Argos Tolga - 3drw ASSEMBLY INSTRUCTIONS

Tolga - 3drw
DR8252001
Assembly Instructions - Please keep for future reference
20kg
339/5626
346/0623
343/9238
Dimensions
Width - 75cm
Depth - 40,65cm
Height - 66,6cm
339/5626 BLUE 346/0623 PINK 343/9238 OAK
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the
Argos = 03456 400 800
Tip : To prevent damage,
we recommend that you
build your unit on the
Customer Helpline:
Issue 1 - 27/11/14
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
• Check you have all the components and tools listed on the following pages.
• Remove all fittings from the plastic bags and separate them into their groups.
• Keep children and animals away from the work area, small parts could choke if swallowed.
• Make sure you have enough space to layout the parts before starting.
• During assembly do not stand or put weight on the product, this could cause damage.
• Assemble the item as close to its final position (in the same room) as possible.
• Assemble on a soft level surface to avoid damaging the unit or your floor.
• Parts of the assembly will be easier with 2 people.
• To reduce the likelihood of damaging your product please ensure that your power drill is set on a low torque setting.
• Assembly should be carried out by a competent adult only.
• do not use this item if any components are missing or damaged.
• this item is suitable for childeren from the age of 6.
Glue safety - Take care when using glue, please follow the advice below•
Skin contact: Remove
contamination by washing with soap and water. This procedure should also be followed prior to eating and drinking.
Eye contact: Rinse immediately with clean water for 15 minutes and seek medical advice.
If swallowed: Seek medical advice immediately.
Care and maintenance
• Only clean using a damp cloth and mild detergent, do no use bleach or abrasive cleaners.
Handy Hints
• Assemble all parts and bolts loosely during assembly, only once the product is complete should you fully tighten the bolts
• From time to time check that there are no loose screws on this unit.
• Regularly check and ensure that all bolts and fi ttings are tightend properly.
• This product should not be discarded with household waste. Take to your local authority waste disposal centre.
Note: if required the next page can be cut out and used as reference throughout the assembly. Keep this page with these instructions for future reference.
1
If you have damaged or missing components,
Components - Panels
call the Customer Helpline:
Please check you have all the panels listed below
03456 400 800
Left Side x 1
1
(666 x 386 x 15mm)
P2063
Top x 1
4
(720 x 385 x 18mm)
P1486
Left Drawer Side x 1
9
(350 x 140 x 12.5mm)
LA1614
Right Side x 1
2
(666 x 386 x 15mm)
P2062
Drawer Back x 3
5
(681 x 343 x 2.5mm)
BO2540
Plinth x 2
7
(720 x 70 x 15mm)
P7058
Drawer Back x 1
10
(670 x 140 x 12,5mm)
LA1617
Back x 1
3
(619 x 746 x 2.5mm)
BO2551
Drawer Front x 1
6
(747 x 247 x 18mm)
P4139
Drawer Front x 2
8
(747 x 175 x 18mm)
P4138
Right Drawer Side x 1
11
(350 x 140 x 12.5mm)
LA1615
Left Drawer Side x 2
12
(350 x 120 x 12,5mm)
LA1624
Drawer Back x 2
13
(670 x 120 x12.5mm)
LA1619
Right Drawer Side x 2
14
(350 x 120 x 12,5mm)
LA1625
2
Components - Fittings
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
A
Locking screw x 16 (5x24mm)
D
12.5mm Pozi screw x 42
FK1515
Nail x 30
FK1235
L-Bracket x 1
FK1415
Nail holder x 1
P
FK1011
FK1309
PM1515 RA
FK1010
12mm
Locking nut x 6 (12x10mm)
FK1301
E
10mm Fixing screw drawer x 12
FK1410
Wood dowel x 4 (5x30mm)
FK1234
KJ
Peg, brown x 1
PM1515 LA
NM
Runner left part A x 3
PM1515 RB
Q
FK1012
CB
15mm
Large locking nut x 10 (15x12mm)
FK1400
F
Screw x 1 (4x15mm)
FK1250
IHG
Drawer base support x 18
FA1510
L
Glue x 1
PM1515 LB
O
Runner left part B x 3
ZF99936
R
Runner right part A x 3
Tools required
Phillips screwdriver (medium & large)
Flatblade screwdriver (medium)
7mm Suitable drill bit (for use with wall plug)
Runner right part B x 3
Drill
Spirit level
Setsquare
Wall plug (6mm) and parkerscrew x 1
Small hammer
0102030405060708090 100 110 120 130 140 150
0123456
Ruler/tape measure
Eye protection (when using a hammer or glue)
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100
The screws length is measured from the head to the point (30mm screw shown).
