MADE IN
BRITAIN
Dimensions
Width - 72cm
Depth - 49cm
Height - 189cm
Stirling - 1 Drawer 2 Door Robe
Assembly Instructions - Please keep for future reference
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 1 - 07/11/14
Important - Please read these instructions fully before starting assembly
343/9049
345/7162
Safety and Care Advice
Important - Please read these instructions fully before starting assembly
• Warning: This unit weighs
approximately 48kgs.
Please lift with care.
• Check you have all the
components and tools listed on
pages 1, 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Parts of the assembly will be
easier with 2 people.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor (use opened
out unit carton).
1
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
Note: If required the next page
can be cut out and used as
reference throughout the
assembly. Keep this page with
these instructions for future
reference.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Safety note: It is
recommended that this unit is
secured to a wall using the
bracket supplied.
• Dispose of all packaging
carefully and responsibly.
Tools required
Rule
ScissorsSquare
Spirit
level
Hammer Bradawl
Eye protection
(when using a
hammer or drill)
Cross-head
screwdriver
Step ladder
Electric drill
(do not use
for fitting
screws)
Components - Panels
Please check you have all the panels listed below
2
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Left Side (D3016A)
(1810 x 457mm)
Right Side (D3017A)
(1810 x 457mm)
1
7
13
2
14
8
6
10
12
9
3
4
5
Hanging Rail (FHR649)
(649mm long)
11
Door (D3019A)
(1553 x 339mm) x 2
Top (D3014A)
(718 x 490mm)
Base (D3015B)
(718 x 490mm)
Horizontal (D3018A)
(659 x 456mm)
Drawer Front (D3000A)
(685 x 245mm)
Left Drawer
Side (W370-195LH)
(370 x 195mm)
Drawer Base (T637-367)
(637 x 367mm)
Right Drawer
Side (W370-195RH)
(370 x 195mm)
Back (X1836-685)
(1836 x 685mm)
Back Rail (D3020A)
(659 x 123mm)
Drawer Back (W626-195)
(626 x 195mm)
Please check you have all the fittings listed below
3
Components - Fittings
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Note: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may be supplied than are required.
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
A B
D E F
G H I
N
L
Small locking
nut (F3) x 2
C
Nail (F51) x 33
40mm Screw (F910) x 16
R
J
9mm Screw (F74) x 2
K
9mm Screw (F73) x 4
38mm Screw (F81) x 4
Knock-in Peg (F171GY) x 4
Large locking
nut (F900) x 2
Metal dowel (F901) x 4
Wooden dowel (F22) x 2
M
Wedgefix (F639) x 4
P
Q
Hinge (F518) x 6
Hinge plate
(F523) x 6
O
13mm Screw (F63) x 14
Rail holder
(F1014) x 2
Strap Screw Washer x 2
Overbalance protector kit (F269) x 1
Foot (F340) x 4
Handle (F463) x 4
S
Drawer runner (F1004) x 2
6
Assembly Instructions
4
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Step 1
A
B
A
C
C
C
C
8
9
Step 2
Prepare the drawer
front
Screw 2 metal dowels
into the drawer front .
Note: Tighten the metal
dowels up fully against
the panels.
A
6
Prepare the drawer
sides
Insert a small locking
nut into the hole
shown on the left drawer
side and the right
drawer side .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
Step 3
C
8
9
Attach the drawer
sides to the drawer
front
Push the left drawer side
. and right drawer side
. onto the back of the
drawer front .
Turn the small locking
nuts on the left
drawer side and right
drawer side .
Note: Turn the locking
nuts clockwise to
secure panels - more
than 1/2 a turn.
8
9
6
C
C
9
8
A
A
6
8
9
Assembly Instructions
5
Step 4
6
F
F
Fit the drawer base
Slide the drawer base
down the grooves in the
large drawer sides
and and down into
the groove in the large
drawer front .
Step 5
Fit the large drawer
back
Fit the drawer back
between the drawer
sides and .
Make sure that the
drawer base fits into
the groove in the drawer
back .
Hold the drawer back
in position and tap the
knock-in pegs
through the holes in the
drawer sides and .
