Phoenix Wall Desk
Assembly lnstructions - Please keep for future reference
455/5991
497/4479
498/1307
460/6613
Dimensions
Width - 80cm
Depth - 60 cm
Height -180.5 cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800
Issue 1-19-10-15
Safety and Care Advice
Check you have all the
components and tools listed on
pages 2 and 3.
Remove all fittings from the
plastic bags and separate them
into their groups.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
Assemble the item as close
to its final position (in the same
room) as possible.
Assemble on a soft level
surface to avoid damaging the
unit or your floor.
Assembly requires 2 people.
Keep this instructions for future
use.
Do not stand or put excessive
weight on the product, this
could cause damage.
From time to time check that
there are no loose screws on
this unit.
We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers and
Allen keys.
Dispose of all packaging
carefully and responsibly.
This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
1
Components - Parts
lf you have damaged or missing components.
call the Customer Helpline :
0345 6400 800
Desk Top x 1
1
(77x60x1.8cm)
Base Panel x 1
4
(77x29.3x1.5cm)
Top Shelf x 1
7
(77x21.2x1.5cm)
Lower Divider x 1
2
(33x27.4x1.5cm)
Upper Divider
5
(Left And Right) x 2
(19.3x11.6x1.5cm)
Upper Shelf x 1
8
(77x26.5x1.5cm)
Lower Shelf x 1
3
(77x27.5x1.5cm)
6
Top Horizontal Rail X 1
(77x11.7x1.5cm)
Drawer Divider x 1
9
(24.7x11.5x1.5cm)
Drawer Shelf x 1
10
(77x23.5x1.5cm)
Side Panel (Right)x 1
12
(180.6x40x1.5cm)
Middle Divider x 1
11
(32.9x23.2x1.5cm)
2
Components - Parts
13
Side Panel (Left) x 1
(180.6x40x1.5cm)
lf you have damaged or missing components.
call the Customer Helpline :
0345 6400 800
Upper Divider (Middle) x 1
14
(19.3x11.6x1.5cm)
Drawer Back x 2
17
(34.9x8.9x1.2cm)
Drawer Base x 2
19
(35.6x20.8x0.3cm)
Drawer Side (Right) x 2
15
(21.3x9x1.2cm)
Drawer Front x 2
18
(37.4x11.1x1.5cm)
Lower Back Panel x 2
20
(77.7x34x0.3cm)
Drawer Side (Left) x 2
16
(21.3x9x1.2cm)
Middle Back Panel x 1
21
(77.7x47.4x0.3cm)
Upper Back Panel （Extra hole） x 1
22
(77.7x46.7x0.3cm)
Lower Divider x 1
23
(33x27.4x1.5cm)
3
Components - Fittings
0345 6400 800
A
Short 30mm wooden dowel x 46
D
35mm screw x 49
G
F
Crosshead nut x 4
J
F
Plastic trim x 1
M
F
20mm screw x 2
B
Metal dowel x 14
E
Plastic drawer runner x 4
H
F
53mm screw x 4 Allen Key x 1
K
F
Small locking nut x 8
N
F
Plastic Drawer Stop x 4 Plastic Bracket x 14
C
Large locking nut x 6
F
F
10mm screw x 8
F
I
L
F
Handle x 2
O
F
Q
P
F
16mm screw x 14
F
S
Sticker x (24+2)
V
F
Long 50mm wooden dowel x 4
F
Wall Strap x 2
T
F
Sticker x (6+2)
Tools required
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110115 120 125 130135 140 145 150
0
1 2 3 4 5 6
Ruler/tape measure
Ruler - Use this ruler to help correctly identify the screws
R
F
screw x 2
U
F
10mm screw x 3
Phillips screwdriver
(Not supplied)
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120 125 130 135 140 145 150 155 160 165 170
4
Assembly Instructions
Preparing panels
Place desk top flat onto
1
the floor with
the fixing holes facing up.