3
105
110 115 120 125 130 135 140 145 150 155 160 165 170
Assembly Instructions
Step - 1
Insert large locking nuts C into plinth 7.
Make sure the ‘arrow’ on locking nuts C points towards the hole in the edge of 7.
Put drop of glue L into the 2 holes of plinth 7.
Put dowels F into the holes of plinth 7.
Do this step twice
Step - 2
Attaching runners a: Fix runner right part A P
on right side 2 as shown usesing 10mm fixing screw drawer E into right side 2.
2x
a:
C
H
7
C
L
H
E
E
A
E
P
P
E
7
C
H
A
A
A
E
Note: look carreful for the right postion.
Screw 24mm locking screw A into right side 2.
Note: Insert 24mm locking screw A as far as shown.
Do not over tighten.
Insert 12,5mm pozi
b:
screw D as shown into right side the 2 to fix runner right part A P.
b:
P
A
A
D
E E
D
E
2
Finished front edge
DD D
P
D
D
D
D
P
P
D
2
P
D
D
Finished front edge
4
Assembly Instructions
Step - 3
Attaching runners a: Fix runner leftpart A N on leftside 1 as shown usesing 10mm fixing screw drawer E into left side 1.
Note: look carreful for the right postion.
Screw 24mm locking screw A into right side 1.
Note: Insert 24mm locking screw A as far as shown.
Do not over tighten.
a:
A
A
A
E
Finished front edge
A
N
E E
E
E
N
E
N
E
1
A
D DD
E
A
b: Insert 12,5mm pozi
screw
right side the 1 to fix runner left part A N.
D as shown into
Step - 4
Insert large locking nuts C into top 4.
Make sure the ‘arrow’ on locking nuts C points towards the hole in the edge of 4.
b:
D
Finished front edge
C
D
D
N
D
C
C
D
N
1
4
D
D
D
D
N
C
C
C
C
Finished front edge
5
Assembly Instructions
Step - 5
Attaching panels
Put drop of glue L into the 2 holes of left side 1 and right side 2 on the bottom of the sides.
1
4
Position left side 1 and right side 2 onto plinth 7 and top 4.
Use a screwdriver to turn locking nuts clockwise to lock.
Step - 6
Fitting back panel
Attach back 3 to the back with the coloured surface facing the inside using nails G. Use nail holder M to hold the nails G vertical and at correct distance as you secure the back 3. Nails G should be spaced about 150mm apart.
G
7
2
7
G
1
2
G
G
G
3
G
G
G
M
G
G
G
G
G
7
1
L
Important:
Furniture MUST be ‘square’ when back is attached.
2
7
G
M
6
Assembly Instructions
Step - 7
Preparing drawer
Insert locking nuts B into left drawer side 9 and right drawer side !.
Make sure the ‘arrow’ on locking nuts B points towards the hole in the edge of 9 and !.
9
Put drop of glue L into the 3 holes of left drawer side 9 and right drawer side !.
Attach left drawer side 9 and right drawer side ! onto drawer back 0.
Insert drawer back 5.
B
11
10
B
L
9
11
10
5
B
A
Step - 8
Screw 24mm locking screw A into drawer front
6.
Note: Insert 24mm locking screw A as far as shown.
Do not over tighten.
Step - 9
Position drawer onto drawer front 6.
Use a screwdriver to turn locking nuts clockwise to lock
A
9
6
A
10
11
5
6
7
Assembly Instructions
Step - 10
a: Turn over drawer.
Fix runner left part B O on left drawer side 9 as shown using 12,5mm pozi screw D. Fix runner right part B Q on right drawer side ! as shown using 12,5mm pozi
screw D.
a:
Q
D
5
5
11
O
9
D
10
b:
Fix runner left part B O
and runner right part B Q using 12,5mm pozi screw
D.
Slide drawer base support I in corner as shown and fix them, using the attached screws .
b:
I
I
I
I
I
I
I
I
5
D
D
O
9
9
D
5
I
I
10
10
I
D
D
D
Q
I
I
8
Assembly Instructions
Step - 11
Preparing drawer
Insert locking nuts B into left drawer side @ and right drawer side $.
Make sure the ‘arrow’ on locking nuts B points towards the hole in the edge of @ and $.