7
8
9
6
10
8 9
7
10
10
F
7
F
F
Attach the handles
Attach 2 handles to
the drawer front using
screws .
O
H
Step 6
6
8
9
8 9
10
8
9
7
H
O
H
O
6
Step 7
Fit the wedgefixes
Turn the large drawer
assembly over and slide
4 wedgefixes into the
front and back grooves,
as shown, and tighten up
the screws.
M
M
M
M
M
M
Finished front edge
Finished front edge
Assembly Instructions
6
Step 8
P
Finished
front edge
I
S
Prepare the left side
a: Fit 3 hinge plates
to the left side
making sure that the slot
is facing towards the
finished front edge.
Push a rail holder into
the left side . Make
sure that it is fitted
straight, in line with the
panel edges and then
secure with screw .
Place a runner onto
the left side . Slide
back the top of runner
and use the 2nd hole
from the front to fit the
1st screw .
Screw a metal dowel
into the left side .
b: Slide the runner
back the other way and
fit the 2nd screw into
the corresponding hole
in the left side .
P
1
N
1
S
1
I
S
I
1
a:
b:
L
A
1
N
L
P
P
P
A
I
S
I
1
1
Assembly Instructions
7
Step 9
Finished
front edge
Finished
front edge
G
G
Finished
front edge
I
S
Prepare the right side
a: Fit 3 hinge plates
to the right side
making sure that the slot
is facing towards the
finished front edge.
Push a rail holder into
the right side . Make
sure that it is fitted
straight, in line with the
panel edges and then
secure with screw .
Place a runner onto
the right side . Slide
back the top of runner
and use the 2nd hole
from the front to fit the
1st screw .
Screw a metal dowel
into the right side .
b: Slide the runner
back the other way and
fit the 2nd screw into
the corresponding hole
in the right side .
P
2
N
2
S
2
I
S
I
2
2
b:
a:
L
A
N
L
P
P
P
A
I
S
P
Finished front edge
2
Finished front edge
2
I
2
Fit the horizontal to
the right side
Attach the horizontal
to the right side using
2 screws .
5
2
G
Step 10
plain
chipboard
surface
5
Finished
front edge
Assembly Instructions
8
Step 11
Step 12
Fit the back rail to the
right side
Push the back rail
onto the right side .
Use a screwdriver to
tighten the large locking
nut fitted to the back
rail .
Note: Turn the large
locking nut as far as it
will go - more than 1/2 a
turn.
12
12
2
B
B
B
A
Note: Support
the back rail
until the left side
has been fitted
in the next step.
12
2
Finished
front edge
D
Prepare the back rail
Insert 2 large locking
nuts into the back rail
. .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
Tap 2 wooden dowels
into the back rail .
Note: Wooden dowels
must not stick out from
the edge by more than
10mm or they may
damage other panels.
12
B
D
12
10mm
D
B
B
B
D
Plain chipboard
surface
12
G
G
G
G
Polystyrene
block
Polystyrene
block
Assembly Instructions
9
Step 13
Step 14
Fit the left side
Push the left side
onto the horozontal
and back rail .
Attach the left side to
the horizontal using 2
screws .
Use a screwdriver to
tighten the large locking
nut fitted to the back
rail .
1
5
12
B
12
G
G
1
5
G
1
5
12
Fit the top
Attach the top to the
left side and right
side using 4 screws
. .
Note: To make it easier
to fit the top and base
panels, place polystyrene blocks from the
packaging underneath
the side panels to raise
the assembly.
3
1
2
G
3
1
2
Assembly Instructions
Step 15
Step 16
1
2
G
G
G
G
4
plain
chipboard
surface
Fit the base
Attach the base to
the left side and right
side using 4 screws
. .
4
1
2
G
Fit the feet
Fit the 4 feet to the
base using 4 screws .
Note: You may find it
easier to turn the foot as
the screw is held with
the screwdriver.
K
G
4
K
K
K
K
10
4
G
Assembly Instructions
11
Step 17
Fit the back
a: Square up the unit by
making sure that
measurement x to x
equals y to y.
b: Place the back
onto the unit.
Nail around the
outside edges of the
back .
Note: Nails should
be spaced about
150mm apart.
