10
F
G H I
K
Rule Scissors Hammer
Eye protection (when using a hammer or drill)
Cross-head screwdriver
Small locking nut (F3) x 10
C
Nail (F51) x 16
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
J
Drawer runner (F1004) x 10
Handle (F930) x 5
25mm Screw (F50) x 10 9mm Screw (F74) x 10 9mm Screw (F73) x 20
L
Knock-in Peg (F171GY) x 20
Plastic Nail (F91) x 4
M
Wedgefix (F639) x 16
N
Strap
Screw Washer x 2
Overbalance protector kit (F269) x 1
Assembly Instructions
4
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Step 1
x 3
Prepare the drawer fronts
Screw 2 metal dowels into the holes shown on the back of each large drawer front .
Note: Tighten the metal dowels up fully against the panels.
B
5
Prepare the drawer sides
Insert a small locking nut into the hole shown on the left drawer side and right drawer side .
Note: The arrow on the locking nut must point towards the hole in the edge of the panel.
B
E
8
9
Step 2
B
B
B
B
5
Step 3
x 3
x 3
x 3
B
E
Attach the drawer sides to the drawer fronts
Push the left drawer sides . and right drawer sides . onto the back of the large drawer fronts .
Turn the small locking nuts on the left drawer side and right drawer side .
Note: Turn the locking nuts clockwise to secure panels - more than 1/2 a turn.
8 9
5
E
E
8 9
E
E
E
8
9
9
8
5
Assembly Instructions
5
Step 4
Attach the handle
Attach a handle to each large drawer front using 2 screws .
K
G
Step 6
5
x 3
G
G
K
5
5
L
L
Fit the large drawer base
Slide the large drawer base down the grooves in the drawer sides and and down into the groove in the large drawer front . .
Step 5
Fit the large drawer back
Fit the large drawer back . between the drawer sides and .
Make sure that the drawer base fits into the groove in the drawer back .
Hold the drawer back in position and tap the knock-in pegs through the holes in the drawer sides and .
13
8 9
5
11
8 9
13
11
11
L
x 3
x 3
x 3
L
L
8
13
13
9
8
8 9
11
M
Fit the wedgefixes
Turn the large drawer assemblies over and slide 4 wedgefixes into the front and back grooves, as shown, and tighten up the screws.
M
M
M
M
M
Step 7
9
Assembly Instructions
6
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Step 8
Prepare the drawer sides
Insert a small locking nut into the hole shown on the left drawer side and right drawer side .
Note: The arrow on the locking nut must point towards the hole in the edge of the panel.
E
8
9
Step 9
Step 10
E
x 2 x 2
E
E
8
9
x 2
B
B
B
E
Prepare the 2 small drawer fronts
Screw 2 metal dowels into the small left drawer front and the small right drawer front .
Note: Tighten the metal dowels up fully against the panels.
B
6
Attach the drawer sides to the small drawer fronts
Push the left drawer sides . and right drawer sides . onto the back of the 2 small drawer fronts and .
Turn the small locking nuts on the left drawer side and right drawer side .
Note: Turn the locking nuts clockwise to secure panels - more than 1/2 a turn.
8
7
9
6
E
E
8 9
9
B
B
B
B
7
6 7
Note: The small right drawer front has a shallow identification mark.
8
6
7
Assembly Instructions
Step 11
L
L
Fit the small drawer base
Slide the small drawer base down the grooves in the drawer sides and and down into the groove in the small drawer fronts . and .
Step 12
Fit the small drawer back
Fit the small drawer back . between the drawer sides and . Make sure that the small drawer base fits into the groove in the small drawer back .
Hold the small drawer back in position and tap the knock-in pegs through the holes in the drawer sides and .
Step 13
14
8 9
6 7
12
8 9
14
12
12
L
Attach the handles
Attach a handle to each small drawer front . and using 2 screws .
Note: Do not overtighten the screw.
K
G
6 7
x 2
x 2
x 2
L
L
9
8
6
7
14
14
9
8
8 9
12
H
8
9
x 2
7
Step 14
M
M
Fit the wedgefixes
Turn the drawer assemblies over and slide 2 wedgefixes into the front and back grooves, as shown, and tighten up the screws.
M
M
G
G
K
Profiled
front edge
Profiled
front edge
Profiled
front edge
Assembly Instructions
8
Step 15
Profiled
front edge
I
J
I
J
Back edge
I
J
Prepare the left side
a: Place 4 runners on
the left side . Slide back the top of the runner and use the 1st hole from the front to fit the 1st screw .
b: Slide the runner back
the other way and use the 3rd hole from the back to fit the 2nd screw .
c: Screw 4 metal
dowels into the left side .
a:
b:
c:
1
I
B
1
I
J
I
J
I
J
I
J
1
1
1
I
I
I
I
B
B
B
B
Assembly Instructions
9
Step 16
Prepare the right side
a: Place 4 runners on
the right side . Slide back the top of the runner and use the 1st hole from the front to fit the 1st screw .
b: Slide the runner back
the other way and use the 3rd hole from the back to fit the 2nd screw . .
c: Screw 4 metal
dowels into the right side .
