Argos VCB43B12M ASSEMBLY INSTRUCTIONS

Bagged Large Cylinder
Vacuum Cleaner

Instruction Manual - Please keep for future reference

VCB43B12M

For the relevant accessories

information ,please visit

http://www.argosspares.co.uk/

Or call 08445570320

Important - Please read these instructions fully before installing or using

These instructions contain important information which will help you get the
best from your appliance and ensure safe and correct use and maintenance.

Contents

Safety Information 2-3

Parts 4

Assembly 5

Operation 6-7

Operating the appliance 6

Using the Cleaning Accessories 7

Maintenance 8-10

Disposable dust bags and filters 8

Replacing the dust bag 8

Cleaning the motor filter 9

Cleaning the air filter or HEPA filter 10

Troubleshooting 11

Technical Specifications 12

Guarantee 13

1

Safety Information

Important - Please read all instructions before use and keep for future reference

FOR HOUSEHOLD USE ONLY.
When using the vacuum cleaner,
basic safety precautions should
always be observed, including the
following:

1. Only use the vacuum cleaner
indoors on dry surfaces. Do not
handle the plug or vacuum
cleaner with wet hands. Do not
use outdoors or on wet surfaces.

2. Turn off the vacuum cleaner
controls before disconnecting or
connecting from the mains supply.

3. Always unplug the vacuum
cleaner before connecting or
disconnecting the vacuum hose
and accessories.

4. Children should be supervised
to ensure that they do not play
with the appliance.

5. This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance in
a safe way and understand the
hazards involved.

6. Only use as described in this
manual. Only use
recommended attachments.

7. Do not use the vacuum cleaner
if it has been dropped, damaged,
left outdoors or dropped into
water.

8. Do not use the vacuum cleaner
with a damaged cord or plug. If
the supply cord is damaged,
please consult qualified
technician.

9. Do not pull or carry by cord. Do
not use the cord as a handle,
close a door on the cord or pull
cord around sharp edges or
corners. Do not run the vacuum
cleaner over the cord. Keep the
cord away from heated surfaces.

10. Do not put any objects into
openings. Do not use with any
openings blocked and do not
restrict air-flow. Keep all openings
free of dust, lint, hair or anything
that might reduce airflow.

11. Keep hair, loose clothing,
fingers and all parts of the body
away from openings and moving
parts.

12. Do not pick up hot coals,
cigarette butts, matches or any
hot, smoking or burning objects.

13. Do not pick up flammable or
combustible materials (lighter
fluid, petrol, kerosene etc.) or use
in the presence of explosive
liquids or vapours.

2

Safety Information

Important - Please read all instructions before use and keep for future reference

14. Do not vacuum up harmful or
toxic material (chlorine, bleach,
ammonia, drain cleaner etc.).

15. Do not vacuum up hard or
sharp objects such as glass, nails,
screws, coins, etc.
16 Do not use without ALL of the
filters in place.

17. Take extra care when
vacuuming on stairs.

18. Keep vacuuming area well lit.

19. Store the vacuum cleaner in a
cool, dry area.

20. Turn off the on/off switch
before unplugging the vacuum
cleaner.

21. Only use CE-approved 13
amp extension cords.
Non-approved cords may
overheat. Care should be taken to
arrange the cord so that the cord
cannot be tripped over.

WARNING: Always switch off
and unplug the vacuum cleaner
from the electrical outlet before
assembling, opening or emptying
the dirt container, connecting/
disconnecting the attachments, or
carrying out maintenance or
troubleshooting checks.

CAUTION: The vacuum cleaner
is a very powerful unit. Before
plugging the cord into the electrical
outlet, make sure the switch is in the
‘off’ position. Hold the vacuum
cleaner firmly when starting and in
use.

IMPORTANT: If the inlet, hose or
extension tube is blocked, switch off
the vacuum cleaner and remove the
blockage(s) before re-starting the
vacuum cleaner.

IMPORTANT: We recommend
that filters should be checked and
cleaned periodically.
For washable filters, ensure they are
completely dry before inserting back
into the vacuum cleaner.
Do not wash with detergents. Only
use warm water, max 40°C.

IMPORTANT: The motor is
equipped with a thermal cut-out. If for
any reason the unit should overheat,
the thermostat will automatically turn
the unit off. Should this occur, unplug
the vacuum cleaner from the
electrical outlet and turn off the
switch. Remove dirt container and
empty. Clean filters. Allow the unit to
cool for approximately one (1) hour.
To re-start, plug into an electrical
outlet and switch back on. This
vacuum cleaner is intended for
household use only and NOT for
commercial or industrial use.

PLEASE KEEP INSTRUCTIONS
FOR FURTHER USE

3

Parts

Please familiarise yourself with parts and accessories listed below

2

1

5

678

3

4

10

9

1

Handle lid dust bag compartment

2

On/off button

3

High class H12 HEPA filter underneath grid

4

Button for automatic cord rewinding

5

Button to set the suction power

Tools required for assembly

12

14

11

Hose and handle

12

Combination floor head

6

Dust full indicator

7

Hose inlet

8

Handle

9

Dust bag frame

10

Dust bag

13

Crevice tool

14

Telescopic metal tube

11

13

4