Stand the unit up for
the next step.
14
E
14
The measurement from top corner X to bottom corner X must be
equal to the measurement from top corner Y to bottom corner Y
a:
yy
y
x
x
b:
E
14
Warning: The
unit is heavy.
Lift with care.
Step 18
J
J
2nd threaded
hole
S
J
Fit the drawers
Slide both the runners
forward and locate the
drawer sides and
between them, lining up
the holes in the drawer
sides with the 2nd
'threaded' holes in the
runners .
Working from the inside
of the drawer, insert 2
screws through the
drawer sides and out into
the 2nd threaded hole in
the runner.
Note: Do not overtighten
the screws .
If they catch on the
runner you may need to
loosen them slightly.
J
S
S
8 9
J
Assembly Instructions
Step 19
12
Fit the hanging rail
Push hanging rail into
the rail holders fitted
to the side panels.
11
N
11
N
11
Step 20
Prepare the 2 doors
Push fit 3 hinges into
each of the 2 doors .
Secure each hinge with
2 screws .
Note: Before securing
with the screws, make
sure that the hinges are
positioned at 90 degrees
with the edge of the
door.
L
Q
13
x 2
90
Q
Q
L
L
Q
L
L
Q
L
L
13
Assembly Instructions
13
Step 21
Fit doors and handles
Note: The easiest way to
attach each door is
to fit the top hinge first,
then align and fit the
other hinges.
a: Push the hinge
onto the front part of the
hinge plate .
The recess at the bottom
of screw B goes into the
slot in the hinge plate.
b: Keep the hinge
FLAT against the hinge
plate as you slide it
across as far as it will go.
Tighten screw A.
c: The hinge must be
flat against the hinge
plate prior to any
adjustment.
d: The hinge must
NOT be AT AN ANGLE
to the hinge plate
when assembled.
This would indicate that
the recess at the bottom
of screw B had not
located in the slot in the
hinge plate and the hinge
would not be secure.
Remove the hinge from
the hinge plate and then
re-assemble being
careful to follow
instructions a-c.
e: Attach a handle to
each door using
screw .
Q
Q
Q
P
P
P
Q
P
O
H
13
13
e:
a: b:
c: d:
P
Q
P
P
B
P
Q
Q
Q
A
Q
P
B
O
O
H
13
13
Assembly Instructions
Step 22
14
Adjust the doors if
needed
a: Before adjusting the
doors, use a spirit level
to check the base (or
top) of the unit is level,
front-to-back and
side-to-side in the 3
positions shown.
Use suitable packing
pieces (not supplied) to
make the unit level
BEFORE making any
adjustment to the hinges,
as shown.
b: Height adjustment.
Loosen screws A on
hinge plates and move
door up or down as
required.
Retighten screw A.
c: Forward and Back
adjustment.
Loosen screw B on hinge
plate and move door in
or out as required.
Retighten screw B.
d: Sideways
adjustment.
To move door ‘out’
loosen screw C.
To move door ‘in’ tighten
screw C.
b:
c:
d:
a:
A
A
B
C
Assembly Instructions
15
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
and quote the reference numbers on the component pages.
Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW
Step 23
Assembly is complete
R
Warning: The
unit is heavy.
Lift with care.
ALR3105
Fit the overbalance
protector
To prevent possible
overbalancing we
recommend that this unit
is secured to a suitable
wall by use of the
overbalance protector kit
. fitted to the unit or, an
alternative fixing method
of your choice.
Wall fixings are not
supplied as they will
need to suit the wall
type.
Note: Take care when
drilling the wall that you
do not drill into any
pipes, wires etc.
If in doubt, consult an
expert.
R
WALL
Wall fixing
(not supplied)
Screw
(not supplied)
Washer
Strap
R
Strap
Washer
Screw
TOP OF UNIT
R
MADE IN
BRITAIN
Dimensions
Width - 40.5cm
Depth - 39cm
Height - 49.5cm
Stirling - 2 Drawer Bedside
Assembly Instructions - Please keep for future reference
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 1 - 10/11/14
Important - Please read these instructions fully before starting assembly
355/8243
356/5470
Safety and Care Advice
Important - Please read these instructions fully before starting assembly
• Warning: This unit weighs
approximately 12.5kgs.