Put drop of glue L into the 3 holes of left drawer side @ and right drawer side $
Attach left drawer side @ and right drawer side $ onto drawer back #.
Insert drawer back 5.
Do this step twice.
Step - 12
Screw 24mm locking screw A into drawer front
6.
2x
2x
14
B
13
5
B
12
13
A
L
12 14
B
A
A
8
Note: Insert 24mm locking screw A as far as shown.
Do not over tighten.
Do this step twice.
Step - 13
Position drawer onto drawer front 8.
Use a screwdriver to turn locking nuts clockwise to lock.
Note: look carefully to the posiions of drawer front 8.
12
13
14
5
13
14
8
12
5
8
9
Assembly Instructions
Step - 14
a: Turn over drawer.
Fix runner left part B O on left drawer side @ as shown using 12,5mm pozi screw D. Fix runner right part B Q on right drawer side $ as shown using 12,5mm pozi
screw D.
a:
12
O
Q
5
O
12
D
Q
5
13
D
14
13
D
D
14
b:
Fix runner left part B O
and runner right part B Q using 12,5mm pozi screw D. Slide drawer base support I in corner as shown and fix them, using the attached nail.
b:
D
12
D
O
I
I
I
I
D
I
I
D
D
Q
D
5
D
D
12
O
13
I
D
I
I
I
I
I
D
D
Q
5
D
13
II
10
Assembly Instructions
Step - 15
Inserting drawers
as shown. For adjusting the drawers see ‘adjustment’ on page ‘drawer adjustment’..
4
6
9
Step - 16
F. Position L-bracket J on
top 4 as shown, fix using screw F.
Note: there is no pre-drilled hole for screw F.
1
12
12
F
J
R
4
8
8
6
Use R to fix on the wall, please see last page for more information.
Use peg K to square your furniture. Knock peg K in, as far as you require, under the end of the side of the forniture. Then snap off flush with the side.
11
1
K
J
F
8
8
K
!
A Guide to - Drawer adjustment
Adjustment
N P
Note: Each drawer can be
adjust for approximately 1mm up or down on each site of the drawer.
Remove drawer, adjust the wheel from runner left part and runner right part as shown.
Insert drawer.
Repeat above steps until the desired result is achieved.
Runner left part A x 2
+1 mm
Runner right part A x 2
-1 mm
0
12
A Guide to - Wall Mounting & Fixings
Important note:
If plastic wall plugs are supplied with your product:
- these are only suitable for use in masonry walls.
If you are in any doubt about the correct wall plugs for your wall, seek professional advice.
Failure of the product due to using incorrect fixings is the responsibility of the installer.
Important: When drilling into walls always
check that there are no hidden wires or pipes etc.
Make sure that the screws and wall plugs being used are suitable for supporting your unit. Consult a qualified tradesperson if you are unsure.
Hints:
1: General rule: Always use a larger screw and wall plug
if you are not sure.
2: Ensure you use the recommended drill bit to match the wall
plug and hole size.
3: Ensure you drill the hole horizontally, do not force the drill or
enlarge the hole.
4: Take extra care when drilling high walls, ceilings and ceramic
tiles. Ensure wall plugs are inserted beyond the thickness of the ceramic tiles to avoid the tiles splitting or cracking.
5: Ensure wall plugs are well fitted and are a tight fit in the
drilled hole.
Types of walls
No.1 “General Purpose” wall plug
Generally aerated blocks should not be used to support heavy loads, use a specialist fitting in this case. For light loads, general purpose wall plugs can be used.
No.2 “Plasterboard” wall plug
You can use one of the following types of wall plug if your walls are made of brick, breeze block, concrete, stone or wood.
No.3 “Cavity Fixing” wall plug
For use with plasterboard partitions or hollow wooden doors.
No.4 “Cavity Fixing-Heavy Duty”
wall plug
No.5 “Hammer Fixing” wall plug
For use with walls stuck with plasterboard. The hamemr fixing allows it to be fixed to the wall rather than the plasterboard. Always check the fixing is secure to the retaining wall.
No.6 “Shield Anchor” wall plug
Heavy loads
For use when attaching light loads on to plasterboard partitions.
Care & Maintenance
13
For use when fitting or supporting heavy loads such as shelving, wall cabinets and coat racks.
Safety: Always check the fitting
and location to ensure your safety in and around the home.
For use with heavier loads such as TV & HiFi speakers and satelite dishes etc.
Fitting: From time to time check the fitting to ensure the wall plugs or screws do not become loose.
Loading...