Profiled
front edge
I
J
Back edge
I
J
I
J
2
I
B
2
a:
b:
c:
2
2
2
I
J
I
J
I
J
I
J
I
I
I
I
B
B
B
B
Profiled
front edge
Profiled
front edge
Profiled
front edge
A
A
Assembly Instructions
10
Prepare the top
Tap 4 wooden dowels into the top as shown.
Note: Wooden dowels must not stick out from the edge by more than 10mm or they may damage other panels.
Insert 4 large locking nuts into the top .
Note: The arrow on the locking nut must point towards the hole in the edge of the panel.
Screw 2 metal dowels into the top .
10mm
A
A
3
3
D
Step 18
B
3
D
D
D
D
A
A
Finished
front edge
3
B
Step 17
B
A
D
D
A
Prepare the rails
Tap 2 wooden dowels into each of the rails .
Insert 2 large locking nuts into each of the rails .
A
4
D
4
4
x 2
Assembly Instructions
11
Step 19
Finished
front edge
Finished
front edge
Prepare the divider
a: Place a runner on
the divider as shown. Slide back the top of runner and use the 1st hole from the front to fit the 1st screw .
b: Slide the runner
back the other way and fit the 2nd screw into the corresponding hole in the divider .
Insert 2 large locking nuts into the divider . .
Turn the divider over
c: Place a runner on
the divider as shown. Slide back the top of runner and use the 1st hole from the front to fit the 1st screw .
d: Slide the runner
back the other way and fit the 2nd screw into the corresponding hole in the divider .
10
I
I
E
10
10
J
J
10
I
I
10
J
J
a: b:
c:
d:
I
E
E
Note: Due to the manufacturing process, the 2 holes for
the large locking nut can be on either surface of the divider.
Finished
front edge
I
Finished
front edge
10
10
10 10
Turn the divider over
Finished
front edge
I
J
I
J
Finished
front edge
I
J
I
J
D
B
Join the divider and top
Push the top onto the divider as shown.
Use a screwdriver to tighten the 2 large locking nuts fitted to the divider . Note: Turn the large locking nuts as far as they will go - more than 1/2 a turn.
3
D
D
10
3
Finished
front edge
Finished
front edge
10
Step 20
10
Assembly Instructions
12
Step 21
D
B
Join the right side and top
Push the top onto the right side as shown.
Use a screwdriver to tighten the 2 large locking nuts fitted to the top .
Note: Turn the large locking nuts as far as they will go - more than 1/2 a turn.
Step 22
3
2
D
D
3
Profiled
front
edge
2
3
Finished
front edge
Note: Support this rail until the left side has been fitted in the next step.
Fit the rails
Push the rails onto the right side as shown.
Use a screwdriver to tighten the 2 large locking nuts fitted to the rails .
4
2
D
4
2
3
Finished
front edge
4
4
Assembly Instructions
13
Step 23
Fit the left side
Push the left side onto the assembly.
Use a screwdriver to tighten the 4 large locking nuts fitted to the top and the rails .
D
1
3
4
y
y
x
b:
C
Fit the back
a: Square up the unit by
making sure that measurement x to x
equals y to y.
b: Place the back
onto the unit.
Nail around the outside edges of the back .
Note: Nails should be spaced about 150mm apart.
15
C
The measurement from top corner X to bottom corner X must be
equal to the measurement from top corner Y to bottom corner Y
a:
15
Step 24
Warning: The unit is heavy. Lift with care.
Fit the 4 plastic nails
Tap 2 plastic nails into the bottom edge of each of the sides and . .
F
1
2
Stand the unit up for the next step.
3
4
4
1
x
F
F
F
F
2
1
15
Assembly Instructions
14
Step 25
Fit the drawers
Starting with the bottom drawer, slide both the runners forward and locate the drawer sides and between them, lining up the holes in the drawer wrap with the 2nd 'threaded' holes in the runners .
Working from the inside of the drawer, insert 2 screws through the drawer sides and out into the 2nd threaded hole in the runner.
Note: Do not overtighten the screws . If they catch on the runner you may need to loosen them slightly.
Assembly is complete
H
J
J
H
2nd threaded
hole
J
H
8 9
Warning: The unit is heavy. Lift with care.
H
6
H
J
H
8
9
Assembly Instructions
15
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
and quote the reference numbers on the component pages.
Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW
Step 25
Strap
Strap
Washer
Washer
Screw
(not supplied)
Screw
Wall fixing
(not supplied)
Wall
Wall
Fit one end of the strap to the wall
Fit the other end of the strap to a
suitable position on the unit
Fit the overbalance protector
To prevent possible overbalancing we recommend that this unit is secured to a suitable wall by fitting of the overbalance protector kit . to the unit or an alternative fixing method of your choice.
Wall fixings are not supplied as they will need to suit the wall type.
N
N
N
Warning: Take care
when drilling the wall that
you do not drill into any
pipes, wires etc. If in
doubt, consult an expert
ALR3120
Loading...