Please lift with care.
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Parts of the assembly will be
easier with 2 people.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor (use opened
out unit carton).
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Safety note: If there is any
chance of this unit being pulled
over by children etc. it is
recommended that the unit is
secured to a wall using suitable
fixings (not supplied).
• Dispose of all packaging
carefully and responsibly.
1
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
Note: If required the next page
can be cut out and used as
reference throughout the
assembly. Keep this page with
these instructions for future
reference.
Components - Panels
Please check you have all the panels listed below
2
1
2 3
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
4 5
Top (D2990A)
(405 x 390mm)
Small Drawer Front (D2994A)
(372 x 156mm)
Left Side (D2991A)
(413 x 352mm)
Base (D2993B)
(405 x 390mm)
Right Side (D2992A)
(413 x 352mm)
Large Drawer Front (D2995A)
(372 x 245mm)
Drawer Base (T324-347)
(324 x 347mm) x 2
Small Drawer
Back (W313-124)
(313 x 124mm)
Large Drawer
Back (W313-195)
(313 x 195mm)
Small Left Drawer
Side (W350-124LH)
(350 x 124mm)
Small Right Drawer
Side (W350-124RH)
(350 x 124mm)
Large Left Drawer
Side (W350-195LH)
(350 x 195mm)
Large Right Drawer
Side (W350-195RH)
(350 x 195mm)
Back (X439-372)
(439 x 372mm)
6
7 8 9
10 11 12
13
14
Please check you have all the fittings listed below
Tools required
3
Components - Fittings
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Note: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may be supplied than are required.
Rule Scissors Hammer
Eye protection
(when using a
hammer or drill)
Cross-head
screwdriver
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
A B
D E F
G H I
L
Small locking
nut (F3) x 4
C
Nail (F51) x 10
40mm Screw (F910) x 8
M
J
9mm Screw (F74) x 4
K
9mm Screw (F73) x 8
Drawer runner (F1004) x 4
38mm Screw (F81) x 2
Knock-in Peg (F171GY) x 8
Handle (F463) x 2
Large locking
nut (F900) x 4
Metal dowel (F901) x 8
Wooden dowel (F22) x 2
Wedgefix (F639) x 4
N
Foot (F340) x 4
Assembly Instructions
4
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Step 1
A
B
A
C
C
C
C
7
8
Step 2
Prepare the large
drawer front
Screw 2 metal dowels
into the large drawer
front .
Note: Tighten the metal
dowels up fully against
the panels.
A
5
Prepare the large
drawer sides
Insert a small locking
nut into the hole
shown on the large left
drawer side and the
large right drawer side
. .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
Step 3
C
7
8
Attach the large
drawer sides to the
large drawer front
Push the large left drawer
side and large right
drawer side onto the
back of the large drawer
front .
Turn the small locking
nuts on the large left
drawer side and large
right drawer side .
Note: Turn the locking
nuts clockwise to
secure panels - more
than 1/2 a turn.
7
8
5
C
C
8
7
A
A
5
5
7
8
F
F
Assembly Instructions
5
Step 4
8
Fit the drawer base
Slide the drawer base
down the grooves in the
large drawer sides
and and down into
the groove in the large
drawer front .
Step 5
Fit the large drawer
back
Fit the large drawer back
. between the large
drawer sides and .
Make sure that the
drawer base fits into
the groove in the large
drawer back .
Hold the large drawer
back in position and
tap the knock-in pegs
through the holes in the
large drawer sides
and .
13
7
8
5
9
7 8
13
9
9
F
7
8
8
7
13
5
8
8
9
13
7
F
F
Attach the handle
Attach a handle to the
large drawer front
using screw .
L
H
Step 6
5
H
L
5
Assembly Instructions
6
Step 7
Fit the wedgefixes
Turn the large drawer
assembly over and slide
2 wedgefixes into the
front and back grooves,
as shown, and tighten up
the screws.
K
K
K
K
C
C
C
10
11
Step 9
Step 8
A
Prepare the small
drawer front
Screw 2 metal dowels
into the small drawer
front .