Insert short wooden dowels
A
into
desk top as
1
shown.
Screw metal dowels
into desk top as shown.
Note:
Screw metal
B
1
dowels as far as shown.
Do not overtighten.
B
1
B
A
Preparing panels
Place lower divider and
23
flat onto the floor with
2
the fixing holes facing up.
Insert short wooden dowels
into each side as shown.
A
2
A
23
A
5
Assembly Instructions
Preparing panels
With help, locate lower
divider to the underside
of
2
desk top as shown.
1
Insert large locking nuts
into the holes in
.
divider .
2
Turn locking nuts
lower
C
C
clockwise to secure.
Preparing panels
1
C
2
C
Place lower shelf flat
3
onto the floor with the fixing
holes facing up.
Insert short wooden dowels
A
into
shown.
lower shelf as
Screw metal dowels
lower shelf as
into
3
B
3
shown.
Note:
Screw metal
dowels as far as shown.
Do not overtighten.
A
B
3
B
6
Assembly Instructions
Preparing panels
With help, assemble lower
3
to lower divider
shelf
using screws .
2
D
1
2
3
Preparing panels
With help, assemble base
4
to the remaining
panel
lower divider using
screws .
Note: Ensure the groove
along one edge of base panel
is on the same side as
4
lower divider .
Insert short wooden dowels
A
into
panel
the ends of base
.
4
23
D
23
D
23
4
D
A
Groove on inside
7
Assembly Instructions
Step 7
Preparing panels
With help, assemble
lower divider and base
panel assembly , to the
lower shelf as shown.
4
23
3
Insert large locking nuts
into one side of
divider
Turn locking nuts
clockwise to secure.
.
23
lower
C
Step 8
C
C
2
3
23
4
C
Groove
Groove
Preparing panels
Insert short wooden dowels
A
into both
(left and right) as shown.
upper dividers
5
5
A
x 2
8
Assembly Instructions
Step 9
Preparing panels
Insert short wooden dowels
A
into
as shown.
top horizontal rail
6
6
A
Step 10
Preparing panels
With help, assemble both
upper dividers (left and
right) ,to top horizontal
rail using screws .
5
6
D
5
5
6
D
9
Assembly Instructions
Step 11
Preparing panels
Insert short wooden dowels
A
into the ends of
as shown.
7
top shelf
A
7
Step 12
Preparing panels
With help, assemble
top shelf to upper
dividers (left and right)
and top horizontal rail
using screws as shown.
Note: Ensure the groove
along one edge of top shelf
is facing down as shown.
7
7
5
6
D
5
6
5
7
D
Groove
10
Assembly Instructions
Step 13
Preparing panels
Insert short wooden dowels
A
into the ends of
shelf as shown.
8
upper
A
8
Step 14
Fitting drawer runners
With help, assemble plastic
drawer runners
sides of
using screws .
Insert short wooden dowels
A
into the side of drawer
divider as shown.
drawer divider
9
to both
E
F
9
E
F
9
A
11
Assembly Instructions
Step 15
Preparing panels
With help, assemble upper
shelf to drawer divider
using screws .
8
9
D
9
8
D
Step 16
Preparing panels
Insert short wooden dowels
A
into each end of
10
.
shelf
Screw metal dowels
into
drawer shelf as
shown.
Note:
dowels as far as shown.
Do not overtighten.
Screw metal
drawer
B
10
A
B
10
B
12
Assembly Instructions
Step 17
Preparing panels
Insert long wooden dowels
V
into
shown.
middle divider as
11
11
V
Step 18
Preparing panels
With help, assemble drawer
10
shelf to middle divider
using screws .
11
D
11
10
D
13
Assembly Instructions
Step 19
Preparing panels
With help, locate the drawer
9
divider
assembly, onto
shelf
and upper shelf
8
10
.
drawer
Insert large locking nuts
C
into the holes in one side
drawer divider .
of
Turn locking nuts
9
C
clockwise to secure.