Note: Tighten the metal
dowels up fully against
the panels.
A
6
A
A
6
Prepare the small
drawer sides
Insert a small locking
nut into the hole
shown on the small left
drawer side and the
small right drawer side
. .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
C
10
11
6
Assembly Instructions
7
Step 10
B
A
C
10
11
F
F
Fit the drawer base
Slide the drawer base
down the grooves in the
small drawer sides
and and down into
the groove in the small
drawer front .
Step 12
Fit the small drawer
back
Fit the small drawer back
. between the small
drawer sides and .
Make sure that the small
drawer base fits into
the groove in the small
drawer back .
Hold the small drawer
back in position and
tap the knock-in pegs
through the holes in the
small drawer sides
and .
13
10
11
6
12
10 11
13
12
12
F
10
11
F
F
13
10
11
13
12
10
11
Step 11
Attach the small
drawer sides to the
small drawer front
Push the small left drawer
side and small right
drawer side onto the
back of the small drawer
front .
Turn the small locking
nuts on the small left
drawer side and
small right drawer side
. .
10
11
6
C
11
10
6
Profiled
front edge
Assembly Instructions
8
Step 13
Step 15
Step 14
H
L
Fit the wedgefixes
Turn the small drawer
assembly over and slide
2 wedgefixes into the
front and back grooves,
as shown, and tighten up
the screws.
K
K
Attach the handle
Attach a handle to the
small drawer front
using screw .
L
H
6
K
K
6
Prepare the top
Screw 4 metal dowels
into the top .
A
3
A
A
A
A
3
Assembly Instructions
9
Step 16
Finished
front edge
I
M
a:
b:
c:
Prepare the left side
a: Place 2 runners on
the left side . Slide
back the top of runner
and use the 2nd hole
from the front to fit the
1st screw .
b: Slide the runner
back the other way and
fit the 2nd screw into
the corresponding hole
in the left side .
c: Insert 2 large locking
nuts into the left side
. .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
Tap a wooden dowel
into the left side .
Note: Wooden dowels
must not stick out from
the edge by more than
10mm or they may
damage other panels.
1
I
I
B
1
M
M
1
I
M
I
M
I
I
B
B
D
10mm
D
D
Finished
front edge
Finished
front edge
Finished
front edge
B
1
1
1
1
Assembly Instructions
10
Step 17
Prepare the right side
a: Place 2 runners on
the right side . Slide
back the top of runner
and use the 2nd hole
from the front to fit the
1st screw .
b: Slide the runner
back the other way and
fit the 2nd screw into
the corresponding hole
in the right side .
c: Insert 2 large locking
nuts into the right
side .
Tap a wooden dowel
into the right side .
2
I
I
B
2
M
M
2
2
Finished
front edge
I
M
a:
b:
c:
I
M
I
M
Finished
front edge
Finished
front edge
Finished
front edge
I
I
B
B
D
2
2
2
D
Finished
front edge
Finished
front edge
Profiled
front edge
Assembly Instructions
11
Step 18
Note: To make it easier to fit the top and base
panels, place polystyrene blocks from the packaging
underneath the side panels to raise the assembly.
Join the top and right
side
Push the right side
onto the top .
Use a screwdriver to
tighten the 2 large
locking nuts fitted to
the right side .
Note: Turn the large
locking nuts as far as
they will go - more than
1/2 a turn.
3
B
2
B
2
A
B
2
3
Join the left side
Push the left side
onto the top .
Use a screwdriver to
tighten the 2 large
locking nuts fitted to
the left side .
3
B
1
1
Step 19
3
1
Profiled
front edge
Assembly Instructions
12
Step 20
Fit the base
Attach the base to
the left side and right
side using 4 screws
. .
1
4
2
G
G
G
G
G
plain
chipboard
surface
4
1
2
G
4
Fit the feet
Fit the 4 feet to the
base using screws .
Note: You may find it
easier to turn the foot as
the screw is held with
the screwdriver.
N
G
4
N
N
N
Step 21
N
Assembly Instructions
13
Step 22
Fit the back
a: Square up the unit by
making sure that
measurement x to x
equals y to y.
b: Place the back
onto the unit.
Nail around the
outside edges of the
back .
Note: Nails should
be spaced out evenly.
Stand the unit up for
the next step.
14
E
The measurement from top corner X to bottom corner X must be
equal to the measurement from top corner Y to bottom corner Y
a:
14
y
y
x
x
14
b:
E
Assembly Instructions
14
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
and quote the reference numbers on the component pages.
Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW
Step 23
Fit the drawers
Starting with the large
bottom drawer, slide
both the runners
forward and locate the
drawer sides between
them, lining up the holes
in the drawer wrap with
the 2nd 'threaded' holes
in the runners .
Working from the inside
of the drawer, insert 2
screws through the
drawer sides and out into
the 2nd threaded hole in
the runner.
Note: Do not overtighten
the screws .
If they catch on the
runner you may need to
loosen them slightly.
Assembly is complete
J
M
M
J
J
J
2nd threaded
hole
M
J
ALR3106
MADE IN
BRITAIN
Dimensions
Width - 72cm
Depth - 39cm
Height - 86.5cm
Stirling - 4 Drawer Chest
Assembly Instructions - Please keep for future reference
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 1 - 10/11/14
Important - Please read these instructions fully before starting assembly
357/4681
359/1994
Safety and Care Advice
Important - Please read these instructions fully before starting assembly
• Warning: This unit weighs
approximately 27kgs.
Please lift with care.
• Check you have all the
components and tools listed on
pages 1, 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Parts of the assembly will be
easier with 2 people.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor (use opened
out unit carton).
1
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
Note: If required the next page
can be cut out and used as
reference throughout the
assembly. Keep this page with
these instructions for future
reference.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Safety note: It is
recommended that this unit is
secured to a wall using the
bracket supplied.
• Dispose of all packaging
carefully and responsibly.
Tools required
Rule Scissors Hammer
Eye protection
(when using a
hammer or drill)
Cross-head
screwdriver
Electric drill
(only use when
drilling into walls)
Components - Panels
Please check you have all the panels listed below
2
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
1
2
3
6
4
Small Left Drawer
Side (W350-124LH)
(350 x 124mm) x 3
Small Right Drawer
Side (W350-124RH)
(350 x 124mm) x 3
Large Left Drawer
Side (W350-195LH)
(350 x 195mm)
Large Right Drawer
Side (W350-195RH)
(350 x 195mm)
7
8 9
10
11 12
13
14
15
Top (D2996A)
(718 x 390mm)
Left Side (D2997A)
(732 x 352mm)
Right Side (D2998A)
(732 x 352mm)
Base (D2999B)
(718 x 390mm)
Large Drawer Front (D3000A)
(685 x 245mm)
Small Drawer Front (D3001A)
(685 x 156mm) x 3
Back Rail (D3002A)
(659 x 96mm)
Drawer Base (T637-347)
(637 x 347mm) x 4
Small Drawer Back
(W626-124)
(626 x 124mm) x 3
Large Drawer Back
(W626-195)
(626 x 195mm)
Back (X758-685)
(758 x 685mm)
5
Please check you have all the fittings listed below
3
Components - Fittings
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Note: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may be supplied than are required.
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
A B
D E F
G H I
L
Small locking
nut (F3) x 8
C
Nail (F51) x 20
40mm Screw (F910) x 8
M
J
9mm Screw (F74) x 8
K
9mm Screw (F73) x 16
Drawer runner (F1004) x 8
38mm Screw (F81) x 8
Knock-in Peg (F171GY) x 16
Handle (F463) x 8
Large locking
nut (F900) x 6
Metal dowel (F901) x 14
Wooden dowel (F22) x 6
Wedgefix (F639) x 16
N
Foot (F340) x 4
O
Strap Screw Washer x 2
Overbalance protector kit (F269) x 1
Tools required
Rule
Scissors
Hammer
Eye protection
(when using a
hammer or drill)
Cross-head
screwdriver
Electric drill
(only use when
drilling into walls)
6
Assembly Instructions
4
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Step 1
A
B
A
C
C
C
C
8
9
Step 2
Prepare the large
drawer front
Screw 2 metal dowels
into the large drawer
front .
Note: Tighten the metal
dowels up fully against
the panels.