Step 20
Preparing panels
C
10
9
8
C
11
With help, assemble
middle divider ,to the top
shelf assembly ( )
using screws .
11
7
6
5
D
D
5
5
7
11
6
14
Assembly Instructions
Step 21
Preparing panels
With help, assemble plastic
E
drawer runners
side panels and ,
right
using screws as shown.
to left and
12
F
13
F
E
13
F
E
12
E
E
Step 22
Assembling side panel
Carefully align all
sub-assemblies together as
shown.
With help, locate left side
13
panel into position and
secure using fixings
H
and as shown.
G
D
7
10
8
1
3
G
4
13
H
I
D
15
Assembly Instructions
Step 23
Fitting back panels
With help, carefully turn
the wall desk over onto it's
side as shown.
22
Warning: The
desk is heavy. Lift with
wall
care.
With help, slide lower back
20
panels
panel and upper back
panel into position as
, middle back
21
22
shown.
Insert plastic trim in
between
as shown.
20
lower back panels
J
Step 24
Assembling side panel
J
21
20
20
13
I
H
With help, locate right side
12
panel into position and
secure using fixings
H
and as shown.
G
D
D
G
12
16
Assembly Instructions
Step 25
Fitting divider
Locate upper divider into
the central position at the
top of the unit and secure
from behind using screws .
14
D
14
D
17
Assembly Instructions
Step 26
Securing back panels
With help , stand the wall
desk upright.
Warning: The desk is
heavy. Lift with care .
a: Secure back panels
22
and using screws as
shown.
20
U
a:
20
22
U
b: Ensure the desk is
straight and square.
Fit plastic brackets
around the edges of all
back panels as shown.
Use screws to secure.
P
O
20
b:
O
P
18
Assembly Instructions
Step 27
Fixing to wall
It is recommended that the
wall desk is fixed to the
wall to ensure stability.
Assemble wall straps
to the back of top
horizontal rail using
screws .
With help, move the unit
to the desired location.
Mark the fixing hole
locations on the wall and
remove the unit.
Drill the wall and fit
suitable plugs for your wall
type.
Note: Wall plugs are not
supplied.
drilling. Check the wall for
hidden pipes or
cables.Re-position the
unit and secure the wall
straps to the wall.
Note: Screws are not
supplied.
R
Warning: Before
6
Q
Q
6
R
19
Assembly Instructions
Step 28
Assembling drawers
a: Assemble drawer back
in between drawer sides
16
and using screws .
15
D
17
a:
D
15
Note: Ensure the grooves
are correctly aligned at the
bottom as shown.
b: Screw metal dowels
into
drawer front as
shown.
Note:
dowels as far as shown.
Do not overtighten.
Assemble handle to
drawer front using
screw
Screw metal
18
as shown.
M
B
18
L
grooves to align
b:
B
17
16
x 2
B
M
18
c: Side drawer base into
the grooves as shown .
Locate drawer front into
position .
Insert small locking nuts
into the holes in drawer sides
and .
15 16
Turn locking nuts
clockwise to secure.
Repeat for both drawers.
19
18
K
K
c:
K
18
L
K
19
x 2
x 2
20
Assembly Instructions
Step 29
Locating drawers
Locate both drawers into
position.
Fit plastic drawer stops ,
into the holes on the inside
of drawer sides and
as shown.
15 16
N
15
N
N
21
Assembly Instructions
Step 30
a:
Covering fixing holes
a: Stickers can be used
to cover the fixing holes
as shown.
S
S
b: Stickers can be used
to cover the fixing holes
as shown.
T
b:
T
If you need help or have damaged or missing parts, call the
Home Retail Group. 489-499 Avebury Boulevard. Saxon Gate West. Central Milton Keynes. MK9 2NW
Customer Helpline: 0345 6400 800
22
Loading...