A
6
Prepare the pair of
large drawer sides
Insert a small locking
nut into the hole
shown on the large left
drawer side and the
large right drawer side
. .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
Step 3
C
8
9
Attach the large
drawer sides to the
large drawer front
Push the large left drawer
side and large right
drawer side onto the
back of the large drawer
front .
Turn the small locking
nuts on the large left
drawer side and large
right drawer side .
Note: Turn the locking
nuts clockwise to
secure panels - more
than 1/2 a turn.
8
9
6
C
C
9
8
A
A
6
8
9
F
6
Assembly Instructions
5
Step 4
F
Fit the drawer base
Slide the drawer base
down the grooves in the
large drawer sides
and and down into
the groove in the large
drawer front .
Step 5
Fit the large drawer
back
Fit the large drawer back
. between the large
drawer sides and .
Make sure that the
drawer base fits into
the groove in the large
drawer back .
Hold the large drawer
back in position and
tap the knock-in pegs
through the holes in the
large drawer sides
and .
14
8
9
6
10
8 9
14
10
10
F
8
9
9
8
14
10
14
8
9
F
F
Attach the handles
Attach 2 handles to
the large drawer front
using screw .
L
H
Step 6
6
H
L
H
L
6
Assembly Instructions
6
Step 7
Fit the wedgefixes
Turn the large drawer
assembly over and slide
4 wedgefixes into the
front and back grooves,
as shown, and tighten up
the screws.
K
K
C
C
11
12
Step 9
Step 8
A
Prepare the 3 small
drawer fronts
Screw 2 metal dowels
into each small drawer
front .
Note: Tighten the metal
dowels up fully against
the panels.
A
7
A
A
7
Prepare the 3 pairs of
small drawer sides
Insert a small locking
nut into the hole
shown on the small left
drawer side and the
small right drawer side
. .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
C
11
12
K
K
K
K
C
x 3
x 3 x 3
F
F
7
x 3
x 3
x 3
Assembly Instructions
7
Step 10
B
A
C
11
12
Fit the drawer bases
Slide the drawer base
down the grooves in the
small drawer sides
and and down into
the groove in the small
drawer front .
Fit the small drawer
backs
Fit the small drawer back
. between the small
drawer sides and .
Make sure that the small
drawer base fits into
the groove in the small
drawer back .
Hold the small drawer
back in position and
tap the knock-in pegs
through the holes in the
small drawer sides
and .
14
11
7
7
13
11 12
14
13
13
F
11
12
F
F
14
11
12
14
13
11
12
Step 11
Attach the small
drawer sides to the
small drawer fronts
Push the small left drawer
side and small right
drawer side onto the
back of the small drawer
front .
Turn the small locking
nuts on the small left
drawer side and
small right drawer side
. .
11
12
7
C
12
11
Step 12
12
Assembly Instructions
8
Step 13
Step 15
Step 14
Fit the wedgefixes
Turn the small drawer
assembies over and slide
4 wedgefixes into the
front and back grooves,
as shown, and tighten up
the screws.
K
Attach the handles
Attach 2 handles to
each of the small drawer
fronts using screws .
L
H
7
Prepare the top
Screw 4 metal dowels
into the top .
A
3
H
L
H
L
K
K
K
K
K
7
A
A
A
A
Profiled
front edge
3
x 3
x 3
D
Finished
front edge
Finished
front edge
Finished
front edge
Assembly Instructions
9
Step 16
Finished
front edge
I
M
a:
b:
c:
Prepare the left side
a: Place 4 runners on
the left side . Slide
back the top of runner
and use the 2nd hole
from the front to fit the
1st screw .
b: Slide the runner
back the other way and
fit the 2nd screw into
the corresponding hole
in the left side .
c: Screw a metal dowel
. into the left side .
Insert 2 large locking
nuts into the left side
. .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
Tap 2 wooden dowels
into the left side .
Note: Wooden dowels
must not stick out from
the edge by more than
10mm or they may
damage other panels.
1
I
I
A
1
B
1
M
M
1
10mm
D
D
B
1
I
M
I
M
I
M
I
M
I
I
I
I
B
B
D
A
1
1
1
Assembly Instructions
10
Step 17
Prepare the right side
a: Place 4 runners on
the right side . Slide
back the top of runner
and use the 2nd hole
from the front to fit the
1st screw .
b: Slide the runner
back the other way and
fit the 2nd screw into
the corresponding hole
in the right side .
c: Screw a metal dowel
. into the right side .
Insert 2 large locking
nuts into the right
side .
Tap 2 wooden dowels
into the right side .
2
I
I
B
2
M
M
2
2
Finished
front edge
I
M
a:
b:
c:
D
I
M
I
M
I
M
I
M
I
I
I
I
B
B
D
D
A
Finished
front edge
Finished
front edge
Finished
front edge
2
2
2
A
2
D
Finished
front edge
Profiled
front edge
Assembly Instructions
11
Step 18
Join the top and right
side
Push the right side
onto the top .
Use a screwdriver to
tighten the 2 large
locking nuts fitted to
the right side .
Note: Turn the large
locking nuts as far as
they will go - more than
1/2 a turn.
3
B
2
B
2
A
B
Prepare the back rail
Insert 2 large locking
nuts into the back rail
. .
Tap 2 wooden dowels
into the back rail .
Step 19
Note: To make it easier to fit the top and base
panels, place polystyrene blocks from the packaging
underneath the side panels to raise the assembly.
2
3
B
B
D
B
5
5
D
5
plain chipboard surface
Assembly Instructions
12
Step 20
Fit the back rail
Push the back rail
onto the right side .
Use a screwdriver to
tighten the large locking
nut fitted to the back
rail .
5
B
5
2
5
plain chipboard surface
2
Note: Support the back
rail until the left side has
been fitted in the next step.
Polystyrene
block
Polystyrene
block
Step 21
Fit the left side
Push the left side
onto the top and
back rail .
Use a screwdriver to
tighten the 3 large
locking nuts fitted to
the left side and back
rail .
1
B
5
1
3
5
1
3
5
Assembly Instructions
13
Step 22
Fit the base
Attach the base to
the left side and right
side using 4 screws
. .
1
4
2
G
Fit the feet
Fit the 4 feet to the
base using screws
and tighten them.
Note: You may find it
easier to turn the foot as
the screw is held with
the screwdriver.
N
G
4
Step 23
G
G
G
G
plain
chipboard
surface
4
2
1
G
4
N
N
N
N
Assembly Instructions
14
Step 24
Step 25
Fit the back
a: Square up the unit by
making sure that
measurement x to x
equals y to y.
b: Place the back
onto the unit.
Nail around the
outside edges of the
back .
Note: Nails should
be spaced out evenly.
Stand the unit up for
the next step.
15
E
The measurement from top corner X to bottom corner X must be
equal to the measurement from top corner Y to bottom corner Y
a:
15
b:
E
15
Warning: The
unit is heavy.
Lift with care.
y
y
x
x
Strap
Strap
Washer
Washer
Screw
(not supplied)
Screw
Wall fixing
(not supplied)
Wall
Wall
Fit one end of the strap to the wall
Fit the other end of the strap to a
suitable position on the unit
Fit the overbalance
protector
To prevent possible
overbalancing we
recommend that this unit
is secured to a suitable
wall by use of the
overbalance protector kit
. fitted as shown or an
alternative fixing method
of your choice.
Wall fixings are not
supplied as they will
need to suit the wall
type.
O
O
O
Warning: Take care
when drilling the wall that
you do not drill into any
pipes, wires etc. If in
doubt, consult an expert
Assembly Instructions
15
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
and quote the reference numbers on the component pages.
Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW
ALR3109
Step 26
Fit the drawers
Starting with the large
bottom drawer, slide
both the runners
forward and locate the
drawer sides between
them, lining up the holes
in the drawer wrap with
the 2nd 'threaded' holes
in the runners .
Working from the inside
of the drawer, insert 2
screws through the
drawer sides and out into
the 2nd threaded hole in
the runner.
Note: Do not overtighten
the screws .
If they catch on the
runner you may need to
loosen them slightly.
Assembly is complete
J
M
M
J
2nd threaded
hole
M
J
J
J
Loading...
